Vutec Lectric 2-C User manual

Installation Instructions
Lectric 2-C & 4-C
FLUSHCEILINGMOUNTSCREEN
LARGESERIES
VIDEO PROJECTION SCREENS

1
06/26/2017 Rev. B
INSTL-L2-C_L4-C-B
VUTEC CORPORATION
www.vutec.com
TEL: [phone]
FAX: [phone]
EMAIL: info
@
vutec.com
IMPORTANT SAFETY INSTRUCTIONS
Basic safety precautions should always be followed; including the following:
♠Read and understand all instructions before proceeding with the installation and operations.
♠Lectric 2-C and Lectric 4-C meet requirement for fire-resistant and low smoke-producing
characteristics suitable for operation in a building’s environmental air space, such as above
suspended ceilings, in accordance with Section 300-22 (C) of the national Electric Code,
ANSI/NFPA 70, and sections 2-128, 12-010(3) and 12-100 of the Canadian Electric Code, Part 1,
CSAC22.1.
♠Be certain that the supporting structure is sound and capable of carrying the weight as required.
♠Seek qualified electricians to perform electrical requirements.
♠Obtain proper lifting mechanism to raise and hold the unit steady for installation.
♠Plan ahead so the installation can go smoothly and efficiently.
IMPORTANTWARNINGSANDCAUTIONS!
WARNING:AWARNINGALERTSTHEPOSSIBILITYOFSERIOUSINJURYORDEATHIFTHEINSTRUCTIONSARENOTFOLLOWED.
CAUTION:ACAUTIONALERTSTHEPOSSIBILITYOFDAMAGEORDESTRUCTIONOFEQUIPMENTIFTHEINSTRUCTIONSARENOT
FOLLOWED.
WARNING:FAILURETOREAD,THOROUGHLYUNDERSTAND,ANDFOLLOWALLINSTRUCTIONSCANRESULTINSERIOUSPERSONAL
INJURY,DAMAGETOEQUIPMENT,ORVOIDINGOFFACTORYWARRANTY!ITISTHEINSTALLER’SRESPONSIBILITYTOMAKE
SUREALLCOMPONENTSAREPROPERLYASSEMBLEDANDINSTALLEDUSINGTHEINSTRUCTIONSPROVIDED.
WARNING:FAILURETOINSTALLELECTRICALREQUIREMENTSACCORDINGTONATIONAL/LOCALELECTRICALCODESANDREGULATIONS
MAYCAUSEPREMATUREFAILURE,FIREHAZARD,ELECTRICALSHOCK,UNSAFEPRACTICEANDREVOCATIONOFUSE.
DISCLAIMER
Vutec Corporation intends to make this manual accurate and complete. However, Vutec makes no claim that the
information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency
in connection with the installation for use of this product. The information contained in this document is subject to change
without notice. Vutec makes no representation of warranty, expressed or implied, regarding the information contained
herein. Vutec assumes no responsibility for accuracy, completeness or sufficiency of the information contained in this
document.
PRE- INSTALLATION
1) Carefully cut and remove packing materials.
2) Carefully unpack and inspect the unit for sign of damages.
3) Be sure to recheck and measure all pertinent dimensions before installation.
4) Most basic tools are required for installation.
SAVE THESE INSTRUCTIONS

2
06/26/2017 Rev. B
INSTL-L2-C_L4-C-B
VUTEC CORPORATION
www.vutec.com
TEL: [phone]
FAX: [phone]
EMAIL: info
@
vutec.com
LECTRIC 2-C & 4-C
FLUSHCEILINGMOUNTWITHSERVICEDOOR
SELF-SUPPORTED (shown) and TAB-TENSIONED screens
Figure 1
SCREEN TYPE LENGTH DIM. A
SELF-SUPPORTED VIEWING WIDTH + 15 1/2 7 3/4
TAB-TENSIONED VIEWING WIDTH + 22 1/2 11 1/4

