Wampat K-QUA1501A User manual

K-QUA1501A
Assembly Instructions
3

1
8
8
9
9
4
3
6
7
7
5
2
10
１
11
13
12
12
14
15
16
16
17
17
10

1 2
1 2
● The provided glue(part J) is to
secure wood dowels(A) in place .
When first inserting dowels,
locate the appropriate hole for
the dowel , place a small amount
of glue in the hole and insert the
dowel . Wipe away excess glue
immediately.
● In future assembly steps when
dowels are necessary to attach
assembly parts together,place a
small amount of glue on the end
of the dowel before attaching
parts together. Wipe away
excess glue immediately.
Wooden dowel
Ø8x30mm
A x 28
Cam bolt
Ø6x35mm
B x 12 C x 12
Cam lock
Ø15x11mm
D x 12
Sticker
E x 12
K x 8
Shelf support pin
Ø8x5x16mm
BoltGlue tube
J x 1
Ø4x50mm
F x 8
H x 14
Plastic wedge
I x 14
Flat-head screw
Screw
Ø3x17mm
Hexagon socket key
M 4
M x 1
Philips head screwdriver
required for assembly
(not included)
Ø6x13mm
U x 2
V x 2 W x 2 X x 2
Screw
Ø4x12mm
Screw
Ø4x25mm Plastic strap Nut
２
G x 4
L x 12
Ø5/32"x22mm
N x 4
O x 2
Handle
Handle bolt
P x2 Q x 4 R x 2 S x 4 T x 26
Magnetic catch Hinge
Ø3x15mm
Screw Metal piece
Ø4x38mm
Screw
Ø6x57mm
Bolt
Ø3x12mm
Screw

Ø6x35mm
· Screw parts (B) into panels (7).
7
7
B
B x 4
３

1 2 3
Ø8x30mm Ø15x11mm
A
C A x 4 C x 4
４
6 3
· Insert dowels(A) into panels(3,6).
· Attach panels (7) to panels (3,6).
· Insert and secure cam lock (C) to panels
(3,6) to lock it.
7
7

Ø8x30mm
A x 4 G x 4
1 2 3
3
6
88
A G
５
Ø4x38mm
· Insert dowels(A) into panels(8).
· Attach panels (3,6) to panels (8)
using screws(G)

Ø4x50mmØ8x30mm
3
6
5
4
2
A
A x 10 F x 8
６
F
· Insert dowels(A) into panels(3,4,5,6).
· Attach panels (3,4,5,6) to panel (2)
using screws(F).

７
·Carefully slide panels (9,10,11) into
place along the back of the assembly.
10
10 9
9
11

Q x 4P x 2B x 8
８
1
· Screw parts (B) into panels (1)
B
Ø3x15mm
· Attach parts(P) to panels(1)
using screws(Q) as shown.
Q
P

９
1 2 3
Ø8x30mm Ø15x11mm
A x 10 C x 8
1
34
56
A
C
· Insert dowels(A) into panels(3,4,5,6).
· Attach panel (1) to panels (3,4,5,6).
· Insert and secure cam lock (C) to panels
(3,4,5,6) to lock it.

１０
M x 1 K x 8
K
· Attach parts (17) to parts (16)
using Bolts(K).
M 4 Ø6x13mm
16
17
17
16

１１
L x 12
· Attach parts(16,17) to panel(2) using Bolts(L).
L
2
Ø6x57mm
16
16
17
17

１２
10
10
9
9
I x 14
H x 14
Ø3x17mm
· Secure parts(H) using Screws(I).
H
I
11

１３
E x 12
13
Ø8x5x16mm
· Attach panelS(12,13) to panels(3,4,5,6) using parts(E).
E
12
12
3
4
5
6

T x 14S x 4R x 2
O x 2
N x 4
Ø5/32"x22mm Ø3x12mm
14
14
15
15
T
O
N
T
S
R
１４
· Attach parts(S) to panels(14,15) using Screws(T).
· Attach parts(O) to panels(14,15) using Screws(N).
· Attach parts(R) to back of panels(14,15) using
Screws(T).

１５
15
14
T x 12
Ø3x12mm
T
7
7
3
Attach panels(14,15) to panels(7) using Screws(T).

１６
1 2 3
WARNING
Ø4x12mm Ø4x25mm
U x 2 V x 2 W x 2 X x 2
Serious or fatal injuries can occur from furniture tipping over. To prevent the furniture from
tipping over we recommend that it is permanently fixed to the wall. Wall anchor and
hardware are included with this product. Please make sure hardware is suitable for your
walls before installing, as different wall materials may require different types of anchors.
1
Wall
U
W
V
X

1 2
· Stick stickers(D) on cam lock(C).
Final Assembly
D x 12
１７
