Vulcan-Hart VCD5 User manual

VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
A2780 ISO9001 Vulcan-Hart Co.
F-37318 (8-07)
STANDARD FEATURES
Heavy duty 20 gauge polished stainless steel cabinet with
tubular steel inner frame for increased durability.
1" legs.
Magnetic door latch with 90 degree stopping mechanism.
Removable heating module (with fan) for easy cleaning.
One-piece doors.
Illuminated on/off switch.
Temperature adjust from 140° to 190°F.
Capacity 17.5 pounds / 22 gallons.
One 1250 watt (10.5 amp) heating element.
Requires 120 volt, 60 Hz, single phase power supply.
Furnished with 6' power cord with NEMA 5-15 plug.
One year limited parts and labor warranty.
OPTIONS
Lexan door.
Adjustable cord length.
Two year extended limited parts and labor warranty.
n
n
n
n
n
n
n
n
n
n
n
®
®
®
MODEL VCD5
FIRST-IN FIRST-OUT CHIP WARMER
MODEL: VCD5 Series First-In First-Out Chip Warmer
SPECIFICATIONS:
First-in First-out chip warming cabinet, Vulcan-Hart Model No
VCD5. Heavy duty 20 gauge polished stainless steel cabinet
with tubular steel inner frame for increased durability. 1" legs.
One-piece doors. Magnetic door latch with 90 degree stopping
mechanism. Removable heating module (with fan) for easy
cleaning. Illuminated on/off switch.Temperature range from 140°
to 190°F. Capacity 17.5 pounds / 22 gallons. One 1250 watt (10.5
amp) heating element. Requires 120 volt, 60 Hz, single phase
power supply. 6' power cord with NEMA 5-15 plug.
Exterior dimensions: VCD5: 24¼"w x 26¼"d x 20¾"h
NSF listed. UL listed. UL listed to Canadian safety standards.
Model VCD5

VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
F-37318 (8-07)
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
MODEL VCD5
FIRST-IN FIRST-OUT CHIP WARMER
Shipping
Model No. Capacity High Deep Wide Weight Volts Watts Amps
VCD5 22 gallon 20¾" 26¼" 24¼" 115# 120 1250 10.5
