VPC i2 MX Series User manual

i2 MX USER’S MANUAL: SECTION 7 VIRGINIA PANEL CORPORATION
2/5/16
7-1 For the most current information available, visit www.vpc.com
i2 MX MODULE INSERT(S) INSTALLATION/REMOVAL
PART # 310 130 XXX AND 410 130 XXX
TOOLS REQUIRED
Phillips Head Screwdriver
i2 MX MODULE INSERT(S) REMOVAL INSTRUCTIONS
1. If working with a receiver, use a Phillips head screwdriver to remove
strain relief by removing screws (Figure A).
The ITA will require removal of backshell rst see Section 4 of this User’s
Manual.
2. Using a Phillips head screwdriver, remove the two Phillips at head
screws that are holding the frame halves together.
For ITA use a Phillips head screwdriver to loosen the two captive screws
on the back of rear frame (Figure B).
3. Pull halves apart.
4. Remove module insert(s).
i2 MX MODULE INSERT(S) INSTALLATION INSTRUCTIONS
1. For installing module insert(s), orient insert(s) as shown in (Figure A)and
(Figure C). Place insert(s) ledge on at surface shown in (Figure D), then
put halves together and tighten with at head screws using a Phillips
head screwdriver.
NOTE: Receiver/ITA frame halves are keyed to be placed together only one
direction.
Figure A. Module insert install and removal
(receiver shown).
Figure D. Module insert install and removal
(receiver shown).
Figure C. Module insert install and removal
(receiver shown).
RECEIVER PIN
A1 UPPER LEFT
ITA PIN A1
UPPER RIGHT
PHILLIPS
FLAT HEAD
SCREWS (2)
FLAT SURFACE
Figure B. ITA frame separation.
PHILLIPS
CAPTIVE
SCREWS (2)

i2 MX USER’S MANUAL: SECTION 7 VIRGINIA PANEL CORPORATION
2/5/16
7-2 For the most current information available, visit www.vpc.com
TOOLS REQUIRED
Phillips Head Screwdriver
VTAC HSD RAIL(S) REMOVAL INSTRUCTIONS
1. If working with a receiver, use a Phillips head screwdriver to
remove strain relief by removing screws (Figure A).
The ITA will require removal of backshell rst. See Section 2 of this
User’s Manual for instructions.
2. After removing strain relief/backshell, use a Phillips head
screwdriver to remove the two Phillips at head screws that are
holding the frame halves together (Figure A).
For ITA use Phillips head screwdriver to loosen the two captive
screws on the back of the rear frame (Figure B).
3. Pull halves apart.
4. Remove VTAC HSD Rail(s).
VTAC HSD RAIL(S) INSTALLATION INSTRUCTIONS
1. To install VTAC HSD Rail(s), orient rail(s) as shown in (Figure A).
Figure C illustrates the identiers to aid in orientation (receiver rails
shown). The receiver rails are marked with ‘RR’ (receiver right) and
‘RL’ (receiver left) when viewing from mating face. The ITA rails
are marked with ‘IR’ (ITA right) and ‘IL’ (ITA left) when viewing from
rear/wiring side.
2. Place rail(s) ledge on at surface shown in (Figure D), then put
halves together and tighten the two Phillips at head screws using
a Phillips head screwdriver.
NOTE: Receiver/ITA frame halves are keyed to be placed together
only one direction.
VTAC HSD RAIL(S) INSTALLATION/REMOVAL INSTRUCTIONS
PART # 310 130 XXX AND 410 130 XXX
Figure A. VTAC HSD Rail(s) install/removal (receiver shown).
Figure D. VTAC HSD Rail(s) install/removal
(receiver shown).
Figure C. VTAC HSD Rail(s) - Identiers.
‘RR’ RECEIVER
RIGHT
‘RL’ RECEIVER
LEFT
BLACK PIN AI
INDICATOR
FLAT SURFACE
PHILLIPS
FLAT HEAD
SCREWS (2)
TOP
BOTTOM
TOP OF
RAIL
Figure B. ITA frame separation.
PHILLIPS
CAPTIVE
SCREWS (2)
