Assembly Instructions
P.1
Revised 11/2022 V-1
Item # : BR20BRXNS
2018

P.2
I. Ensure that all parts and hardware are available before beginning assembly.
II. Follow each step carefully to ensure the proper assembly of this product.
III. Two people are recommended for ease in the assembly of this product.
IV. The three main types of hardware used to assemble this product are wood
dowels, screws and bolts.
V. The provided glue is to secure wood dowels in place. When first inserting dowels, locate
the appropriate hole for the dowel, place a small amount of glue in the hole and insert
the dowel. Wipe away excess glue immediately.
In future assembly steps when dowels are necessary to attach assembly parts together,
place a small amount of glue on the end of the dowel before attaching parts together.
Wipe away excess glue immediately.
VI. A Phillips head screwdriver and hammer is required for the assembly of this product.
VII. Power tools should not be used to assemble this product.
VIII. Maintenance Guide
To maintain long term performance and easy gliding of your solid wood drawers, we recommend
applying wax to the wooden guide rails.
1. Bee's wax is recommended or Paraffin wax from a standard candle can be used.
2. Apply the wax by rubbing it on the wooden guide rails where there is wood-on-wood contact
when opening and closing the drawer. (Wax should be room temperature, do not melt the wax
onto the wood)
3. Wax should be applied every few months for the first year and then only when needed after
that to keep the drawers sliding smoothly.
General Assembly Guidelines

Right side panel
Top panel
Back panel
Left side panel
Bottom panel
1
2
3
4
7
01
01
01
01
01
Upper drawer front
10 01
Left drawer side
11 02
Foot
8 04
Right drawer side
Drawer back
Drawer bottom
12
13
14
02
02
02
Description QtyPart# Description QtyPart#
Parts List
P.3
1
2
3
4
10
15
7
8
8
8
8
9
9
9
916
16
11
12
13
14
11
12
13
14
Drawer runner
9 04
Lower drawer front
15 01
Drawer handle
16 02

Tape measure and hammer
recommended for assembly
(not included)
A
B
C
D
E
F
Ø8*30mm Wood dowel 28 pcs
08 pcs
Screw 08 pcs
Ø3,5*30mm Screw 22 pcs
Ø4,0*40mm Screw 06 pcs
Ø10*10 Nail 16 pcs
Ø7*60mm Screw
4mm Hex Key
G04 pcs
H01 pcs
I Glue 01 pcs
Ø8*20mm Wood dowel
Ø4,0*25mm
JScrew 04 pcs
Ø4,5*30mm
P.4
Hardware List

AØ8*30mm 20
I01
Please assemble on
a clean soft surface
to avoid damage.
P.5
A
A
A
11
2x
B
B
9
4x
Insert wood dowel (A) and glue (I)
into parts (2, 3, 11, 12).
Insert wood dowel (B) and glue (I) into part (9).
12
2x A
A
2
3
A
A
A
A
A
A
A
A
A
A
A
A
Step 1 Attention to the
dowel size:
Ø8*20mm
Step 2
BØ8*20mm 08
I01

Step 3
Step 4
P.6
Fix the part (4) to the parts (2, 3) with screws (E)
E
Ø4,0*40mm 06
Ø7*60mm
4mm
G04
H01
Use screw (G) and hex key (H) to attach the feet
to the body.
E
E
E
4
2
3
H
G
G+H
8
E
E
E
G+H
8
8
8

Step 5
Step 6
FØ10*10 16
Secure back panel (7) to body with nails (F)
P.7
Use screw (D) to attach
part (1) to body
D
Ø3,5*30mm 06
F
7
1
D
D
F
F
F
F
F
F
F
F
F
F
F
F
F
D

Step 7
Step 8
C
Use the screw (C) to attach the parts (9) to the parts (2,3)
NOTE: The extra holes in the part (9) must be top
Insert wood dowel (A) into the front hole
in the drawer rails (9)
A
FRONT
P.8
Ø4,0*25mm 08
AØ8*30mm 04
A
FRONT
2
C
9
C
9
9
9
9
C
C
C
C
A
A
A

Step 9
Step 10
P.9
DD
D
D
12
11
DD
DD
13
14
10
DD
D
12
11
DD
DD
13
14
15
DØ3,5*30mm 08
NØ4,5*30mm 02
while attach parts (16) to part (10),
with screws(N), using the
predrilled holes.
2nd -Attach parts (11,12)
3th - Insert panel (13) into groves.
N
16
10
DØ3,5*30mm 08
NØ4,5*30mm 02
N
16
15
N
N
10
16
and secure part (14) with screws (D)
to part (10), with screw (D)
and philips screwdriver
1st - Hold the front of the drawer
so it doesn't become unsettled,
and philips screwdriver
2nd -Attach parts (11,12)
to part (15), with screw (D)
and philips screwdriver
N
N15
16
while attach parts (16) to part (15),
with screws(N), using the
predrilled holes.
1st - Hold the front of the drawer
so it doesn't become unsettled,
3th - Insert panel (13) into groves.
and secure part (14) with screws (D)
and philips screwdriver

Step 11
P.10
AØ8*30mm 04
A
A
A
10
15
40
lbs
24
lbs
Insert wood dowel (A) on the inside of the drawers, with the drawer inside the unit,
after having passed the wood dowel that is in the drawer runner.
Make sure the wood dowel is flush with the panel.
Assembly Complete!
