Walgreens WGNBPW-710 User manual

AUTOMATIC WRIST
Blood Pressure
Monitor
÷5-YHDU
/LPLWHG
Warranty
9HU%
:*1%3W-710
(OPDQXDOHQHVSDŅRO
HPSLH]DHQODSÀJLQD

1
TABLE OF CONTENTS
INTRODUCTORY INFORMATION:
Important Product Notices and
Safety Instructions .......................................... 3
About Blood Pressure..................................... 5
Blood Pressure Standard................................ 5
How This Blood Pressure
Monitor Works ................................................. 7
USAGE INFORMATION:
Name/Function of Each Part ........................... 8
Display Explanations....................................... 9
Installing Batteries ........................................ 11
Date & Time Set Procedure........................... 13
Applying the Cuff........................................... 14
Correct Measurement Posture ..................... 15
Measurement Procedure............................... 16

2
Risk Category Index ...................................... 19
Irregular Heartbeat Detector (IHB) .............. 20
Recalling Values from Memory..................... 21
Clearing Values from Memory...................... 21
Important Notes Regarding Your
Blood Pressure Measurement...................... 22
Care, Maintenance & Cleaning ..................... 23
Potential for Electromagnetic
Interference.................................................... 25
Electromagnetic Compatibility (EMC).......... 26
Troubleshooting............................................. 28
Specifications ................................................ 29
5 Year Limited Warranty................................ 31

3
IMPORTANT PRODUCT NOTICES AND
SAFETY INSTRUCTIONS
When using your blood pressure monitor, basic precautions
should always be followed. Please read and follow all
instructions and warnings before using this product. Save
these instructions for future reference.
t 1MFBTFOPUFUIBUUIJTJTBIPNFIFBMUIDBSFQSPEVDUPOMZ
and it is not intended to serve as a substitute for the
advice of a physician or medical professional.
t 5IJTEFWJDFVTFTUIFPTDJMMPNFUSJDNFUIPEUPNFBTVSF
systolic and diastolic blood pressure, as well as heart rate.
t Do not use this device for diagnosis or treatment of any
health problem or disease. Measurement results are
for reference only. Consult a healthcare professional for
interpretation of blood pressure measurements. Contact
your physician if you have or suspect any medical
problem. Do not change your medications without the
advice of your physician or healthcare professional.
t 5IJTQSPEVDUJTOPUTVJUBCMFGPSQFPQMFXJUIBSSIZUINJBT
This device may have difficulty determining the proper
blood pressure for pregnant women, individuals with
irregular heartbeat, diabetes, poor circulation of blood,
kidney problems or for users who have suffered from a
stroke.
t &YDFTTJWFVTFNBZSFTVMUJOCMPPEGMPXJOUFSGFSFODFXIJDI
is likely to cause uncomfortable sensations, such as partial
subcutaneous hemorrhage, or temporary numbness to
your wrist. In general these symptoms should not last
long. However, if you do not recover in time, please seek
advice from a medical professional.

4
t $POTVMUZPVSQIZTJDJBOCFGPSFNFBTVSJOHCMPPE
pressure at the wrist if you have any of the following
conditions: Severe hypertension, severe diabetes, severe
arteriosclerosis, severe kidney disease or vascular disease
that may compromise circulation.
t 5IFQVMTFEJTQMBZJTOPUTVJUBCMFGPSDIFDLJOHUIFGSFRVFODZ
of heart pacemakers.
t &MFDUSPNBHOFUJDJOUFSGFSFODF5IFEFWJDFDPOUBJOT
sensitive electronic components. Avoid strong electrical or
electromagnetic fields in the direct vicinity of the device (e.g.
mobile telephones, microwave ovens). These may lead to
temporary impairment of measurement accuracy.
t $POTJEFSUIFFMFDUSPNBHOFUJDDPNQBUJCJMJUZPGUIFEFWJDF
FYQPXFSEJTUVSCBODFSBEJPGSFRVFODZJOUFSGFSFODFFUD
Please use this device indoors only.
t 6TFCMPPEQSFTTVSFNPOJUPSPOMZGPSJUTJOUFOEFEVTF
t Do not wrap the cuff around body parts other than your
wrist.
t /PUGPSVTFCZPSPOQFSTPOTVOEFSUIFBHFPG
t Do not use this device on infants, children, or those who
DBOOPUFYQSFTTUIFJSPXOJOUFOUJPO
t 6TFPOMZ7i"""wBMLBMJOFCBUUFSJFTGPSQPXFSTVQQMZ
Blood pressure measurements determined with this device
BSFFRVJWBMFOUUPUIPTFPCUBJOFECZBUSBJOFEPCTFSWFSVTJOH
the cuff/stethoscope auscultatory method, within the limits
prescribed by the American National Standard, Manual,
electronic, or automated sphygmomanometers.

