WABCO ABS/EBS CODE READER User manual

ABS/EBS CODE READER
USER MANUAL

ABS/EBS CODE READER
USER MANUAL
UŽIVATELSKÁ PŘÍRUČKA
BENUTZERHANDBUCH
MANUAL DE USUARIO
MANUEL D‘UTILISATION
KORISNIČKI PRIRUČNIK
FELHASZNÁLÓI KÉZIKÖNYV
MANUALE D‘ISTRUZIONE
GEBRUIKSAANWIJZING
ユーザーマニュアル
PODRĘCZNIK UŻYTKOWNIKA
MANUAL DO USUÁRIO
MANUAL DO UTILIZADOR
KULLANICI EL KITABI
用户手册
Edition 2
This publication is not subject to any update service.
You will find the current version on the internet at
http://www.wabco.info/8159802423
© 2020 WABCO Europe BVBA – All rights reserved.
Subject to amendment.
Version 1 (02.2020) multilingual
815 980 242 3


3
Table of contents
EN
Table of contents
1 List of abbreviations........................................................................................................................................ 4
2 Symbols used................................................................................................................................................... 5
3 Safety information............................................................................................................................................ 6
4 Introduction ...................................................................................................................................................... 7
5 Installation ........................................................................................................................................................ 8
5.1 Connecting the ABS/EBS Code Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6 Operation .......................................................................................................................................................... 9
6.1 Setting the language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6.2 Setting the background lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7 Functions........................................................................................................................................................ 11
7.1 Specifying the installed braking system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7.2 Reading out the fault memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7.3 Interpreting the error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.4 Clearing the fault memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7.5 Reading out the diagnostic identifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7.6 Reading out the ECU product number. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7.7 Displaying the supply voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8 Supported WABCO ECUs.............................................................................................................................. 15
9 Fault codes and their meaning ..................................................................................................................... 17
10 Disposal .......................................................................................................................................................... 26
11 WABCO regional offices................................................................................................................................ 27
Edition 2
Version 1 (12/2019)
815 980 242 3
This publication is not subject to an updating service.
You will find the current version at:
http://www.wabco.info/i/646

4
List of abbreviations
EN
1 List of abbreviations
Abbreviation Meaning
ABS (German: Anti-Blockier-System); Anti-lock brake system
EBS Electronic Braking System
ECU Electronic Control Unit
FMI Failure Mode Identifier
SPN Suspect Parameter Number
TEBS Electronic Braking System for Trailers
VCS Vario-Compact-System; compactly structured ABS for trailers

5
Symbols used
EN
2 Symbols used
DANGER
The signal word denotes a hazard with a high degree of risk which, if not avoided, will result in death
or serious injury.
WARNING
The signal word denotes a hazard with a medium degree of risk which, if not avoided, can result in
death or serious injury.
CAUTION
The signal word denotes a hazard with a low degree of risk which, if not avoided, may result in minor
or moderate injury.
NOTICE
The signal word denotes a hazard which, if not avoided, can result in material damage.
Important information, notes and/or tips
Reference to information on the internet
Descriptive text
– Action step
1. Action step 1 (in ascending order)
2. Action step 2 (in ascending order)
Consequence of an action
Listing
•Listing
Note on the use of a tool / WABCO tool

6
Safety information
EN
3 Safety information
Observe all necessary regulations and instructions:
– Follow all warning notes, notices and instructions in this document to avoid personal injury and
material damage.
– Follow the company's accident prevention regulations as well as regional and national regulations.
– Follow the instructions of the axle and vehicle manufacturer.
– Make sure your workplace is dry as well as adequately lit and ventilated.
Make provisions for a safe work environment:
– Only trained and qualified technicians may carry out work on the vehicle.
– Please wear personal protection equipment to prevent injuries:
Safety gloves
Safety goggles
– Pedal actuations can lead to severe injuries if persons are in the vicinity of the vehicle. Make sure
that pedals cannot be actuated as follows:
– Switch the transmission to "neutral" and actuate the park brake.
– Secure the vehicle against rolling by using chocks.
– Fasten a visible note to the steering wheel indicating that work is being performed on the
vehicle and that the pedals are not to be actuated.
– Do not use the ABS/EBS Code Reader in the vicinity of:
heat sources
magnetic fields
exhaust gases
sources of electricity
– Do not expose the ABS/EBS Code Reader to impact, shock or moisture (water or other liquids).

