WatchGuard SOHO
WebBlocker
WatchGuard SOHO WebBlocker is an optional feature of the WatchGuard
SOHO and SOHOtc that provides Web site filtering capabilities. It enables
you to exert fine control over the types of Web sites users on your private
network are allowed to view.
How WebBlocker Works
WebBlocker relies on a URL database built and maintained by The Learn-
ing Company for the CyberPatrol. The WebBlocker database contains
many thousands of IP addresses and directories. These addresses are
divided into categories based on content such as Drug Culture, Intoler-
ance, or Sexual Acts.
WatchGuard copies the database to our Web site at regular intervals.
Every time a user on your private network attempts to reach an Internet
Web site, the SOHO queries our database and determines whether or not
to block the site. Depending on conditions, the SOHO decides whether or
not to block the site:

2 WatchGuard SOHO
Web Site Not in CyberPatrol List
If the site is not in our database, the Web browser opens the page for
viewing.
Web Site in CyberPatrol List
If the site is in our database at WatchGuard, the SOHO checks whether
or not you have chosen to block that type (or category) of site. When
the category is blocked, the browser displays a page informing the
user that the site is unavailable for viewing. If the category is not
blocked, the Web browser opens the page for viewing.
WatchGuard WebBlocker Database Unavailable
If for any reason, the WatchGuard WebBlocker database is unavailable,
for example if there is briefly a problem between your ISP and the
nearest WatchGuard server, the browser displays a page informing the
user that the site is unavailable for viewing.
Bypassing the SOHO WebBlocker
Ocassionally you may want to allow select individuals to bypass the fil-
tering functions of the SOHO WebBlocker. For example, if you are using
the SOHO in a home as a telecommuter, you may want to block a cate-
gory from your children while still retaining access for the adults in the
household.
The SOHO WebBlocker configuration page includes a Full Access Pass-
word field. You can configure this password and give it to only those
members of your private network who should be able bypass the Web-
Blocker. When a site is blocked or unavailable, the user has the option of
entering the full access password. With the password entered, the
browser displays the otherwise blocked site. Once the password is
entered, the user can browse any site on the Internet until either the Pass-
word Expiration duration passes or the individual closes the browser.

WebBlocker Guide 3
Purchasing and Enabling the SOHO WebBlocker
Purchasing and Enabling the SOHO WebBlocker
To use WatchGuard SOHO WebBlocker, you must first purchase and
enable the WebBlocker feature key.
1. Open your Web browser to the WatchGuard SOHO LiveSecurity Ser-
vice:
KWWSELVGZDWFKJXDUGFRP62+2/RJLQDVS
2. If you have already activated LiveSecurity, enter your User Name and
Password and click Login. If you are a new user, follow instructions to
activate your LiveSecurity Service.
3. Once logged in to LiveSecurity, click the WebBlocker link.
4. On the WebBlocker for SOHO Information page, click Buy Now.
5. Accept the end-user licence agreement, enter your credit card and bil-
ing information, then accept the order summary.
$QRUGHUFRQILUPDWLRQSDJHDSSHDUVDQGDQHZIHDWXUHNH\LVJHQHUDWHGIRU\RXU
62+2GHYLFH7KHQH[WWLPHWKH62+2GHYLFHUHERRWVDQGFRQWDFWV:DWFK*XDUGLW
ZLOOREWDLQWKHQHZIHDWXUHNH\DQGHQDEOH:HE%ORFNHU
6. Reboot the SOHO.
Configuring the SOHO WebBlocker
Use the WatchGuard SOHO Configuration pages to enter settings for the
SOHO WebBlocker. You must provide the location of the nearest Watch-
Guard WebBlocker server, a full access password for bypassing Web-
Blocker, the duration the full access password is valid, and the categories
you wish to block.
1. Open a Web browser and enter the IP address to access the Watch-
Guard SOHO Configuration menu.
7KHGHIDXOWFRQILJXUDWLRQ,3DGGUHVV
2. Select Services.
7KH6HUYLFHVPHQXDSSHDUV
3. Select Web Blocking.
7KH:HE%ORFNHUFRQILJXUDWLRQSDJHDSSHDUV,WSURYLGHVFRQWUROVIRUDFWLYDWLQJDQG
FRQWUROOLQJ:HE%ORFNHUDVZHOODVFKHFNER[HVWRGHWHUPLQHZKLFKFRQWHQWW\SHVFDQ
EHDFFHVVHG

