Walker Edison D48CA1 User manual

D48CA1
Revised 02/2016

Insert the cam bolts (B) to the top (1) and bottom panel (2).
Insert the wooden dowel (A) to the side panel (3,4,5,6). Insert the cam bolts (B) to the
drawer front panel (8).

Released the drawer tray arms as per diagram.
Assemble the drawer tray arms (K) to the drawers side panel (10,11).

Assemble the side panel (3,4,5,6) to the bottom panel (2) and secure it with cam locks (C).
Place the top panel (1) on top of the side panels (3,4,5,6) and secure it with cam locks (C).

Attached the chrome legs (13) to the bottom panel (2) and secure it with washer (D),
spring washer (E), bolts (D) and wrench (L).
Attach the back panel (7) to the desk and secure it with screw (G).

Assemble the drawer tray arms (J) to the side panel (3,4,5,6) and secure it with screw (J).
Assemble the drawer side panel (10,11) to the drawer back panel (9) with screw (H).

Slot in the drawer bottom panel (12) to drawer side panel (10,11) and use cam locks (C)
to secure the drawer front panel (8) to the drawer side panel (10,11).
Use sticker (M) to cover the cam locks of the drawers.

Assemble the drawers as per diagram.