7
Introduction
EN
4 Introduction
The ABS/EBS Code Reader is a device for the diagnosis of WABCO braking systems in trailers, towing
vehicles and buses. The sections below describe and explain operation and functions of the device.
All menu items in these instructions are stated in English. The language of the ABS/EBS can be
adapted, as described in Chapter "6.1 Setting the language", page 9.

8
Installation
EN
5 Installation
Before you can start the device up you need to connect it to the vehicle. There are numerous WABCO
diagnostic cables available for this. Different ports can be used to connect the device to the vehicle.
Please use the manufacturer specifications for guidance, or find out more at
http://www.wabco.info/i/1365.
There you will also find information about our comprehensive range of WABCO System Diagnosis with
PC.
5.1 Connecting the ABS/EBS Code Reader
1. Select the correct diagnostic cable.
2. Connect the cable to the vehicle interface.
3. Attach the ABS/EBS Code Reader to the diagnostic cable.
4. Switch on the ignition to ensure a power supply.
The device is automatically supplied with voltage from the vehicle and switches itself on.
After switching on, the device briefly displays the installed version, before switching to the main
menu.

9
Operation
EN
6 Operation
The ABS/EBS Code Reader can be used with one hand. A two-line digital display is located in the top
section with buttons for operating the device in the bottom section.
Key Meaning Explanation
EXIT Exit Exit menu or function
UP Up To access a menu item further up
DOWN Down To access a menu item further down
OK OK Confirm command or access a submenu
The menu structure is a circumferential menu. When the last menu item is reached by scrolling down or
up, the display jumps back to the first/last menu item.
At the top side there is a connecting cable with a 9-pin D-Sub connector. This connector is compatible
with all diagnostic cables from WABCO currently on the market and enables an easy connection to the
vehicles.
The ABS/EBS Code Reader does not require its own power supply. The power is supplied by the vehicle
to which it is connected.
6.1 Setting the language
The device is supplied with English as the default language. Please carry out the following steps to
change the language:
1. Attach the ABS/EBS Code Reader as described in Chapter "5 Installation", page 8.
2. Select menu item "2) Settings" (using the "UP" and "DOWN" buttons).
3. Confirm by pressing the "OK" button.
4. Select the "Language" menu item (using the "UP" and "DOWN" buttons).
5. Confirm by pressing the "OK" button once.
6. Use the "UP" and "DOWN" buttons to select the language you want.
7. Confirm the desired language by pressing the "OK" button.
The device is set to the language of your choice.

10
Operation
EN
6.2 Setting the background lighting
The background lighting can be changed under the "Settings" menu item.
1. Attach the ABS/EBS Code Reader as described in Chapter "5 Installation", page 8.
2. Select menu item "2) Settings" (using the "UP" and "DOWN" buttons).
3. Confirm by pressing the "OK" button.
4. Select the menu item "Backg. Light" (using the "UP" and "DOWN" buttons).
5. Confirm by pressing the "OK" button.
6. Use the "UP" and "DOWN" buttons to adjust the brightness of the display as required.
7. Save your settings by pressing the "OK" button and exit the menu.
If you only press the "Exit" button, you will exit the menu without saving the settings.

