WAGNER EPG-SPRINT User manual

0102 II 3(2)D IP64 80°C
P_01110
%
Tribo Corona
5
4
3
2
1
120
100
80
60
40
30
20
15
10
5
μA
μA
0
10
20
30
40
50
60
70
80
90
100
Ø
12
10
11
9
8
m /h
5.0
4.0
3.0
2.0
6.0
3
5.5
4.5
3.5
2.5
2.2
2x
kV
90
80
70
60
50
40
30
20
10
100
m /h
4.0
3.0
2.0
1.0
0.5
0.4
0.3
0.2
0.1
1.5
EPG
SP
R
I
NT
P_01742
EPG
SPRINT X
2x
2x
0
%
100
%
kV
80
60
40
20
100
Tri Cor
5
4
3
2
1
120
80
40
20
10
10
20
30
40
50
60
70
80
90
Ø
12
10
11
9
8
m/h
2.0
3.0
0.5
0.3
0.1
1.5
3
5.5
4.5
3.5
2.5
Tri
μA
Universal Control Unit for
Powder Coating Guns
EPG-SPRINT
EPG-SPRINT X
EPG-SPRINT XE
Version 09/2017
Original Service Manual

3
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
Table of Contents
1 GENERAL INFORMATION 6
1.1 Preface 6
1.2 Warnings, Notices and Symbols in these Instructions 6
1.3 Languages 7
1.4 Abbreviations 7
2 CORRECT USE 8
2.1 Device Type 8
2.2 Type of Use 8
2.3 Use in an Explosion Hazard Area 8
2.4 Safety Parameters 9
2.5 Reasonably Foreseeable Misuse 9
2.6 Residual Risks 10
3 IDENTIFICATION 11
3.1 Explosion Protection Identication in Accordance with ATEX 11
3.2 Permissible Device Combinations 11
4 GENERAL SAFETY INSTRUCTIONS 12
4.1 Safety Instructions for the Operator 12
4.1.1 Electrical Devices and Equipment 12
4.1.2 Personnel Qualications 12
4.1.3 Safe Work Environment 12
4.2 Safety Instructions for Sta 13
4.2.1 Safe Handling of WAGNER Powder Spray Devices 13
4.2.2 Grounding the Device 13
4.2.3 Product Hoses 13
4.2.4 Cleaning 14
4.2.5 Handling Powder Lacquers 14
4.3 Protective and Monitoring Equipment 15
4.4 Safety Feature Identication 16
5 DESCRIPTION 17
5.1 Fields of Application, Correct Use 17
5.2 Technical Data 18
5.2.1 EPG-SPRINT 18
5.2.2 EPG-SPRINT X 19
5.2.3 EPG-SPRINT XE 20
5.3 Permitted Accessories 22
5.4 Scope of Delivery 22
5.4.1 Scope of Delivery of EPG-SPRINT 22
5.4.2 Scope of Delivery of EPG-SPRINT X 22
5.4.3 Scope of Delivery of EPG-SPRINT XE 22
5.5 Operating Elements of EPG-SPRINT 23
5.5.1 Overview of Control Panel Front Side 23
5.5.2 Connections on the Rear Side of the EPG-SPRINT 28
5.6 Operating Elements of EPG-SPRINT X/EPG-SPRINT XE 30
5.6.1 Overview of Control Panel Front Side 30
5.6.2 Connections on the Rear Side of the EPG-SPRINT X 35
5.6.3 Connections on the Rear Side of the EPG-SPRINT XE 37

