WAGO 852-1112 User manual

Pos:2/Dokumentationallgemein/Einband/EinbandHandbuch- F ro nts ei t e 2015 - mit DocV ari abl e n (Sta nd ar d)@ 9\mod_1285229289866_0.docx@ 64941 @ @ 1
WAGO-ETHERNET-Zubehör 852
Manual
852-1112
8-Port 1000BASE-T-Industrial-Eco-Switch
Mounting, Installation and Handling
Version 1.1.0
FW/HW-
Version 01/01
Pos: 3 / All e Seri e n ( Al lg e m ein e M od ul e) /R ec htl ic h es , A ll ge mei n es /I mpr e ss um für Sta nd ard h an d büc h er - al lg . A ng a be n, Ansc hri ft en, T elef o nn u m mer n und E -Mai l-Adr es s e n @ 3\mod_1219151118203_21.docx@ 21060@ @ 1

2 WAGO-ETHERNET-Zubehör 852
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
© 2016 WAGO Kontakttechnik GmbH & Co. KG
All rights reserved.
WAGO Kontakttechnik GmbH & Co. KG
Hansastraße 27
D-32423 Minden
Phone: [phone] – 0
Fax: [phone] – 1 69
E-Mail: [email protected]om
Web: http://www.wago.com
Technical Support
Phone: [phone] – 5 55
Fax: [phone] – 85 55
E-Mail: [email protected]om
Every conceivable measure has been taken to ensure the accuracy and
completeness of this documentation. However, as errors can never be fully
excluded, we always appreciate any information or suggestions for improving the
documentation.
E-Mail: [e-mail]
We wish to point out that the software and hardware terms as well as the
trademarks of companies used and/or mentioned in the present manual are
generally protected by trademark or patent.
=== Ende d er Lis t e f ür Te xt mar ke Ei nb and _ vor n e = = =

WAGO-ETHERNET-Zubehör 852 Table of Contents 3
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
Pos: 5 /D o ku ment ati on allg e mei n /Ver zei c hni ss e/I nh alt s verz ei ch nis - Ü b er schr if t oG und Ver zei ch nis @ 3\mod_1219151230875_21.docx@21063 @ @ 1
Table of Contents
1Notes about this Documentation................................................................. 5
1.1 Validity of this Documentation................................................................. 5
1.2 Copyright................................................................................................... 5
1.3 Symbols..................................................................................................... 6
1.4 Number Notation....................................................................................... 8
1.5 Font Conventions ...................................................................................... 8
2Important Notes ........................................................................................... 9
2.1 Legal Bases ............................................................................................... 9
2.1.1 Subject to Changes ............................................................................... 9
2.1.2 Personnel Qualification ........................................................................ 9
2.1.3 Proper Use of the Industrial Switches .................................................. 9
2.1.4 Technical Condition of Specified Devices ........................................... 9
2.1.5 Standards and Regulations for Operating the Industrial Switches ..... 10
2.2 Safety Advice (Precautions).................................................................... 11
2.3 Special Use Conditions for ETHERNET Devices .................................. 13
3General........................................................................................................ 14
3.1 Package Contents .................................................................................... 14
3.2 Industrial ETHERNET Technology........................................................ 14
3.3 Switching Technology ............................................................................ 14
3.4 Auto Negotiation..................................................................................... 14
3.5 Autocrossing ........................................................................................... 14
3.6 Switching, Filtering................................................................................. 15
3.7 Store-and-forward switching mode......................................................... 15
3.8 Line Depth in PROFINET ...................................................................... 15
3.9 Port Speed & Duplex Mode .................................................................... 15
4Device Description ..................................................................................... 16
4.1 View ........................................................................................................ 17
4.1.1 Front View.......................................................................................... 17
4.1.2 Top View ............................................................................................ 18
4.2 Connectors............................................................................................... 19
4.2.1 Power Supply (PWR/RPS)................................................................. 19
4.2.2 Network Connections ......................................................................... 20
4.2.2.1 10/100/1000Base-T........................................................................ 20
4.3 Display Elements .................................................................................... 21
4.3.1 Device LED ........................................................................................ 21
4.3.2 Port LEDs ........................................................................................... 22
4.4 Label........................................................................................................ 23
4.4.1 Hardware and Software Version ........................................................ 23
4.5 Technical Data ........................................................................................ 24
4.5.1 Device Data ........................................................................................ 24
4.5.2 Power Supply...................................................................................... 24
4.5.3 Communication .................................................................................. 24
4.5.4 Environmental Conditions.................................................................. 24
4.6 Approvals ................................................................................................ 25
5Mounting..................................................................................................... 26

4 Table of Contents WAGO-ETHERNET-Zubehör 852
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
5.1 Installation site ........................................................................................ 26
5.2 Installation on a Carrier Rail................................................................... 26
5.3 Removal from Carrier Rail...................................................................... 27
6Connect Devices ......................................................................................... 28
6.1 Power Supply .......................................................................................... 28
7Appendix..................................................................................................... 29
7.1 RJ-45 Cable............................................................................................. 29
List of Figures ...................................................................................................... 30
List of Tables........................................................................................................ 31
=== En de der Lis te für T extmar ke Verz eich nis_vor ne == =

