INTRODUCTION
Thanks for choosing a Wachendorff device.
Timer TI327401 can be set in 5 different modes: Timer-ON, Timer-OFF,
Pause-Work, Oscillator, PWM (time-proportioned output), all options
with independent setting of ON-OFF time.
3 digital inputs are available (NPN/PNP) for external commands like
Start, Stop, Reset; one input is also analogic in order to allow the
modification of working times by external potentiometer.
5 different time bases (hundredths, tenths, seconds, minutes, hours).
Counting can be incremental or decremental.
MEMORY CARD (optional)MEMORY CARD (optional)
Parameters and setpoint values can be copied from one device to
another using the Memory card
There are two methods:
insert the memory card .
On activation display 1 shows and display 2 shows
The device loads the new data and starts again
The memory card is equipped with an internal battery with a life of about 1.000
uses.
Insert the memory card and press the programming button.
When writing the parameters, the LED turns red and on completing the procedure
it changes to green. It is possible to repeat the procedure.
To the memory card values, follow the procedure described in the first
method, setting display 2 to so as not to load the parameters on controller.
Enter configuration and .
Exit configuration. Changes are saved automatically.
This procedure restores the factory settings of the instrument.
With the device connected to the power supply
when the controller is off
With the controller disconnected from the power supply:
change at least one parameter
update
LOADING DEFAULT VALUES
.A
(Only if the values stored on Mmeory Card are correct).
By pressing the key display 2 shows
Confirm using the key .
.
ttention: pls. Perform first an update of the
memory card.
>
>
UPDATING MEMORY CARD.
PRESS
for 3 seconds
Display 1 shows
and 1st digit flashes,
display 2 shows
EFFECT OPERATION
Or
Modify flashing digit,
press to reach the following digit
Enter password
to confirm
Display shows first parameter
of configuration table
1
2
3
WIRING DIAGRAMWIRING DIAGRAM
POTENTIOMETER 0 to 5/10 Kohm
Accuracy 1.000 points
P-01 Timer Function
Timer On
Timer Off
Pause/Work
Oscillator
PWM
FUNCTION CONFIGURATION
P-02 Power-off Memory
Disable
Only Timer
Timer / State
BACKUP MEMORY CONFIGURATION
P-03 Hardware Input 1
INPUT CONFIGURATION
LIST of PARAMETERSLIST of PARAMETERS
Potentiometer:
1 use potentiometers 0 to 5/ 10kohm
2 connect cursor to pin I3; a wrong connection ma damage the
potentiometer and lead to lock of th device.
3 accuracy on input is max 1000 points, therefore set the parameters "Upper
limit" and "Lower limit with a max difference of 1000 units.
4 To calibrate the scale of potentiometer enter t e configuration mode and
select:
To modify Set1 or Set2 by external potentiometer follow the steps below:
-
-y
e
-
"
(Ex.: LoS1 to 50,0 and uPS1 to 150,0 to modify time value related to Set1 between
50 and 150 seconds with steps of one tenth). Greater differences would make
unstable the less significant digit.
-h
Hin.3 as Pot
Fin.3 as Set1 or Set2
P.tAr as Enable
Exit configuration mode and place potentiometer at minimum level and press key,
then place potentiometer at max level and press premere key: the device
automatically exit the calibration procedure.
N.B.:Aswitch-off of the device would interrupt the calibration.
Timer operating modes
Activate output at elapsing of counting
Deactivate output at elapsing of counting
T1 and T2 start in sequence
Activate a percentage of output on a fixed time base
T1 and T2 start in sequence and cycling
Memory after switch-off
Disabled
Memory stores only value of Timer
START/STOP statusMemory stores value of Timer and
NPN
PNP
TTL
NPN
PNP
TTL
P-04 Hardware Input 2
Configuration Input 1
NPN
PNP
TTL
NPN
PNP
TTL
Configuration Input 2
Default
Default
Default
Default
SETPOINT CONFIGURATION
OUTPUT CONFIGURATION
DISPLAY CONFIGURATION
P-05 Hardware Input 3
P-06 Active State Input 1
P-07 Active State Input 2
P-08 Active State Input 3
PNP
TTL
Potent.
High Level
Low Level
Rising edge
High Level
Low Level
Rising edge
High Level
Low Level
Rising edge
Configuration input 3
Activate Input 1
Activate Input 2
Activate Input 3
PNP
TTL
Potentiometer
High level
Low level
Rising edge
High level
Low level
Rising edge
High level
Low level
Rising edge
P-09 Function Input 1
P-12 Function Key UP
P-10 Function Input 2
P-11 Function Input 3
P-16 Format Set 1
P-18 Display Set 1
P-17 Format Set 2
P-19 Display Set 2
P-13 Output Q1 Setup
P-14 Output Q2 Setup
P-15 Type of Timer
Disable
Start / Stop
Start / Stop-Reset
Reset-Start / Stop
Reset / Start / Stop
Second.Cent
Second.Decimal
Second
Minute.Second
Hour.Minute
Hour
Second.Cent
Second.Decimal
Second
Minute.Second
Hour.Minute
Hour
Disable
Start / Stop
Start / Stop-Reset
Reset-Start / Stop
Reset / Start / Stop
Reset
Wait
Hold
Disable
Out Timer 1 n.o.