4
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
Table of Contents
6 SPARE PARTS 39
6.1 How Can Spare Parts Be Ordered? 39
6.2 EPG-SPRINT Control Unit 40
6.3 EPG-SPRINT X Control Unit 43
6.4 EPG-SPRINT XE Control Unit 46
6.5 Resources and Special Tools 49
6.6 Handling the Release Tool for the Air Diuser 50
7 REPAIR WORK 51
7.1 Personnel Qualications 51
7.2 Safety Instructions 51
7.3 Replacing a Proportional Valve 53
7.4 Replacing the Incremental Encoder 55
7.5 Replacing the Display Print 56
8 PARAMETERS FOR SERVICE PURPOSES 57
8.1 Test Parameters 58
8.2 Calibration Parameters 58
8.3 Accessing the Service Level (C31-C34) 59
8.4 Accessing and Adjusting Parameter Value 60
9 SERVICE LEVEL 61
9.1 Parameter C31, Checking Air Outlets 61
9.2 Parameter C34, I/O Test (Input and Output) 64
10 PLANT LEVEL 68
10.1 Plant Level Parameters 68
10.2 Accessing the Plant Level Parameters 69
10.3 Parameter C41, Measuring and Calibrating Operating Pressure 70
10.4 Parameter C42, Calibrating Air Outlets 71
10.5 Parameter C43, Master Reset 74
10.6 Parameter C44, High-voltage Calibration 75
10.7 Parameter C45, Default Setting of Oset for Air Channels 78
11 MEASURING EQUIPMENT 81
11.1 Air Flow Measuring Device 81
11.2 Air Pressure Measuring Device 81
11.3 High-voltage Measuring Device 82
11.4 Voltmeter 82
12 EXTENDED INTERFACE FOR REMOTE CONTROL 83
12.1 Manual Gun Mode 83
12.2 Automatic Gun Mode 83
12.3 Manual Gun with External Control 84
12.4 Recipe Selection Input 84
12.4.1 Selection Via Pulse Length 84
12.4.2 Selection with Transfer Protocol 85
13 BLOCK DIAGRAMS 88
14 FURTHER ERROR MESSAGES 90
15 SOFTWARE UPDATE 93

5
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
16 SOFTWARE HISTORY 97
16.1 EPG-SPRINT 97
16.2 EPG-SPRINT X 98
16.3 EPG-SPRINT XE 98
17 WARRANTY AND CONFORMITY DECLARATIONS 99
17.1 Important Notes Regarding Product Liability 99
17.2 Warranty Claim 99
17.3 CE Declaration of Conformity EPG-SPRINT 100
17.4 EC Type Examination Certicate EPG-SPRINT 101
17.5 CE Declaration of Conformity EPG-SPRINT X/EPG-SPRINT XE 103
17.6 EC Type Examination Certicate EPG-SPRINT X/EPG-SPRINT XE 104
17.7 FM Identication EPG-SPRINT/EPG-SPRINT X/EPG-SPRINT XE 105
Table of Contents

6
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
1 GENERAL INFORMATION
This service manual contains information and instructions for the operation, repair, service
and maintenance of the control units.
This equipment can be hazardous if it is not operated in accordance with the information
provided in this service manual and the corresponding operating manual.
1.1 PREFACE
1.2 WARNINGS, NOTICES AND SYMBOLS IN THESE INSTRUCTIONS
Warning instructions in this operating manual highlight particular dangers to users and to
the device and state measures for avoiding the hazard. These warning instructions fall into
the following categories:
Danger - immediate risk of danger.
Non-observance will result in death or serious injury.
Warning - possible imminent danger.
Non-observance may result in death or serious injury.
Caution - a possibly hazardous situation.
Non-observance may result in minor injury.
Note - provides information about particular characteristics and how to proceed.
Notice - a possibly hazardous situation.
Non-observance may result in damage to property.
This notice warns you of a hazard!
Possible consequences of not observing the warning instructions.
The signal word indicates the hazard level.
The measures for preventing the hazard and its consequences.
DANGER
This notice warns you of a hazard!
Possible consequences of not observing the warning instructions.
The signal word indicates the hazard level.
The measures for preventing the hazard and its consequences.
WARNING
This notice warns you of a hazard!
Possible consequences of not observing the warning instructions.
The signal word indicates the hazard level.
The measures for preventing the hazard and its consequences.
CAUTION
This notice warns you of a hazard!
Possible consequences of not observing the warning instructions. The signal word
indicates the hazard level.
The measures for preventing the hazard and its consequences.
NOTICE

