VSI 1000-X Series Owner's manual

SERIES 1000-X ELECTRIC ACTUATORS
VER:0812-1

SERIES 1000-X ELECTRIC ACTUATORS
2VER: 0812-1
CONTENTS
NOTES 3
NAMES OF COMPONENTS 4
OVERALL DIMENSIONS AND SPECIFICATIONS FOR 1005-X 5
OVERALL DIMENSIONS AND SPECIFICATIONS FOR 1010-X 6
OVERALL DIMENSIONS AND SPECIFICATIONS FOR 1020-X THRU 1060-X 7
OVERALL DIMENSIONS AND SPECIFICATIONS FOR 1100-X THRU 1250-X 8
SPECIFICATIONS FOR MODULATING ACTUATORS 9
CONTROL CIRCUIT WIRING 10
APPLICATION REQUIREMENTS 11
MOUNTING ON A VALVE 12
ADJUSTMENT OF ACTUATOR - 2 POSITION 13
ADJUSTMENT OF ACTUATOR - MODULATING 14
MAINTENANCE AND SERVICE 16
TROUBLESHOOTING 16

SERIES 1000-X ELECTRIC ACTUATORS
3 VER: 0812-1
NOTES
1. No manual operaon of the actuator while the device is energized.
2. The actuator is equipped with an over heang protecon device. When the motor exceeds
the temperature of 257° F (125°C) , the overheat protecon device will automacally switch
o the motor.
3. It is necessary to take addional leakage protecon steps when installing the actuator and
pung it into service. See page 11 for more informaon on proper conduit installaon
precauons.
4. It is necessary to provide the proper sealing of the waterproof cable ends on the inlet side
of the actuator. This will help to prevent the actuator from becoming damage by water or
dirt coming into the actuator from outside sources.
5. Be sure to double check the input voltages and all other connecons.
6. Do not wire two or more actuators in either series or parallel. Otherwise, it can cause
movement to become out of control, or the motor temperatures to rise due to the
interference they can correct with each other.
7. A minimum of 18 gauge wire needs to be used for all wiring connecons.
8. The servo controller must be wired and adjusted according to the instrucon manual to
prevent any damage from occurring.
9. Service personnel for the installaon and adjustment of the actuator need to be qualied
for these operaons.
10.Do not operate the actuator purposely under overloaded condions.
11.Valve Soluons, Inc. will not be responsible in the improper modicaon or lack of proper
maintenance of the actuators.
12.All actuators have the proper wiring diagram axed to the inside cover. All wiring should
follow these diagrams.

SERIES 1000-X ELECTRIC ACTUATORS
4VER: 0812-1
NAMES OF COMPONENTS
1Gear Cover 2Electric Cover 3Handwheel
4Junction Box Cover 5Push Button 6Conduit Plug
7Hex Handle 8Handle Snap Holder 9Travel Stop Nut
10 Travel Stop 11 Worm Shaft 12 Handle Socket
13 Reducing Gear Group 14 Capacitor 15 Inductor
16 Open Cam Lock Screw 17 Close Cam Lock Screw 18 Opening Gear
19 Heater 20 SPDT Limit Switch 21 Position Indicator
22 Position Pointer 23 Potentiometer Gear 24 Potentiometer
S (SHUT) Direction of arrow (clockwise) represents close.
O (OPEN) Direction of arrow (counter-clockwise) represents open.
1 2
3
4
5
6
7
8
9
10
111213
14 1516 17
18
19
20
21
22
2324
14
21
19
22
2 POSITION MODULATING