WAGO-ETHERNET-Zubehör 852 Notes about this Documentation 5
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
Pos: 7 / All e S eri e n ( All ge mei n e M od ul e) /Üb ers c hri ft en/ Ebe n e 1/H in w eis e z u dies er D o ku me nt ati on - Ü ber sc hr ift 1 @ 4\mod_1237987661750_21.docx@ 29029@ 1 @ 1
1 Notes about this Documentation
Pos: 8 /Al le S eri en ( Allg em ein e Mod ul e)/Si cher h eits- unds onstige Hinweise/Hinweis/Hinweis:Dokumentationaufbewahren@ 4\mod_1237987339812_21.docx @ 29026@ @ 1
Always retain this documentation!
This documentation is part of the product. Therefore, retain the documentation
during the entire service life of the product. Pass on the documentation to any
subsequent user. In addition, ensure that any supplement to this documentation is
included, if necessary.
Pos: 9 / All e S er i en ( All g e mei n e M od ul e) /Üb er sc hr i ft en/ E be ne 2/G ülti g kei t sb erei c h - Üb er sc hr ift 2 @ 12\mod_1338912448776_21.docx@ 96469@ 2 @ 1
1.1 Validity of this Documentation
Pos: 10 /S er ie 85 2 (ET H E RN E T-Z ube hör )/ Hin wei se z ur Dok um ent ati on/G ül tig kei tsb erei c h D ok umentation852-xxxx @ 16\mod_1378458208696_21.docx @ 130868@ @ 1
This documentation is only applicable to WAGO ETHERNET accessory products
“8-Port 1000BASE-T-Industrial-Eco-Switch” (852-1112).
Pos: 11 /A ll e Ser i en ( All ge mei ne M od ule) /R ec htli c hes, All gem ei nes /Gül tig keit sb erei c h D ok ume nt ati on E rg änz ung "ab <F W/H W/ SW-V er si o n>" @ 2 0\mod_1407749774742_21.docx@ 161508@ @ 1
This documentation is only applicable from FW/HW-Version 01/01.
Pos: 12.1 /All e Seri en ( Al lg emei ne M o d ule) /Ü ber s c hri ft e n/ Eb e ne 2/U r h eb er sc hut z - Ü ber sc hri ft 2 @ 23\mod_1435647042188_21.docx@ 184808@ 2@ 1
1.2 Copyright
Pos: 12.2 /All e Seri en ( Al lg emei ne Mo d ule) /R ec htli ch es , A llg e mei nes /U rh eb ersc hu tz aus führ li ch @ 4\mod_1235565145234_21.docx @ 27691@ @1
This Manual, including all figures and illustrations, is copyright-protected. Any
further use of this Manual by third parties that violate pertinent copyright
provisions is prohibited. Reproduction, translation, electronic and phototechnical
filing/archiving (e.g., photocopying) as well as any amendments require the
written consent of WAGO Kontakttechnik GmbH & Co. KG, Minden, Germany.
Non-observance will involve the right to assert damage claims.
Pos:12.3/Dokumentationallgemein/Gliederungselemente/---Seite nwe chs el--- @ 3\mod_1221108045078_0.docx @ 21810@ @ 1