4 WatchGuard SOHO
4. Check the Enable Web Filtering checkbox.
7KLVWXUQVRQ62+2:HE%ORFNHU
5. Enter the Full Access Password.
7KH)XOO$FFHVV3DVVZRUGSURYLGHVXVHUV\RXVHOHFWWRHQWHUDSDVVZRUGWKDW
E\SDVVHVRWKHUZLVHEORFNHGVLWHV
6. Enter Password Expiration duration in minutes.
6HWWLQJWKHSDVVZRUGH[SLUDWLRQDWIRUH[DPSOHPLQXWHVHQVXUHVWKDWXQDW
WHQGHG:HEEURZVHUVZLOOEHGLVFRQQHFWHGDIWHUVLWWLQJLGOHIRUPLQXWHV7KLV
HQVXUHVWKDWRQO\WKHLQGLYLGXDOVFKRVHQWRXVHWKH)XOO$FFHVV3DVVZRUGZLOOEHDEOH
WREURZVHRWKHUZLVHEORFNHGVLWHV
7. Create your organization’s browsing profile.
(QDEOHWKHFKHFNER[HVIRUWKHFDWHJRULHVWRZKLFK\RXZDQWWRGHQ\DFFHVV
8. Click the Submit button to register your changes.
6XEPLWWLQJWKHSDJHDOWHUV\RXUFRQILJXUDWLRQILOHWRWXUQRQ:HE%ORFNHUDQGEORFN
XVHUVIURPDFFHVVLQJ:HEVLWHVWKDWPDWFKWKHFDWHJRULHV\RXFKHFNHGLQ6WHS

WebBlocker Guide 5
WebBlocker Categories
WebBlocker Categories
WebBlocker relies on a URL database built and maintained by The Learn-
ing Company for the CyberPatrol. The Learning Company constantly
searches the Internet to update the list of blocked sites in each of 14 cate-
gories.
$OORIWKHFDWHJRULHVSHUWDLQWRDGYRFDF\UDWKHUWKDQRSLQLRQDQGRU
HGXFDWLRQDOPDWHULDO)RUH[DPSOHWKH'UXJV'UXJ&XOWXUHFDWH
JRU\EORFNVVLWHVGHVFULELQJKRZWRJURZDQGXVHPDULMXDQDEXWGRHV
QRWEORFNVLWHVGLVFXVVLQJWKHKLVWRULFDOXVHRIPDULMXDQD
Alcohol/Tobacco
Pictures or text advocating the sale, consumption, or production of
alcoholic beverages and tobacco products.
Illegal Gambling
Pictures or text advocating materials or activities of a dubious nature
which may be illegal in any or all jurisdictions, such as illegal business
schemes, chain letters, copyright infringement, computer hacking,
phreaking (using someone’s phone lines without permission) and
software piracy. Also includes text advocating gambling relating to
lotteries, casinos, betting, numbers games, on-line sports or financial
betting, including non-monetary dares.
Militant/Extremist
Pictures or text advocating extremely aggressive or combative behav-
ior or advocacy of unlawful political measures. Topic includes groups
that advocate violence as a means to achieve their goals. It also
includes pages devoted to “how to” information on the making of
weapons (for both lawful and unlawful reasons), ammunition, and
pyrotechnics.
Drug Culture
Pictures or text advocating the illegal use of drugs for entertainment.
Includes substances used for other than their primary purpose to alter
the individual’s state of mind, such as glue sniffing. This criterion
would not block sites describing typically illegal drugs that are legally
prescribed for medicinal purposes (i.e., drugs used to treat glaucoma
or cancer).
Satanic/Cult
Pictures or text advocating devil worship, an affinity for evil, wicked-
ness, or the advocacy to join a cult. A cult is defined as: A closed soci-