SERIES 1000-X ELECTRIC ACTUATORS
5VER: 0812-1
OVERALL DIMENSIONS AND SPECIFICATIONS FOR 1005-X
S
O
32
36
Ø70
Ø70
Ø50
45°
4-M6
4-M8
Evenly Distributed
Evenly Distributed
Direct Mount Parameters
Square Shaft
Mounting Flanges
Stem Height
14 x 14
F05 F07
Height ≤32mm
113
63 49 24
S
O
160
83 77
102.5
Fig. A
1005-X SPECIFICATIONS
Power Supply AC24V AC110V AC220V
Motor Power 10W 10W 10W
Rated Current 1.50A 0.24A 0.16A
Max. Current 2.08A 0.34A 0.17A
Standard Torque / Run Time 50Nm/20s - 30Nm/10s
Turning Angle 0° - 90° Adjustable
Total Weight 4.41lbs (2.0kg)
Insulang Resistance AC24V: 100Ω/250VDC AC110V/AC220V: 100Ω/500VDC
Withstand Voltage Class AC24V: 500VAC - 1 Minute AC110V/AC220V: 1500VAC - 1 Minute
Protecon Class IP67 NEMA 4X
Installaon Angle At or above the center line of the pipe. See Fig. A
Ambient Temperature -22°F - +140°F (-30°C - +60°C)
Ambient Humidity ˂ 95% Relave Humidity
Duty Cycle 80%
Opons Handwheel

SERIES 1000-X ELECTRIC ACTUATORS
6VER: 0812-1
OVERALL DIMENSIONS AND SPECIFICATIONS FOR 1010-X
Direct Mount Parameters
Square Shaft
Mounting Flanges
Stem Height
17 x 17
F05 F07
Height ≤32mm
121
71 50 24 98
196
98
126
S
O
Ø70
Ø50
4-M8
4-M6
45°
Evenly Distributed
Evenly Distributed
Ø90
32 33
S
O
Fig. A
1010-X SPECIFICATIONS
Power Supply AC24V AC110V AC220V
Motor Power 25W 25W 25W
Rated Current 2.12A 0.57A 0.30A
Max. Current 3.12A 0.81A 0.47A
Standard Torque / Run Time 100Nm / 30s
Turning Angle 0° - 90° Adjustable
Total Weight 6.61lbs (3.0kg)
Insulang Resistance AC24V: 100MΩ/250VDC AC110V/AC220V: 100MΩ/500VDC
Withstand Voltage Class AC24V: 500VAC - 1 Minute AC110V/AC220V: 1500VAC - 1 Minute
Protecon Class IP67 NEMA 4X
Installaon Angle At or above the center line of the pipe. See Fig. A
Ambient Temperature -22°F - +140°F (-30°C - +60°C)
Ambient Humidity ˂ 95% Relave Humidity
Duty Cycle 80%
Opons Handwheel

SERIES 1000-X ELECTRIC ACTUATORS
7VER: 0812-1
OVERALL DIMENSIONS AND SPECIFICATIONS FOR 1020-X THRU 1060-X
158
95 63 24 121
255
134
148
45
48
Ø125
Ø102
Ø70
4-M10
Evenly Distributed
4-M8
Evenly Distributed
45°
Direct Mount Parameters
Square Shaft
Mounting Flanges
Stem Height
27 x 27
F07 F10
Height ≤45mm
Fig. A
1020-X / 1040-X / 1060-X SPECIFICATIONS
Model 1020-X 1040-X 1060-X
Power AC24V AC110V AC220V AC24V AC110V AC220V AC110V AC220V
Motor Power 40W 40W 40W 40W 90W 90W 90W 90W
Rated Current 3.15A 0.65A 0.37A 2.42A 1.12A 0.57A 1.18A 0.60A
Max. Current 5.30A 1.68A 0.78A 4.38A 3.41A 1.78A 3.60A 1.87A
Standard Torque / Run Time 300Nm / 45s 200Nm / 30s 400Nm/ 100s 400Nm / 30s 600Nm / 30s
Turning Angle 0° - 90° Adjustable
Total Weight 17.63lbs (8.0kg) 18.74lbs (8.5kg) 19.41lbs (9.0kg)
Insulang Resistance AC24V: 100MΩ/250VDC AC110V/AC220V: 100Ω/500VDC
Withstand Voltage Class AC24V: 500VAC - 1 Minute AC110V/AC220V: 1500VAC - 1 Minute
Protecon Class IP67 NEMA 4X
Installaon Angle At or above the center line of the pipe. See Fig. A
Ambient Temperature -22°F - +140°F (-30°C - +60°C)
Ambient Humidity ˂ 95% Relave Humidity
Duty Cycle 80%
Opons Handwheel