6 Notes about this Documentation WAGO-ETHERNET-Zubehör 852
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
Pos: 12.4 /All e Seri en ( Al lg emei ne M o dul e)/Ü ber sc hri fte n/ Ebe ne 2/S ymbol e - Ü b ers chr if t 2 @ 13\mod_1351068042408_21.docx @ 105270@ 2 @ 1
1.3 Symbols
Pos: 12 .5.1 /Al le Seri en (All gemei ne Mod ul e)/ Si ch er h eits - u nd s ons ti ge H i n weis e/ G ef ahr /G ef a hr : _ War nu ng vor P er s on en sch ä de n al lg e mei n _ - Er läu ter ung @ 13 \mod_1343309450020_21.docx@ 101029@ @ 1
Personal Injury!
Indicates a high-risk, imminently hazardous situation which, if not avoided, will
result in death or serious injury.
Pos: 12 .5.2 /Al le Seri en (All gemei ne Mod ule)/ Sicher heits- u nd sons tig e H i n weis e/ Ge fa hr /G ef a hr : _ Warnu ng vor Per son ensch äden d urch ele ktrisc hen Str om_ - Erläuterung@ 13\mod_1343309694914_21.docx@ 101030@ @ 1
Personal Injury Caused by Electric Current!
Indicates a high-risk, imminently hazardous situation which, if not avoided, will
result in death or serious injury.
Pos: 12 .5.3 /Al le Seri en (All gemei ne Mod ule)/ Sicher heits- u nd sons ti g e Hi n weis e/ War n ung/ W arn ung : _ W arn u ng vor P ers one nsc h äd en allg em ei n_ - Erläuterung @ 13\mod_1343309877041_21.docx@ 101035@ @ 1
Personal Injury!
Indicates a moderate-risk, potentially hazardous situation which, if not avoided,
could result in death or serious injury.
Pos: 12 .5.4 /Al le Seri en (All gemei ne Mod ule)/ Sicher heits- u nd sons ti g e Hi n weis e/ Vors ic ht /V ors ic ht: _War n ung vor Per s one nsc hä d en al lg em ein _ - Erläuterung@ 13\mod_1343310028762_21.docx@ 101038@ @ 1
Personal Injury!
Indicates a low-risk, potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
Pos: 12 .5.5 /Al le Seri en (All gemei ne Mod ule)/ Si ch erh ei ts- u nd sons ti ge H i n weis e/ Ac htu ng/ Ac htu ng : _ War nu ng vor Sac hsc h äden allg e mei n _ - Erläuterung@ 13\mod_1343310134623_21.docx@ 101041@ @ 1
Damage to Property!
Indicates a potentially hazardous situation which, if not avoided, may result in
damage to property.
Pos: 12 .5.6 /All e Ser ie n ( All ge mei ne M od ule) / Sich erh eit s- und so ns tig e H i n weis e/ Ac htu ng/ Ach tu ng : _ War nu ng vor Sac hsc h äden dur c h el ek tros t atis c he Aufl adu ng _ - Er l äut er ung @ 13\mod_1343310227702_21.docx@ 101044@ @ 1
Damage to Property Caused by Electrostatic Discharge (ESD)!
Indicates a potentially hazardous situation which, if not avoided, may result in
damage to property.
Pos: 12 .5.7 /Al le Seri en (All gemei ne Mod ule)/ Sicher heits- u nd sonstige Hi nweise/Hinweis/Hinweis:_Wichtiger Hin weis allgemein_- Er l äut er u ng @ 13\mod_1343310326906_21.docx@ 101047@ @ 1
Important Note!
Indicates a potential malfunction which, if not avoided, however, will not result in
damage to property.
Pos: 12 .5.8 /All e Ser ie n ( All ge mei ne M od ule) / Sich erh eit s- und so ns tig e H i n weis e/I nf or ma tio n/I nf or ma ti on: _W ei ter e I nf or ma ti o n al lg e mei n_ - Erl äu ter ung @ 13 \mod_1343310439814_21.docx@ 101051@ @ 1

WAGO-ETHERNET-Zubehör 852 Notes about this Documentation 7
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
Additional Information:
Refers to additional information which is not an integral part of this
documentation (e.g., the Internet).
Pos:12.6/Dokumentationallgemein/Gliederungselemente/---Seite nwe chs el--- @ 3\mod_1221108045078_0.docx @ 21810@ @ 1

8 Notes about this Documentation WAGO-ETHERNET-Zubehör 852
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
Pos: 12.7 /All e Seri en ( Al lg emei ne M o dul e)/Ü ber sc hri fte n/ Ebe ne 2/Dar st ell ung der Z a hle ns yst em e - Ü ber s chr ift 2 @ 23\mod_1435647128078_21.docx @ 184811@ 2@ 1
1.4 Number Notation
Pos: 12.8 /All e Seri en ( Al lg emei ne Mo d ule) /R ec htli ch es , A llg e mei nes /Z ahl ens y st e me @ 3\mod_1221059454015_21.docx@ 21711@ @ 1
Table 1: Number Notation
Number Code
Example
Note
Decimal
100
Normal notation
Hexadecimal
0x64
C notation
Binary
'100'
'0110.0100'
In quotation marks, nibble separated with
dots (.)
Pos: 12.9 /All e Seri en ( Al lg emei ne M o dul e)/Ü ber sc hri fte n/ Ebe ne 2/Sc hri ft ko nvent i one n - Ü ber sc hri ft 2 @ 23\mod_1435647186005_21.docx@ 184814@ 2@ 1
1.5 Font Conventions
Pos: 12.1 0 / All e Seri e n ( Al lg e m ein e M o dul e) /R e ch tl ich es , A ll ge m ein es / Sc hr ift k onv e nti on en @ 3 \mod_1221059521437_21.docx@ 21714@ @1
Table 2: Font Conventions
Font Type
Indicates
italic
Names of paths and data files are marked in italic-type.
e.g.: C:\Program Files\WAGO Software
Menu
Menu items are marked in bold letters.
e.g.: Save
>
A greater-than sign between two names means the selection of a
menu item from a menu.
e.g.: File > New
Input
Designation of input or optional fields are marked in bold letters,
e.g.: Start of measurement range
“Value”
Input or selective values are marked in inverted commas.
e.g.: Enter the value “4 mA” under Start of measurement range.
[Button]
Pushbuttons in dialog boxes are marked with bold letters in square
brackets.
e.g.: [Input]
[Key]
Keys are marked with bold letters in square brackets.
e.g.: [F5]
Pos: 13 /D o ku me nt ati o n al lg e mei n/ Gl ie der ung s ele m e nte /---Seit e n we chs el --- @ 3\mod_1221108045078_0.docx@ 21810 @ @ 1

