Waggz WZ-230N User manual

01
Version A Version B
The image shown here is indicative only. If there is inconsistency between the image and the actual product, the actual product shall govern.
WZ-230N / WZ-230NL
User Manual
Built to impress and ready to work – equipment by and for pet groomers
Waggz Roll-Lift
Solid Tub with Roll-Out Stairs
WZ-230N
Waggz XL Roll-Lift
XL Solid Tub with Roll-Out Stairs
WZ-230NL
1.TECHNICAL SPECS
WZ-230N
Basin Size 50 x 28.75 in 、127 x 73 cm
Height
(Floor to Bottom of Basin) 37.5 in 、95.2 cm
Rolling Mechanism Hair-proof casters and
medical-grade foot brake
Max Weight Capacity 265 lb 、120 kg
Door Width 16 inches 、40.6 cm
Frame Material Polished stainless steel
Product Net Weight 176 lb 、80 kg
(3-person lift)
Door Style Lift out
WZ-230NL
Basin Size 60 x 28.75 in 、152.4 x 73 cm
Height
(Floor to Bottom of Basin) 37.5 in 、95.2 cm
Rolling Mechanism Hair-proof casters and
medical-grade foot brake
Max Weight Capacity 265 lb 、120 kg
Door Width 20 inches 、50.8 cm
Frame Material Polished stainless steel
Product Net Weight 220 lb 、100 kg
(4-person lift)
Door Style Lift out

02
2.CONTACT INFORMATION
Thank you for your purchase! This quick-start guide will help you get the most out of your new Waggz grooming tub.
If you have any questions, need replacement parts, or want to purchase additional products, just get in touch!
Visit 910 Canal Pl, City of Industry, CA 91746
Call 626-549-1212
Email [email protected]
Follow @waggzgrooming
3.GENERAL GUIDANCE
UPON ARRIVAL
Please carefully examine your grooming tub and review the packing list. If you notice any missing parts or damaged components,
notify Waggz immediately.
Do not attempt to disassemble the table before contacting Waggz.
CLEANING, CARE, AND MAINTENANCE
Waggz grooming tubs are built to impress and ready to work. Regular cleaning and routine maintenance will keep it that way!
Follow these steps to extend the life of your tub and protect your Waggz 2-year warranty:
WORKING CONDITIONS
Temperature: avoid extreme cold (<40°F) and extreme heat (>104°F)
Humidity: avoid extreme dryness (<20%) and extreme humidity (>90%)
DAILY CLEANING
Remove hair and dander from the tub, then wipe clean with a mild detergent. Please avoid using anti-grease detergents and
citrus-based cleansers, which may damage the finish on your tub. Stains should be promptly treated with 1 part ethyl alcohol to 20
parts water, then rinse well. Dry all surfaces between uses.
QUARTERLY INSPECTION
• Complete a visual inspection of all equipment and accessories
• Check the tightness and state of wear on all screws, bolts, bushings, and pins
• Check that wheels are attached securely and roll smoothly with clean treads
• Check the stability and installation of all adjustable components
• Check that the foot lock correctly activates the brake and works efficiently
NON-ROUTINE MAINTENANCE
• For safety reasons and to avoid invalidating the warranty, Waggz alone must diagnose and organize action for any faults relating
to the roll-out stair casters and brake.
• Maintenance technicians must be familiar with the contents of this instruction booklet and may only use original Waggz parts and
components.
• Always complete a full safety inspection of the tub after rough handling, falls, drops, or bumps.
WARNING
• IF YOU EVER HAVE SAFETY CONCERNS ABOUT THE CONDITION OF COMPONENTS, IMMEDIATELY DISABLE THE EQUIPMENT TO
PREVENT USE UNTIL SAFETY RISKS HAVE BEEN REMOVED OR RESOLVED.
• IMMEDIATELY RECORD AND REPORT ANY DEFECTS OR DAMAGES DIRECTLY TO THE MANUFACTURER.

3.PACKING LIST
4.ASSEMBLY INSTRUCTIONS
Grooming tub with
3 folding splash guards
and lift-out door
X1 set
X1
56-inch
shower hose
X1 set
Adjustable
shower head
X1 set
Metal storage
shelves
X2 sets
Left floor
basin cover
X1 set
03
A
C
X1
B
D
Stair with 2 wheels
and locking foot brake
X1 set
C
Rack base
X1 set
B E
H I
STEP 1
Right floor
basin cover
X1 set
F
Thermostatic
shower faucet
X1 set
G
Shower head
holder and screws
59-inch water hoses、
4/6 tap connectors
X1 set
J
X2 sets
K
62-inch
drainpipe
X1 set
L
Overflow pipe
X1 set
M
3-part hair
filter and drain
X1 set
N
Grooming
loop hooks
X3 sets
O
Press down to lock brake
will not move
DOWN
Lift to release brake
ready to roll
UP
X1
A
STEP 2
#1 #2
STEP 3
#1

5.TABLE DIMENSIONS
04
STEP 4
50"(127cm) / 60"(152.4cm)
20"(50.8cm)
25.75"(73cm)
20"
(50.8cm)
17.5"
(44.4cm)
19.5"(49.5cm)
15.55"(39.5cm)
25.2"(64cm)
37.5"(95.2cm)
#1
#1 #2
#2
X2
D
STEP 5
X1
F
X1
E
X1
G
X1
H
X1
I
X1
J
X1
K
X1
L
X1
M
X1
N
X3
O
#1 #3 #4
#2
#1 #2
E
F
Optional Usage Modes for Standing Racks
57.5"(146cm)
50"(127cm) / 60"(152.4cm)
20"(50.8cm)
25.75"(73cm)
20"
(50.8cm)
17.5"
(44.4cm)
19.5"(49.5cm)
21.5"(54.5cm)
25.2"(64cm)
37.5"(95.2cm)
57.5"(146cm)
E
F
E
F
#2
150cm
150cm
#1
1. The standard hot and cold water hoses in this
kit are 59 inches long. If your water lines are
more than 59 inches away, we recommend
purchasing an extended water pipe adapter.
2. Please match the hot and cold water lines
and hoses with the matching faucet inlets, as
marked in the diagram.
4. Floor basin covers can also be used as puppy
boosters, when elevated on the inner rail.
Hot waterCold water
Caution：
Safety Tips:
• 1. Check space between the splash guards and ceiling before installation and assembly.
• 2. Adjust and stabilize feet for even balance before loading animals into the tub.
** NEVER LEAVE ANIMALS ON UNATTENDED. ALWAYS MONITOR FOR SAFETY **
WZ-230N WZ-230NL