7
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
1.3 LANGUAGES
The service manual is available in the following languages:
German 2309349 English 2309350
1.4 ABBREVIATIONS
Number of pieces
Position
Marking in the spare parts lists
Order No. Order number
Spare part
Wrench size
EPG-SPRINT:
The operating manual is available in the following languages:
German 2305220 English 2305222
French 2305224 Italian 2305225
Spanish 2305226 Russian 2321631
EPG-SPRINT X:
The operating manual is available in the following languages:
German 2327591 English 2329371
French 2330847 Italian 2330848
Spanish 2330849 Russian 2333349
Chinese 2333350
EPG-SPRINT XE:
The operating manual is available in the following languages:
German 2354911 English 2354913
French 2354914 Italian 2354915
Spanish 2354916 Russian 2354917
Chinese 2354918

8
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
2 CORRECT USE
2.1 DEVICE TYPE
Universal control unit for controlling electrostatic manual and automatic spray guns
2.2 TYPE OF USE
The EPG-SPRINT/EPG-SPRINT X/EPG-SPRINT XE control unit is intended for controlling
electrostatic manual and automatic powder spray guns of type A-P (2 mJ) according to
DIN EN 50050-2 and DIN EN 50177.
Incorrect use!
Risk of injury and damage to the device.
Only connect original WAGNER spray guns to the EPG-SPRINT/
EPG-SPRINT X/EPG-SPRINT XE control unit.
The PEM-C3R and PEM-T3R manual spray guns may not be
connected to the EPG-SPRINT/EPG-SPRINT X/EPG-SPRINT XE
control unit.
WARNING
2.3 USE IN AN EXPLOSION HAZARD AREA
The EPG-SPRINT/EPG-SPRINT X/EPG-SPRINT XE control unit is intended for use with powder
spray guns of types A-P up to 2 mJ in accordance with the prototype test PTB 06 ATEX 03/
PTB 12 ATEX 5001.
The EPG-SPRINT/EPG-SPRINT X/EPG-SPRINT XE control unit may be used in the dust
explosion zone (Zone 22) under the following conditions:
– Control unit correctly tted in rack.
– Rack correctly and securely sealed on rear with associated cover.
– All plug connections are securely locked.
– All connections not needed (mains output, remote control) are sealed with dust
protection caps.

9
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
2.5 REASONABLY FORESEEABLE MISUSE
– Coating work pieces which are not grounded
– Use of defective components and accessories
– Use with not permissible powder coating guns
2.4 SAFETY PARAMETERS
WAGNER accepts no liability for any damage arising from incorrect use.
Electrostatic spray equipment may only be operated in an intact condition, damaged
devices must be decommissioned immediately and repaired.
Use the device only to work with the products recommended by WAGNER.
Only operate the device as a whole.
Do not deactivate safety xtures.
Spare parts and accessories may have safety-relevant properties.
Use only WAGNER original spare parts and accessories.
The use of the control unit is only permissible under the following conditions:
the operating sta have previously been trained on the basis of this operating manual,
the safety regulations listed in this service manual are observed,
the operating, maintenance and repair information in this service manual is observed,
and the statutory requirements and accident prevention regulations standards in the
country of use are observed.

10
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
2.6 RESIDUAL RISKS
Residual risks are risks which cannot be ruled out even in the event of correct use.
If necessary, warning and prohibition signs at the relevant points of risk indicate residual
risks.
Residual risk Source Consequences Specic measures Lifecycle
phase
Skin contact with
powder lacquers
and cleaning
agents
Handling powder
lacquers and
cleaning agents
Skin irritation, allergies Wear protective
clothing
Operation,
Observe safety data
sheets
maintenance,
disassembly
Powder lacquer
in air outside the
dened working
area
Lacquering
outside the
dened working
area
Inhalation of substances
which are hazardous to
health
Observe work
and operation
instructions
Operation,
maintenance

