Walker Edison BTODSP User manual

Item #: BTODSP
Assembly Instructions
Revised 06/2012

Instruction Manual
IMPORTANT INFORMATION
READ BEFORE ASSEMBLING THIS PRODUCT
Follow the information on the warning labels found on the bunk bed and on the packaging. Do not
remove the warning labels from the bed.
Use only a mattress with the dimensions 74-75 in.L x 37.5-38.5 in.W x 6 in.H on the upper bunk.
The surface of the mattress must be at least 5 in. (127mm) below the upper edge of the guardrails.
Mattress must not exceed the maximum thickness of 6 in.
Always use the recommended size of mattress or mattress support, or both, to help prevent the
likelihood of entrapment or falls.
The use of a water or sleep flotation mattress is prohibited.
Replacement parts, including additional guardrails, may be obtained from any of Walker Edison
Furniture Company’s dealers or by contacting us online at www.walkeredison.com.
DO NOT use substitute parts. Contact the manufacturer or dealer for replacement parts.
Always use guardrails on the upper bunk. If the bunk bed will by placed next to a wall, the guardrail
running the full length of the bed should by placed against the wall to prevent entrapment between
the bed and the wall.
Periodically check that the guardrails, ladders and other components of the bed are in their proper
position, free from damage and that all connectors are tight.
Always use the ladder to access the upper bunk.
DO NOT allow children under 6 years of age to use the upper bunk.
DO NOT allow horseplay on or under the bed. Prohibit jumping on the bed.
Prohibit more than one person on the upper bunk.
The use of a night light may provide an added safety precaution for a child using the upper bunk.
STRANGULATION HAZARD – Never attach or hang items to any part of the bunk bed that are not
designed for use with the bed; including but not limited to hooks, belts and jump ropes.
Keep these instructions for future reference.

Parts List
18
18
12
11
20

Hardware List
Bolt
Bolt
Bolt
Double-ended bolt

Assembly Options
Option A - Ladder Left
To build this option follow Steps 1-11
and Steps 12A-16A.
Option B - Ladder Right
To build this option follow Steps 1-11
and Steps 12B-16B.

Attach guardrail (13) and crossbar (11) to posts (1,4) using bolts (A). Tighten bolts (A) with wrench (G).Please
note the position of all pre-drilled holes as shown above before attaching bunk bed parts together.
Attach second guardrail (13) and crossbar (12) to posts (2,3) using bolts (A). Tighten bolts (A) with wrench (G).
Please note the position of all pre-drilled holes as shown above before attaching bunk bed parts together.
11
12

Attach support leg (17) to crossbar (16) using bolts (A). Tighten bolts (A) with wrench (G).
Attach crossbar (7) to post (1), crossbars (8,10) to post (4) and crossbar (16) to crossbar (11) using bolts (A).
Please note the position of all pre-drilled holes as shown above before attaching bunk bed parts together.
Tighten bolts (A) with wrench (G).
11

Attach opposite end of crossbar (7) to post (2), opposite ends of crossbars (8,10) to post (3) and opposite end
of crossbar (16) to crossbar (12) using bolts (A). Please note the position of all pre-drilled holes as shown
above before attaching bunk bed parts together. Tighten bolts (A) with wrench (G).
12

Roll mattress support slats (19) out along the upper bunk and secure them to the upper bunk using anchors (F)
and bolts (A) where indicated above. Bolts (A) will screw directly into crossbars (7,8). Tighten bolts (A) with
Attach guardrail (18) to posts (3,4) using bolts (A). Secure guardrail (18) to crossbar (8) using bolts (B). Tighten
all bolts (A,B) with wrench (G).
wrench (G).
7
8
18

Attach second guardrail (18) to posts (1,2) using bolts (A). Secure guardrail (18) to crossbar (7) using bolts (B).
Tighten all bolts (A,B) with wrench (G).
Attach extension leg (5) to post (1) and extension leg (6) to post (2) using bolts (A). Tighten bolts (A) with
wrench (G).
18

Attach crossbar (9) to extension legs (5,6) using bolts ( B). Tighten bolts (A,B) with wrench (G).
Roll mattress support slats (20) out along the lower bunk and secure them to the lower bunk using anchors (F)
and bolts (A) where indicated above. Bolts (A) will screw directyly into crossbars (9,10). Tighten bolts (A) with
9
10
wrench (G).
A,
20

Screw double-ended bolts (D) into post (4).
Slide washers (E) onto double-ended bolts (D). Screw ladder rungs (15) onto double-ended bolts (D).
rungs (15) will fit into washers (E).
Ladder

Fit washers (E) onto opposite ends of ladder rungs (15). Attach ladder support rail (14) to ladder rungs (15)
using bolts (C). Tighten bolts (C) with wrench (G).
Secure ladder support rail (14) to guardrail (13) using bolt (A) and to crossbar (11) using bolt (B). Tighten bolts
(A,B) with wrench (G).
11

Option A
Final Assembly

Screw double-ended bolts (D) into post (3).
Slide washers (E) onto double-ended bolts (D). Screw ladder rungs (15) onto double-ended bolts (D).
rungs (15) will fit into washers (E).
Ladder

Fit washers (E) onto opposite ends of ladder rungs (15). Attach ladder support rail (14) to ladder rungs (15)
using bolts (C). Tighten bolts (C) with wrench (G).
Secure ladder support rail (14) to guardrail (13) using bolt (A) and to crossbar (12) using bolt (B). Tighten bolts
(A,B) with wrench (G).
12

Option B
Final Assembly
