Walgreens WGNBPW-200 User manual

WGNBPW200
WIC 899781
• 5-Year
Limited Warranty
El manual en
español empieza
en la página 33
AUTOMATIC WRIST
Blood Pressure
Monitor

2
TABLE OF CONTENTS
INTRODUCTORY INFORMATION:
Important Product Notices and Safety
Instructions ..............................................4
About Blood Pressure.............................6
Blood Pressure Standard........................7
How This Blood Pressure
Monitor Works .........................................8
USAGE INFORMATION:
Name/Function of Each Part ...................9
Display Explanations.............................10
Installing Batteries ................................12
Date & Time Set Procedure...................13
Applying the Cuff...................................14
Correct Measurement Posture .............15
Measurement Procedure.......................16
Risk Category Index ..............................18

3
Irregular Heartbeat Detector ....................... 19
Excessive Body Motion Detection............... 20
Recalling Values from Memory.................... 20
Clearing Values from Memory..................... 21
Important Notes Regarding Your
Blood Pressure Measurement..................... 21
Care, Maintenance, & Cleaning ................... 22
Potential for Electromagnetic Interference 24
Electromagnetic Compatibility (EMC)......... 25
Troubleshooting............................................ 29
Specifications ............................................... 30
5-Year Limited Warranty............................... 32

4
IMPORTANT PRODUCT NOTICES
AND SAFETY INSTRUCTIONS
When using your blood pressure monitor, basic precautions should
always be followed. Please read and follow all instructions and warnings
before using this product. Save these instructions for future reference.
• This device uses the oscillometric method to measure systolic
and diastolic blood pressure, as well as heart rate.
• Please note that this is a home health care product only and it is
not intended to serve as a substitute for the advice of a physician
or medical professional.
• Not for use by or on persons under the age of 18.
• This device is only intended for use by those individuals with a
wrist circumference ranging from 5.3"-8.4" (13.5cm-21.5cm).
• DO NOT use this device for diagnosis or treatment of any health
problem or disease. Measurement results are for reference only.
Consult a health care professional for interpretation of pressure
measurements. Contact your physician if you have or suspect any
medical problem. Do not change your medications without the
advice of your physician or health care professional.
• This product is not suitable for people with arrhythmias.
• This device may have difficulty determining the proper blood
pressure for pregnant women and for individuals with irregular
heartbeat, diabetes, poor circulation of blood, kidney problems,
or for users who have suffered from a stroke.
• Not suitable for people undergoing intravenous injection on any
limb, women who may be pregnant and those with preeclampsia.
• For those who have undergone mastectomy surgery (especially
those who have had lymph nodes removed), it is recommended
to take a measurement on the unaffected side.
• Excessive use may result in blood flow interference, which is likely
to cause uncomfortable sensations, such as partial subcutaneous
hemorrhage, or temporary numbness to your arm. In general,

5
these symptoms should not last long. However, if symptoms
persist, seek advice from a medical professional.
• When used along with other medical electronic equipment on the
same wrist, pressurization of the cuff may cause the other devices
to temporarily malfunction.
• Consult your physician before measuring blood pressure at the wrist
if you have any of the following conditions: Severe hypertension,
severe diabetes, severe arteriosclerosis, severe kidney disease or
vascular disease that may compromise circulation.
• The pulse display is not suitable for checking the frequency of
heart pacemakers.
• Not suitable for use on patients with implanted electrical devices,
such as a cardiac pacemakers or defibrillators.
• Electromagnetic interference: The device contains sensitive
electronic components. Avoid strong electrical or electromagnetic
fields in the direct vicinity of the device (ex. mobile telephones,
microwave ovens). These may lead to temporary impairment of
measurement accuracy.
• Consider the electromagnetic compatibility of the device (ex. power
disturbance, radio frequency interference, etc.).
• Please use this device in a home health care environment only.
• Use blood pressure monitor only for its intended use.
• DO NOT wrap the cuff around body parts other than your wrist.
• DO NOT use this device on infants, children, or those who cannot
express their own intention.
• Use only 1.5V “AAA” alkaline batteries for power supply.
Blood pressure measurements determined with this device are
equivalent to those obtained by a trained observer using the cuff/
stethoscope auscultatory method, within the accuracy limits prescribed
by the American National Standard, manual, electronic, or automated
sphygmomanometers. The sphygmomanometer was clinically
investigated according to the requirement of ISO 81060-2:2013.