11
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
3 IDENTIFICATION
3.1 EXPLOSION PROTECTION IDENTIFICATION IN ACCORDANCE WITH ATEX
The device is suited for use in potentially explosive areas, in accordance withTest Certicate
PTB 06 ATEX 5003 (EPG-SPRINT) or PTB 12 ATEX 5001 (EPG-SPRINT X/EPG-SPRINT XE).
0102 II 3(2)D IP 64 80 °C
CE: European Communities
0102: Number of notied body which issues the recognition of quality assurance in
production.
Ex: Symbol for explosion protection
II: Device class II
3: Category 3 (Zone 22)
(2): Impact on equipment of category 2
D: Ex-atmosphere dust
IP64: Protection class 64
80 °C: Temperature class: maximum surface temperature < 80 °C; 176 °F
3.2 PERMISSIBLE DEVICE COMBINATIONS
The following powder spray guns may be connected to the EPG-SPRINT/EPG-SPRINT X/
EPG-SPRINT XE:
Manual spray guns
– Corona spray gun PEM-X1, PEM-X1 CG, PEM-C3, PEM-C4,
PEM-C4-Ergo
– Tribo spray gun PEM-T3
Automatic spray guns
– Corona spray gun PEA-C3, PEA-C4
– Corona spray gun PEA-C3XL, PEA-C4XL
– Tribo spray gun PEA-T3
– Tribo spray gun PEA-T3XL
Only EPG-SPRINT X/EPG-SPRINT XE (starting from software version 212)
– Tribo lance TL1
Older or other gun types may only be connected to the control unit after rst checking
their suitability with WAGNER.
Permissible device combinations for the USA and Canada, see Chapter 17.7 "FM Approval".

12
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
4 GENERAL SAFETY INSTRUCTIONS
4.1 SAFETY INSTRUCTIONS FOR THE OPERATOR
4.1.1 ELECTRICAL DEVICES AND EQUIPMENT
4.1.2 PERSONNEL QUALIFICATIONS
4.1.3 SAFE WORK ENVIRONMENT
Keep this operating manual at hand near the device at all times.
Always follow local regulations concerning occupational safety and accident prevention.
To be provided in accordance with the local safety requirements with regard to the
operating mode and ambient inuences.
May only be maintained by skilled electricians.
Must be operated in accordance with the safety regulations and electrotechnical
regulations.
Must be repaired immediately in the event of problems.
Must be decommissioned if they pose a hazard.
Must be de-energized before work is commenced on active parts.
Secure the device against being switched back on without authorization. Inform sta
about planned work.
Observe electrical safety regulations.
Ensure that the device is operated, maintained and repaired only by trained persons.
The oor in the working area must be electrostatically conductive (measurements
according to EN 1081 and EN 61340-4-1).
The footwear worn by the operators must comply with the requirements of EN ISO 20344.
The measured insulation resistance must not exceed 100 megohms.
The protective clothing, including gloves, must comply with the requirements of
EN ISO 1149-5. The measured insulation resistance must not exceed 100 megohms.
The powder release must be electrically interlocked with the powder spray system's
exhaust air equipment.
Excess coating product (overspray) must be collected up safely.
Ensure that there are no ignition sources such as naked ames, sparks, glowing wires,
or hot surfaces in the vicinity. No smoking.
Maintain sucient quantities of suitable re extinguishers and ensure that they are
serviceable.
The operating company must ensure that an average concentration of powder lacquer
in the air does not exceed 50% of the lower explosion limit (LEL = max. permitted
concentration of powder to air). If no reliable LEL value is available, the average
concentration must not exceed 10 g/m³.

13
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
4.2.1 SAFE HANDLING OF WAGNER POWDER SPRAY DEVICES
4.2.2 GROUNDING THE DEVICE
4.2.3 PRODUCT HOSES
4.2 SAFETY INSTRUCTIONS FOR STAFF
Use only an original WAGNER powder hose.
Make sure that the hoses are laid only in suitable places. Hoses should not be laid in the
following places under any circumstances:
– in high-traffic areas,
– on sharp edges,
– on moving parts or
– on hot surfaces.
Ensure that the hoses are never run over by vehicles (e.g., fork lifts), or that the hoses are
never put under pressure from the outside in any other way.
Ensure that the hoses are never kinked. Observe maximum bending radii.
The electrostatic charge may, in certain cases, give rise to electrostatic charges on the
device. This may result in the formation of sparks or ames when discharging.
Ensure that the device is grounded before each coating process.
Ground the work pieces to be coated.
Ensure that all persons inside the working area are grounded, e.g., by wearing
electrostatically conductive shoes.
The functionality of grounding cables must be checked regularly (see EN 60204).
Do not point spray guns at people.
Before all work on the device, in the event of work interruptions and functional faults:
– Switch o the energy/compressed air supply.
– Secure the spray gun against actuation.
– Relieve pressure on spray gun and device.
– In case of functional faults: Identify and correct the problem, proceed as described
in the "Fault Rectication" chapter.
Always follow the information in this manual, particularly the general safety instructions
and the warning instructions.
Always follow local regulations concerning occupational safety and accident prevention.
Under no circumstances may people with pacemakers enter the area where the high-
voltage eld between the spray gun and the work piece to be coated builds up!