5
ABOUT BLOOD PRESSURE
What is Blood Pressure?
#MPPEQSFTTVSFJTUIFQSFTTVSFFYFSUFEPOUIFBSUFSZ
walls while blood flows through the arteries. The
pressure measured when the heart contracts and
sends blood out of the heart is systolic (highest) blood
pressure. The pressure measured when the heart
dilates with blood flowing back into the heart is called
diastolic (lowest) blood pressure.
Why Measure Your Blood Pressure?
Among today’s various health problems, those associated
with high blood pressure are very common. High blood
pressure dangerously correlates with cardiovascular
diseases. Therefore, blood pressure monitoring is
important for identifying those at risk.
BLOOD PRESSURE STANDARD
The table on page 6 contains defined levels for hypertension
that are publicly available from the National Heart Lung and
Blood Institute at the U.S. National Institutes of Health (NIH)
(http://www.nhlbi.nih.gov/health/dci/Diseases/Hbp/HBP_
WhatIs.html). Users can compare their own blood pressure
readings against these defined levels to determine if they
may be potentially at increased risk.
5IJTUBCMFJTBQQMJDBCMFUPNPTUBEVMUTBHFEBOEPMEFS

6
Blood pressure tends to go up and down, even in people who
normally don’t have high readings. If your numbers stay above
UIFiOPSNBMwSBOHFNPTUPGUIFUJNFZPVNBZCFBUJODSFBTFE
risk and should consult your physician.
Although one can easily find where their own blood pressure
SFBEJOHTGBMMPOUIJTUBCMFUIJTNPOJUPSDPNFTFRVJQQFEXJUI
B3JTL$BUFHPSZ*OEFYUIBUBVUPNBUJDBMMZDPNQBSFTFBDI
reading to the defined levels and provides a helpful cue if
your reading falls into one of the stages that could potentially
JOEJDBUFJODSFBTFESJTL4FFQBHFGPSNPSFJOGPSNBUJPOPO
this feature.
Please note that cues provided by this monitor are only
intended to assist you in using this table. The table and cues
are only provided for convenience to help you understand
your non-invasive blood pressure reading as it relates to
the NIH information. They are not a substitute for a medical
FYBNJOBUJPOCZZPVSQIZTJDJBO*UJTJNQPSUBOUGPSZPVUP
consult with your physician regularly. Your physician will tell
you your normal blood pressure range as well as the point at
which you may actually be considered to be at risk.
Category Systolic (mmHg) Diastolic (mmHg)
Normal -FTTUIBO and -FTTUIBO
Prehypertension  or 
High Blood Pressure
4UBHF  or 
4UBHF PSIJHIFS or PSIJHIFS

7
HOW THIS BLOOD PRESSURE
MONITOR WORKS
This monitor uses innovative technology to detect your
blood pressure. This technology enables the monitor
to automatically inflate and deflate at the appropriate
level for each individual. With one touch of a button,
the cuff will automatically inflate to block the blood flow
UISPVHIZPVSBSUFSZ/FYUUIFEFGMBUJPOQSPDFTTTUBSUT
Please note that any muscle movement during inflation
or deflation will cause measurement error. When
measurement is complete, the monitor will display
your systolic pressure, diastolic pressure, and pulse
readings.
The monitor automatically finds where your measurement
results fall on the NIH’s National Heart Lung and Blood
Institute’s table and provides a cue if your reading falls into
one of the stages that could potentially indicate increased
SJTL4FFQBHFGPSNPSFJOGPSNBUJPOPOUIJTGFBUVSF
The appearance of the icon indicates that a pulse
irregularity consistent with an irregular heartbeat was
EFUFDUFEEVSJOHNFBTVSFNFOU3FGFSUPQBHFGPSNPSF
information on the Irregular Heartbeat Detector.

8
NAME/FUNCTION OF EACH PART
Accessories for unit :
i"""wTJ[F7BMLBMJOF
batteries included with the
unit.
MEMORY
RECALL Button
Wrist Cuff
Battery Cover START/STOP
Button
DATE/TIME
SET Buttons
LCD Display

9
DISPLAY EXPLANATIONS
Systolic
Pressure
Diastolic
Pressure
Date/Time Indicator
Heart Rate

10
Display Symbols:
Weak Battery Symbol: Appears when batteries
should be replaced.
Pulse Symbol: Shows the heart rate per minute.
Irregular Heartbeat Detector:4FFQBHFGPS
more information.
Risk Category Index:4FFQBHFGPSNPSF
information.
Measurement Error: Wrap the cuff correctly and
keep wrist steady during measurement. Measure
again.
Air Circuit Abnormality: Measure again.
Pressure Exceeding 300 mmHg: Switch the unit
off to clear, then measure again.
Error Determining Measurement Data: Measure
again.
System Error: Measure again.
If and any of the following letters and numbers
appear in the area that systolic pressure should be
displayed, an error has occurred with your reading.
See Troubleshooting section of this manual for more
information.

