Item # __________________________
C.S.I. Section 11420
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
A2780
ISO9001
Vulcan-Hart
Co.
F-32530 (11-07)
2GR45DF shown
GR KLEENSCREEN PLUS® FILTRATION SYSTEM
STANDARD FEATURES
Filter system accommodates minimum of two, maximum of
four fryer cabinets (GR45F), maximum of three (GR65F or
GR85F).
Choose from Millivolt (M), Solid State (D), or Computer (C)
Controls.
Boil Out ByPass™ removes water or discard oil .
Drain valve interlock switch - available on (D) and (C) controls.
18 gauge, #304 series stainless steel filter vessel.
6" Casters adjustable - 2 locking, 2 non-locking.
Electronic ignition on solid state (D) and computer (C)
control fryers.
Drawn (seamless) 18 gauge, #304 stainless steel
filter pan. 70 lbs. frying compound capacity on GR45F,
110 lbs. capacity on GR65 & GR85F.
Paperless stainless steel filter screen filters from 2
sides filter area = 270 sq. inches. Mircro Filtartion
Fabric Envelope filter area = 350 square inches.
1/3H.P. motor and pump circulates frying compound at a
rate of 8.0 gallons per minute.
Patented solenoid activated one touch push button switch
to engage pump and motor (solid state controls (D) and
computer (C) models only).
Large primary crumb catch basket.
Tank brush, stainless steel crumb scoop and clean-out rod.
120 volt, 60 Hz, 1 phase.
One year limited parts and labor warranty.
12 year fry tank replacement part warranty.
GR KLEENSCREEN PLUS® FILTRATION
SYSTEM
SPECIFICATIONS:
Patented Built-in filter system, Vulcan-Hart Model No. 2GR (lb.
capacity - 45, 65 or 85) (control type M, D, or C) F (add suffix-F to
fryer battery model No., i.e. 2GR45DF). Filter sytem accommo-
dates minimum of two, maximum of four cabinets for GR45F
and maximum of three for GR65F and GR85F. Filter vessel
constructed of 18 gauge #304 series stainless steel. The
2GR45F filter pan weighs only 12.2 lbs. and the filter pan for the
2GR65 & 85F weighs only 20.5 lbs. 1/3H.P. motor/ pump
circulates hot frying compound at the rate of 8 gallons per
minute, activated by a patented solenoid push button switch.
Patented System provided standard with paperless stainless
steel mesh filter screen. A complimentary package of
KleenScreen Plus® Fabric Envelopes is also included. Stan-
dard equipment comes on casters, a primary crumb catch
basket, tank brush, scoop and clean-out rod. Hands free oil
return line connection. Drain valve interlock switch turns fryer's
burners off when drain valve is opened. Requires 120 volt, 60 Hz,
1 phase power supply.
CSA design certified. NSF Listed.
ACCESSORIES
Stainless steel tank cover.
Micro-Filtration Fabric Envelopes - 6 filters/per package
6' High Temperature Discard Hose
"Add-On" Frymate - VX15, VX21, VX21S or VX21MS.
Rear oil reclamation discard connection.
GR45F - Twin Basket Lifts
GR65F & GR85F - Single and Twin Basket Lifts
Prison Security Package
Flexible gas hose with quick disconnect.
OPTIONS
Second year extended limited parts and labor warranty.
REFERENCEMATERIALS
See 1GR45 Spec Sheet F-32630
See 1GR65 Spec Sheet F-32631
See 1GR85 Spec Sheet F-32632
BUILT-IN FILTER SYSTEM FOR GR SERIES FRYERS
SPECIFY TYPE OF GAS: NATURAL OR PROPANE
SPECIFY ALTITUDE: NATURAL GAS ABOVE 2,000 FT.
PROPANE GAS ABOVE 3,500 FT.

Printed On Recycled Pap
er
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
F-32530 (11-07)
BUILT-IN FILTER SYSTEM FOR GR SERIES FRYERS
Model No. 2 Fryers 3 Fryers 4 Fryers
Width Width Width
GR45F 31" 461/2" 62"
GR65F 42" 63" -
GR85F 42" 63" -
BATTERYDIMENSIONS:
IMPORTANT
1. A combination valve with pressure regulator is provided with
this unit.
Natural Gas 4.0" (102 mm) W.C.
Propane Gas 10.0" (254 mm) W.C.
2. An adequate ventilation system is required for Commercial
Cooking Equipment. Information may be obtained by writing
to the National Fire Protection Association, Batterymarch
Park, Quincy, MA 02269. When writing refer to NFPA No. 96.
3. All models require a 6" (152 mm) clearance at both sides and
rear adjacent to combustible construction.
TOP VIEW
2GR45F/
2GR65F/
2GR85F
SERIES
4. All models require a 16" (407 mm) minimum clearance to
adjacent open top burner units.
5. This appliance is manufactured for commercial installation
only and is not intended for home use.
SERVICE CONNECTIONS:
P1 11/4" (32 mm) NPT common rear gas connection.
E1 120 volt, 60 Hz, 1 phase electrical connection (filter pump).
GR KLEENSCREEN PLUS®
FILTRATION SYSTEM
E1
P1
FRONT VIEW
2GR45F/
2GR65F/
2GR85F
SERIES
SIDE VIEW
2GR45F/
2GR65F/
2GR85F
SERIES
