Vulcan-Hart GH6 User manual

Item # __________________________
C.S.I. Section 11420
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
0
8
7
2
A
1
0
0
9
O
S
I
.
o
C
t
r
a
H
-
n
a
c
l
u
V
F-32396 (05/06)
6
H
G
:
L
E
D
O
M
e
g
n
a
R
s
a
G
y
t
u
D
y
v
a
e
H
r
e
n
r
u
B
n
e
p
O
MODEL GH6
OPEN BURNER HEAVY DUTY GAS RANGE
Heavy duty six burner gas range with oven, Vulcan-Hart Model
No. GH6. Stainless steel body and 6" adjustable legs. 1
1
⁄ 4
front gas manifold. Six 30,000 BTU/hr. cast burners with lift-o heads.
Individual pilot lights for each burner. Six cast iron top grates with
aeration bowls. Oven interior measures 26"w x 28"d x 14"h.
Porcelain enamel on steel hearth, door and side liners. One oven
rack and two rack positions. 50,000 BTU/hr. heavy cast "Flame
Retention"burnerwithpilotignition.Thermostatadjustsfrom150°
to 500°F. Controls located in the cool zone.
Exterior dimensions: 34"w x 39 1⁄8"d x 36" working height on
6" legs.
CSA design certied. NSF listed.
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
GH6 Standard Oven
GH6C Convection Oven
GH6S Storage Base
STANDARD FEATURES
Stainless steel body and 6" adjustable legs.
11⁄4" diameter front gas manifold.
Six 30,000 BTU/hr. cast burners with lift-o heads. Individual
pilot lights for each burner.
Six cast iron top grates with aeration bowls.
Oven controls located in the cool zone.
Oven interior measures 26"w x 28"d x 14"h. Porcelain enamel
on steel hearth, door and side liners. One oven rack and two
rack positions. 50,000 BTU/hr. "Flame Retention" burner with
pilot ignition. Thermostat adjusts from 150° to 500°F.
One year limited parts and labor warranty.
OPTIONS
Snorkel TM convection oven in place of standard oven. Add
sux "C" to the model number. Porcelain enamel on steel
interior measures 26 1⁄8"w x 22 3⁄32"d x 14 1⁄8"h. Three oven racks
and ve rack positions. 32,000 BTU/hr. burner with pilot
ignition.Thermostat adjustsfrom 200°to500°F.
1⁄4H.P.blower
motor with 7 foot power cord and plug. 120/60/1, 5 amps.
Cabinet storage base in place of standard oven. Add the sux
"S" to the model number.
Stainless steel back nishing panel.
Common front top ledge up to 68" wide. (Not for use on griddle
tops, spreader plates and deep fat fryers.)
Cap and cover manifold end(s). (No charge.)
15/8" stainless steel toe base - 315⁄8" working height.
Set of four 5" diameter casters, two locking.
Stainless steel dolly frame with casters, up to 102" wide.
Cooling fan for Snorkel TM convection oven motor. Required
when unit is installed with a back nishing panel or a toe base.
3⁄4" rear gas connection. (Refer to spec sheet F-31525).
Second year extended limited parts and labor warranty.
SPECIFICATIONS
" diameter

Printed On Recycled Paper
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specications without notice.
F-32396 (05/06)
MODEL GH6
OPEN BURNER HEAVY DUTY GAS RANGE
GH6C SIDE VIEW
GH6 SIDE VIEW
LESS LEGS
TOP VIEW
GH6S
CABINET BASE
GH6 & GH6C
FRONT VIEW
Gas Rated Input BTU/hr. Working Approx.
Model Top Oven Total Width Depth Height Ship. Wt.
GH6 gk342/.sbl535000,032000,05000,081
GH6C 1⁄8" 36" 595 lbs./278 kg
GH6S gk861/.sbl073000,081—000,081
IMPORTANT
1. A gas pressure regulator suitable for battery or single unit
application must be furnished and installed. Natural gas 6.0"
W.C., propane gas 10.0" W.C.
2. An adequate ventilation system is required for commercial
cooking equipment. Information may be obtained by writing to
the National Fire Protection Association, Batterymarch Park,
Quincy, MA 02289. When writing, refer to NFPA No. 96.
3. These units are manufactured for installation in accordance
with ANSZ223.1A (latest edition), National Fuel Gas Code.
Copies may be obtained from the American Gas Association,
1515 Wilson Blvd., Arlington, VA 22209.
4. Clearances: Combustible Non-combustible
Rear 6" 0"
Sides 6" 0"
5. For proper ueing, a backguard or high shelf must be installed
with each unit. Please refer to spec sheet F-31537 for specic
styles and types.
6. Thisapplianceismanufacturedforcommercialinstallationonly
and is not intended for home use.
ACCESSORIES
17" high stainless steel backguard. (Common backguards
available up to 102" wide.)
23" high stainless steel single deck high shelf. (Common high
shelves available up to 72" wide.)
35"highstainlesssteeldoubledeckhighshelf.(Commonhigh
shelves available up to 72" wide.)
Additional oven rack(s).
Gas pressure regulator (specify size and type of gas).
Flexible gas hose with quick disconnect and restraining
device. Consult price book for available sizes.
180,000 32,000 212,000 34 "
39