3
06/26/2017 Rev. B
INSTL-L2-C_L4-C-B
VUTEC CORPORATION
www.vutec.com
TEL: [phone]
FAX: [phone]
EMAIL: info
@
vutec.com
HOUSING INSTALLATION
Lectric 2-C is designed for flush ceiling mount. As shown in Figure 2a, Option 1 is the preferred mounting
method which requires access space above the ceiling. The mounting brackets may be placed anywhere along
the housing length as desired. However, it is best to evenly space them for uniform weight distribution. It is
recommended the end mounting brackets should not be more than 4 inches from each end of housing.
The housing has a built-in trim flange around the bottom. Ceiling tiles or drywall may be placed on top of this
flange for a finished appearance.
WARNING:SUPPORTINGSTRUCTUREMUSTBECAPABLEOFCARRYING4TIMESTHEUNITWEIGHT.CHECKWEIGHTDATAATTHEENDOF
THISDOCUMENT.
Threaded rods of 3/8 (10mm) diameter, hex nuts and helical lock washers are to be provided by installers.
After securing the housing in the ceiling check that the housing is level and plumb. Make adjustments as
necessary then tighten the hex nuts.
It is recommended that safety cables be added to the housing for additional safety concern. The cables may be
looped and tied to end mounting brackets between the housing and bracket (Figure 2c).
An alternate mounting method is available as shown in Figure 3. This mounting option must be requested in
advance at the time of order placement for the mounting holes to be drilled.
It is the installer responsibility to supply proper mounting hardware for option 2 mounting.
Option 2 mounting requires the screen roller assembly to be removed to gain access for the mounting screws
along the middle section of the housing.
Figure 2b
Some Parts Removed
For Illustration
Figure 2a
Option 1- Suspended mounting

4
06/26/2017 Rev. B
INSTL-L2-C_L4-C-B
VUTEC CORPORATION
www.vutec.com
TEL: [phone]
FAX: [phone]
EMAIL: info
@
vutec.com
Refer to the SCREEN ROLLER ASSEMBLY REMOVAL Section for instructions.
CAUTION:BESURETOPLACETHECONNECTINGWIRESINSIDEBEFOREPROCEEDINGWITHTHEHOUSINGINSTALLATION.
Install the housing once the screen roller assembly is removed. Be sure the housing is level and plumb.
Figure 2c
Option 1 - Suspended Mounting
Figure 3
Option 2 – Blind Pocket Mounting

5
06/26/2017 Rev. B
INSTL-L2-C_L4-C-B
VUTEC CORPORATION
www.vutec.com
TEL: [phone]
FAX: [phone]
EMAIL: info
@
vutec.com
ELECTRICAL CONNECTIONS
All required wirings are connected. The pigtail (Figure 4a or 4b) should be replaced with a 4-conductor cable
(by installers) straight run to the wall switch or other control devices.
Schematics are provided with this instruction at the end.
WARNING:THEINITIALHOOK‐UPANDCALIBRATIONPROCEDURESAREINTENDEDTOBEPERFORMEDBYAQUALIFIEDSERVICEMAN.
Figure 4a
Electrical Connections 120 VAC
On each end of the service door; remove the screws (Figure 2b) to untie the door.
Remove the electrical cover to gain access to the electrical compartment. Simply push up or using a screwdriver
and make a light hit upward on the cover to pop open (Figure 5a).
Pull down the Eurostrip to replace the pigtail with 4-conductor cable. The cable should go to location where the
wall switch is to be located.
Make connections to the wall switch. Perform quick test by sending the screen down and then up.
Push the Eurostrip back up in the electrical compartment and reinstall the electrical cover. Refer to Figures 5a
and 5b, keep the cover in contact with the motor bracket while pulling down on the screw of the cover. Note the
cover is lightly force fit inside the housing.
Close the service door and reinstall the screw on each end.
NOTE:FOR230VACINSTALLATION,REFERTOFIGURE4b.

6
06/26/2017 Rev. B
INSTL-L2-C_L4-C-B
VUTEC CORPORATION
www.vutec.com
TEL: [phone]
FAX: [phone]
EMAIL: info
@
vutec.com
Figure 4b
Electrical Connections 230 VAC
The screen may also be operated by optional IR/RF remote control, optional 12VDC trigger relay, optional Low
Voltage control or optional Home Automation control by AMX, Crestron, etc. Consult Vutec for further details.

7
06/26/2017 Rev. B
INSTL-L2-C_L4-C-B
VUTEC CORPORATION
www.vutec.com
TEL: [phone]
FAX: [phone]
EMAIL: info
@
vutec.com
Figure 5a Figure 5b
UPPER LIMIT ADJUSTMENT
The upper limit for the screen is when the bottom weight bar stop just inside the housing. Do not change the
screen upper limit unless absolutely necessary.
LOWER LIMIT ADJUSTMENT
WARNING:UNLESSOTHERWISESPECIFIEDANDORDERED,STANDARDLEADERDROPIS12INCHESMAXIMUM.EXCEEDINGTHE
MAXIMUMMAYCAUSETHESCREENTOFALLOFFTHEROLLERANDVOIDTHEWARRANTY.
HEXSOCKETLIMITSWITCH
Key features of the hex socket (Figures 2a and 6) limit switch:
⇒Each full turn (360 degrees) of the hex socket cause the screen to travel approximately 3/4 inch.
⇒Follow the label affixed to the electrical cover plate for turning of the hex sockets.
⇒As the hex socket is turning, the screen will move only in the direction of increasing travel.
Hint: Going down direction (lower limit) will see the screen move as more down being adjusted but not
the opposite.
MORESCREENDROP
Send the screen down to the lower limit and it should stop automatically. Leave the control switch on.
Turn the White hex socket in the + direction (see label on electrical cover plate) to make the screen come down
more. Stop turning when the screen reaches the desired lower limit.