WAGO-ETHERNET-Zubehör 852 Important Notes 9
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
Pos: 14 /A ll e Ser i en ( All ge mei ne M od ule) /Ü b ersc hrif te n/ Ebe ne 1/ Wic hti ge Erl äu ter ung en - Ü ber sc hr ift 1 @ 4\mod_1241428899156_21.docx@32170 @ 1 @ 1
2 Important Notes
Pos: 15.1 /All e Seri en ( Al lg emei ne M o dul e)/R ec htl ich es , All ge m ei nes/ Wic htig e Er l äut er ung en - Ei nlei t u ng @ 3\mod_1221059818031_21.docx@ 21717@ @ 1
This section includes an overall summary of the most important safety
requirements and notes that are mentioned in each individual section. To protect
your health and prevent damage to devices as well, it is imperative to read and
carefully follow the safety guidelines.
Pos: 15 .2 /All e Seri en ( All ge mei ne M od ule) /Ü bers c hrif te n/ Ebe ne 2/R ec htl ic he Gr undl ag en - Ü ber sc hr ift 2 @ 3\mod_1221060626343_21.docx@ 21726@ 2 @ 1
2.1 Legal Bases
Pos: 15.3 /All e Seri en ( Al lg emei ne Mo d ule) /R ec htli ch es , A llg e mei nes /Ä nd er ung s vorb eh alt - Üb erschr ift 3 und In halt @ 3\mod_1221060036484_21.docx @ 21720 @ 3 @ 1
2.1.1 Subject to Changes
WAGO Kontakttechnik GmbH & Co. KG reserves the right to provide for any
alterations or modifications that serve to increase the efficiency of technical
progress. WAGO Kontakttechnik GmbH & Co. KG owns all rights arising from
the granting of patents or from the legal protection of utility patents. Third-party
products are always mentioned without any reference to patent rights. Thus, the
existence of such rights cannot be excluded.
Pos: 15.4 /Serie 852 (ETHERNET-Z ube hör )/Wi c htig e Er l äut er unge n/ Per so nalq ual ifi kati on 852- xxxx - Ü b er sc hri f t 3 un d I n hal t @ 3\mod_1222346340968_21.docx @ 22264@ 3 @ 1
2.1.2 Personnel Qualification
All sequences implemented on Series 852 devices may only be carried out by
electrical specialists with sufficient knowledge in automation. The specialists
must be familiar with the current norms and guidelines for the devices and
automated environments.
All changes to the controller should always be carried out by qualified personnel
with sufficient sufficient skills in PLC programming.
Pos:15.5/Serie852(ETHERNET-Zubehör)/Wichtige Erläuterungen/BestimmungsgemäßeVerwendung852-xxxx - Ü bersc hrift 3 und I nhalt @ 3\mod_1222346110578_21.docx@ 22258 @ 3 @ 1
2.1.3 Proper Use of the Industrial Switches
The device is designed for the IP30 protection class. It is protected against the
insertion of solid items and solid impurities up to 2.5 mm in diameter, but not
against water penetration. Unless otherwise specified, the device must not be
operated in wet and dusty environments.
Pos: 15.6 /All e Seri en ( Al lg emei ne Mo d ule) /R ec htli ch es , A llg e mei nes /T ec hni sc her Z us t and der Ger ät e - Ü bersc hrift 3 und I nhalt @ 3\mod_1221060446109_21.docx@ 21723@ 3 @ 1
2.1.4 Technical Condition of Specified Devices
The devices to be supplied ex works are equipped with hardware and software
configurations, which meet the individual application requirements. WAGO
Kontakttechnik GmbH & Co. KG will be exempted from any liability in case of
changes in hardware or software as well as to non-compliant usage of devices.
Please send your request for modified and new hardware or software
configurations directly to WAGO Kontakttechnik GmbH & Co. KG.
Pos:15.7/Dokumentationallgemein/Gliederungselemente/---Seite nwe chs el--- @ 3\mod_1221108045078_0.docx @ 21810@ @ 1

10 Important Notes WAGO-ETHERNET-Zubehör 852
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
Pos:15.8/Serie852(ETHERNET-Zubeh ör)/Wic htig e Erläut erung en/N orme n und Ric htlini en 852- xxxx - Über schri ft 2 und Inh alt @ 3\mod_1222346239453_21.docx@ 22261@ 3 @ 1
2.1.5 Standards and Regulations for Operating the Industrial
Switches
Please observe the standards and regulations that are relevant to installation:
•The data and power lines must be connected and installed in compliance
with the standards to avoid failures on your installation and eliminate any
danger to personnel.
•For installation, startup, maintenance and repair, please observe the accident
prevention regulations of your machine (e.g., BGV A 3, “Electrical
Installations and Equipment”).
•Emergency stop functions and equipment must not be deactivated or
otherwise made ineffective. See relevant standards (e.g., DIN EN 418).
•Your installation must be equipped in accordance to the EMC guidelines so
electromagnetic interferences can be eliminated.
•Please observe the safety measures against electrostatic discharge according
to DIN EN 61340-5-1/-3. When handling the modules, ensure that
environmental factors (persons, workplace and packing) are well grounded.
•The relevant valid and applicable standards and guidelines regarding the
installation of switch cabinets must be observed.
Pos:15.9/Dokumentationallgemein/Gliederungselemente/---Seite nwe chs el--- @ 3\mod_1221108045078_0.docx @ 21810@ @ 1

