Wampat D01D1072 User manual

D01D1072
Assembly Instructions

Tips for Cushions
1
3
OK
2
In order to compress the package, we put the cushions in
the gap of some parts. So there may be crinkle on the fabric.
Don’t worry. Just flap every corner of the cushion evenly and
it will get back into its original shape soon.
IMPORTANT, RETAIN FOR
FUTURE REFERENCE:
READ CAREFULLY.
Safety
For domestic use only.
Don't tighten all the bolts before the product is fully assembled.



Periodic structural checks of this product should be
It would be useful to ask someone to help you assemble
the product.
undertaken, do not use if you have any doubts about its
Do not stand on the seat.
Do not sit on the armrest.
Do not let children play with this product.
Maximum load per seat: 250 lbs.
At the beginning of the season

product are secure, do not use if you have any doubts
At the end of the season
This product should be stored under cover during
prolonged spells of adverse weather (wet or cold) and
also during the winter (ideally in a garden shed or
garage).
Always clean and dry thoroughly before storage.

WHAT’S IN THE BOX WHAT’S IN THE BOX
M6* 35
M6* 15
1 2
A1 x2 A2 x2
A4 x2A3 x2
B1 x1
B4 x1
B2 x2
B3 x2
C1 x2 C2 x2
C3 x2
D x2
F x2
E x2
C4 x2
J x1
H x30
G x8
I x38

Final Assembly
3 4
1 3
2
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
NOTE:If any screw holes cannot be aligned,
loosen all the screws and go back step 1
and restart assembly.Finally, please tighten
all the screws.
H
I
A1
A4
A3
H
I A2
E
D

5 6
4 6
Final Assembly
5
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
NOTE:If any screw holes cannot be aligned,
loosen all the screws and go back step 1
and restart assembly.Finally, please tighten
all the screws.
H
I
H
I
C2
C3
C4
C1
F

7 8
7 8
Final Assembly
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
NOTE:If any screw holes cannot be aligned,
loosen all the screws and go back step 1
and restart assembly.Finally, please tighten
all the screws.
B1
B2
B2
B3
B3
G
I
B4
G
I