14
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
4.2.4 CLEANING
Before starting cleaning or any other manual work, the high voltage in the spray area
must be shut down and locked to prevent it from being switched back on.
Lock the compressed air supply and decompress the device.
Secure the device against being switched back on without authorization.
Use only electrically conducting and grounded tanks for cleaning uids.
Preference should be given to non-ammable cleaning uids.
Flammable cleaning liquids may only be used if, after switching o the high voltage, all
high-voltage conducting parts are discharged to a discharge energy of less than 0.24 mJ
before they can be accessed.
Most ammable solvents have an ignition energy of around 0.24 mJ or 60 nC.
The cleaning agent's ash point must be at least 15 K above the ambient temperature.
Only mobile industrial vacuum cleaners of design 1 (see EN 60335-2) may be used to
remove dust deposits.
4.2.5 HANDLING POWDER LACQUERS
When preparing or processing the powder and cleaning the device, take note of the
processing regulations laid down by the manufacturer of the powder lacquers being
used.
Take note of the manufacturer’s instructions and the relevant environmental protection
regulations when disposing of powder lacquers.
Implement the prescribed safety measures, in particular the wearing of safety glasses
and safety clothing as well as the use of protective hand cream.
Use a mask or breathing apparatus if necessary.
To ensure sucient protection of health and the environment, only operate the device
in a powder booth or on a spray wall with activated ventilation (exhaust air).

15
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
4.3 PROTECTIVE AND MONITORING EQUIPMENT
Protective and monitoring equipment!
Risk of injury and damage to the device.
Protective and monitoring equipment must not be removed,
modied or rendered unusable.
Regularly check for perfect functioning.
If defects are detected on protective and monitoring equipment,
the system must not be operated until these defects are remedied.
WARNING

16
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
4.4 SAFETY FEATURE IDENTIFICATION
Plates bearing information for the user have been attached to the work openings of the powder
coating booth.
The plate size corresponds to the standard category 100 mm; 3.94 inches.
The label plates, which must be attached, are shown below:
High voltage!
In the control cabinet:
(25 mm; 0.98 inch)
Voltage before main switch
Forbidden for unauthorized
persons!
Explosive atmosphere!
Forbidden for persons
with a cardiac pacemaker!
Follow the instructions in the
operating manual!
Smoking, re, and open
ames are prohibited!
Wear electrostatically
conductive footwear!
Danger of crushing!
Risk of tripping!
Do not jump on the
booth oor!
Danger of slipping!

17
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
5 DESCRIPTION
5.1 FIELDS OF APPLICATION, CORRECT USE
The EPG-SPRINT/EPG-SPRINT X/EPG-SPRINT XE control unit can be used as a stand-alone
unit in manual coating systems or can be used, together with other units, in a PrimaTech/
ProTech M automatic system.
– When a Corona gun is connected, Corona current scale and the high-voltage supply
and control unit are active.
– When a Tribo gun is connected, the Tribo current scale is activated, while the high-
voltage supply and control unit are deactivated.
The control unit recognizes if a manual or automatic spray gun is connected. If an automatic
gun is connected, the control unit can only be controlled using the higher-level remote
control.
Incorrect use!
Risk of injury and damage to the device.
Only connect original WAGNER spray guns to the EPG-SPRINT/
EPG-SPRINT X/EPG-SPRINT XE control unit.
The PEM-C3R and PEM-T3R manual spray guns may not be
connected to the EPG-SPRINT/EPG-SPRINT X/EPG-SPRINT XE
control unit.
WARNING