SERIES 1000-X ELECTRIC ACTUATORS
8VER: 0812-1
OVERALL DIMENSIONS AND SPECIFICATIONS FOR 1100-X THRU 1250-X
148
310
162
165
54
Ø135
56
130
217
87 24
Ø140
Ø125
Ø102
45°
4-M10
Evenly Distributed
4-M12
Evenly Distributed
4-M16
Evenly Distributed
Direct Mount Parameters
Square Shaft
Mounting Flanges
Stem Height
36 x 36
F10F12 F14
Height ≤54mm
Fig. A
1100-X / 1160-X / 1250-X SPECIFICATIONS
Model 1100-X 1160-X 1250-X
Power AC110V AC220V AC110V AC220V AC110V AC220V
Motor Power 120W 120W 140W 140W 140W 140W
Rated Current 1.93A 0.94A 1.75A 0.96A 1.75A 0.98A
Max. Current 3.80A 2.12A 3.93A 2.16A 3.95A 2.20A
Standard Torque / Time 1000Nm/30s 1600Nm/48s 2500Nm/75s
Turning Angle 0° - 90° Adjustable
Total Weight 37.48lbs (17.0kg) 43.0lbs (19.5kg) 43.0lbs (19.5kg)
Insulang Resistance AC110V/AC220V: 100MΩ/500VDC
Withstand Voltage Class AC110V/AC220V: 1500VAC - 1 Minute
Protecon Class IP67 NEMA 4X
Installaon Angle At or above the center line of the pipe. See Fig. A
Ambient Temperature -22°F - +140°F (-30°C - +60°C)
Ambient Humidity ˂ 95% Relave Humidity
Duty Cycle 70%
Opons Handwheel

SERIES 1000-X ELECTRIC ACTUATORS
9 VER: 0812-1
SPECIFICATIONS FOR MODULATING ACTUATORS
SERIES 1000-X MODULATING ACTUATOR SPECIFICATIONS
Model 1005/S-X 1010/S-X 1020/S-X 1040/S-X 1060/S-X 1100/S-X 1160/S-X 1250/S-X
Power AC110/220 AC110/220 AC110/220 AC110/220 AC110/220 AC110/220 AC110/220 AC110/220
Output
Torque 50Nm 100Nm 200Nm 400Nm 600Nm 1000Nm 1600Nm 2500Nm
Acng
Time 20s 30s 30s 30s 45s 30s 48s 75s
Turning
Angle 0° - 90° Adjustable
Motor
Power 10W 25W 40W 90W 90W 120W 140W 140W
Rated
Current 0.24A/0.16A 0.57A/0.35A 0.65A/0.37A 1.12A/0.57A 1.18A/0.60A 1.93A/0.94A 1.75A/0.96A 1.75A/0.98A
Total
Weight 4.41lb(2kg) 6.61lb(3kg) 17.64lb(8kg) 18.74lb(8.5kg) 19.84lb(9kg) 37.48lb(17kg) 43.0lb(19.5kg) 43.0lb(19.5kg)
Input
Signal 4-20mA or 2-10VDC
Output
Signal 4-20mA
Basic
Error < ± 1%
Reciprocat-
ing Error < 1%
Dead
Band 0.5% - 5.0% Adjustable
Repeang
Error 0 < 2.5%
Insulang
Resistance 100MΩ / 500VDC
Withstand
Voltage Class 1500VAC - 1 Minute
Protecon
Class IP67 NEMA 4X
Installaon
Angle At or above the center line of the pipe. See Fig. A
Ambient
Temperature -22°F - +140°F (-30°C - +60°C)
Ambient
Humidity ˂ 95% Relave Humidity
Duty
Cycle 80% 70%
Opons Handwheel