WAGO-ETHERNET-Zubehör 852 Important Notes 11
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
Pos: 15.1 0 / Al le Ser ie n ( All ge m ein e M o dul e) /Üb er sc hri ft en /Eb en e 2/ Si ch erh eit s hin wei s e - Ü ber s chr ift 2 @ 6\mod_1260180299987_21.docx@ 46724@ 2 @ 1
2.2 Safety Advice (Precautions)
Pos: 15.1 1 /Al le Seri en ( Allg em ein e M odul e)/Si ch erh eits - und so nstige H inwei se/Ei nlei tung Sic herh eitshi nweis e Hard ware @ 6\mod_1260180170493_21.docx@ 46720 @ @ 1
For installing and operating purposes of the relevant device to your system the
following safety precautions shall be observed:
Pos: 15.1 2.1 / All e S eri en (Al lg em eine M o dul e)/Si ch erh eits- un d s o nsti g e H in w eis e /G ef a hr/G ef ahr : Nic ht an G er ät e n un ter S pa nnu ng ar bei te n! @ 6\m od_1260180365327_21.docx@ 46727@ @ 1
Do not work on devices while energized!
All power sources to the device shall be switched off prior to performing any
installation, repair or maintenance work.
Pos: 15.1 2. 2 / S eri e 852 ( ETH ER N ET -Z ub ehör ) / Wic ht ig e Erlä ut er ung e n/ Si ch er hei ts- u nd sons tig e H in w eis e/G ef a hr : Ein bau 085 2-xx xx n ur in G e hä us en , S c hr än ke n oder ele kt ri sc h e n B et ri ebsr äu me n! @ 22 \mod_1432282091645_21.docx@ 182573@ @ 1
Only install in appropriate housings, cabinets or electrical operation rooms!
WAGO's 852 Series ETHERNET Switches are considered exposed operating
components. Therefore, only install these switches in lockable housings, cabinets
or electrical operation rooms. Access must be limited to authorized, qualified staff
having the appropriate key or tool.
Pos: 15.1 2. 3 / All e Seri en ( Allg em ein e M odul e)/Si c herh eits - und s o nsti g e H in w eis e/ G ef ahr /G ef ahr : Unfal l v erh üt ung s v ors c hri ft en be ach te n! @ 6\mod_1260180657000_21.docx @ 46735 @ @ 1
Pos: 15.1 2.4 / All e S eri en (Al lg em eine M o dul e)/Si ch erh eits- unds onstige Hin wei se /G ef a hr /G ef ahr : A uf nor mger ec ht e n A nsc hl uss ac ht en! @ 6 \mod_1260180753479_21.docx@ 46739@ @ 1
Pos: 15.1 3.1 / All e S eri en (Al lg em eine M o dul e)/Si ch erh eits- un d s o nsti g e H in wei se /A cht ung /Ac ht u ng : N ic ht i n T el ek om muni kati ons n etz en ei ns etz en! (Z usa tz RJ-45) @ 3\mod_1224065187468_21.docx@ 24076@ @ 1
Do not use in telecommunication circuits!
Only use devices equipped with ETHERNET or RJ-45 connectors in LANs.
Never connect these devices with telecommunication networks.
Pos: 15.1 3.2 / All e S eri en (Al lg em eine M o dul e)/Si ch erh eits- un d s o nsti g e H in w eis e /A cht u ng /Ac ht u ng : D ef e kte oder bes ch ädi gt e Ger ät e austa us c h en! @ 6\mod_1260180857358_21.docx@ 46743 @ @ 1
Replace defective or damaged devices!
Replace defective or damaged device/module (e.g., in the event of deformed
contacts), since the long-term functionality of device/module involved can no
longer be ensured.
Pos: 15.1 3.3 / All e S eri en (Al lg em eine M o dul e)/Si ch erh eits- un d s o nsti g e H in w eis e /A cht u ng /Ac ht u ng : G erä te vor kri ec he n den und isol i er end en Sto ff en sc hüt ze n! @ 6\mod_1260181036216_21.docx @ 46747 @ @ 1
Protect the components against materials having seeping and insulating
properties!
The components are not resistant to materials having seeping and insulating
properties such as: aerosols, silicones and triglycerides (found in some hand
creams). If you cannot exclude that such materials will appear in the component
environment, then install the components in an enclosure being resistant to the
above-mentioned materials. Clean tools and materials are imperative for handling
devices/modules.
Pos: 15.1 3.4 / All e S eri en (Al lg em eine M o dul e)/Si ch erh eits- unds onstige Hinweise/Achtung/Achtung:Reinigungnur mit zulässigenMat er ial ie n! @ 6\mod_1260181203293_21.docx@ 46751@ @ 1

