Wacom INTUOS 4 User manual

General specifications for all Intuos4 tablets
Resolution 5,080 lpi
Pressure levels 2,048
Accuracy (pen) +/- 0.25 mm (0.010 in)
Accuracy (lens cursor) +/- 0.15 mm (0.006 in)
Tilt range (all pens) +/- 60 degrees
(+/- 50 degrees on Intuos4 S tablets)
Reading height 10 mm (0.39 in)
Maximum report rate 200 points per second
Interface USB 1.1 to USB mini-B
(Intuos4 S, M and L tablet models)
USB 1.1 (Intuos4 XL)
Bluetooth 2.1 + EDR (Intuos4 Wireless)
Cable length 2.5 m (8.2 ft), detachable on S, M, Wireless
and L tablet models
Power requirements DC 5V, less than 300 mA, from primary USB
port or powered USB hub
Certification FCC class B, CE, VCCI Class B, BSMI,
and compliance C-Tick, MIC, GOST-R, RoHS EU, Chinese
RoHS, Industry Canada Class B
Intuos4.
The pen tablet generation for photo-
graphers, illustrators, 3D-designers
and fine artists who want to release
their full creative potential.
Discover why it sets new
benchmarks for the whole pen
tablet category:
• Natural: New Wacom Tip Sensor
with 2,048 levels of pressure
sensitivity
• Flexible: Ambidextrous design
• Comfortable: User-defined Touch
Ring with toggle functionality
• Individual: 8 customisable
ExpressKeys™ including
OLED-displays on M, Wireless, L
and XL tablet models
• Intuos4 Wireless: Easy
connection to any Bluetooth
enabled computer while moving
freely up to 33 ft (approx. 10 m)
• Well-equipped: Grip Pen with
pen stand, colour identification
rings, thick-bodied replacement
grip, 5 standard nibs, 1 stroke nib,
1 flex nib, 3 felt nibs
• New radial menus for fast access
to shortcuts
• Consistent: New surface
structure and design for easy
strokes
• Reliable: 2 years warranty
• State of the art: Supports
Microsoft® Windows® 7, Windows®
XP™(+SP2) and Windows® Vista |
Mac OS X 10.4.8 or higher
Killer instinct.
And where it comes to life.
Character designer: Matt Cioffi

Intuos4 S tablet
157.5 x 98.4 mm (6.2 x 3.9 in)
309.0 x 208.0 x 12.0 mm
(12.2 x 8.2 x 0.5 in)
approximately
800 g (1.76 lb) approximately
1
6
no ExpressKey™ displays
PTK-440-EN/4 949268 614382
Intuos4 M tablet
223.5 x 139.7 mm (8.8 x 5.5 in)
370.0 x 254.0 x 12.0 mm
(14.5 x 10.0 x 0.5 in)
approximately
1.0 kg (2.2 lb) approximately
1
8
8, next to ExpressKeys™
PTK-640-EN/4 949268 614467
Intuos4 Wireless tablet
203.2 x 127.0 mm (8.0 x 5.0 in)
363.0 x 253.0 x 15.0 mm
(14.3 x 10.0 x 0.6 in)
approximately
900 g (2.0 lb) approximately
(with battery)
1
8
8, next to ExpressKeys™
PTK-540WL-EN/4 949268 615402
Intuos4 L tablet
325.1 x 203.2 mm (12.8 x 8.0 in)
474.0 x 320.0 x 14.0 mm
(18.6 x 12.6 x 0.5 in)
approximately
1.8 kg (3.96 lb) approximately
1
8
8, next to ExpressKeys™
PTK-840-EN/4 949268 614542
Intuos4 XL tablet
462.0 x 304.8 mm (19.2 x 12.0 in)
623.0 x 462.0 x 28.0 mm
(24.5 x 18.2 x 1.1 in)
approximately
3.0 kg (6.60 lb) approximately
1
8
8, next to ExpressKeys™
PTK-1240-D/4949268 614368
(DTP model) & PTK-1240-C/
4949268 614320 (CAD model)
Available as DTP or CAD model.
Active area (W x D)
Physical size (W x D x H)
Weight
Touch Ring
ExpressKeys™
ExpressKey™ displays
Product Code / EAN Code
Wacom Europe GmbH • Europark Fichtenhain A9 • 47807 Krefeld • Germany • www.wacom.eu
© 2010 Wacom Company, Limited. All rights reserved. Wacom, the logo and Intuos are trademarks or registered trademarks of the Wacom Company, Ltd. All other company names and product
names are trademarks and/or registered trademarks of their respective owners. Modifications and errors excepted.
BRO-I4DCC-EN
Intuos4 Airbrush
(optional accessory)
162.5 x 17.5 x 32.5 mm
(L x W x D)
(6.40 x 0.69 x 1.28 in)
23 g (0.81 oz)
approximately
1 standard nib,
1 stroke nib,
1 flex nib,
1 felt nib.
fingerwheel
approx. 1,024 levels
of resolution
KP-400E
4949268790512
Intuos4 Inking Pen
(optional accessory)
151.5 x 12.5 mm (L x D)
(5.97 x 0.49 in)
12 g (0.42 oz)
approximately
2 standard nibs,
3 inking cartridges.
-
KP-130
4949268790536
Intuos4 Art Pen
(optional accessory)
156.2 x 15.5 x 15.8 mm
(L x W x D)
(6.15 x 0.61 x 0.62 in)
20 g (0.7 oz)
approximately
2 chisel-shaped
standard nibs,
2 chisel-shaped
felt nibs, 3 standard art
nibs, 3 felt art nibs.
360 degrees
of barrel rotation
KP-701E
4949268790529
Intuos4 Classic Pen
(optional accessory)
150.7 x 12.2 mm (L x D)
(5.94 x 0.48 in)
12 g (0.42 oz)
approximately
1 standard nib,
1 stroke nib,
1 flex nib,
1 felt nib.
-
KP-300E
4949268790505
Intuos4 Lens Cursor
(optional accessory)
159.0 x 66.0 x 33.8 mm
(L x D x H)
(6.26 x 2.60 x 1.33 in)
75 g (2.65 oz)
approximately
Supplied as standard
with Intuos4 XL CAD
model.
-
KC-210
4949268790482
Physical size
Weight
Includes
Additional feature
Product Code /
EAN Code
Intuos4 Grip Pen
156.5 x 14.9 mm (L x D)
(6.17 x 0.59 in)
18 g (0.63 oz)
approximately
thick-bodied
replacement grip, box
content S, M, Wireless,
L, XL (DTP version):
5 standard nibs,
1 stroke nib, 1 flex nib,
3 felt nibs; box content as
accessory: 1 standard
nib, 1 stroke nib, 1 flex
nib, 1 felt nib.
-
KP-501E
4949268790499
Intuos4 Mouse
(optional accessory)
102.9 x 61.8 x 38.6 mm
(L x D x H)
(4.05 x 2.43 x 1.52 in)
83 g (2.9 oz)
approximately
-
5 mouse buttons
and 1 finger wheel
KC-100
4949268790475