11
Functions
EN
7 Functions
7.1 Specifying the installed braking system
Once the device is connected it can search for the brake control unit in the vehicle.
1. Attach the ABS/EBS Code Reader as described in Chapter "5 Installation", page 8.
2. Select menu item "1) Scan" (using the "UP" and "DOWN" buttons).
3. Confirm by pressing the "OK" button.
If a WABCO control unit is found, it is displayed with name and device generation
(e.g.: TEBS-E).
7.2 Reading out the fault memory
If the device detected a WABCO braking system in the vehicle, the device can read out the memory
from the ECU. System messages are shown in the two-line display in the following format:
01) 144/1 (1)
Count: 1
5
123 4
1
2
3
4
5
Index no.
SPN (Suspect Parameter Number - numbers of the
components concerned)
FMI (Failure Mode Identifier)
A 1 or a 0 in brackets is displayed behind each fault
code. The 1 indicates that an active fault is present in the
system, the 0 indicates that an inactive fault is stored.
Indicates how often the fault occurs.
1. Attach the ABS/EBS Code Reader as described in Chapter "5 Installation", page 8.
2. Select menu item "1) Scan" (using the "UP" and "DOWN" buttons).
3. Confirm by pressing the "OK" button.
The connection takes a few seconds. Once a connection has been established, the version of
the connected system is briefly displayed.
4. Select menu item "1) View DTCs" (using the "UP" and "DOWN" buttons).
5. Confirm by pressing the "OK" button.
6. Use the "UP" and "DOWN" buttons to navigate through the error messages.

12
Functions
EN
7.3 Interpreting the error codes
1. Scan the QR code on the back of the code reader with the camera in your smartphone (or another
mobile device).
Once the code has been scanned, your mobile device will automatically access the website
https://services.wabco-auto.com/codekey/.
Alternatively, visit the web page https://services.wabco-auto.com/codekey/.
1. Under "System", select the system affected by the error.
2. Under "Code", enter the error codes in the input fields.
3. Click on the "Submit" button.
The error description is displayed.
4. Rectify the error in the vehicle.
If you do not have a mobile device or computer to hand, you can look up the error codes in
Chapter "9 Fault codes and their meaning", page 17.

13
Functions
EN
7.4 Clearing the fault memory
The ABS/EBS Code Reader can be used to delete fault memory entries relating to the braking
system, provided these are inactive faults. Active faults can only be deleted once the cause has been
eliminated.
1. Attach the ABS/EBS Code Reader as described in Chapter "5 Installation", page 8.
2. Select menu item "1) Scan" (using the "UP" and "DOWN" buttons).
3. Confirm by pressing the "OK" button.
The connection takes a few seconds. Once a connection has been established, the version of
the connected system is briefly displayed.
4. Select menu item "2) Clear DTCs" (using the "UP" and "DOWN" buttons).
5. Confirm by pressing the "OK" button.
6. Confirm the request by pressing the "OK" button.
Clear DTCs?
All inactive faults are deleted.
7.5 Reading out the diagnostic identifier
The ABS/EBS Code Reader can be used to read out the diagnostic identifier. This can help your
WABCO partner in providing more precise assistance.
1. Attach the ABS/EBS Code Reader as described in Chapter "5 Installation", page 8.
2. Select menu item "1) Scan" (using the "UP" and "DOWN" buttons).
3. Confirm by pressing the "OK" button.
The connection takes a few seconds. Once a connection has been established, the version of
the connected system is briefly displayed.
4. Select menu item "3) Diagnostic Identifier" (using the "UP" and "DOWN" buttons).
5. Confirm by pressing the "OK" button.
The diagnostic identifier is displayed. This consists of 8 characters and is normally constructed
in the format XX XX XX XX.
Example:
1B 22 33 44

14
Functions
EN
7.6 Reading out the ECU product number
The ABS/EBS Code Reader can be used to read out the WABCO product number for the brake control
unit.
You can find information on WABCO products here: http://www.wabco.info/i/1365
Please contact your WABCO partner for further information.
1. Attach the ABS/EBS Code Reader as described in Chapter "5 Installation", page 8.
2. Select menu item "1) Scan" (using the "UP" and "DOWN" buttons).
3. Confirm by pressing the "OK" button.
The connection takes a few seconds. Once a connection has been established, the version of
the connected system is briefly displayed.
4. Select menu item "4) WABCO Part No." (using the "UP" and "DOWN" buttons).
5. Confirm by pressing the "OK" button.
The product number is displayed. This consists of 10 characters and is normally constructed in
the format XXX XXX XXX X.
Example:
480 102 080 0
7.7 Displaying the supply voltage
After connecting the device, the supply voltage can be displayed.
1. Attach the ABS/EBS Code Reader as described in Chapter "5 Installation", page 8.
2. Select menu item "3) Supply Voltage" (using the "UP" and "DOWN" buttons).
3. Confirm by pressing the "OK" button.
The current supply voltage is displayed in volts.
Example:
24.0 V