SERIES 1000-X ELECTRIC ACTUATORS
10VER: 0812-1
ELECTRICAL WIRING
2 POSITION UNITS
The opening and closing operaon of the actuator is regulated with the travel limit switches which open the
power circuit to the motor. Two power legs and a common are needed in order to drive the actuator open and
closed. Auxiliary switches are for status of valve (open/closed). The 1005-X units are not equipped with the
manual override push ON/OFF buon. In order to operate the 1005-X units with the manual override, power
must be turned o or disconnected from the unit. All other units are equipped with the manual override
push ON/OFF buon which disconnects power to the motor so that the actuator can be manually operated
using the hand crank or hand wheel
Terminal wiring as follows:
1. Power common
2. Close operaon (Power Hot)
3. Open operaon (Power Hot)
4. Auxiliary contact common
5. Auxiliary contact open status
6. Auxiliary contact closed status
7. Chassis ground
MODULATING WITH SERVO CONTROL PACK (110/220VAC)
The modulang of the actuator is soware driven based on the input signal to the Servo Control Pack. Input
Signal is 4-20mA or 2-10VDC and Output (Feedback) is 4-20mA. The 1005/S-X units are not equipped with the
manual override push ON/OFF buon. In order to operate the 1005/S-X units with the manual override,
power must be turned o or disconnected from the unit.
1005S-X Units use the SF-ZB Servo Control Pack – All other units use the SF-LB Servo Control Pack
Terminal wiring as follows:
1. “N” is for power neutral
2. “L” is for line power
3. Input “-“ is for the negave input signal
4. Input “+” is for the posive input signal
5. Output “-“ is for the negave output signal
6. Output “+” is for the posive output signal
* Oponal auxiliary contacts will be wired on a separate
terminal strip (1- Common, 2- Open, 3-Closed)
Y&G
GREY
BROWN
WHITE
BLACK
RED
BLUE
HEATER
OLS
CLS
C
M
PE
FULL CLOSE SIGNAL
FULL OPEN SIGNAL
COM
OPEN
CLOSE
KL
N
PUSH BUTTONTHERMAL PROTECTOR
ACTUATOR
FIELD WIRING
GND 7
6
5
4
3
2
1
HEATER
PE
GREY
BROWN
WHITE
PINK
PURPLE
ORANGE
BLACK
RED
BLUE
FULL CLOSE SIGNAL
FULL OPEN SIGNAL
COM
+
OUTPUT SIGNAL
-
L
POWER SUPPLY
N
+
INPUT SIGNAL
-
THERMAL PROTECTOR PUSH BUTTON
MC
L
1K
RP
1
2
3
SERVO-CONTROLLER
FIELD WIRING
ACTUATOR
*

