WARRIOR 57522 Assembly instructions

Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back
of the manual (or month and year of purchase if product has no number). Keep this manual and the receipt
in a safe and dry place for future reference. 23e
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2023 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
57522
7 PIECE
BI-METAL HOLE SAW SET

Page 2 For technical questions, please call 1-888-866-5797. Item 57522
Specifications
Type Bi-Metal
Piece Count 7
Saw Sizes 7/8", 1", 1-1/8", 1-1/4", 1-1/2"
Other Pieces Adapter with Clamp Washer
Pilot Drill Bit
IMPORTANT SAFETY INFORMATION
1. Wear ANSI-approved safety goggles
and heavy-duty work gloves
during setup and use.
2. Set contains sharp blades.
Keep away from children.
3. Use correct size arbor for
selected Hole Saw.
4. Verify drill’s chuck is in good
condition and fits securely.
5. Do not use excessive pressure
when cutting a hole.
6. Use as intended only;
do not modify tools.
7. Inspect before every use; do not
use if parts are loose or damaged.
8. Use both hands when drilling and
keep blade at 90° to workpiece.
9. Store saw blades in secure
location away from children.
10. Read and adhere to all safety
warnings and operating instructions
of drill used with Set.
11. The warnings, cautions, and
instructions discussed in this
instruction manual cannot cover all
possible conditions and situations
that may occur. It must be understood
by the operator that common sense
and caution are factors which cannot
be built into this product, but must
be supplied by the operator.
SAVE THESE INSTRUCTIONS.

Page 3For technical questions, please call 1-888-866-5797.Item 57522
Setup
TO PREVENT INJURY:
Wear heavy-duty work gloves and ANSI-approved safety goggles
during setup and whenever handling the Hole Saws.
1. Select the desired size Hole Saw.
2. Thread Small Mandrel into
Hole Saw securely.
3. Use the Adapter to attach the Small
Mandrel to medium size Hole Saws
(Such as a 1-1/2" size.) Carefully
thread Adapter with Clamp Washer
into Hole Saw and then thread the
Small Mandrel through the bottom
so that it screws into the Adapter.
4. Adjust Small Mandrel position on
Pilot Drill Bit. Tighten Set Screw.
5. Open jaws of drill chuck
(sold separately).
6. Place the Pilot Drill Bit shaft
completely into the chuck and
securely tighten the chuck.
Set
Screw
Hole
Saw
Pilot
Drill Bit
Small
Mandrel
Clamp
Washer
Adapter

Operation
1. Holding the drill at 90° to the workpiece,
set the Hole Saw on the workpiece.
2. Press the drill’s trigger to turn it on.
3. If the drill is a variable speed type,
cut the workpiece slowly until a circle
groove is made in the workpiece.
Then cut faster.
4. When the hole is cut, release the
trigger and wait for the Hole Saw
to come to a complete stop before
removing it from the workpiece.
5. When finished, remove
the Hole Saw from drill’s chuck.
6. Remove Hole Saw from the Mandrel
and clean off Hole Saw with a cloth.
7. Store the Hole Saws out
of reach of children.
8. Replace the Pilot Drill Bit if
dull or broken.
Make sure the Bit is securely held
in place after being reinstalled.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Replacement parts are not available for this item. Reference UPC 193175428820.