15
Supported WABCO ECUs
EN
8 Supported WABCO ECUs
Version 1.01 of the ABS/EBS Code Reader supports access to WABCO ABS control units in towing vehicles and
buses, as well as ABS and EBS control units in trailers.
Below is a detailed list of supported electronic units:
Braking system ECU part number Braking system ECU part number
VCS II 400 500 070 0 ABS D + 446 004 314 0
VCS II 400 500 081 0 - 400 500 084 0 ABS SAE 446 004 315 0 - 446 004 316 0
VCS II 400 500 086 0 ABS D + 446 004 317 0 - 446 004 318 0
ABS SAE 446 003 401 0 - 446 003 402 0 ABS SAE 446 004 319 0
ABS D + 446 003 403 0 - 446 003 404 0 ABS D + 446 004 320 0 - 446 004 321 0
ABS SAE 446 003 405 0 - 446 003 412 0 ABS SAE 446 004 322 0 - 446 004 323 0
ABS D + 446 003 413 0 ABS D + 446 004 324 0 - 446 004 330 0
ABS SAE 446 003 414 0 - 446 003 415 0 ABS D + 446 004 333 0
ABS D + 446 003 416 0 ABS SAE 446 004 401 0
ABS SAE 446 003 417 0 - 446 003 420 0 ABS D + 446 004 403 0 - 446 004 404 0
ABS D + 446 003 421 0 - 446 003 422 0 ABS SAE 446 004 405 0
ABS SAE 446 003 701 0 - 446 003 703 0 ABS D + 446 004 406 0 - 446 004 414 0
ABS D + 446 003 704 0 - 446 003 705 0 ABS SAE 446 004 415 0
ABS SAE 446 003 706 0 ABS D + 446 004 416 0
ABS SAE 446 003 708 0 ABS SAE 446 004 417 0 - 446 004 420 0
ABS D + 446 003 709 0 ABS D + 446 004 421 0 - 446 004 422 0
ABS SAE 446 003 712 0 ABS SAE 446 004 423 0
ABS D + 446 003 713 0 ABS D + 446 004 424 0
ABS SAE 446 003 715 0 - 446 003 716 0 ABS SAE 446 004 426 0
ABS SAE 446 003 717 0 - 446 003 734 0 ABS D + 446 004 427 0 - 446 004 428 0
ABS SAE 446 003 740 0 ABS SAE 446 004 429 0
ABS E+ 446 003 747 0 - 446 003 749 ABS D + 446 004 430 0 - 446 004 432 0
ABS E+ 446 003 752 0 ABS SAE 446 004 601 0 - 446 004 603 0
ABS E+ 446 003 755 0 - 446 003 760 0 ABS SAE 446 004 605 0
ABS E+ 446 003 764 0 - 446 003 765 0 ABS D + 446 004 606 0 - 446 004 607 0
ABS E+ 446 003 767 0 - 446 003 774 0 ABS SAE 446 004 608 0
ABS E+ 446 003 827 0 ABS D + 446 004 609 0
ABS E+ 446 003 829 0 ABS SAE 446 004 610 0
ABS E+ 446 003 831 0 - 446 003 833 0 ABS D + 446 004 611 0 - 446 004 612 0
ABS SAE 446 004 302 0 ABS D + 446 004 614 0
ABS D + 446 004 304 0 ABS D + 446 004 616 0 - 446 004 617 0
ABS SAE 446 004 305 0 ABS SAE 446 004 618 0 - 446 004 620 0
ABS D + 446 004 306 0 - 446 004 310 0 ABS D + 446 004 621 0 - 446 004 622 0
ABS SAE 446 004 311 0 ABS SAE 446 004 623 0
ABS SAE 446 004 313 0 ABS SAE 446 004 625 0 - 446 004 628 0