SERIES 1000-X ELECTRIC ACTUATORS
11 VER: 0812-1
Power Supply Requirement
• Power supply for the corresponding unit must meet the electrical requirements for voltage and current
rangs.
• The power supply shall be as follows:
AC 24V ±10% AC 110V ±10% AC 220V ±10%
Selection of Fuses for Circuit Breaker
AC24V AC110C AC220V
1005-X 5A 3A 2A
1010-X 7A 5A 3A
1020-X/1040-X/1060-X N/A 7A 5A
1100-X/1160-X/1250-X N/A 10A 7A
APPLICATION REQUIREMENTS
Installation Conditions
• Series 1000-X Units can be installed outdoors and indoors – NEMA 4X or IP67.
• Series 1000-X Units are not explosion proof and cauon should be taken to avoid inammable and
explosive environments.
• Installaon consideraon should be taken into account to allow for manual operaon of the units as
well as any maintenance.
• Ambient temperature should be within -30°C - +60°C.
Medium Working Temperature
• Care should be taken to prevent the heat of the working medium from exceeding the actuator ambient
temperature limits.
• When the temperature of the working medium exceeds the actuator limit a thermal coupling shall be
installed to reduce the heat transfer between the medium and the actuator.
• Standard bracket may be used when the working medium is below 80°C.
• A higher temperature bracket may be need for temperatures exceeding 80°C.
Waterproof
cable connector
Branch
Connector
Plastic tube
Conduit and Cable Installation
• Refer to gure 1 when for installaon of conduit
• Conduit should be ½” NPT and all ngs should be sealed
water ght
• Actuator shall be installed above the conduit so that any
water in the conduit will not make its way inside the unit.
• If actuator must be installed below conduit, a drip loop or
drain should be provided to allow any water to exit the piping
• Refer to gure 2 for installaon of cable directly into unit (No
Conduit).
• The outer diameter of the cable shall be ø9mm-ø11mm.
• Cable smaller than specied above may allow water to enter the
unit and cannot be used.
• When possible power wiring and signal wiring should be routed
through separate conduits
• All units have two conduit entries. One for power, one for control.
Figure 1
Seal Ring
Cable
Lock Nut
ø9 ~ ø11
Figure 2

SERIES 1000-X ELECTRIC ACTUATORS
12VER: 0812-1
MOUNTING ON A VALVE
INSTALLATION OF ACTUATOR TO VALVE (FIG. 3)
Note: Direct mounting the actuator removes the bracket and coupling from the mounting process, but
the remainder remains the same.
1. Rotate valve to full closed posion. Ensure that the valve rotates freely with no obstrucon.
2. Using the proper bolts aach the bracket to the valve – ghten loosely.
3. Place the coupling onto the stem of the valve
4. Using the manual override handle, rotate the actuator to the full closed posion so that the pointer
indicator points to “SHUT” (stang posion of the scale).
5. Insert the output drive sha of the actuator into the coupling.
6. Aach bracket to actuator and ghten all bolts.
7. Drive the actuator using the manual crank handle and conrm that the valve rotates without obstruc-
on. Ensure the valve is fully open as the actuator rotates to full open posion.
Figure 3
Figure 4
Mounting Tips:
NOTE: This is not for direct mounting the actuator to the valve.
• If providing own bracket, ensure that the materials provided are
manufactured professionally and meet the requirements in Fig. 4.
• The precision of the coupling holes is crucial to prevent any
backlash or damage to the actuator.
• It is necessary to ensure the posional angles of the coupling
holes to prevent exceeding the actuator’s working range.
• Only ghten bolts aer the actuator, bracket and valve have
been properly aligned.
The coaxiality between axes A andBshall not exceed 0.2mm.

