Walker Edison B44DIAZ User manual

Insert wooden dowel (A) into parts (3,4,5), and secure cam bolt (B) into parts (3,5) with
Philips head screwdriver as per diagram.

Insert wooden dowel (A) into parts (1,6), and secure cam bolt (B) into parts (1,6) with
Philips head screwdriver as per diagram.

Using cam lock (C) secure part (1) to part (6) with Philips head screwdriver as per diagram.

Using cam lock (C) secure part (3) to parts (1,6) with Philips head screwdriver as per diagram.

Using cam lock (C) secure part (5) to parts (1,6) with Philips head screwdriver as per diagram.

Using screw (G) secure plastic wedge (F) to parts (1,3,5,6) with Philips head screwdriver
as per diagram.

Using cam lock (C) secure part (4) to part (1) with Philips head screwdriver as per diagram.

Using screw (E) attach part (2) to parts (3,4,5,6) with hex key (K) as per diagram.

Using bolt (H) attach part (7) to part (8) with hex key (K) as per diagram.

Using bolt (J) attach part (7) to part (2) with hex key (K) as per diagram.

Place sticker (D) cover the holes as per diagram.

Put part (9) on the top of part (1) as per diagram.