6
ABOUT BLOOD PRESSURE
What is Blood Pressure?
Blood pressure is the pressure exerted on the artery walls while
blood flows through the arteries. The pressure measured when the
heart contracts and sends blood out of the heart is systolic (highest)
blood pressure. The pressure measured when the heart dilates with
blood flowing back into the heart is called diastolic (lowest) blood
pressure. Both the systolic and diastolic pressure are necessary for
a physician to evaluate the status of a patient’s blood pressure.
Why Measure Your Blood Pressure?
Among today’s various health problems, those associated with high
blood pressure are very common. High blood pressure dangerously
correlates with cardiovascular disease. Therefore, blood pressure
monitoring is important for identifying those at risk.
Why Do My Readings Vary?
Blood pressure is a body parameter that is subject to normal
variations throughout the day. A single reading that is different from
yours or your doctor’s readings are not necessarily inaccurate. The
average of several readings, taken under similar conditions, using
the same wrist, is preferred for accurate blood pressure readings.
Why Are My Readings Different Than Those Taken at My
Doctor’s Office?
Many experience a phenomenon called “White Coat Hypertension”
when measured by a doctor. White Coat Hypertension refers to
blood pressure that rises above its usual level when measured in
a clinical setting, such as a doctor’s office.

7
BLOOD PRESSURE STANDARD
This table contains defined levels for hypertension that are publicly
available from the American Heart Association®(AHA 2017). Users
can compare their own blood pressure readings against these
defined levels to determine if there is a potential increased risk.
This table is applicable to most adults aged 18 and older.
Blood pressure tends to go up and down, even in people who normally
don’t have high readings. If your numbers stay above the normal range
most of the time, you may be at an increased risk and should consult
your physician.
Although one can easily find where their own blood pressure readings
fall on this table, this monitor comes equipped with a Risk Category
Index that automatically compares each reading to the defined levels
and provides a helpful cue if your reading falls into one of the stages
that could potentially indicate increased risk. See page 18 for more
information on this feature.
Blood Pressure Category
Systolic
mmHg (upper
number)
Diastolic
mmHg (lower
number)
Indicator
Color
Normal <120 and <80 Green
Elevated 120–129 and <80 Yellow
High Blood Pressure
(hypertension) Stage 1 130–139 or 80–89
Red
High Blood Pressure
(hypertension) Stage 2 140–180 or 90–120
Hypertensive Crisis
(consult your doctor immediately) >180 and/or >120
*Source: AHA 2017

8
Please note that cues provided by this monitor are only intended to
assist you in using this table. The table and cues are only provided
for convenience to help you understand your noninvasive blood
pressure reading as it relates to the American Heart Association®
information. They are not a substitute for a medical examination by
your physician. It is important for you to consult with your physician
regularly. Your physician will tell you your normal blood pressure
range as well as the point at which you may actually be considered
to be at risk.
HOW THIS BLOOD PRESSURE
MONITOR WORKS
This monitor uses innovative GentleInflate™ technology to measure
your blood pressure. With one touch of a button, the monitor
automatically takes the reading during inflation, then deflates,
delivering a quick, comfortable, and quiet measurement every time.
Please note that any muscle movement during inflation will
cause measurement error. When measurement is complete, the
monitor will display your systolic pressure, diastolic pressure,
and pulse readings.
The monitor automatically finds where your measurement results fall
on the American Heart Association®(AHA 2017) table and provides
a cue if your reading falls into one of the stages that could
potentially indicate increased risk. Please refer to page 18 for more
information on this feature.
The appearance of the icon indicates that a pulse irregularity
consistent with an irregular heartbeat was detected during
measurement. Refer to page 19 for more information on the Irregular
Heartbeat Detector.

9
NAME/FUNCTION OF EACH PART
NOTE:
The “MEM” button is also used to set the date and time.
Other Accessories:
2 “AAA” 1.5V alkaline
batteries (included)
START/STOP
Wrist Cuff
Battery Cover
(Located on
bottom of unit)
LCD
Display
Date & Time SetMemory Recall/
Date & Time Select

10
DISPLAY EXPLANATIONS
Date/Time
Indicator
Diastolic
Pressure
Systolic
Pressure
Heart Rate
Irregular
Heartbeat
Detector

11
/
START
STOP
Low Battery Symbol: Appears when batteries should be
replaced, or when +/- polarities have been positioned incorrectly.
/
START
STOP
Pulse Symbol: Shows heart rate in beats per minute.
Irregular Heartbeat Detector: Irregular heartbeat detected
during measurement. See page 19 for more information.
Risk Category Index: Indicates the blood pressure level.
See page 18 for more information.
Memory Average: Displays average of last 3 readings.
Excessive Body Motion Detector: Appears when
excessive body movement, especially of the wrist the cuff
is worn, is detected during the measurement. See page 20
for more information. NOTE:The measured blood pressure
reading may not be accurate if the icon is displayed.
Display Symbols:
Incorrect cuff placement: Correct and measure again.
Error Determining Measurement Data: Relax, do not
move, and measure again.
Error Determining Measurement Data: Wrap the cuff
properly, keep steady, and measure again.
Pulse Signal Not Detected: Relax for 3 minutes, measure again.
System Error: Turn off monitor and measure again. If EE still appears
on the display followed by any other character (ex: EE4, EEA, etc.),
please contact Consumer Relations.
Pressure Measurement Out of Range: Switch the unit off
to clear, then measure again.
If any of the following letters and numbers appear in the area
that systolic pressure should be displayed, an error has occurred
with your reading. See Troubleshooting section of this manual for
more information.