12 Important Notes WAGO-ETHERNET-Zubehör 852
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
Clean only with permitted materials!
Clean soiled contacts using oil-free compressed air or with ethyl alcohol and
leather cloths.
Pos: 15.1 3.5 / All e S erie n (Al lge mei ne M o dule) /Sic h erhei ts- undsonstigeHinweise/Achtung/Achtung:Kein Kontaktspray verwenden!@ 6\mod_1260181290808_21.docx@ 46755@ @ 1
Do not use any contact spray!
Do not use any contact spray. The spray may impair contact area functionality in
connection with contamination.
Pos: 15.1 3.6 / All e S eri en (Al lg em eine M o dul e)/Si ch erh eits- unds onstige Hinweis e /A cht u ng /Ac ht u ng : V er pol ung en der Date n- un d Ver sor g u ng sl eit u ng en ver m eid e n! @ 6\mod_1260184045744_21.docx @ 46767@ @ 1
Do not reverse the polarity of connection lines!
Avoid reverse polarity of data and power supply lines, as this may damage the
devices involved.
Pos: 15.1 3.7 / All e S eri en (Al lg em eine M o dul e)/Si ch erh eits- unds onstigeHinweise/Achtung/Achtung:Elektrostatische Entl adu ng verm ei den! @ 6\mod_1260181364729_21.docx@ 46759@ @ 1
Avoid electrostatic discharge!
The devices are equipped with electronic components that may be destroyed by
electrostatic discharge when touched. Please observe the safety precautions
against electrostatic discharge per DIN EN 61340-5-1/-3. When handling the
devices, please ensure that environmental factors (personnel, work space and
packaging) are properly grounded.
Pos: 15.1 4 /D o ku ment ati o n all ge mei n/G li ed eru ngsel e me nte/---S ei ten w ec hs el--- @ 3 \mod_1221108045078_0.docx@ 21810@ @ 1

WAGO-ETHERNET-Zubehör 852 Important Notes 13
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
Pos: 15.1 5 / All e S er ie n (Al lg em ein e M o dul e)/R ec htl ich es, Allg e mein es/ Sp ezi ell e Ei ns atz best i mm ung en f ür ET H ERN ET -Ger ät e - Ü b ers chr if t 2 un d I n halt @ 1 2\mod_1336642945500_21.docx @ 94792@ 2@ 1
2.3 Special Use Conditions for ETHERNET Devices
If not otherwise specified, ETHERNET devices are intended for use on local
networks. Please note the following when using ETHERNET devices in your
system:
•Do not connect control components and control networks to an open
network such as the Internet or an office network. WAGO recommends
putting control components and control networks behind a firewall.
•Limit physical and electronic access to all automation components to
authorized personnel only.
•Change the default passwords before first use! This will reduce the risk of
unauthorized access to your system.
•Regularly change the passwords used! This will reduce the risk of
unauthorized access to your system.
•If remote access to control components and control networks is required,
use a Virtual Private Network (VPN).
•Regularly perform threat analyses. You can check whether the measures
taken meet your security requirements.
•Use “defense-in-depth” mechanisms in your system's security configuration
to restrict the access to and control of individual products and networks.
Pos: 16 /D o ku me nt ati o n al lg e mei n/ Gl ie der ung s ele m e nte /---Seit e n we chs el --- @ 3\mod_1221108045078_0.docx@ 21810 @ @ 1

14 General WAGO-ETHERNET-Zubehör 852
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
Pos: 17 /A ll e Ser i en ( All ge mei ne M od ule) /Ü b ersc hrif te n/ Ebe ne 1/ Ei nl eit ung - Ü b ersc hr ift 1 @ 3\mod_1222676076609_21.docx@ 22308@ 1 @ 1
3 General
Pos:18.1/Serie852(ETHERNET-Zubeh ör )/Ei nl ei t ung / Lie fer u mf ang 852-01 01, -01 02, -01 03, -1102,-1112 @ 3\mod_1222683414218_21.docx@ 22314@ 2 @ 1
3.1 Package Contents
•One Industrial Switch
•DIN rail bracket
•Protective caps for unused ports
Pos:18.2/Serie852(ETHERNET-Zubeh ör) /Einl ei tung / In dust riel l e ET HER N ET-Te ch nol ogi e 8 52-1102,1112 @ 27\mod_1470744313508_21.docx@ 218063@ 2 @ 1
3.2 Industrial ETHERNET Technology
The range of WAGO Switches ensures scalability of your network infrastructure
with outstanding electrical and mechanical characteristics. These rugged devices
are designed for industrial use and are fully compliant with the IEEE 802.3,
802.3u, 802.3ab, 802.3az, 802.3x and 802.1p standards.
They have power supply with a supply voltage range of 9 … 57 V. Characteristics
such as auto-negotiation and auto MDI/MDIX (crossover) on all
10/100/1000BASE-T ports are also realized.
Pos:18.3/Serie852(ETHERNET-Zubeh ör )/Ei nl ei t ung / S witc hi ng -Technologie@ 3\mod_1222683606296_21.docx@ 22317@ 2 @ 1
3.3 Switching Technology
Another approach to pushing beyond the limits of ETHERNET technology is the
development of switching technology. A switch bridge ETHERNET packets at
the MAC address level of the ETHERNET protocol transmitting among
connected ETHERNET or Fast ETHERNET LAN segments.
Switching is a cost-effective way of increasing the total network capacity
available to users on a local area network. A switch increases capacity and
decreases network loading by dividing a local area network into different
segments, which don´t compete with each other for network transmission
capacity.
Pos:18.4/Serie852(ETHERNET-Zubeh ör )/Ei nl ei t ung / A uto-Negotiation 852-1102, 1111,1112@ 19\mod_1400500269605_21.docx@ 15 4182 @ 2 @ 1
3.4 Auto Negotiation
The Industrial Switch’s 10/100/1000Mbit/s switched RJ-45 ports auto negotiates
with connected devices to determine the fastest data transmission rate supported
by both devices. This helps make the Switch a plug and play device. The Switch’s
RJ-45 ports support full or half duplex, depending on which transmission speed is
supported by the attached device.
Pos:18.5/Serie852(ETHERNET-Zubeh ör )/Ei nl ei t ung / A uto cr ossi ng @ 2 7\mod_1474448769211_21.docx@ 220493@ 2 @ 1
3.5 Autocrossing
Autocrossing (MDI/MDI-X, “Medium Dependent Interface”) allows the
transmission and reception lines to be crossed automatically at twisted pair
interfaces.
This allows users to use cables and cross-over cables in the same manner 1:1.
Pos: 18 .6 /Ser ie 852 ( ETH ERN ET -Zu be hör ) /Ei nl eit ung / S wit c hing , Fil ter n @ 3\mod_1222427760578_21.docx@ 22298 @ 2 @ 1