16
Supported WABCO ECUs
EN
Braking system ECU part number Braking system ECU part number
ABS D + 446 004 629 0 - 446 004 631 0 ABS SAE 884 905 044 0
ABS D + 446 004 634 0 ABS SAE 884 905 073 2
ABS D + 446 004 635 0 ABS SAE 884 906 193 2
ABS D + 446 004 636 0 - 446 004 638 0 ABS SAE 884 906 196 0
ABS E+ 446 004 639 0 - 446 004 641 0 ABS SAE 884 906 244 0
ABS E+ 446 004 643 0 - 446 004 650 0 ABS SAE 884 906 438 2 - 884 906 439 2
ABS E+ 446 004 652 0 - 446 004 653 0 ABS SAE 884 906 441 2 - 884 906 442 2
ABS E+ 446 004 657 0 ABS SAE 884 906 443 0 - 884 906 444 0
ABS SAE 446 106 060 2 - 446 106 065 2
ABS SAE 446 106 070 2 - 446 106 081 2
ABS SAE 446 106 100 2 - 446 106 106 2
ABS SAE 446 106 110 2 - 446 106 112 2
ABS SAE 446 106 201 0 - 446 106 211 0
ABS SAE 446 106 201 2 - 446 106 205 2
ABS SAE 446 106 208 2
ABS SAE 446 106 214 0 - 446 106 215 0
ABS SAE 446 106 216 2 - 446 106 217 2
ABS SAE 446 106 217 0 - 446 106 219 0
ABS SAE 446 106 220 2 - 446 106 221 2
ABS E+ 446 106 242 0 - 446 106 247 0
VCS II 446 108 085 0
TEBS-D 480 102 000 0 - 480 102 005 0
TEBS-D 480 102 010 0
TEBS-D 480 102 014 0 - 480 102 015 0
TEBS-E 480 102 030 0 - 480 102 036 0
TEBS-E 480 102 060 0 - 480 102 066 0
TEBS-E 480 102 080 0
ABS SAE 884 904 416 2
ABS SAE 884 904 446 2
ABS SAE 884 904 468 0
ABS SAE 884 904 479 0
ABS SAE 884 904 631 0
ABS SAE 884 904 771 2 - 884 904 772 2
ABS SAE 884 904 792 0
ABS SAE 884 904 817 2
ABS SAE 884 904 867 0
ABS SAE 884 904 879 0 - 884 904 880 0
ABS SAE 884 904 890 2
ABS SAE 884 904 906 0
ABS SAE 884 904 928 2

17
Fault codes and their meaning
EN
9 Fault codes and their meaning
On the pages below you will find explanations of the system messages displayed on your device. Please note that the
meanings of the stored messages may vary depending on the braking system and generation.
Towing vehicle and bus ABS
SPN Affected component
1 Wheel sensor front axle left (A1L)
2 Wheel sensor front axle right (A1R)
3 Wheel sensor drive axle left (A2L)
4 Wheel sensor drive axle right (A2R)
5 Wheel sensor additional axle left (A3L)
6 Wheel sensor additional axle right (A3R)
7 Pressure modulator front axle left (A1L)
8 Pressure modulator front axle right (A1R)
9 Pressure modulator drive axle left (A2L)
10 Pressure modulator drive axle right (A2R)
11 Pressure modulator additional axle left (A3L)
12 Pressure modulator additional axle right (A3R)
13 Relay, endurance brake deactivation
14 Power supply axles 1+2 or supply for diff. valve or ground 2
15 Power supply axle 3,or ground line diff. valve, or AUX
16 Pressure sensor
18 3/2 solenoid valve rear axle(s)
19 Differential lock or 3/2 solenoid valve front axle(s) or power supply for ESC module
20 Prop. valve or centre differential lock
21 Electric engine interface
22 Speed signal input
23 ABS warning lamp or warning lamp relay
55 Brake light switch 1 (SPN: 1045 - Brake Light Switch 1)
79 Tire pressure monitoring
81 Trailer warning lamp
88 VDC, ESC data connection / ESC module
89 Data connection SAS (steering-wheel angle sensor)
94 Hill Start Aid system
102 Status differential lock (transfer box)
151 Status differential lock (transfer box differential lock)
231 SAE J1939 vehicle CAN data connection
248 SAE J1939 port
249 SAE J1922 port
251 Supply voltage
253 Calibration memory / parameter setting
254 ECU / System component