SERIES 1000-X ELECTRIC ACTUATORS
13 VER: 0812-1
ADJUSTMENT OF ACTUATOR - 2 POSITION
Units are calibrated at the factory to rotate 90° - if any adjustment is needed please use the following
procedure.
1. Adjustment of electric limits for 2 posion valves (Fig 5.)
a. Full Closed posion adjustment: Using the manual hand wheel or hand crank, drive the valve to the full closed posion.
Ensure the pointer on the dome lid is poinng red zero “shut”. If not, remove lid and loosen dome indicator and re-posion to
red zero “shut”. To adjust the closed limit switch, loosen shut posion regulang sha (S) using 2mm Allen wrench and rotate
the stroke dog D1 (lower) clockwise unl the K1 switch makes click. Tighten shut posion regulang sha (S).
b. Full Open posion adjustment: Using the manual hand wheel or hand crank, drive the valve to the full open posion.
Ensure the pointer on the dome lid is poinng yellow zero “open. To adjust the open limit switch, loosen open posion regulat-
ing sha (O) using 2mm Allen wrench and rotate the stroke dog D2 (upper)counter-clockwise unl the K3 switch makes click.
Tighten open posion regulang sha (O).
Figure 5
2. Adjustment of mechanical stops (Fig 6 & 7) PLEASE SEE WARNING BELOW BEFORE PROCEEDING!
To prevent damage, the electrical limit switches need to be set to make contact prior to the sha reaching the mechanical
stops.
a. Using the manual override handle or hand wheel, rotate the valve to the full closed posion unl the switch K1 clicks.
b. Loosen the lock-nut on the le side of the unit and rotate the adjusng screw clockwise using Allen wrench unl the screw
comes into contact with the stopper – then back o ½ of a turn (counterclockwise). Tighten lock nut.
c. Repeat step above for open direcon of operaon.
3. Electric Test
a. Connect wiring per the control circuit diagram – located in the terminal cover lid.
b. Verify that the valve rotates to the closed posion by observing the dome indicator points to red zero “shut”.
c. Verify that the valve rotates to the open posion by observing the dome indicator points to yellow zero “open”.
d. Aer all adjustments menoned above, check the alignment of the dome indicator scale and pointer. If the pointer is not
aligned properly on open and closed posion – adjust as needed by loosening the dome lock screw and then reghtening.
Scale plate
Dome indication
Full-open position
Full-close position
Lock screw
Opening gear
Shut position regulating shaft
Open position regulating shaft
S(Red) O(Green)
D2
D1
O
S
K1
K2
K3
K4
Open-direction  middleposition
Close-directionmiddleposition
Micro-switch
Clockwise
Stroke dog
Counter-
Clockwise Clockwise
Regulang sha
Figure 6
Adjusng screw for
closing limit-switch
Adjusng screw for
opening limit-switch
Lock Nut
Mechanical
Limit Stopper
Figure 7
Electric Limit-Switch
(Full Close Posion)
Electric Limit-Switch
(Full Open Posion)
Mechanical Limit-Switch
for close direcon
Mechanical Limit-Switch
for open direcon
90°
2.5°
2.5°

SERIES 1000-X ELECTRIC ACTUATORS
14VER: 0812-1
ADJUSTMENT OF ACTUATOR - MODULATING
Figure 9
N L
1
1
2 2
1 2 3 4 5 6 7
3
3
1
1
1 2 3
SF-ZB Servo-Controller (1005/S-X)
SF-LB Servo-Controller (All other models)
Figure 8
1. Following procedures in secon “INSTALLATION OF ACTUATOR TO VALVE”
install the actuator onto the valve and ensure proper movement of unit by
ulizing the manual crank handle.
2. Drive the valve to the full closed posion using the manual crank handle
and ensure that the mechanical stops are not making contact with the housing
or screws. If there is contact, back o the mechanical limit screws unl there is
no contact. Loosen the lock screw on the dome indicator and posion the scale
to the full closed posion “0” (SHUT POSITION) – ghten the lock screw on the
dome indicator.
3. Drive the valve to the full open posion by using the crank handle and
ensure that the mechanical stops are not making contact with the housing or
screws. If there is contact, back o the mechanical limit screws unl there is no
contact. For 90° rotaon, the dome scale indicator should now be poinng to
“0” (OPEN POSITION).
PLEASE NOTE: ALL ACTUATORS ARE PRE-SET AND TESTED FROM THE FACTORY
AND SHOULD NOT NEED ANY ADJUSTMENT. IF ANY FIELD ADJUSTMENT IS
NEEDED, MECHANICAL LIMITS MUST BE ADJUSTED TO MATCH FIGURE 8.
4. Descripon of Servo-Control Pack (SF-ZB and SF-LB)
• OPEN BUTTON – In “Set Mode” (Switch SA Points to 2) the open buon can be used to rotate the actuator in the open
direcon by pressing down and stopping when released. The open buon is also used to establish the open limits when pressed
at the same me as the “set buon”.
• SHUT BUTTON - In “Set Mode” (Switch SA Points to 2) the shut buon can be used to rotate the actuator in the closed
direcon by pressing down and stopping when released. The shut buon is also used to establish the closed limits when pressed
at the same me as the “set buon”.
• SET BUTTON – In “Set Mode” (Switch SA Points to 2) the set buon is used in coordinaon with the open or closed buons
to set the posion limits.
• SA SWITCH – SA switch is the mode switch. 1 is for direct acng control mode, 2 is for the set mode, 3 is for reverse acng
control mode. Factory set at 1.
• SB SWITCH – SB switch is for loss of control signal. 1 – Actuator will rotate to the open posion upon loss of control signal,
2 – actuator will stay in place upon loss of signal, 3 -actuator will rotate to the closed posion upon loss of control signal. Factory
set at 2.
• SC SWITCH – The SF-LB Servo-Control Pack can allow for 2-10VDC* control or 4-20mA control. The SC switch selects the
applicable control signal. The SF-ZB Servo-Control Pack (used only in the 1005S Models) does not have this funconality.
*The factory default control signal is 2-10VDC.
WARNING: ANY MOVEMENT OF THE POTENTIOMETER GEAR WILL ALTER THE FUNCTIONALITY OF
THE ACTUATOR AND IT MUST BE RETURNED TO THE FACTORY FOR RE-CALIBRATION.
WARNING: CONNECT WIRING AS SHOWN IN FIGURE 9. IF POWER LEADS ARE CONNECTED TO
CONTROL SIGNAL INPUT TERMINALS, DAMAGE WILL OCCUR TO THE SERVO CONTROL PACK.

