Walker Edison BU42ARC2D User manual

P.1
Copyright
202
0b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
Please visit our websitefor the most current instructions, assemblytips, report damage,
or request parts. www.walkeredison.com
Revised 07/05/2020 (I)
Walker Edison
TM
AssemblyInstructions
Item#:BU42ARC2D

P.3
Parts List
1
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
2
3
6
7
7
4
5
8
8
9
9
10
11
11
12
12

P.4
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
HardwareList
The hardware quantities listed above are required for proper assembly.
Someextrahardware may also have been included.
Philipsheadscrewdriverrequiredforassembly
(notincluded)
Ø8x30mm WoodendowelA 24 pcs
Ø6x35mm CamboltB 16 pcs
Ø15x11mm CamlockC 16 pcs
Ø30mm StickerD 16 pcs
Ø6x50mm ScrewE 10 pcs
Ø6x12mm BoltF 16 pcs
M4 HexkeyG 1 pc
HandleH 2 pcs
Ø4x19mm HandleBoltJ 2 pcs
Ø3x17mm ScrewK 6 pcs
PlasticwedgeL 6 pcs
Europehinge
M
4pcsN
Shelf supportpinP 8 pcs
Q
RØ4x25mm Screw 1 pc
Plasticstrap 1 pc
Nut 1 pc
Ø3.5x14mm Screw 24 pcs
Ø4x12mm Screw 1 pc
S
T
1 pcU Gluetube

Secure cam bolt (B) into part (1) with Philips head screwdriver as per diagram.

Insert wooden dowel (A) into parts (3,4), then secure cam bolt (B) into parts (3,4) with Philips head
screwdriver as per diagram.

Insert wooden dowel (A) into parts (5,6,8) as per diagram.

P.8
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
Step 4 21 3
4
8
8
C
CC
C
Finished edge
Using cam lock(C) secure part (8) to part (4) with Philips head screwdriver as per diagram.

Using cam lock(C) secure part (3) to part (8) with Philips head screwdriver as per diagram.

P.10
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
Step 6
2
E
G
3
4
5
6
Using screw (E) attach part (2) into parts (3,4,5,6) with hex key (G) as per diagram.

Put part (10) as per diagram.

P.12
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
Step 8
2
12
G
F
12
FF
Using bolt (F) attach part (12) to part (2) with hex key (G) as per diagram.

Using cam lock(C) secure part (1) to parts (3,4,5,6) with Philips head screwdriver as per diagram.

Using screw (K) secure plastic wedge (L) with Philips head screwdriver as per diagram.

P.15
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
Step 11
7
7
8
8
E
G
2
Put part (7) as per diagram.Using screw (E) attach part (2) into parts (7) with hex key (G) as per
diagram.

P.16
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
Step 12
D
D
D
D
D
Place sticker (D) cover the holes as per diagram .

Insert shelf support pin (P) into parts (4,5,6) as per diagram. Make sure you place the four shelf
support pins (P) in the same level. So the shelf is not titled .Put part (9) into unit as per diagram.
Tilt and rest the adjustable shelf (9) onto the shelf support pins .

Using handle bolt (J) attach part (11) into handle ,then using screw (M) attach Europe hinge (N)
into part (11) with Philips head screwdriver as per diagram.

Using screw (M) attach Europe Hinge (N) into part (4) with Philips head screwdriver as per diagram.

Using screw (M) attach Europe Hinge (N) into part (6) with Philips head screwdriver as per diagram.