11
INSTALLING BATTERIES
5IFCBUUFSZDPWFSJTMPDBUFEBMPOHUIF
side of the monitor. Remove battery
cover by pressing down and pulling
away from the monitor.
*OTUBMMCBUUFSJFTBDDPSEJOHUPUIF
polarity indications inside the
DPNQBSUNFOUBTTIPXOJOGJHVSF
Battery Type: 2 Alkaline LR03
“AAA” size
*OTFSUUIFPUIFSCBUUFSZBDDPSEJOH
to the polarity indications inside the
DPNQBSUNFOUBTTIPXOJOGJHVSF
3FQMBDFUIFDPWFSCZJOTFSUJOHJU
back into place.





12
Replace the batteries if:
t5IFXFBLCBUUFSZTZNCPMBQQFBSTPOUIFEJTQMBZ
t/PUIJOHBQQFBSTPOUIFEJTQMBZXIFOUIFQPXFSJT
switched on.
As the supplied batteries are for test only, they may
be discharged earlier than batteries you buy in stores.
Replace all batteries at one time (as simultaneous set).
6TFPOMZ7i"""wBMLBMJOFCBUUFSJFT3FNPWFCBUUFSJFT
XIFOUIFVOJUJTOPUJOVTFGPSFYUFOEFEQFSJPETPG
time. Date and time will need to be reset if batteries are
removed or replaced. Clean contacts on battery and in
battery compartment with a soft dry cloth each time you
install batteries.
Note:
#BUUFSJFTBSFIB[BSEPVTXBTUF%POPUEJTQPTFPGUIFN
together with the household garbage.

13
DATE & TIME SET PROCEDURE
5PBEKVTUUIFEBUFBOEUJNFQSFTTUIFDATE/TIME SET
button located on the top of the monitor.
5IFEJTQMBZXJMMTIPXBCMJOLJOHOVNCFSTIPXJOHUIF
HOUR. Change the HOUR by pressing the button.
Each press will increase the number by one in a cycling
manner. Press the DATE/TIME SET button again to
confirm the entry, and the screen will show a blinking
number representing the MINUTE.
$IBOHFUIF.*/65&.0/5)%":BOE:&"3BT
EFTDSJCFEJO4UFQBCPWFVTJOHUIF button to
change the numbers and the DATE/TIME SET button
to confirm the entries.
Press the button
blinking HOUR
increasing HOUR
confirm the entry
repeat process to set MINUTE,
MONTH, DAY and YEAR

14
APPLYING THE CUFF
3FNPWFBMMXBUDIFTXSJTUKFXFMSZFUDQSJPSUPBUUBDIJOH
the wrist monitor. Clothing sleeves
should be rolled up and the cuff should
be wrapped around bare skin for
correct measurements.
"QQMZDVGGUPMFGUXSJTUXJUIQBMNGBDJOH
up as shown in Fig. A.
.BLFTVSFUIFFEHFPGUIFDVGGJTBCPVU
w_wDNGSPNUIFQBMNBT
shown in Fig. B.
*OPSEFSUPFOTVSFBDDVSBUF
measurements, fasten the hook and
loop strap securely around your wrist so
UIFSFJTOPFYUSBTQBDFCFUXFFOUIFDVGG
and the wrist. If the cuff is not wrapped
tight enough, the measurement values
will not be accurate.
*GZPVSQIZTJDJBOIBTEJBHOPTFEZPV
with poor circulation in your left arm,
place the cuff around your right wrist as
shown in Fig. C.
Note:
t5IJTEFWJDFTIPVMEOPUCFVTFEXIFOZPVSXSJTUJT
XPVOEFEPSJOKVSFE
t*GJUJTOPUQPTTJCMFUPVTFUIFDVGGPOZPVSMFGUXSJTU
it can also be used on your right wrist. However, all
measurements should be made using the same wrist.
Fig. A
Fig. B
Fig. C