SERIES 1000-X ELECTRIC ACTUATORS
15 VER: 0812-1
ADJUSTMENT OF ACTUATOR - MODULATING
• DB SWITCH – Allows for the selecon of dead band on the potenometer. Sengs are 1-10 which correspond to 0.5% to
5.0%.
• L1 LAMP – Green LED is the power indicator and illuminates when power is applied to terminals “N” and “L” of the Servo-
Control Pack.
• L2 LAMP – Red LED shows a malfuncon of the control signal input and illuminates when the control signal is lost or weak.
• L3 LAMP – Red LED shows a malfuncon of the posioning circuit and illuminates when the potenometer lead is open,
shorted or damaged.
• L4 LAMP – Red LED shows an over-torque condion illuminates if the valve is jammed or binding and the actuator’s torque
is exceeded.
5. Seng of Servo-Control Pack (SF-ZB and SF-LB)
• SERVO-CONTROL PACK POSTION LIMITS ARE FACTORY SET – UNLESS A CHANGE IN LIMIT SETTING IS DESIRED – NO
ADJUSTMENT SHOULD BE NECESSARY.
1. For the SF-ZB (1005S-X Models Only) Servo-Control Pack, there are two models – SF-ZB2 (2-10VDC) and SF-ZB4 (4-20mA).
The SF-LB Servo-Control Pack has a switch seng SC SWITCH which allows the user to select the control signal. For the following
procedure, select the proper control signal for the unit being adjusted.
2. Using a small screwdriver, rotate the Switch SA to “2” – this is the set mode. All sengs of the actuator can be adjusted in
the set mode.
3. FULL CLOSED POSITION LIMIT SETTING – Perform steps 1-2 above - Adjust the posion of the valve to the full closed
posion using the OPEN and/or SHUT buons. While pressing and holding the SET buon, press the SHUT buon and hold
both buons down for 4 seconds L2 LAMP will illuminate and then exnguish – release both buons at the same me. Closed
posion of the valve is now set.
4. FULL OPEN POSITION LIMIT SETTING – Perform steps 1-2 above - For Full Open limit seng the control signal must be
applied – 20mA or 10VDC depending on SC SWITCH seng. Adjust the posion of the valve to the full open posion using the
OPEN and/or SHUT buons. While pressing and holding the SET buon, press the SHUT buon and hold both buons down
for 4 seconds L2 LAMP will illuminate and then exnguish – release both buons at the same me. Open posion of the valve is
now set.
• CONTROL SIGNAL LOSS FAILURE MODE – If the control signal is lost, the actuator can be set to rotate the valve to a
predetermined state – FAIL OPEN, FAIL IN PLACE, FAIL CLOSED. Set SWITCH SB to 1 for open, 2 for in place and 3 for closed.
Factory set to 2. Note: Varying the selecon on SWITCH SB will be eecve even when the actuator is in full automac mode.
• DIRECT ACTING vs. REVERSE ACTING OPERATION – SWITCH SA is used for controlling the travel direcon of the actuator.
Actuators are factory set for direct acng (2-10V, 2V is closed and 10V is open and for 4-20mA, 4mA is closed and 20mA is open)
set SW A to 1 (direct acng). If reverse acng is desired (2-10V, 10V is closed and 2V is open and for 4-20mA, 20mA is closed and
4mA is open) set SW A to 3 (reverse acng).
• DEAD BAND SETTING – The dead band seng is used to adjust the actuators sensivity to the input control signal. The
lower the dead band seng, the more movement will occur in the actuator based on the resoluon of the control signal. Servo
Control packs are factory set to a midrange sensivity of around 3%. If less sensivity is desired, the DB SWITCH can be rotated
clockwise up to 5%. If more sensivity is desired, the DB SWITCH can be rotated counter-clockwise down to 0.5%.
5. TESTING – Set SW SA to 1 or 3 depending on the direct or reverse acng designaon. Apply the input signal to the Servo
Control Pack – verify the output signal corresponds to the input signal per the chart below.
TEST POINT INPUT SIGNAL
4mA or 2V 8mA or 4V 12mA or 6V 16mA or 8V 20mA or 10V
SCALE POINTER CLOSED “0” 2.5 5 7.5 OPEN “0”
VALVE POSITION 0% OPEN 25% OPEN 50% OPEN 75% OPEN 100% OPEN
OUTPUT CURRENT 4mA 8mA 12mA 16mA 20mA
Note: When SW SA is poinng towards posion 3 (reverse acng), the input signal of 2V or 4mA corresponds to the valve being 100%
open. The feedback reading will correspond to 100% open – 20mA.

