Wampat W22F5121W User manual

Assembly Instructions
Please read this manual carefully before beginning assembly of this product.Keep this manual for future reference.
W22F5121W

1-1

1
1
2
3
4
4
5
6
7
7
8
9
10
11
12
13
14
15
16
16
17
18
19
20
21
21
22
23
23
24
25
25
26
26
26
27
27
28
28
29
29
30
30
31
31

２
x 40 x 42 x 12 x 46 x 4 x 24
x 8 x 16 x 3 x 10 x 14 x 3
x 14 x 1 x 1 x 2 x 16 x 4
x 2 x 8 x 1 x 4 x 33 x 6
x 2 x 2
A B CD E F
GH I JK L
M N OPQR
STUV W X
Y Z Philips screwdriverr
Slotted screwdriver
Tools Required (Not included)
Cam lock
Cam bolt
Ø6x35mm Ø4x30mm
Screw Wooden dowel
Ø5x45mm
Screw
Ø3.5x12mm
Screw
Ø4x16mm
Bolt
Ø4x12mm
Screw Magneticplate Plastic wedge
Ø3x14mm
Screw Handle
Ø6x50mm
Bolt Magnetic catch Magnetic catch Cam bolt
Ø6x40mm
Nut Shelf support pin
Handle
Ø6x30mm
Bolt Allen key Drawer slide
Ø3x12mm
Screw Hinge
Brake caster Caster

３
1
· Gently screw cam bolts(A) into panel(3).
· Attach part(24) to panels(23) with parts(25).
x 5
23
23
24
25
25
A
3
A

4
2
· Attach panel(3) to panels(23) with bolts(M) and parts(Q) correctly.
· Attach panel(7) to panel(3) with screws(C) correctly.
· Insert dowels(D) into panel(3).
x 4 x 4 x 2 x 3
QM
23
23
3
MQ
CD
3
7
MQD
C
L1
L2 L1 > L2

5
3
· Attach slider arm(V-1) to panel(7) with screws(F) correctly.
· Separate the sliders bracket(V-2) from the sliders arm(V-1) as per diagram.
x 3 x 4
V
FV
V-1 V-2
V-1
F
7

6
4
· Insert dowels(D) into panel(3).
· Attach panel(14) to panel(3) correctly.
· Insert and secure cam locks(B) to panel(3) to lock it.
· Gently screw cam bolts(A) into panel(14). x 4 x 2
1 2 3
x 4
3
BD
14
A
14
A
B
D

7
5
· Attach slider arm(V-1) to panel(5) with screws(F) correctly.
· Turn over panel(5) 180 °, then attach another slider arm(V-1) to it with screws(F) correctly.
x 6
V-1
F
180°
V-1
F
5
F

8
6
· Gently screw cam bolts(A) into panels(6,9).
· Attach parts(N,O) to panel(6) with screws(K).
x 1 x 1 x 4 x 4 NO
A K
O
N
K
A
6
9

9
7
· Insert dowels(D) into panel(5).
· Attach panel(5) to panel(6) with screws(E) correctly.
· Insert dowels(D) into panel(9).
· Attach panel(9) to panel(6)correctly.
· Insert and secure cam locks(B) to panel(9) to lock it.
x 4 x 2 x 2
1 2 3
6
69
5
DE B
D
E
D
B

10
8
· Insert dowels(D) into panel(10).
· Attach panel(10) to panel(9) correctly.
· Insert and secure cam locks(B) to panel(10) to lock it.
x 2x 2
1 2 3
DB
Finished edge
9
10
B
D

11
9
· Insert dowels(D) into panels(6,10).
· Attach panel(3) to panels(6,10).
· Insert and secure cam locks(B) to panels(6,10) to lock it.
x 4x 4
1 2 3
DB
6
10
3
D
B

12
10
Finished edge
· Gently screw cam bolts(A) into panels(19,20).
· Attach panel(22) to panel(19) correctly, then insert and secure cam locks(B) to
panel(22) to lock it.
· Attach parts(21) to panel(19), attach panel(20) to panel(22) and parts(21).
· Insert and secure cam locks(B) to panel(22) to lock it.
1 2 3
x 4 x 4
AB
19 20
A
19
20
21
22
B
21
19
22

13
11
· Gently screw cam bolts(A) into panels(2,13).
x 7
A
213
A

14
12
· Attach panel(2) to panels(19,20) with bolts(M) and parts(Q) correctly.
· Attach panel(7) to panel(2) with screws(C) correctly.
· Insert dowels(D) into panel(2).
x 4 x 4 x 2 x 3
QM
MQ
CD
2
19
20
2
7
M
Q
L1
L2
L1 > L2
D
C

15
13
· Attach slider arm(V-1) to panel(7) with screws(F) correctly.
· Insert dowels(D) into panel(2).
· Insert and secure cam locks(B) to panel(2) to lock it.
· Attach panel(13) to panel(2) correctly.
x 3
1 2 3
x 2x 4
V-1
F
F
7
2
13
DB
D
B

16
14
· Insert and secure cam lock(B) to panel(12) to lock it.
· Insert dowels(D) into panels(6,12).
· Insert and secure cam locks(B) to panels(6,12) to lock it.
· Attach panel(2) to panels(6,12).
· Insert dowel(D) into panel(12), attach panel(12) to panel(3) correctly. x 4x 4
1 2 3
DB
3
12
12
2
B
6
B
D

17
15
· Insert dowels(D) into panels(2,3,9,12,13,14).
· Attach panel(11) to panel(12) with screws(E).
· Attach panel(11) to panels(2,3,9) with bolts(M) and parts(Q) correctly.
x 6 x 6
x 2
x 10
QM
MQ
ED
2
13
3
14
9
12
11
E
D
M
Q

16
18
· Attach parts(Y,Z) to panel(11) with screws(H).
x 2 x 2
x 16 YZ
H
11
Y
Z
H
