Vulcan-Hart Value Series V36-1 User manual

Model V36-1
SPECIFICATIONS
36” wide gas restaurant range, Vulcan Model No. V36-1.
Stainless steel front, sides, backriser, high shelf, oven handle
and bullnose. High temperature burner T knobs with set screw.
Nickle plated bullet feet. Porcelain door liner and oven bottom.
Six 28,000 BTU/hr. cast top burners with lift-off burner heads.
Individual pilot for each burner. 12” x 12” cast top grates
with aeration bowls. Heavy duty top grates and burner heads.
Compression spring door hinge system for durability. 35,000
BTU/hr. Standard oven measures 26 1/4”w x 22”d x 14 1/2”h.
Thermostat adjusts from Low to 500 degrees F. One oven
rack with four rack positions. 3/4” rear gas connection and
gas pressure regulator. Total input: 203,000 BTH/hr.
Exterior Dimensions:
32”d x 36”w x 58”h on 6” adjustable legs
V36-1TNatural Gas / 1 Standard Oven
V36-2TPropane / 1 Standard Oven
STANDARD FEATURES
Fully MIG welded frame■
Stainless steel front, backriser, lift-off high shelf■
6” Stainless steel adjustable legs■
28,000 BTU/hr open top burners with lift-off heads■
Individual pilot for each burner■
12” x 12” cast top grates with aeration bowls■
Welded crumb tray■
35,000 BTU/hr standard oven cavity measures■
26 1/4”d x 22”w x 14 1/2”h
Oven thermostat adjusts from Low to 500°F■
One oven rack and four rack positions■
3/4” rear gas connection and gas pressure regulator■
One year limited parts and labor warranty■
ACCESSORIES (Packaged & Sold Separately)
Extra oven rackT
Extra rack guides (set of two)T
Reinforced backriser and high shelf for mountingT
salamander broiler
Set of four casters (two locking)T
11” high stainless steel ue riser in place of standard T
backriser and high shelf
Item # __________________ C.S.I. Section 11420
36” GAS RESTAURANT RANGE
6 OPEN BURNERS
VULCAN VALUE SERIES
F-37390 (07/08)
Vulcan & Wolf Range
a division of ITW Food Equipment Group LLC
P.O. Box 696 nLouisville, KY 40201 nToll-free: 1-800-814-2028 nLocal: 502-778-2791 nQuote & Order Fax: [phone]

A pressure regulator sized for this unit is included.1.
Natural gas 5.0” W.C., propane gas 10.0” W.C.
Gas line connecting to range must be 3/4” or larger. If2.
exible connectors are used, the inside diameter must be
3/4” or larger.
An adequate ventilation system is required for commercial3.
cooking equipment. Information may be obtained by
writing to the National Fire Protection Association,
1 Batterymarch Park, Quincy, MA 02269, www.NFPA.org.
When writing, refer to NFPA No. 96.
These units are manufactured for installation in4.
accordance with ANSZ223.1A (latest edition), National
Fuel Gas Code. Copies may be obtained from The
American Gas Association, 400 N Capitol St. NW,
Washington, DC 20001, www.AGA.org.
Clearances5. Rear Sides
Combustible 6” 10”
Standard Oven Non-combustible 0” 0”
Convection Oven Non-combustible Min. 4” 0”
For proper combustion, install equipment on adjustable6.
legs or casters provided with unit.
For proper combustion, install equipment on adjustable7.
legs or casters provided with unit.
NOTE: In line with its policy to continually improve its product,
Vulcan reserves the right to change materials and specications
without notice.
Specify type of gas when ordering. Specify altitude when
above 2,000 feet.
INSTALLATION INSTRUCTIONS
TOP
CONFIGURATION
MODEL
NUMBER DESCRIPTION TOTAL INPUT BTU / HR
SHIPPING WEIGHT
LBS / KG
V36-1 6 Burners / 1 Standard Oven / Natural Gas 203,000 520 / 236
V36-2 6 Burners / 1 Standard Oven / Propane 203,000 520 / 236
8” MAX
58”
6” MIN.
24 1/3”
32”
29 3/4”
22 2/3”
29 7/8”
12”
2”
36”
36” GAS RESTAURANT RANGE
6 OPEN BURNERS
VULCAN VALUE SERIES
F-37390 (07/08)
Vulcan & Wolf Range
a division of ITW Food Equipment Group LLC
P.O. Box 696 nLouisville, KY 40201 nToll-free: 1-800-814-2028 nLocal: 502-778-2791 nQuote & Order Fax: [phone]
This appliance is manufactured for commercial use only and is not intended for home use.