12
INSTALLING BATTERIES
1. Slide off the battery cover to open the
battery compartment.
2. Install or replace the 2 “AAA” alkaline
batteries according to the indications
inside the battery compartment.
NOTE:
When removing batteries, pull black ribbon forward.
3. Replace the battery cover.
Replace the batteries if:
• The low battery symbol appears on the display.
• When any button is pressed and nothing is displayed on the screen.
NOTE:
• Date and time will need to be reset if batteries are removed or replaced.
• Replace all batteries at one time (as simultaneous set). Do not
mix old and new batteries.
• Use only 1.5V “AAA” alkaline batteries. Do not mix alkaline, standard
(carbon-zinc) or rechargeable (Ni-Cad, Ni-MH, etc.) batteries.
• When installing batteries, observe proper +/- polarities. Incorrect
installation of batteries may cause damage to the unit.
• Remove batteries when unit is not in use for extended periods of time.
• When the batteries are removed, the measurement values stored in
memory are retained. However, the date and time must be reset.
• Clean contacts on battery and in battery compartment with a soft
dry cloth each time you install batteries.
• Keep batteries away from children as they could pose a choking hazard.
• Recycle or dispose of properly in accordance with all local, state,
province, and country regulations.
• Batteries are hazardous waste. DO NOT dispose of them
together with the household garbage.
• DO NOT dispose of batteries in fire. Batteries may explode or leak.

13
DATE & TIME SET PROCEDURE
It is important to set the Date & Time before using your blood
pressure monitor, so that a time stamp can be assigned to each
record that is stored in the memory.
1. To set the date and time, press the
“Date & Time Set” button.
2. The display will show a blinking number representing the
MONTH. Change the MONTH by pressing the “MEM” button.
Each press will increase the number by one in a cycling manner.
Press the button to confirm the entry. The screen will then
show a blinking number representing the DAY.
3. Change the DAY, YEAR, HOUR, & MINUTE as described in Step
2 above, using the “MEM” button to change the numbers and
the button to confirm the entries.
Repeat process to set DAY, YEAR, HOUR, and MINUTE.
Press the button
“MEM”
Blinking Month
Increase Month
Confirm Entry
IMPORTANT: IF YOU ARE USING THIS BLOOD PRESSURE MONITOR FOR THE FIRST
TIME, PLEASE REMOVE THE PROTECTIVE FILM FROM THE DISPLAY SCREEN.

14
APPLYING THE CUFF
1. Remove all watches, wrist jewelry, etc.
prior to attaching the wrist monitor.
Clothing sleeves should be rolled up
and the cuff should be wrapped around
bare skin for correct measurements.
2. Apply cuff to left wrist with palm facing
up as shown in Fig. A.
3. Make sure the edge of the cuff is about
1/4"–1/2" (1cm–1.5cm) from the palm
as shown in Fig. B.
4. In order to ensure accurate
measurements, fasten the hook and
loop strap securely around your wrist
so there is no extra space between
the cuff and the wrist. If the cuff
is not wrapped tight enough, the
measurement values will not
be accurate.
5. If your physician has diagnosed you
with poor circulation in your left arm,
place the cuff around your right wrist
as shown in Fig. C.
NOTE:
• This device should not be used when
your wrist is wounded or injured.
• If it is not possible to use the cuff on
your left wrist, it can also be used
on your right wrist. However, all
measurements should be made using
the same wrist.
START/STOP
MEM
START/STOP
MEM
START/STOP
MEM
START/STOP
MEM
START/STOP
MEM
START/STOP
MEM
Fig. A
Fig. B
START/STOP
MEM
START/STOP
MEM
START/STOP
MEM
Fig. C

15
CORRECT MEASUREMENT POSTURE
1. Place your elbow on a table so that the cuff
is at the same level as your heart as shown
in Fig. A. Relax your entire body, especially
between your elbow and fingers.
NOTE:
Your heart is located slightly below your armpit.
2. If the cuff is not at the same level as your
heart or if you cannot keep your arm
completely still throughout the reading,
use a soft object, such as a folded towel,
to support your wrist as shown in Fig. B.
3. Turn your palm upwards.
4. Sit upright in a chair with feet flat on the
floor and take 5-6 deep breaths. Avoid
leaning back while the measurement is
being taken as shown in Fig. C.
Fig. A
Fig. B
Fig. C
(X)

