Walker Edison W70CS2D User manual

Item # : W70CS2D
Assembly Instructions
 
 .eredison.com

   P.1

Insert wooden dowel (A) to part (2,15). Insert cam bolt (C) to part (1,15).
Insert wooden dowel (A) to part (3,4,5,10). Attach door stopper (O) to part (10) using screw
(P) with screwdriver.

Insert wooden dowel (A) and cam bolt (C) to part (6,7,8,9).
Attach part (8,9) to part (3), then insert and secure cam lock (B) to part (3) to lock it.

Attach part (6,7) to part (3), then insert and secure cam lock (B) to part (3) to lock it.
Attach part (18) to part (2) using bolt (G) with hex key (R).

Attach part (15) to part (4,5), then insert and secure cam lock (B) to part (4,5) to lock it.
Attach part (4.5) to part (2) using bolt (G) with hex key (R).

Attach part (10) to part (4,5).
Attach part (8,9) to part (2,10), then insert and secure cam lock (B) to part (2,10) to lock it.

Attach part (6,7) to part (2,10), then insert and secure cam lock (B) to part (2,10) to lock it.
Slide back panel (11,12) into grooves as per diagram.

Attach part (1) to frame, then insert and secure cam lock (B) to frame to lock it.
Attach plastic wedge (E) to part (11,12) using screw (F) with screwdriver.

Place sticker (D) over holes as per diagram.
Insert shelf support pin (H) into side panel (3,4,5), then place part (13,14) on top of support
pin (H).

Attach hinge (N) to part (16,17) using screw (I,J), handle (L) using bolt (K), and door plate (M)
using screw (Q) with screwdriver.
Attach part (16,17) to part (3) to secure hinge (N) using screw (I) with screwdriver.