Out Timer 1 n.c.
Out Timer 2 n.o.
Out Timer 2 n.c.
Start
Stop
Disable
Out Timer 1 n.o.
Out Timer 1 n.c.
Out Timer 2 n.o.
Out Timer 2 n.c.
Start
Stop
Incremental
Decremental
Disable
Visualized
Modifiable
Disable
Enable
P-24 Potent. tarature
P-20 Lower limit Set 1
P-21 Upper limit Set 1
P-22 Lower limit Set 2
P-23 Upper limit Set 2
Disable
Reset
Disable
Wait
Hold
Potent. To SET1
Potent. To SET2
Function of Input 1
Function of key
Function Input 2
Function Input 3
Format of counting
Visualization of Set 1
Format of counting
Visualization of Set 2
Setting of output Q1
Setting of output Q2
Counting mode
Disabled
Start / Stop
Start / Stop-Reset
Reset-Start / Stop
Reset / Start / Stop
Seconds, Hundredths
Seconds, Tenths
Seconds
Minutes, Seconds
Hours, Minutes
Hours
Seconds, Hundredths
Seconds, Tenths
Seconds
Minutes, Seconds
Hours, Minutes
Hours
Disabled
Start / Stop
Start / Stop-Reset
Reset-Start / Stop
Reset / Start / Stop
Reset
Wait (stop the counting)
Hold (hold value on display but counting goes on)
Disabled
Output Timer 1 N.O.
Timer 1 N.C.
Timer 2 N.O.
Timer 2 N.C.
Start
Stop
Output
Output
Output
Disabled
Output Timer 1 N.O.
Output Timer 1 N.C.
Output Timer 2 N.O.
Output Timer 2 N.C.
Start
Stop
Incremental
Decremental
Disabled
Visualized
Visualized and modifiable
Disabledd
Enabled
Calibration of potentiometer
Low limit Set 1
Upper limit Set 1
Low limit Set 2
Upper limit Set 2
Reset
Disabled
Wait
Modify SET1 by potentiometer
Modify SET2 by potentiometer
Disabled
(stop the counting)
Hold (Hold value on display but counting goes on)
Default
Default
Default
Default
Default
Default
Default
Default
Default
Default
Default
Default
Default
Default
0.0
0.0
99.9
99.9
Default
PRESS
for 3 seconds
Display 1shows
and 1st digit flashes,
Display 2 shows
EFFECT OPERATION
Or
Modify the flashing digit,
press to reach the next digit
Enter password
to confirm The device loads default values
(factory settings)
Switch-off and restart
the device
1
2
3
Scroll the parameters
4Or
Increade or decrease value on display
by pressing and one of the arrow keys
at same time
Enter new data
which will be stored
releasing the keys
5+Or
End of configuration,
the device exits programming mode.
6
MODIFY PARAMETERS
LOADING DEFAULT SETTINGSLOADING DEFAULT SETTINGS
PRESS
Display SETPOINT 1 / 2
EFFECT
OR
Modify selected SETPOINT
Select the chosen digit
1
2
2a
Modify the flashing digit of the selected setpoint
3a O
MODIFY SETPOINTMODIFY SETPOINT
Proximity
sensor PNP
3 wires
Proximity
sensor PNP
2 wires
+-
OUT
OUT
PNP NPN
PNP
NPN
Read carefully the safety guidelines and programming instructions
contained in this manual before using/connecting the device.
Disconnect power supply before proceeding to hardware settings or
electrical wirings.
Only qualified personnel should be allowed to use the device and/or
service it and in accordance to technical data and environmental
conditions listed in this manual.
Do not dispose electric tools together with household waste materials in
observance of European Directive 2002/96/CE
Operating
temperature
Sealing
Material
Digital
Inputs
Outputs
OUT 24V
Back-UP
Programming
Software
Power Supply
Operating temperature 0-40°C, humidity 35..95uR%
PC ABS UL94V0 self-extinguishing
3PNP/NPN configurable as analogue for potentiometers.
(max 28 Vdc in PNP mode)
2 relays 5A resistive charge
30mA(24Vac),40mA(24 Vdc),60mA (110...230Vac)
Rechargeable battery, approx. 7days autonomy
Labsoftview 2.6 or later
24...230Vac/Vdc +/-15% 50/60Hz / 2W
Front panel IP65 (with optional gasket) ,
Box IP30, Terminal blocks IP20
.
