Walker Edison W48CLCR2D User manual

Insert wooden dowel (A) into parts (5,6,8,9,10,11) as per diagram.

Insert wooden dowel (A) into parts (3,4,12,13) ,and using cam bolt (B) into parts (1,3,4,12,13)
with Philips head screwdriver as per diagram.

Using cam lock (C) secure parts (10,11) into parts (3,4,12,13)with Philips head screwdriver as per
diagram.

Using bolt (J) secure part (2) into parts (3,4,12,13)with hex key (M) as per diagram.

Step 5
6
d
(; 三，
9J

：心
＼
J九
Copyright©2019, by Walker Edison Furniture Co., LLC. All rights reserved.
P.9
Using bolt (J) secure part (2) into parts (5,6,8,9) with hex key (M) as per diagram.

Step 6
Copyright©2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.10
M
Using bolt (N) secure part (15) into parts (2) with hex key (M) as per diagram.

Put part (7) into parts (6,8) as per diagram.

Using cam lock (C) secure part (1) into parts (3,4,6,8,12,13) ,using cam lock (D) secure parts (5,9)
with Philips head screwdriver as per diagram.

Using screw (Q) secure plastic wedge (P) into back panel as per diagram.

Place sticker (E) cover the holes as per diagram.

Insert shelf support pin (H) into parts (12,13) as per diagram.

insert part (14) into parts (12,13) as per diagram.

Using screw (L) secure handle (K) into part (16) with Philips head screwdriver as per diagram.

Using screw (G) secure hinge (F) into part (16) with Philips head screwdriver as per diagram.

Using screw (G) secure hinge (F) into parts (13,16) with Philips head screwdriver as per diagram.

Using screw (G) secure hinge (F) into parts (12,16) with Philips head screwdriver as per diagram.