WAGO-ETHERNET-Zubehör 852 General 15
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
3.6 Switching, Filtering
Packets entering the Industrial Switch with source and destination addresses
belonging to the same port segment will be filtered, limiting those packets to one
port, and relieving the rest of the network from the need to process them. A packet
with a destination address served by another port segment will be forwarded to the
appropriate port, and will not be sent to the other ports where it is not needed.
Packets that are used to maintain network operations (such as the occasional multi
cast packet) are forwarded to all ports.
The Industrial Switch operates in the store and forward switching mode, which
eliminates bad packets and enables peak performance to be achieved when there is
heavy traffic on the network.
Pos:18.7/Serie852(ETHERNET-Zubeh ör )/Ei nl ei t ung / St or e-and-F or war d-Switc hing @ 2 7\mod_1472639407854_21.docx @ 219388@ 2@ 1
3.7 Store-and-forward switching mode
The store-and-forward-switching mode is relay and transfer principle.
With this transfer principle the data packages or messages are relayed via
subsections from one network node to the next where they a buffered for a short
time.
Here they are checked for correctness and validity and then discarded or relayed
on to the final receiver.
Pos:18.8/Serie852(ETHERNET-Zubeh ör )/Ei nl ei t ung / Lini e ntie fe bei PROF IN ET @ 2 8\mod_1479221652347_21.docx @ 387248@2 @ 1
3.8 Line Depth in PROFINET
Line depth (cascading) is the number of all switches in a communication path.
The maximum line depth depends on the send cycle and the switch mode used.
Observe line depth!
Observe the maximum line depth for switches in Store-and-Forward mode
according to the “Topology Check” section of PI-PROFINET Commissioning
Guideline (PROFINET_Commissioning_8081) (www.profibus.com).
Pos:18.9/Serie852(ETHERNET-Zubeh ör) /Einl ei tung / Por tg esc hwi ndi g keit u n d D upl ex-Modus @ 3\ mod_1222427724921_21.docx@ 22294@ 2 @ 1
3.9 Port Speed & Duplex Mode
After a cable is plugged into a specific port, the system uses auto negotiation to
determine the transmission mode for the new twisted pair connection:
If the connected device does not support auto negotiation or has auto negotiation
disabled, an auto sensing process is initiated to select the speed and set the duplex
mode to half duplex.
Pos: 19 /D o ku me nt ati o n al lg e mei n/ Gl ie der ung s ele m e nte /---Seitenwechsel--- @ 3\mod_1221108045078_0.docx@ 21810@ @ 1

16 Device Description WAGO-ETHERNET-Zubehör 852
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
Pos: 20 /Al l e Seri en (All g emei n e M o d ule) /Ü b er schr i f te n/ Eb ene 1/G er ät e bes chr eib ung - Ü ber sc hri f t 1 @ 3\mod_1233756084656_21.docx@ 27096@ 1 @ 1
4 Device Description
Pos:21.1/Serie852(ETHERNET-Zubehör)/Gerät ebes chr eib ung / Ei nl ei t ung/ G er ät eb esc hr ei bu ng 85 2-1112 @ 27\mod_1471860688978_21.docx@ 218731@ @ 1
The 852-1112 is an industrial ETHERNET switch with 8 10/100/1000Base-T
ports, with auto-negotiation and auto-MDI-/MDI-X detection at every port.
Using the industrial ECO switch's 8 ports, several segments can be set up for
reducing network load and a dedicated bandwidth assigned to each user node. The
852-1112 is a cost-effect solution to keep up with the constant demands of IP-
based, industrial communication needs.
The industrial ECO switch is easy to configure and install and is best suited for
small to medium-sized networks.
Pos:21.2/Dokumentationallgemein/Gliederungselemente/---Seite nwe chs el--- @ 3\mod_1221108045078_0.docx @ 21810@ @ 1