SERIES 1000-X ELECTRIC ACTUATORS
16VER: 0812-1
OPERATION AND MAINTENANCE
MAINTENANCE AND SERVICE
• All actuators ulize a high grade molybdenum based grease is used for the gears.
No lubricaon and periodical maintenance is needed.
• If actuators are rarely cycled, periodic rotaon should be scheduled to check if abnormal
condions are present.
TROUBLE SHOOTING
PROBLEM CAUSE REMEDY
Actuator does not operate
Power is not connected Connect Power
Manual/Auto buon is not
engaged
Press manual/auto buon on unit to
engage power
Voltage is too low Check voltage - correct
The actuator is in thermal
protecon mode due to over
torque situaon, or ambient
temperature is too high
Remove over torque condion by
freeing up valve movement. Check
valve to ensure manual movement
and valve is not stuck. Cool down
ambient temperature. Ensure that
mechanical limits are not engaged
with actuator output sha.
Defecve micro-switch Replace the micro-switch
Defecve capacitor Contact Manufacturer
Open diode Contact Manufacturer
Indicator lamp for open/closed
operaons does not illuminate
Indicator lamp malfuncon Contact Manufacturer
Improper micro-switch operaon Contact Manufacturer
Motor connues to operate aer
reaching limit
Defecve micro-switch Contact Manufacturer
Power is not connected correctly Re-check power connecons
Limit switch needs adjustment Follow instrucons and re-set limits
Mechanical limit is out of
adjustment
Re-adjust the mechanical limits
according to the instrucons
Open diode Contact Manufacturer
Water present inside of actuator
Inlet power cables are not properly
installed per instrucons Re-check conduit connecons
The dome indicator lens is broken Contact Manufacturer
Housing screws are not ghtened
and sealed Tighten housing screws
Heater not working or not
connected
Check heater connecons
contact manufacturer
