Assembly Instructions
P.1
Revised 10/2018
Item # : BR2DSLNS
2018
P.2
VIII. Maintenance Guide
To maintain long term performance and easy gliding of your solid wood drawers, we recommend
applying wax to the wooden guide rails.
1.Bee's wax is recommended or Paraffin wax from a standard candle can be used.
2.Apply the wax by rubbing it on the wooden guide rails where there is wood‐on‐wood contact
when opening and closing the drawer. (Wax should be room temperature, do not melt the wax
onto the wood)
3.Wax should be applied every few months for the first year and then only when needed a?er
that to keep the drawers sliding smoothly.
P.3
Right side panel
Top panel
Back panel
Left crossbeam foot
Left side panel
Bottom panel
1
2
3
4
5
6
7
01
01
01
01
02
02
01
Drawer runner
Lower drawer front
Left drawer side
9
10
11
04
01
02
Drawer bottom
Right drawer side
12
13
02
02
Drawer back
14 02
Right crossbeam foot
Description QtyPart# Description QtyPart#
Foot
8 04
Upper drawer front
15 01
1
2
3
4
5
5
6
6
8
8
8
8
9
9
9
9
7
10
11
12
13
14
14
13
12
11 15
P.4
Tape measureand hammer
recommendedfor assembly
(not included)
A
B
C
D
E
F
Ø8*30mm Wooden dowel 32 pcs
16 pcs
Screw 08 pcs
Ø3,5*30mm Screw 26 pcs
Ø4,0*40mm Screw 14 pcs
Ø10*10 Nail 14 pcs
Ø7*80mm Bolt
4mm Hex Key
G04 pcs
H01 pcs
I Glue 01 pcs
Ø8*20mm Wooden dowel
Ø3,5*25mm
P.5
Step 1 Please assemble on
a clean soft surface
to avoid damage.
AØ8*30mm 32
I01
Insert wood dowel (A) and glue (I)
into parts (2, 3, 5, 6, 11, 12).
Insert wood dowel (B) and glue (I)
into part (9).
BØ8*20mm 08
B
B
4x
9
A
A
A
A
2x
2x
A
12
11
A
A
A
A
AA
2x
2x
6
5
A
A
A
A
A
A
A
A
A
A
A
A
2
3
Step 2
P.6
Step 4
D
E
E
E
E
E
E
D
DØ3,5*30mm 04
2x
2x
D
EØ4,0*40mm 06
Ø7*80mm
4mm
G04
H01
EØ4,0*40mm 08
Use screw (E) to a?ach
parts (2,3) to part (4)
Use screw (D) to aach part (5) to part (8)
and aach part (6) to part (8), do this step twice
3
2
4
8
8
5
6
G+H
E
E
E
EE
E
E
H
G
G+H
5
6
Step 3
Attach leg to body.secure feet to the body
from inside the unit with bolt (G) and hex key (H).
Use screw (E) to secure legs to body
Step 6
D
D
D
D
D
DØ3,5*30mm 06
Aach part (1) to body
using screw (D)
1
F
FØ10*10 14
Aach back panel (7)
to the body using nails (F)
7
F
F
F
F
F
F
F
F
FFF
FF
Step 5
P.7
Step 7
C
2
FRONT
C
C
9
C
C
9
C
C
9
C
C
9
3
Use screw (C) to aach parts (9) to parts (2,3)
NOTE: The extra holes in part (9) should
face the top of parts (2,3)
CØ3,5*25mm 08
Step 8
Insert wood dowel (B) into the
front hole in the drawer rail (9).
BØ8*20mm 04
B
FRONT
B
B
B
B
P.8
P.9
Step 12
Step 10
DD
DDDD
DD
DD
DD
DD
DD
DØ3,5*30mm 08
Aach parts (11,12) to part (15) , insert panel (13)
into groves and secure part (14) with screws(D).
DØ3,5*30mm 08
Step 11
15
12
11 13
14
10
12
11 13
14
A?ach parts (11,12) to part (10) , insert panel (13)
into groves and secure part (14) with screws(D).
BØ8*20mm 04
10
15
B
B
B
Assembly Complete!
Insert wood dowel (B) on the
inside of all drawers while
drawer is inside the unit.
Make sure dowel is flush with panel.