WAGO-ETHERNET-Zubehör 852 Device Description 17
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
Pos: 21.3 /All e Seri en ( Al lg emei ne M o dul e)/Ü ber sc hri fte n/ Ebe ne 2/A nsic ht - Ü ber s chr ift 2 @ 4\mod_1240984217343_21.docx@ 31958@ 2 @ 1
4.1 View
Pos:21.4/Serie852(ETHERNET-Zubeh ör )/G er ät e bes chr ei bung / An s ich t/ A nsic ht e n 8 5 2-1 112 @ 27\mod_1471868059183_21.docx@ 218769@ 33 @ 1
4.1.1 Front View
Figure 1: Front View of the Industrial ECO Switch
Table 3: Legend for Figure “Front View of the Industrial ECO Switch”
Pos.
Descrip-
tion
Meaning Details see Section
1 PWR Status LED Power Supply
“Device Description” >
“Display Elements”
2 -
Status LED T-Port 1000-Mbit/s
(1 LED for each port)
“Device Description” >
“Display Elements”
3 -
Status LED T-Port LNK/ACT
(1 LED for each port)
“Device Description” >
“Display Elements”
4 - Port 8 x RJ-45 (10/100/1000BASE-T-Ports)
“Device Description” >
“Connectors”

18 Device Description WAGO-ETHERNET-Zubehör 852
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
4.1.2 Top View
Figure 2: Top View of the Industrial ECO Switch
Table 4: Legend for Figure “Top View of the Industrial ECO Switch”
Pos.
Descrip-
tion
Meaning Details see Section
1
-
Grounding screw
-
2 -
Terminal block (male connector) for power
supply (PWR)
“Device Description” > “
Connectors”
Pos:21.5/Dokumentationallgemein/Gliederungselemente/---Seite nwe chs el--- @ 3\mod_1221108045078_0.docx @ 21810@ @ 1

WAGO-ETHERNET-Zubehör 852 Device Description 19
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
Pos: 21.6 /All e Seri en ( Al lg emei ne Mo d ule) /Ü bers c hri ft en/ Eb e ne 2/ A nsc hl üss e - Ü b er sc hr ift 2 @ 4\mod_1240984262656_21.docx@ 31961 @ 2@ 1
4.2 Connectors
Pos:21.7/Serie852(ETHERNET-Zubeh ör )/G er ät e bes chr ei bung / An s chl üs s e/ An schl üss e 85 2-1112 Spannungsversorgung@ 27\mod_1471869397068_21.docx@ 218773@ 3 @ 1
4.2.1 Power Supply (PWR/RPS)
The female connector (Order No. 2231-102/026-000) can easily be connected to
the 2-pole male connector located on the top of the industrial ECO switch.
The male connector shows the following pin assignment:
Figure 3: Power Supply (PWR) Port
Table 5: Legend fort Figure “Power Supply (PWR) Port “
Pin
Description
Meaning
+
PWR
Primary DC input
-
PWR
Primary DC input
Damage to Property Caused by Electrostatic Discharge (ESD)!
Industrial switch for DC operation: Power supply is provided via an external
direct-current power source. As the industrial switch is not equipped with a power
switch, it switches on immediately when you apply the direct-current power
supply.
Pos:21.8/Dokumentationallgemein/Gliederungselemente/---Seite nwe chs el--- @ 3\mod_1221108045078_0.docx @ 21810@ @ 1

20 Device Description WAGO-ETHERNET-Zubehör 852
852-1112 8-Port 1000BASE-T-Industrial-Eco-Switch
Manual
Version 1.1.0FW/HW-Version 01/01
Pos: 21.9/Serie852(ETHERNET-Zubeh ör) /G er ät e bes chr eib ung / An sc hl üss e/ An schl üss e 85 2-1112 10/100/1000Base-T @ 27\mod_1471870614552_21.docx@ 218887@ 34 @ 1
4.2.2 Network Connections
The industrial Eco switch uses ports with with copper connectors that can be used
with ETHERNET and/or Fast ETHERNET protocols.
Figure 4: Network Connections
Table 6: Legend fort the Figure “Network Connections“
No.
Descrip-
tion
Meaning Details see Section
1 - Connection 8 x RJ-45 (10/100/1000BASE-T
ports)
“Device Description” > …
“10/100/1000BASE-T
ports“
4.2.2.1 10/100/1000Base-T
The 10/100/1000Base-T ports support network speeds of 10 Mbit/s, 100 Mbit/s
and 1000 Mbit/s and can be operated in half and full-duplex transmission modes.
These ports also provide automatic crossover detection (Auto-MDI/MDI-X), with
plug&play capabilities. Simply plug the network cables into the ports; they then
adapt to the end node devices. We recommend the following cable for the RJ-45
ports:
•100 m – Cat 5e or higher
Pos: 21.1 0 /D o ku ment ati o n all ge mei n/G li ed eru ngsel e me nte/---S ei ten w ec hs el--- @ 3 \mod_1221108045078_0.docx@ 21810@ @ 1
