Vulcan-Hart MEW14 Manual

WARMER
MODEL
MEW14
ML-103832
SERVICE MANUAL & CATALOG OF
REPLACEMENT PARTS
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201-0696, TEL. [phone]
FORM 30973 (5-97)

– 2 –
MEW14 WARMER REPLACEMENT PARTS
© VULCAN-HART COMPANY, 1997
1
2
345
6
7
8
9
10
11
12 13 14
16
17
18
15
19 20
21
22
23
24 25
26
27
28
29
38
39
40 41
30-31
32
33
34
36
37
35
42
43
PL-52131
MEW14 WARMER FRAME

–3 –
REPLACEMENT PARTS MEW14 WARMER
MEW14 WARMER FRAME
ILLUS. PART
PL-52131 NO. NAME OF PART AMT.
1 00-920159 Insulation - Panel Side .............................................................................................................1
2 00-540917 Tie - Wire ..................................................................................................................................2
3NS-044-09 Nut Assy. 10-24 Hex Keps ....................................................................................................... 2
4 00-920140-00001 Leg Pad Weldment ...................................................................................................................2
500-911037-00001 “U”Nut ......................................................................................................................................2
6 00-920132 Member - Rear Cross ...............................................................................................................1
7 FE-014-47 Strain Relief ..............................................................................................................................1
8 00-802422-00011 Lead In Wire Assy. ...................................................................................................................1
9 00-806584 Label-Warning ..........................................................................................................................1
10 00-920570 Shield - Heat Front ...................................................................................................................1
11 FE-016-02 Bushing - Snap .........................................................................................................................2
12 00-911501-00005 Connector-Wire ........................................................................................................................3
13 00-423047-00019 Plate - Cover ............................................................................................................................1
14 00-805782 Label-Disconnect Power ..........................................................................................................1
15 FE-023-68 Lug-Solderless .........................................................................................................................1
16 SC-119-23 Mach. Screw 10-24 x 1⁄2Hex Washer Hd. ................................................................................2
17 WL-007-11 Lockwasher 10 ......................................................................................................................... 1
18 00-805727 Label-Ground Marker ...............................................................................................................1
19 00-908805 Label-Ground Warning ............................................................................................................. 1
20 00-805780 Marker-Supply ..........................................................................................................................1
21 00-825368 Plate-Serial Number ................................................................................................................. 1
22 00-920156-00010 Label - Wiring Diagram ............................................................................................................. 1
23 00-804405 Leg - With Adjustable Foot .......................................................................................................4
24 00-920140-00001 Leg Pad Weldment ...................................................................................................................2
25 00-423047-00020 Side Panel Weldment ...............................................................................................................2
26 00-423047-00021 Ventilator - Drain ......................................................................................................................2
27 SC-119-23 Mach. Screw 10-24 x 1⁄2Hex Washer Hd. ................................................................................4
28 NS-044-09 Nut Assy. 10-24 Hex Keps ....................................................................................................... 4
29 00-920131 Member - Front Cross Channel ................................................................................................ 1
30 00-920152 Switch - Infinite Heat ................................................................................................................1
31 00-920221 Switch (240V.)(Infinite Heat) ....................................................................................................1
32 00-820365 Screw - Quick Opening ............................................................................................................2
33 00-805782 Label-Disconnect Power ..........................................................................................................1
34 00-344646-00001 Label .........................................................................................................................................1
35 00-920396 Knob-Control ............................................................................................................................1
36 00-906440-00013 Light-Red Signal .......................................................................................................................1
37 PB-004-69 Plug-Hole ..................................................................................................................................2
38 00-086556-00001 Label .........................................................................................................................................1
39 00-920551-00001 Front Panel Assy. .....................................................................................................................1
40 00-417700-00003 Nameplate ................................................................................................................................1
41 NS-047-68 Lock Nut 1⁄8...............................................................................................................................2
42 00-920670 Upper Front Cross Angle Assy. ................................................................................................1

–4 –
MEW14 WARMER REPLACEMENT PARTS
MEW14 WARMER BODY
1
4
5
6
7
8
9
10
11
15
2
3
PL-52130
12
13
14
16-17-18

–5 –
REPLACEMENT PARTS MEW14 WARMER
MEW14 WARMER BODY
ILLUS. PART
PL-52130 NO. NAME OF PART AMT.
1 00-423047-00030 Pan - Well W/Studs .................................................................................................................. 1
2 00-423047-00031 Difuser W/Studs .......................................................................................................................1
3 00-920151 Insulation ..................................................................................................................................1
4SC-119-23 Mach. Screw 10-24 x 1⁄2Hex Washer Hd. ................................................................................2
5 00-920138 Splash - Rear ...........................................................................................................................1
6SD-036-61 Self-Tapping Screw 10-16 x 1⁄2Slotted Truss Hd., Type B .......................................................2
7 00-920130-00001 Top Frame Weldment ...............................................................................................................1
8NS-044-09 Nut Assy. 10-24 Hex Keps ....................................................................................................... 2
9 00-920143 Panel - Bottom ..........................................................................................................................1
10 SD-036-64 Self-Tapping Screw 8-18 x 3⁄8Slotted Pan Hd., Type AB ......................................................... 4
11 NS-038-08 Lock Nut 1⁄4-20 ..........................................................................................................................4
12 00-920158 Stud ..........................................................................................................................................1
13 NS-038-08 Lock Nut 1⁄4-20 ..........................................................................................................................1
14 00-920157 Standoff ....................................................................................................................................1
15 00-920149 Cover - Element .......................................................................................................................1
16 00-920150-00010 Heater (120 V.) .........................................................................................................................1
17 00-920150-00011 Heater (240 V.) .........................................................................................................................1
18 00-920148 Clamp - Heater .........................................................................................................................3
00-920145-00001 Well Assy. Complete (120 V.) ..................................................................................................1
00-920145-00002 Well Assy. Complete (240 V.) ..................................................................................................1

–6 –
MEW14 WARMER REPLACEMENT PARTS
MEW14 MEDIUM DUTY ELECTRIC
COUNTER FOOD WARMER
SERVICE
WARNING: THE FOOD WARMER AND ITS PARTS ARE HOT. USE CARE WHEN
OPERATING, CLEANING OR SERVICING THE FOOD WARMER.
WARNING: DISCONNECT ELECTRICAL POWER SUPPLY AND PLACE A TAG AT THE
DISCONNECT SWITCH TO INDICATE THAT YOU ARE WORKING ON THE CIRCUIT
BEFORE PERFORMING ANY SERVICE.
REPLACING PILOT "ON" LIGHT OR INFINITE (CONTROL) SWITCH
1. Remove control knob by grasping outer edge and pulling straight out, without twisting or
turning.
2. Remove two screws at top of front panel. Pull edge to open.
3. Disconnect leads to pilot or infinite switch and remove the damaged component. Mark
disconnected leads to identify them.
4. Mount the new infinite switch with fasteners provided. The new pilot light is snapped into
place from the front of the panel.
5. Connect leads to corresponding terminals on new component. Check completed circuit
against circuit diagram inside the front control panel.
7. Reverse steps 1 and 2 to close front panel.
REPLACING HEATING ELEMENT
1. Remove pan well hold-down nut located at center of bottom panel and accessible from
underneath the food warmer.
2. Carefully lift out pan well, and disconnect terminal leads to heating element.
3. Remove the heating element cover (secured by five nuts) and insulation covering the
heating element.
4. Remove heating element hold-down clamp, and remove damaged element.
5. Reverse Steps 1-4 to reassemble.