16
MEASUREMENT PROCEDURE
IMPORTANT NOTES:
• Blood pressure changes with every heartbeat and is in constant
fluctuation throughout the day.
• Blood pressure measurement can be affected by the position of
the user, his or her physiologic condition, and other factors.
Before Measurement:
To help ensure an accurate reading, follow these instructions before
taking a measurement:
• Wait 1 hour after exercising, bathing, eating, drinking beverages
with alcohol or caffeine, or smoking to measure blood pressure.
• Sit quietly and rest for 15 minutes.
• Stress raises blood pressure. Avoid taking measurements during
stressful times.
• Take your reading in a comfortable environment as
measurements can be affected by hot or cold temperatures. Take
your blood pressure at normal body temperature.
During Measurement:
• DO NOT talk or move your arm or hand muscles.
• DO NOT cross your legs. Sit with feet flat on the floor.
• DO NOT touch cuff or monitor during measurement.

17
1. With the cuff wrapped around your wrist, press the “START/
STOP” button. Do not inflate the cuff unless it is wrapped around
your wrist. All digits will light up to check the display functions. The
checking procedure will be completed after about 3 seconds.
2. After all symbols disappear, the display will show “0”. The
monitor is ready to measure and will automatically inflate the
cuff to start measurement.
3. When the measurement is completed, the cuff will deflate
entirely. Systolic pressure, diastolic pressure, and pulse will be
shown simultaneously on the LCD screen. The measurement is
then automatically stored into memory.
NOTE:
• This monitor automatically turns off approximately 1 minute after
last operation. You may also press the “START/STOP” button
to turn the unit off.
• To interrupt the measurement, you may press the “START/
STOP” (recommended) or “MEM” buttons. The cuff will
deflate immediately after this button is pressed.
START/STOP
MEM

18
RISK CATEGORY INDEX
This monitor comes equipped with a Risk Category Indicator that
automatically compares each reading to defined levels established
by the American Heart Association®(AHA 2017) as described earlier
in this manual, and provides a helpful cue if your reading falls into
one of the stages that could potentially indicate increased risk.
Please note that cues provided by this monitor are only intended to
assist you in using this table.
The table is only provided for your convenience to help you
understand your noninvasive blood pressure readings as it relates
to the AHA 2017 information. They are not a substitute for a medical
examination by your physician. It is important for you to consult with
your physician regularly. Your physician will tell you your normal
blood pressure range as well as the point at which you may actually
be considered to be at risk.
Blood Pressure Category
Systolic
mmHg (upper
number)
Diastolic
mmHg
(lower
number)
Indicator
Color
Normal <120 and <80 Green
Elevated 120–129 and <80 Yellow
High Blood Pressure (hypertension) Stage 1 130–139 or 80–89
Red
High Blood Pressure (hypertension) Stage 2 140–180 or 90–120
Hypertensive Crisis (consult your doctor
immediately) >180 and/
or >120
*Source: AHA 2017

19
IRREGULAR HEARTBEAT DETECTOR
The appearance of the icon
indicates that a pulse irregularity
consistent with an irregular heartbeat
was detected during measurement.
Usually this is not a cause for concern.
However, if the symbol appears
often, we recommend you seek
medical advice. Please note that the
device does not replace a cardiac
examination, but serves to detect pulse
irregularities at an early stage.
Movement, shaking, or talking during the measurement can
result in pulse irregularities that may cause the appearance of
this icon. Therefore, it is of great importance to not move or talk
during measurement.
During each measurement, the blood pressure monitor will keep
a record of all the pulse intervals and calculate the average value
of them. If there are 2 or more pulse intervals with 25% or greater
difference, or if there are 4 or more pulse intervals with 15% or
greater difference from the average heartbeat interval, then the
irregular heartbeat symbol will appear on the display with the
measurement result.
Important Information:
This blood pressure monitor is not designed for use by people with
arrhythmias nor for diagnosing or treating an arrhythmia problem.
As a safeguard, we recommend that if you have arrhythmias, such
as atrial or ventricular premature beats and atrial fibrillation or any
other special conditions, you should check with your physician
before using your blood pressure monitor.
Irregular Heartbeat Detector

20
EXCESSIVE BODY MOTION DETECTOR
The icon is displayed if body
movement is detected during
measurement, especially the
movement of the wrist the blood
pressure monitor is worn on.
NOTE:
The measured blood pressure reading may not be accurate if the
icon is displayed.
RECALLING VALUES FROM MEMORY
1. Press the “MEM” button to access the memory.
2. The monitor will first display the calculated average applied to
the last 3 memories. If the records are less than 3, it will display
the latest record instead.
NOTE:
• The average will not include readings where excessive body
motion occurred.
• Every new press of the “MEM” button
will recall a previous reading. The
latest reading will be recalled first.
START/STOP
MEM
Excessive
Body
Motion
Detector
