Watchguard DV-1 guide User manual

WGD00071

2
WatchGuard DV-1 User Guide
Copyright © 2014 WatchGuard Video
All rights reserved.
WatchGuard and DV-1 are trademarks of WatchGuard Video.
All other marks, names, and logos mentioned herein are the
property of their respective owners.
Enforcement Video LLC is a Texas Limited Liability Company
doing business as WatchGuard Video.
WatchGuard Video
415 Century Parkway
Allen, Texas 75013
1-800-605-6734 Toll Free Sales
1-866-384-8567 Toll Free Support
This document is applicable to DV-1 Firmware Version 7.0 and
above.
SAFETY WARNINGS
To prevent fire or shock hazard, do not expose the DV-1 unit
to rain or moisture.
To avoid electrical shock, do not disassemble the DV-1
housing or place any objects other than the DVD inside the
system. Refer servicing to qualified personnel only.
The use of optical instruments with the DV-1 product will
increase eye hazard. As the laser beam used in the DVD
drive is harmful to eyes, do not attempt to disassemble the
DVD drive. Refer servicing to qualified personnel only.
Should any solid object or liquid fall into the DV-1 unit,
disconnect the unit from power and have it checked by
qualified personnel before further operation.

3
