Magic Leap Quick Start Guide
VR Expert
[email protected]
Demkaweg 11 030 7116158
3555HW, Utrecht

In the box
●Magic Leap Headset
●Magic Leap Lightpack
●Controller
●Charging Cable
●UK-EU adapter
●Fit Kit Components
(consists of different
size nose and forehead
pads)
Hardware
Before you start
●That little box near the right eyepiece
is the antenna for your "Six degrees of
freedom" (6DoF) Control. Be gentle
with it.
●Keep Lightpack vents clear so your
device can breathe, These are
located just below the Power Button.
●The Fit Kit components never require
physical force to adjust.
●Don’t drop your device. Secure the
Lightpack in a pocket, your hand, on a
desk, or with a sling
Headset
Controller
Lightpack
Power Button
Home Button
Touchpad
Trigger
Magic Leap Quick Start Guide

Setting up
You’ll need a Magic Leap ID. Magic Leap 1 requires a Magic Leap ID to
connect your device with services like the app store and Magic Leap
World. Before turning on Magic Leap 1, complete these steps:
1. Go to https://id.magicleap.com.
2. Enter your email address.
3. Type your First Name, Last Name, and Date of Birth.
Magic Leap will send a code to your email account. Open that account
and enter the code on the Magic Leap web page.
●Complete your account, including Country to see regional apps in
Magic Leap World, and you're ready to go!
Getting Started
To get started with the Magic Leap 1 you will have to turn it on, below is
described how that works.
Power Up: Once you've connected the Lightwear, hold down the button on
the Lightpack for a 3-count. Next hold down the button on the Control for
a 3-count while holding it close to the lightpack.
Power Down: To turn off Magic Leap 1 from the Launcher, select the battery
icon and then select the power off icon. Control shuts down
automatically. To manually turn off Magic Leap 1, hold down the Lightpack
power button for 8 seconds, then hold down the Control trigger and home
button for 3 seconds.
Wifi:
When Magic Leap 1 starts, it provides an orientation to the core features
and helps you ensure a good fit., connect to the WiFI and logging into your
account.
●To connect to Wifi during your first power up it will show you a list of
all available networks in your area. Simply point the controller and
pull the trigger or tap the touchpad on your preferred network.
●A keyboard will show up for you to fill in the password with. After that
is done click confirm and it will connect to the chosen Wifi network.
Magic Leap Quick Start Guide

Enabling Developer Mode
Enable developer mode on the Magic Leap device to let you connect to
the device from a computer and sideload apps. On the Magic Leap
device, click the setting icon, select Developer, and then select the
following:
●Developer mode - Make Developer Mode options available
●Allow Untrusted Sources - Install apps signed with a development
certificate
●Enable MLDB Access - Let your device to connect to a computer with
Magic Leap Device Bridge:
(https://developer.magicleap.com/en-us/learn/guides/connect-de
vice)
Using the device
Magic Leap 1 has two application types. Below is described how this
works in addition to installing apps and taking screenshots/recording
video.
●Landscape: Landscape apps like Gallery and Screens can share
space with other Landscape apps. To close a Landscape app, look
at the application or point at it using the Control pointer, hold
down the Control bumper to view options, and then select Close.
Double-tap the bumper to quick-close the selected app.
●Immersive: Immersive apps like Create or Dr. Gordbort's Invaders
use your entire space. To close an Immersive app, hold down the
Home button on the Control to pause the experience and open
Launcher. In Launcher with the app selected, press the touchpad
"down" (towards you) to open options and select X to close the
app.
●Installing Apps: To install applications navigate to the app store,
you can easily navigate there through the home screen; press the
home button to open the scroll wheel.
●Delete Apps: From the Launcher with the app selected, press the
touchpad "down" (towards you) to open options and select the
Trashcan icon to delete the app.
●Capture Image or Video: Want to share what you're seeing? Hold
down the Home button and tap the bumper to take a photo. To
start recording video, while holding down Home hold down the
bumper for a long tap - 300 milliseconds, to be precise.
Magic Leap Quick Start Guide

VR-Expert Tips
Best Room Setting:
●Ample light (50 lux) evenly distributed - Think a living room lit in the
evening
●Walls and floors with objects on them rather than broad empty
surfaces
●A chair to sit in while developing - But protect the Lightwear cable
from catching chair arms or furniture
Challenging Conditions:
●Transparent or reflective surfaces, solid white or black walls,
●Crowded areas with moving people, pets, or objects
●Shiny furniture, walls and floors
●Bright overhead lighting can cause tiny rainbows in the optical
display
●Large open spaces with features more than 5 meters from the device
●Direct sunlight or dimly lit areas
●Rooms with glass walls (Tip: Place sticky notes on walls for reference
points.)
View Launcher:
Hold down the Home button for about 3 seconds to return to Launcher, the
home screen for Magic Leap 1. From here you can launch apps and
manage Magic Leap 1 apps and settings.
●Launch Apps: Highlight an app from the launcher using the control
pointer or swiping on the touchpad, and press the trigger to select it.
For Landscape apps, you can then position the app in your space
using the touchpad, hold and drag. This can be done with the trigger
as well..
Updating your Magic Leap
To check for available updates, turn on your Magic Leap 1 device and make
sure it is connected to Wi-Fi.
●Go to Setting > Device
●Scroll down with the touchpad through your device information.
●If an update is available, an Update Now button will be visible.
