Wampat W11F4122W User manual

W11F4122W
Assembly Instructions
Please read this manual carefully before beginning assembly of this product.Keep this manual for future reference.

1-1

1
1
2
3
4
5
6
7
7
8
9
10
11
12
13
14
14

２
15 15
16
17 18
18
17
19
20
21
22
19
20
21
22
19
20
21
22
19
20
21
22

3
● The provided glue(G) is to secure wood
dowels(A) in place . When first inserting
dowels, locate the appropriate hole for the
dowel , place a small amount of glue in the
hole and insert the dowel . Wipe away
excess glue immediately.
● In future assembly steps when dowels are
necessary to attach assembly parts together,
place a small amount of glue on the end of
the dowel before attaching parts together.
Wipe away excess glue immediately.
Philips head screwdriver
required for assembly
(not included)
ABCD
EFGH
IJKL
MO
NP
QS
RT
1 2
1 2
x 30 x 32 x 16 x 16
x 32 x 9x 1x 4
x 48 x 8x 4x 29
x 14x 14 x 4x 2
x 2 x 2x 2x 1
Wooden dowel
Ø8x30mm Ø6x35mm
Cam bolt Cam lock
Ø15x11mm
Cam lock
Ø15x9mm
Sticker Screw
Ø4x44mm Glue tube Drawer slider
Screw
Ø3x12mm Ø5/32"x12mm
Handle bolt Handle Screw
Ø4x32mm
Flat-head screw
Ø3x17mm
Plastic wedge
Ø25x2mm
Footpads Screw
Plastic strap Screw Nut
Ø4x12mm
Ø4x25mm

4
1
· Screw cam bolts (B) into panels (2,4,5,7).
7
7
2
4
5
B
B
x 12

5
2
· Insert dowels (A) into panels (4,5).
· Attach panels (7) to panels (4,5).
· Insert and secure cam locks (C) to panels (4,5) to lock it.
7
7
5
4
C
A
A
C
x 4x 6
1 2 3

6
3
· Insert dowels (A) into panels (4,5).
· Attach panels (14) to panels (4,5) with screws (L) correctly.
5
4
14
14
L
A
L
A
x 8
x 8

7
4
· Separate the slider bracket from the slider arm as per diagram.
Slider arm
Slider arm
Slider bracket
Slider bracket
Hx 4

8
5
· Attach slider arms to panels (14) with screws (I) correctly.
I
14
14
4
5
I
x 12

9
6
· Flip 180° and attach slider arms to panel (6) with screws (I) correctly.
· Attach slider arms to panel (6) with screws (I) correctly.
6
I
I
6
I
x 12

10
7
· Insert and secure cam locks (C) to panel (6) to lock it.
· Attach panel (6) to panel (2) correctly.
· Insert dowels (A) into panel (6).
6
2
AC
A
C
1 2 3
x 2x 2

11
8
· Insert and secure cam locks (C) to panel (2) to lock it.
· Attach panel (5) to panel (2) correctly.
· Insert dowels (A) into panel (2). AC
2
A
C
5
1 2 3
x 2x 2

12
9
· Insert and secure cam locks (C) to panel (2) to lock it.
· Attach panel (4) to panel (2) correctly.
· Insert dowels (A) into panel (2). AC
2
4
A
C
x 2x 2
1 2 3

13
10
· Slide panel (13) into designated area correctly.
· Slide panel (11) and part (12) into designated area.
11
12 13
4
5
2

14
11
x 6 x 6
· Insert dowels (A) into panels (4,5,6).
· Attach panel (3) to panels (4,5,6) with screws (F) correctly.
AF
4
5
6
3
A
F

15
12
· Stick the Footpads (O) to legs (15).
· Install the legs (15,16) to panel (3).
3
15
16
15
15
15
O
O
x 4

16
13
· Slide panel (10) into designated area correctly.
10
4
5
2

17
14
· Screw cam bolts (B) into panel (1).
· Insert dowels (A) into panel (1).
· Attach panel (9) to panel (1) with screws (F).
1
9
ABF
F
A
B
x 2x 4x 3

18
15
· Attach part (8) to panel (1) wiht screws (L).
8
L
1
L
x 5