6 WatchGuard SOHO
ety that is headed by a single individual where loyalty is demanded
and leaving is punishable.
Intolerance
Pictures or text advocating prejudice or discrimination against any
race, color, national origin, religion, disability or handicap, gender, or
sexual orientation. Any picture or text that elevates one group over
another. Also includes intolerant jokes or slurs.
Gross Depictions
Pictures or text describing anyone or anything which is either crudely
vulgar, grossly deficient in civility or behavior, or shows scatological
impropriety. Topic includes depictions of maiming, bloody figures,
and indecent depiction of bodily functions.
Violence/Profanity
Pictures or text exposing extreme cruelty or profanity. Cruelty is
defined as: Physical or emotional acts against any animal or person
which are primarily intended to hurt or inflict pain. Topic includes
obscene words, phrases, and profanity in either audio, text or pictures.
Search Engines
Search engine sites such as AltaVista, InfoSeek, Yahoo! and Google.
Sports and Leisure
Pictures or text describing sporting events, sports figures, or other
entertainment activities.
Sex Education
Pictures or text advocating the proper use of contraceptives. Topic
includes sites devoted to the explanation and description of condoms,
oral contraceptives, intrauterine devices, and other types of contracep-
tives. It also includes discussion sites devoted to conversations with
partners about sexually transmitted diseases, pregnancy and sexual
boundaries. Excluded from this category are commercial sites selling
sexual paraphernalia.
Sexual Acts
Pictures or text exposing anyone or anything involved in explicit sex-
ual acts and/or lewd and lascivious behavior. Topic includes mastur-
bation, copulation, pedophilia, as well as intimacy involving nude or
partially nude people in heterosexual, bisexual, lesbian or homosexual
encounters. It also includes phone sex advertisements, dating services,
adult personals, and sites devoted to selling pornographic CD-ROMs
and videos.

WebBlocker Guide 7
Communicating with CyberPatrol
Full Nudity
Pictures exposing any or all portions of human genitalia. Topic does
not include sites categorized as Partial/Artistic Nudity containing
nudity or partial nudity of a wholesome nature. For example it does
not include Web sites for publications such as National Geographic or
Smithsonian magazine nor sites hosted by museums such as the
Guggenheim, the Louvre, or the Museum of Modern Art.
Partial/Artistic Nudity
Pictures exposing the female breast or full exposure of either male or
female buttocks except when exposing genitalia. Topic excludes all
swimsuits, including thongs.
Communicating with CyberPatrol
At times, you may question whether or not a site is in the database Watch-
Guard receives from CyberPatrol. In addition, perhaps you find a site you
would like to see added to the list. CyberPatrol maintains a Web site that
enables you to directly query the database and provide feedback on its
future growth.
Visiting the CyberPatrol Web Site
To learn more about the CyberPatrol CyberNOT Search Engine®, you can
visit their Web site at:
KWWSZZZF\EHUSDWUROFRPF\EHUQRW
At this site you can learn about how the database is maintained, more
about the CyberLIST criteria, and how to appeal a blocked site or direc-
tory.
Verifying Whether a Web Site is in the WebBlocker Database
Use the CyberNOT Search Engine to search for specific Web sites and
determine whether or not they are included in the database used by
WatchGuard.
1. Open a Web browser to:
KWWSZZZF\EHUSDWUROFRPF\EHUQRWGHIDXOWKWP

8 WatchGuard SOHO
2. Scroll down to display the Cyber Patrol CyberNOT Search Engine.
3. Type the URL of the site to check.
4. Click Check if the URL is on the CyberNOT List.
7KH6HDUFK(QJLQHUHVXOWVQRWLI\\RXZKHWKHURUQRWWKHVLWHLVRQWKH&\EHU127OLVW
8VHWKLVVLWHDOVRWRVXJJHVWDQHZVLWHIRUERWKWKH&\EHU127DQG&\EHU<(6OLVWDV
ZHOODVUHTXHVWDVLWHUHYLHZ
Copyright and Patent Information
&RS\ULJKW:DWFK*XDUG7HFKQRORJLHV,QF$OOULJKWVUHVHUYHG
:DWFK*XDUG62+2:DWFK*XDUG62+2WFDQG:HE%ORFNHUDUHHLWKHUWUDGHPDUNVRU
UHJLVWHUHGWUDGHPDUNVRI:DWFK*XDUG7HFKQRORJLHV,QFLQWKH8QLWHG6WDWHVDQGRWKHU
FRXQWULHV)LUHER[DQG/LYH6HFXULW\DUHWUDGHPDUNVRI:DWFK*XDUG7HFKQRORJLHV,QF
2WKHUEUDQGVDQGWKHLUSURGXFWVDUHWUDGHPDUNVRUUHJLVWHUHGWUDGHPDUNVRIWKHLU
UHVSHFWLYHKROGHUVDQGVKRXOGEHQRWHGDVVXFK
&\EHU3DWUROLVDUHJLVWHUHGWUDGHPDUNRI/HDUQLQJ&RPSDQ\3URSHUWLHV,QF
'RF9HU%:HE%ORFNHU