8
06/26/2017 Rev. B
INSTL-L2-C_L4-C-B
VUTEC CORPORATION
www.vutec.com
TEL: [phone]
FAX: [phone]
EMAIL: info
@
vutec.com
LESSSCREENDROP
Send the screen down to the lower limit and it should stop automatically. Leave the control switch on.
Determine the number of turns required to stop the screen above the desired lower limit.
Turn the White hex socket in the - direction the number of turns that has been determined to make it stop above
the desired lower limit.
Send the screen up half way and stop. Send it down and expect it to stop above the desired lower limit.
Repeat until the screen has stopped above the desired lower limit.
When the screen stops above the desired lower limit; proceed to MORE SCREEN DROP part to lower the screen
to the desired lower limit.
Figure 6
Limit Switch Sockets
PUSHBUTTONLIMITSWITCH
Depending on availability, some screens might be equipped with motor with push button limit switches.
Key features of the push button limit switch:
⇒Button popped out; free running - motor limit switch is not engaged.
⇒Button pushed in; motor limit switch is engaged.
⇒Yellow button for upper limit. White button for lower limit.
CHANGINGTHEUPPERORLOWERLIMIT
Changing the upper or lower limit of the motor with push buttons is simple.
Disengage the limit for the up or down by popping out the appropriate yellow or white button.
Send the screen to the desired limit then stop.
Push in the button to engage the limit switch. The screen limit is set.
Test run the screen and checks the desired limit. Repeat as often.

9
06/26/2017 Rev. B
INSTL-L2-C_L4-C-B
VUTEC CORPORATION
www.vutec.com
TEL: [phone]
FAX: [phone]
EMAIL: info
@
vutec.com
SCHEMATIC
120 VAC Installations
230 VAC Installations

10
06/26/2017 Rev. B
INSTL-L2-C_L4-C-B
VUTEC CORPORATION
www.vutec.com
TEL: [phone]
FAX: [phone]
EMAIL: info
@
vutec.com
TROUBLESHOOTING
SYMPTOMCAUSESOLUTION
Door remains closed and screen will not
come down.
Motor does not hum.
Motor hums.
a- Check breaker fuse.
b- Check wall switch.
c- Push button limit switches might be
tripped.
d- Thermal overload tripped.
e- Defective motor or wall switch.
f- Temporary binding.
g- Capacitor burned out.
a- Replace blown fuse.
b- Check wall switch connections.
Bypassing wall switch as a test.
c- Manually open trap door. See Electrical
to reset push button limit switch. Reset
Yellow button for lower limit.
d- Let motor cool down for 15 minutes.
e- Replace motor or wall switch.
f- Manually open trap door check for
binding.
g- Replace motor.
Screen will not go up.
Motor does not hum.
Motor hums.
a- Check breaker fuse.
b- Check wall switch.
c- Push button limit switches might be
tripped.
d- Thermal overload tripped.
e- Defective motor or wall switch.
f- Temporary binding.
g- Capacitor burned out.
a- Replace blown fuse.
b- Check wall switch connections.
Bypassing wall switch as a test.
c- See Electrical to reset push button limit
switch. Reset White button for upper
limit.
d- Let motor cool down for 15 minutes.
e- Replace motor or wall switch.
f- Check for binding of roller assembly.
g- Replace motor.
Coasting. a- Defective brake. a- Replace motor.
Trap door closed and motor hums.
Trap door not quite closed but motor stop.
a- Check Door Close Limit (DCL) switch a- Adjust DCL switch by moving it up or
down.
Noisy operations. a- Cyclic noise (squeaky) pattern.
b- Gear noise
a- Lubricate roller shaft and bearing at Idler
bracket with typical oil.
b- Replace motor.
ACCESSORIES INCLUDED
1 SPDT DECORA SWITCH
1 SWITCH COVER PLATE
4 MOUNTING BRACKET
9 1/4-20 X 1” LONG HEX HEAD BOLT
9 HELICAL LOCK WASHER FOR 1/4 BOLT
9 1/4-20 HEX NUT
