Walker Edison HT72URB User manual

Item#: HT72URB
Assembly Instructions
  
 

    P.1

Use wrench (P) to secure shelf frame (6) to side frame (2) with bolt (E) through fixed L shape
bracket.
Use wrench (P) to secure part (5) to side frame (2) with bolt (A).

Insert parts (1) into side frame (2).
Use wrench (P) to secure parts (1) with bolt (E).

Use wrench (P) to secure part (4) to parts (1) with bolt (C).
Use wrench (P) to secure three front cross bar (3) to parts (1) with bolt (D), and secure L shape
bracket (K) and bolt (D) to last cross bar(3) to parts (1).

Use wrench (P) to secure seat panel (8) to side frame (2) with bolt (B).
Screw feet (O) on to frame as per diagram.

Use wrench (J) to secure support bar (7) with bolt (G) and nut (H).
Secure support bar (7) to side frame (2) with screw (F).

Place unit in desired location and mark the wall for anchor location. Insert plug (L) into wall as
per diagram.
Secure product to wall with screw (M), washer (N) through L shape bracket (K) and plug (L).