15
CORRECT MEASUREMENT POSTURE
1MBDFZPVSFMCPXPOBUBCMF
so that the cuff is at the same
level as your heart as shown in
'JH"3FMBYZPVSFOUJSFCPEZ
especially between your elbow
and fingers.
Note: Your heart is located
slightly below your armpit.
*GUIFDVGGJTOPUBUUIFTBNF
level as your heart or if
you cannot keep your arm
completely still throughout the
reading, use a TPGUPCKFDUsuch
as a folded towel to support
your wrist as shown in Fig. B.
5VSOZPVSQBMNVQXBSET
4JUVQSJHIUJOBDIBJSBOEUBLF
EFFQCSFBUIT
Avoid leaning back while the
measurement is being taken as
shown in Fig. C.
Fig. A
Fig. B
Fig. C
(X)

16
MEASUREMENT PROCEDURE
Important Notes:
t1PTJUJPOUIFNPOJUPSBUUIFTBNFMFWFMBTZPVSIFBSU
during measurement to ensure accurate readings.
t#MPPEQSFTTVSFDIBOHFTXJUIFWFSZIFBSUCFBUBOEJTJO
constant fluctuation throughout the day.
t#MPPEQSFTTVSFNFBTVSFNFOUDBOCFBGGFDUFECZUIF
position of the user, his or her physiologic condition
BOEPUIFSGBDUPST'PSHSFBUFTUBDDVSBDZXBJUIPVS
BGUFSFYFSDJTJOHCBUIJOHFBUJOHESJOLJOHCFWFSBHFT
with alcohol or caffeine, or smoking to measure blood
pressure.
t#FGPSFBNFBTVSFNFOUJUJTTVHHFTUFEUIBUZPVTJU
RVJFUMZGPSNJOVUFTBTNFBTVSFNFOUTUBLFOEVSJOH
BSFMBYFETUBUFXJMMIBWFHSFBUFSBDDVSBDZ:PVTIPVME
OPUCFQIZTJDBMMZUJSFEPSFYIBVTUFEXIJMFUBLJOHB
measurement.
t%VSJOHUIFNFBTVSFNFOUEPOPUUBMLPSNPWFZPVS
arm or hand muscles.
t4FFQBHFGPSBEEJUJPOBMOPUFTSFHBSEJOHZPVS
blood pressure measurement.
If you are using this blood pressure monitor for the first
time, please remove the protective film from the screen.

17
8JUIUIFDVGGXSBQQFEBSPVOEZPVSXSJTUQSFTTUIF
START/STOP button. Do not inflate the cuff unless
it is wrapped around your wrist. All digits will light
up, checking the display functions. The checking
QSPDFEVSFXJMMCFDPNQMFUFEBGUFSBCPVUTFDPOET
 "GUFSBMMTZNCPMTEJTBQQFBSUIFEJTQMBZXJMMTIPXiw
The monitor is “Ready to Measure” and will
automatically inflate the cuff to begin measurement.
The cuff will then begin deflating as measurement
continues.
Note:
The monitor will re-inflate automatically if the system
EFUFDUTUIBUZPVSCPEZSFRVJSFTNPSFQSFTTVSFGPS
measurement.

 8IFOUIFNFBTVSFNFOUJTDPNQMFUFEUIFDVGG
will deflate entirely and systolic pressure, diastolic
pressure and pulse will be shown simultaneously
on the LCD screen. The measurement is then
automatically stored into memory.
Note:
t5IJTNPOJUPSBVUPNBUJDBMMZUVSOTPGGBQQSPYJNBUFMZ1
minute after last operation. You may also press the
START/STOP button to turn the unit off.
t5PJOUFSSVQUUIFNFBTVSFNFOUZPVNBZQSFTT
the START/STOP button (recommended), the
MEMORY button or DATE/TIME SET ( )
buttons. The cuff will deflate immediately after a
button is pressed.
18

19
RISK CATEGORY INDEX
5IJTNPOJUPSDPNFTFRVJQQFEXJUIB3JTL$BUFHPSZ
*OEFYUIBUBVUPNBUJDBMMZDPNQBSFTFBDISFBEJOH
to defined levels established by the U.S. National
Institutes of Health’s (NIH) National Heart Lung and
Blood Institute as described earlier in this manual,
and provides a helpful cue if your reading falls into
one of the stages that could potentially indicate
increased risk. No cue is given if the reading falls in
the normal range as defined by NIH. Please note that
cues provided by this monitor are only intended to
assist you in using this table. The table and cues are
only provided for convenience to help you understand
your non-invasive blood pressure reading as it relates
to the NIH information. They are not a substitute for a
NFEJDBMFYBNJOBUJPOCZZPVSQIZTJDJBO*UJTJNQPSUBOU
for you to consult with your physician regularly. Your
physician will tell you your normal blood pressure
range as well as the point at which you may actually
be considered to be at risk.
(No Symbol)
