Wampat W07J3062V User manual

W07J3062V
Assembly Instructions
Please read this manual carefully before beginning assembly of this product.Keep this manual for future reference.

1-1

1
8
10
11
12
9
1
2
3
4
5
6
7
13
14

２
x 18
x 6 x 6 x 24 x 6 x 6
x 4 x 12 x 4 x 4
x 14
x 2
x 4
x 4
x 1
x 4 x 4
Tools Required
(Not included)
B
ACDEF
GHJK
I
O
N
L
e
abcd
T
MU
x 2
Q
Footpads
Cam bolt Wooden dowel
Ø8x30mm
Cam lock Screw
Sticker
Plastic wedge Screw
Handle
Handle bolt
Tipping restraint hardware kit
(inside plastic bag)
Screw
Ø6x33.5mm Ø15x11mm
M4x18mm
Ø20x23mm
Ø4x12mm Ø3.5x14mm
Ø4x35mm 25x25mm
Cam lock
Ø12x9mm
Cam bolt
Ø6x28mm
Hinge
Crash pad
Ø10x2mm Shelf support pin
Ø8x5x13mm
Drawer slider
300x27x10mm

３
1
x 6
1
4
A
5
A
· Screw cam bolts (A) into panels (1,4,5).

4
2
x 6
x 2
QD
4
5
D
Slider arm
Slider bracket
Slider arm
Slider bracket
· Separate the slide bracket from the slide arm as per diagram.
· Attach Slider arms to panels (4,5) with screws (D) correctly.

5
3
x 4
x 8 HB
3
7
B
7
7
7
3H
· Insert dowels (B) into Wooden leg (7).
· Attach panels (3) to Wooden leg (7),
· Insert and secure screw (H) to Wooden leg (7) to lock it.

6
4
1 2 3
x 2 x 2
BC
4
5
2
C
B
· Insert dowels (B) into panel (2).
· Attach panels (4,5) to panel (2),
· Insert and secure cam locks (C) to panel (2) to lock it.

7
5
x 4x 4 x 4
3
H
4
5
HB J
7
J
· Insert dowels (B) into panels (4,5).
· Then attach panel (3) to panels (4,5) using screws (H).
· Stick the skid pad (J) on the bottom of the Wooden leg (7).

8
6
6
4
· Carefully slide panel (6) into place along the back of the assembly.

9
7
x 4 x 4
1 2 3
BC
B
C
4
5
1
· Insert dowels (B) into panels (4,5).
· Attach panel (1) to panels (4,5),
· Insert and secure cam locks (C) to panels (4,5) to lock it.

10
8
x 6 x 6
1
4
E
F
6
EF
3
5
· Secure parts (E) to panels (1,3,4,5) using screws (F).

11
9
x 4
9
10
11
9
12
H
H
· Attach panels (9,10) to panel (11) with screws (H).
· Carefully slide panel (12) into place along the bottom of the assembly.

12
10
1 2 3
x 4 x 4 x 2
x 2
8
8
8
N
L
U
10
G
9
UMG
N
· Screw Cam bolts (U) into panel (8).
· Attach Handle (N) to panel (8) with bolts (G).
· Attach panel (8) to panels (9,10).
· Insert and secure cam locks (L) to panels(9,10) to lock it.

13
11
x 6
x 2 D
9
10 D
K
8
K
· Attach slider brackets to panels (9,10) with screws (D) correctly.
· Stick part (K) on panels (8) correctly.

14
12
x 2 x 2 x 4 x 2
NGDO
D
L
13
N
G
· Attach part (O) to panels (13) with screws (D) correctly.
· Attach part (N) to panels (13) with bolts (G) correctly.

15
13
Warning：
follow the next step
to adjust the crack of
the doors .
警告 :
次の手順に従ってドア
の隙間を調整します。
x 8 x 2
x 4 DK
D
K
5
13
I
I
· Attach part (13) to panel (5) with screws (D) correctly.
· Stick part (K) on panels (13) correctly.
· Stick stickers (I) on screw (H).

16
14
1mm
1mm
Panels 13
1mm
Warning：
open the doors and adjust the
right hinge follow the picture 1
and 2 ，and the side crack of
the doors is about 1mm）
警告 :
ドアを開けて、図1と図2に従って
右のヒンジを調整します。ドアの
側面の隙間は約1ミリ。
1
2
3

17
15
Adjust Height / 高さを調節
Adjust front and back / 前後を調節
Adjust Left and right / 左右を調節

18
16
x 4
L
L
14
4
5
· Insert the shelf supports(L) at the desired level and
place the adjustable shelves(14) onto the shelf supports.
