Wampat W02W2111E User manual

W02W2111E
Assembly Instructions

1-3

6
2
4
5
33
8
1
7
１

２
Cam bolt Cam lock Wooden dowel Screw Screw
Bolt Hexagon socket key Wooden leg and
Adjustable glide
Philips head screwdriver
required for assembly
(not included)
square tube
Lifting Mechanism
The connection plate Bolt Bolt
Open End Wrench Nut Bumpers Spring
x 18 x 18 x 20 x 18 x 6
x 8 x 1 x 1 x 1
x 2 x 4 x 4
x 1
x 1 x 8 x 1 x 2
ABCDE
FGHI
JM
L
K
O
NPQ

３
2
3
1
3
F
Fx 8 Gx 1
· Screw part(F) in half, not all.
· Attach panels (1,2) to legs (3) with screws (F).

４
A
4
4
Ax 4
· Screw parts (A) into panels (4).

Cx 4Bx 4
５
B
C
4
4
5
· Insert dowels (C) into panel (5).
· Attach panels (4) to panel (5).
· Insert and secure cam locks (B) to panel (5) to lock it.
1 2 3

Ax 12
６
A
2
1
· Screw parts (A) into panels (1,2).

Bx 8 Cx 8
７
B
C
5
4
4
1
2
1 2 3
· Insert dowels (C) into panels (4,5).
· Attach panels (1,2) to panel (4,5).
· Insert and secure cam locks (B) to panels (4) to lock it.

Ax 2 Bx 4
８
B
A
5
· Screw parts (A) into panel (5).
· Insert and secure cam locks (B) to panel (5) to lock it.

1 2 3
Bx 2 Cx 2
９
B
C
5
6
· Insert dowels (C) into panel (5).
· Attach panel (6) to panel (5).
· Insert and secure cam locks (B) to panel (6) to lock it.

Ex 6Cx 6
１０
6
1
2
7
· Insert dowels (C) into panels (1,2,6).
· Attach panel (7) to panels (1,2,6) with screws (E).

Hx 1
１１
2
7
H
· Attach leg (H) to panel (7).
· Tighten the bolts on the legs.

１２
Lifting Mechanism-L
Lifting Mechanism-R
x 4 x 4x 2
x 1 x 1
· Attach parts (K) to partl (I) with bolts (M) and nuts (O).
· Screw bolts (M) in half, not all.
M
M
O
O
K
K
IN

１３
x 1 x 4
x 1 x 2
· Attach part (J) to part (K) with bolts (L) and nuts (O).
· Screw bolts (L) in half, not all.
· Attach parts (Q) to part (I) as shown.
I
J
JO
O
L
L
Q
Q

１４
L1
L2
x 6
· Attach part (I) to panel (8) with screws (D) correctly.
L1>L2
8
D
I
D

１５
Px 1Dx 12
· Tighten the bolts (L,M).
· Attach part(I) to panels(1,2) with screws(D).
· Stick bumpers (P) on parts (1,2).
1
2
D
P

１６
Final Assembly
· Adjust leg(H) to
level the unit.
