MODEL: GHX SERIES
Heavy Duty Expando Gas Range
GHX SERIES
HEAVY DUTY EXPANDO GAS RANGE
SPECIFICATIONS:
17" wide heavy duty expando gas range, Vulcan-Hart Model No.
___________. Stainless steel front, front top and 6" adjustable
legs. Sides finished in heat resistant paint. 11⁄4" diameter front
gas manifold.
■■GHX45
Two 30,000 BTU/hr. heavy cast two piece “Flame Retention”
burners with individual pilots and control valves. Total input
60,000 BTU/hr. Heavy cast iron aeration plates with deep bowls
and removable cast top grates.
■■GHX60
3⁄4" polished steel griddle plate with front grease trough and
removable grease collector. 4" side splashers and 55⁄8" rear
splasher. Two 20,000 BTU/hr. burners and one manual control
valve. Total input 40,000 BTU/hr. Pilot ignition system. Heat
absorbent fire brick and griddle leveling bolts. NOTE: For
thermostatic griddle control, specify model number GHXM60T.
■■GHX72
One polished cast iron hot top section measures 17"w x 2313⁄16"d.
Ceramic fire brick under hot top. Two 20,000 BTU/hr. burners
and one manual control valve. Total input 40,000 BTU/hr. Pilot
ignition system.
Exterior dimensions: 17"w x 391⁄8"d x 36" working height.
CSA design certified. NSF listed.
SPECIFY TYPE OF GAS AND FINISH WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
■■GHX45 Two 30,000 BTU/hr. open burners
■■GHX60 17" wide griddle top
■■GHX72 17" wide even heat top
STANDARD FEATURES
■Stainless steel front and front top. Sides finished in heat
resistant paint.
■11⁄4" diameter front gas manifold.
■17" wide cabinet storage base with door.
■One year limited parts and labor warranty.
OPTIONS
■■Stainless steel side(s).
■■Stainless steel back finishing panel.
■■Common front top ledge up to 68" wide. (Not for use on
griddle tops, spreader plates and deep fat fryers.)
■■Cap and cover manifold end(s). (No charge.)
■■Set of four 5" diameter casters, two locking.
■■Stainless steel dolly frame with casters, up to 102" wide.
■■Rear gas connection. (Reference spec sheet F31525.)
■■Second year extended limited parts and labor warranty.
Model GHX45 shown Model GHX60 shown Model GHX72 shown
with 17" Backguard with 17" Backguard with 17" Backguard

Printed On Recycled Paper
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
F-32238 (10-03)
GHX SERIES
HEAVY DUTY EXPANDO GAS RANGE
ACCESSORIES
■■17" high stainless steel backguard. (Common backguards
available up to 102" wide.)
■■23" high stainless steel single deck high shelf. (Common
high shelves available up to 72" wide.)
■■35" high stainless steel double deck high shelf. (Common
high shelves available up to 72" wide.)
■■Additional oven rack(s).
■■Gas pressure regulator (specify size and type of gas).
■■Flexible gas hose with quick disconnect and restraining
device. Consult price book for available sizes.
IMPORTANT
1. A gas pressure regulator suitable for battery or single unit
application must be furnished and installed. Natural gas
6.0" W.C., propane gas 10.0" W.C.
2. An adequate ventilation system is required for commercial
cooking equipment. Information may be obtained by writing
to the National Fire Protection Association, Batterymarch
Park, Quincy, MA 02269. When writing refer to NFPA No. 96.
3. These units are manufactured for installation in accordance
with ANSZ223.1a (latest edition), National Fuel Gas Code.
Copies may be obtained from the American Gas Association,
1515 Wilson Blvd., Arlington, VA 22209.
4. All models require a 6" (152 mm) clearance at both sides and
rear adjacent to combustible construction.
5. For proper flueing a backguard or high shelf must be installed
with each unit. Please refer to spec sheet F31537 for specific
styles and sizes.
6. This appliance is manufactured for commercial installation
only and is not intended for home use.
NO. OF BTU/HR. EA. TOTAL WORKING
MODEL BURNERS BURNER BTU/HR. WIDTH DEPTH HEIGHT APPX. SHP. WT.
GHX45 2 30,000 60,000 17" 39
1
⁄ 8 " 36" 200 lbs./91 kg
GHX60 2 20,000 40,000 17" 39
1
⁄ 8 " 36" 260 lbs./118 kg
GHX72 2 20,000 40,000 17" 39
1
⁄ 8 " 36" 250 lbs./113 kg
