Wampat W06F4051W User manual

W06F4051W
Assembly Instructions
Please read this manual carefully before beginning assembly of this product.Keep this manual for future reference.

1-1

1
1
2
3
4
5
6
6
7
8
9
9
10
11
15
15
14
14
12
12
13
13

２
Wooden dowel
Ø8x30mm
Cam bolt
Ø6x35mm
Cam lock
Ø15x11mm
Sticker
Philips head screwdriver
required for assembly
(not included)
1 2
● The provided glue(G) is to secure wood
dowels(A) in place . When first inserting
dowels, locate the appropriate hole for the
dowel , place a small amount of glue in the
hole and insert the dowel . Wipe away
excess glue immediately.
● In future assembly steps when dowels are
necessary to attach assembly parts together,
place a small amount of glue on the end of
the dowel before attaching parts together.
Wipe away excess glue immediately.
1 2
Ø4x44mm
Screw
Plastic wedge
screw
Ø3x12mm Handle
Ø4x25mm
Screw
Plastic strap
Cam lock
Ø15x9mm
Glue tube
Ø5/32"x12mm
Handle bolt
Flat-head screw
Ø3x17mm
Drawer slider
Ø4x32mm
Screw
Footpads Ø4x12mm
Screw
Nut
A B CD
EF
JK
G
S
H
IL
P
Q
M N O
R
x 24 x 20 x 12 x 8
x 20 x 4 x 1 x 2
x 24 x 4 x 2 x 16
x 1
x 8 x 8 x 4 x 1
x 1 x 1

３
1
· Screw Cam bolts (B) into panels (4,5,6).
· Insert dowels (A) into panels (4,5).
· Attach panels (6) to panels (4,5).
· Insert and secure cam locks (C) to panels (4,5) to lock it. Ø8x30mm Ø15x11mmØ6x35mm
4
5
6
B
A
C
5
4
BA C
6
1 2 3
x 8
x 4 x 4

4
2
Ø8x30mm Ø4x32mm
· Insert dowels (A) into panels (4,5).
· then attach panels (9) to panels (4,5) using screw (L).
5
4
9
9
A
L
LA x 8x 8

5
3
Ø3x12mm
· Separate the slide bracket from the slide arm as per diagram.
· Attach Slider arms to panels (9) with screw (I) correctly.
I
Hx 12x 2
Slider arm
Slider arm
Slider bracket
Slider bracket
5
4
9
9
I

6
4
· Insert dowels (A) into panel (2).
· Attach panels (4,5) to panel (2).
· Insert and secure cam locks (C) to panel (2) to lock it. Ø8x30mm Ø15x11mm
4
5
2
A
AC
1 2 3
x 4 x 4

7
5
·Carefully slide panel (7) into place along the back of the assembly.
7
45
2

8
6
· Screw Cam bolts (B) into panel (1).
· Insert dowels (A) into panels (4,5).
· Attach panels (1) to panels (4,5).
· Insert and secure cam locks (C) to panels (4,5) to lock it. Ø8x30mm Ø15x11mmØ6x35mm
1
1
4
5
A
C
B
7
BA C
1 2 3
x 4x 4 x 4

9
7
· Carefully slide panel (8) into place along the back of the assembly.
· Insert dowels (A) into panels (4,5).
· then attach panel (3) to panels (4,5) using screws (F). Ø8x30mm Ø4x44mm
8
4
2
5
4
5
3
A
F
FA x 4x 4

10
8
· attach legs (10) to panel (3).
· Stick the skid pad (O) on the bottom of the legs (10).
3
10
O
10
10 10
Ox 4

11
9
· Secure parts (M) to panels (1,2,3,4,5) using screws (N). Ø3x17mm
4
5
1
3
2
M
N
M N
x 8 x 8

12
10
· Attach panels (12,13) to panel (14) wiht screws (L).
· Carefully slide panel (15) into place along the bottom of the assembly.
Ø4x32mm
Lx 8
×2
12
13
14
15
13
14
12
L

13
11
· Screw Cam bolts (B) into panel (11).
· Attach Handle (K) to panel (11) with bolts (J).
· Attach panel (11) to panels (12,13).
· Insert and secure cam locks (D) to panels
(12,13) to lock it.
×2 Ø6x35mm Ø15x9mm Ø5/32"x12mm
12
13 11
BDK
J
B
J
D
K
1 2 3
x 8 x 8 x 2
x 4

14
12
×2
· Attach slider brackets to panels (12,13) with screws (I) correctly.
Ø3x12mm
I
I
12
13
x 12

15
13
· Stick stickers (E) on cam locks (C,D).
· Assembled the drawers as per diagram
Note :If the drawer does not go in smoothly.
Press or lift the plastic release lever.
Pull out the slider bracket from the slider arm
then re-assembled the drawer until they were
going in smoothly well.
ESlider arm
Slider bracket
1 2
x 20

16
14
Ø4x12mm Ø4x25mm
1
P
Q
R
S
QP R S
Wall
x 1
x 1 x 1 x 1
WARNING
Serious or fatal injuries can occur from furniture tipping over. To prevent the furniture from tipping over we recommend
that it is permanently fixed to the wall. Wall anchor and hardware are included with this product. Please make sure
hardware is suitable for your walls before installing, as different wall materials may require different types of anchors.
1 2 3

17
15
Final Assembly