18
Fault codes and their meaning
EN
564 Status differential lock (transfer box)
566 Status differential lock (transfer box differential lock)
627 Power supply
629 ECU / System component
630 Calibration memory / parameter setting
631 System configuration / system setup do not match
639 SAE J1939 vehicle CAN data connection
701 AUX I/O #01
702 AUX I/O #02
703 AUX I/O #03
704 AUX I/O #04
705 AUX I/O #05
706 AUX I/O #06
789 Rotational speed sensor front axle Left
790 Rotational speed sensor front axle Right
791 Rotational speed sensor drive axle Left
792 Rotational speed sensor drive axle Right
793 Rotational speed sensor additional axle Left
794 Rotational speed sensor additional axle Right
795 Modulator valve front axle Left
796 Modulator valve front axle Right
797 Modulator valve drive axle Left
798 Modulator valve drive axle Right
799 Modulator valve additional axle Left
800 Modulator valve additional axle Right
801 Retarder control relay
802 Relay Diagonal 1
803 Relay Diagonal 2
806 3/2 solenoid valve rear axle(s)
807 3/2 solenoid valve front axle(s) / trailer
810 Speed signal input
811 Towing vehicle ABS warning lamp
812 ATC lamp (stability control lamp)
1042 Electronic towing vehicle / trailer CAN interface (ISO 11992)
1045 Stop-light switch
1049 Pressure sensor 1 / analogue input 1
1050 Pressure control / supply pressure
1052 Pressure sensor 2 / analogue input 2
1055 Pressure sensor 3 / analogue input 3
1056 3/2 directional control valve trailer
1069 Tire pressure

19
Fault codes and their meaning
EN
1070 Vehicle deceleration monitoring
1204 No loads connected
1351 Air Compressor
1792 Trailer ABS warning lamp
1807 Data connection SAS (steering-wheel angle sensor)
1809 Lateral accelerometer
1810 Longitudinal accelerometer
2622 Hill Start Aid system
3509 Power supply (sensors, stability control)
520210 Electronic stability control system (CAN data connection / ESC module)
520211 Electronic stability control system (CAN data connection / steering-wheel angle sensor
/ ESC module)
520310 Electronic Air Dryer
520400 Extended CAN messages / CAN vehicle bus
Towing vehicle and bus ABS
FMI Fault description
0 Data valid, but above normal operation range (most severe level)
1 Data valid, but below normal operation range (most severe level)
2 Data erratic, intermittent or incorrect
3 Voltage above normal, or shorted to UBat
4 Voltage below normal or shorted to ground
5 Current below normal or open circuit
6 Current above normal (grounded circuit, internal short circuit)
7 Mechanical system is not responding correctly or out of adjustment
8 Incorrect frequency, pulse width or period
9 Timeout or cabling
10 Implausible input signal
11 Failure mode not identifiable / root cause unknown
12 Bad intelligent device or component
13 Signal out of valid range
14 Implausible value
VCSII
SPN Affected component
3 Rotational speed sensor c
4 Rotational speed sensor d
5 Rotational speed sensor e
6 Rotational speed sensor f
7 Solenoid valve A
9 Solenoid valve C
Table of contents
Languages:
Other WABCO Diagnostic Equipment manuals