18
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
5.2 TECHNICAL DATA
Dimensions:
Height 136 mm; 5.35 inches
Width 270 mm; 10.63 inches
Depth (without operating elements) 200 mm; 7.87 inches
Weight 3.3 kg; 7.28 lb
Electrical:
Mains (AC) 85 VAC-250 VAC
Frequency 47 Hz-440 Hz
Input power maximum 40 W
Output voltage maximum 22 Vpp
Output current Max. 0.9A
High voltage 10-100 kV (adjustable in 1 kV steps)
Corona current limitation 5 μA-120 μA (adjustable in 1 μA steps)
Tribo current measuring range 0 μA-15 μA
Tribo current limitation 0 μA-5 μA (adjustable in 0.1 μA steps)
Tribo current cut o greater than 12 μA
(ATEX: switching o of the unit)
Protection class IP 64
Ex zone II 3(2)D 80 °C; 176 °F (Zone 22)
Pneumatic:
Input air pressure 0.6-0.8 MPa; 6-8 bar; 87-116 psi
Air ow maximum 15 m³/h
Sum of dosing and feed air 1-6 m³/h
Gun air 0.05-4.0 m³/h
Required compressed air quality as per ISO8573.1 6.5.2
Connection hose diameter 8 mm; 0.315 inches
Ambient conditions:
Operating temperature range 5-45 °C; 41-113 °F
5.2.1 EPGSPRINT

19
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
Dimensions:
Height 136 mm; 5.35 inches
Width 270 mm; 10.63 inches
Depth (without operating elements) 200 mm; 7.87 inches
Weight 3.3 kg; 7.28 lb
Electrical:
Mains (AC) 90 VAC-250 VAC
Frequency 47 Hz-63 Hz
Input power maximum 40 W
Output voltage maximum 22 Vpp
Output current Max. 0.9A
High voltage 10-100 kV (adjustable in 1 kV steps)
Corona current limitation 5 μA-120 μA (adjustable in 1 μA steps)
Tribo current measuring range 0 μA-15 μA
Tribo current limitation 0 μA-5 μA (adjustable in 0.1 μA steps)
Tribo current cut o greater than 12 μA
(ATEX: switching o of the unit)
Protection class: IP 64
Ex zone II 3(2)D 80 °C; 176 °F (Zone 22)
Pneumatic:
Input air pressure 0.6-0.8 MPa; 6-8 bar; 87-116 psi
Air ow maximum 15 m³/h
Sum of dosing and feed air 1-6 m³/h
Gun air 0.05-4.0 m³/h
Required compressed air quality as per ISO8573.1 6.5.2
Connection hose diameter 8 mm; 0.315 inches
Ambient conditions:
Operating temperature range 5-45 °C; 41-113 °F
5.2.2 EPGSPRINT X

20
EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
Dimensions:
Height 136 mm; 5.35 inches
Width 270 mm; 10.63 inches
Depth (without operating elements) 200 mm; 7.87 inches
Weight 3.3 kg; 7.28 lb
Electrical:
Mains (AC) input terminal 90 VAC-250 VAC
Frequency 47 Hz-63 Hz
Input power maximum 110 W
Mains (AC) output terminal Vibrator motor maximum 70 W
Output voltage spray gun maximum 22 Vpp
Output current spray gun Max. 0.9A
High voltage 10-100 kV (adjustable in 1 kV steps)
Corona current limitation 5 μA-120 μA (adjustable in 1 μA steps)
Tribo current measuring range 0 μA-15 μA
Tribo current limitation 0 μA-5 μA (adjustable in 0.1 μA steps)
Tribo current cut o greater than 12 μA
(ATEX: switching o of the unit)
Ex identication:
according to EN (ATEX, EN) II 3(2)D
according to Class & Division (North America) Class II, Division 2, Group E, F and G
Pneumatic:
Input air pressure 0.6-0.8 MPa; 6-8 bar; 87-116 psi
Air ow maximum 15 m³/h
Sum of dosing and feed air 1-6 m³/h
Gun air 0.05-4.0 m³/h
Required compressed air quality as per
ISO8573.1, 2010
6.5.2
Connection hose diameter 8 mm; 0.315 inches
Ambient conditions:
Operating temperature range 5-40 °C; 41-104 °F
5.2.3 EPGSPRINT XE
