Watchguard XCS Series Installation instructions

WatchGuard
®
XCS
Hardware Guide
XCS 880
ML8AE4

ii WatchGuard® XCS
Copyright Information
Copyright© 2013 WatchGuard Technologies, Inc. All rights reserved.
WatchGuard, the WatchGuard logo, LiveSecurity, and any other mark listed as a trademark in the “Terms of Use” portion of
the WatchGuard Web site that is used herein are either registered trademarks or trademarks of WatchGuard Technologies,
Inc. and/or its subsidiaries in the United States and/or other countries. All other trademarks are the property of their
respective owners.
Part Number: 275-4680-001 Rev C
Revised: November 19, 2013
Notice to Users
Information in this guide is subject to change without notice. Updates to this document are posted on the WatchGuard
web site, at http://www.watchguard.com/help/documentation. Companies, names, and data used in examples herein are
fictitious unless otherwise noted. No part of this guide may be reproduced or transmitted in any form or by any means,
electronic or mechanical, for any purpose, without the express written permission of WatchGuard Technologies, Inc.
Complete copyright, trademark, patent, and licensing information can be found in
the WatchGuard product documentation. You can find this document online at:
http://www.watchguard.com/help/documentation/

Hardware Guide 1
Hardware Specifications
The WatchGuard® XCS appliance is an easy-to-use, all-inclusive email and web appliance that provides
security and privacy of inbound and outbound traffic. It is the first product that provides correlated content
security and threat prevention with consolidated administration and reporting across multiple protocols.
The WatchGuard XCS provides content security that enables data loss prevention, encryption and content
filtering with integrated threat prevention for viruses, spam, spyware, phishing, and malware attacks, all in a
secured appliance.
Secure Operating System
The WatchGuard XCS delivers the most complete security available for messaging systems. The appliance runs
on a customized secure operating system that does not allow uncontrolled access to the system. There is no
command line access and the WatchGuard XCS runs as a closed system, preventing accidental or deliberate
misconfiguration by administrators, which is a common cause of security vulnerabilities.
Package Contents
XCS device
Quick Start Guide
Hardware warranty card and LiveSecurity® Service activation card
Power cords
Rail mounting kit

Hardware Specifications
2
About Your Hardware
Hardware Specifications
Environmental Requirements
To safely install your XCS device, we recommend that you:
Install it in a network rack.
Put it in a secure area, such as a locked room, to keep the device from people who do not have
permission to use it.
Connect it to a conditioned power supply to prevent damage from sudden power changes.
Other environmental requirements for the WatchGuard XCS device:
XCS 880
Processor Intel E3-1225v2 (4 core)
Memory 8GB (2 x 4GB)
ECC DDR3 1600 Dual Channel
Hard Drives 2 x 1TB SATA 7200 RPM Hard Drives (RAID 1)
Power supply 275W Dual Redundant Power Supply,
100–240 VAC, 4.0A MAX, 50/60 Hz, Autosensing
Network
Interfaces
4 port Intel E1G44HT network card
USB Ports 2 x USB ports
I/O Interfaces 1 x VGA DB15
1 x Serial DB9
Dimensions Depth =22.6” (57.4 cm)
Width = 17.0” (43.18 cm)
Height = 1.75” (4.5 cm)
Weight Without rails: 23.5 lbs (10.7 kg)
With rails: 28 lbs (12.7 kg)
Operating temperature 0 to 40°C (32 to 104°F)
Non-operating temperature –40 to 70°C (–40 to 158°F)
Operating relative humidity 10% to 85% non-condensing
Non-operating relative humidity 5% to 90%

Hardware Guide 3
Hardware Specifications
Hardware Description
Front View
The front of the XCS device.
This is a close-up of the LED panel.
Power Button
Press the power button to power on and off the device. Before you power off your device, make sure
your operating system is correctly shut down. Hold the power button for at least five seconds to force
a power off.
Power Indicator
The power indicator lights when power is supplied to the device and the device is operational.
Storage Activity
The storage activity indicator flashes when the hard disk drive is active.
On the XCS 880 device, the individual status lights on each hard drive in the RAID array supersedes
the main storage activity indicator.
Caution
You must disconnect the AC power cord from both power supplies before you remove the
cover cover of the XCS device. If you open the cover without prior authorization from
WatchGuard, the Hardware Warranty is voided.

Hardware Specifications
4
Hard Drive Carriers
Each hard drive carrier has two indicators:
Status: The upper status indicator is green during normal operation. When the status flashes red, this
indicates the drive is rebuilding. When the status is solid red, it indicates a drive failure.
Activity: The lower activity indicator flashes amber to indicate drive activity.
To replace a hard drive carrier:
1. On the front of the device, find the
release tab located on the right side of
the hard drive you want to replace. The
failed drive status indicator will be solid
red.
2. Pull the tab outward to release the
hinged arm on the hard drive.
3. Pull the hard drive out of the slot.
4. On the replacement hard drive, open the
hinged arm.
5. Slide the replacement hard drive into the
slot.
6. Push until the hard drive is flush with the
front of the XCS device. Then close the
hinged arm to lock the drive into place.
Caution
Failure to power off the XCS device, disconnect the power cords from the back of the device
and from the power source, and wait two minutes for power dissipation before performing
the installation of the hard drive, can result in personal injury or death.
Caution
Electro-Static Discharge (ESD) can cause damage to the hard drive. Attach an ESD strap to
your wrist and to a grounded source before you open the device or remove any module.
Wear the ESD strap during the full procedure.

Hardware Guide 5
Hardware Specifications
Rear View
This is a close-up of the rear of the device.
USB Interfaces
There are two USB interfaces that support additional peripherals, for example. a USB keyboard for use
with the XCS device console.
VGA Video Interface (Console)
You can use the VGA video connector to connect a monitor and view the XCS device console screen.
Serial Port
You can use a DB9 connector for the serial port (COM1) to connect a UPS (Uninterruptible Power
Supply). The serial port can also be used to connect to the serial console if you do not have a monitor
and a keyboard.
Power Supplies
There are two power supplies on the XCS 880 device, each with their own power indicator light at the
top.
If one of the power supplies fails, the green power indicator light for that power supply goes out and
an audible alarm sounds.
Alarm Reset Button
If either of the two power supplies fails for any reason, an audible alarm sounds. To silence the audible
alarm, press the reset button located to the left of the power supplies.
Power Indicators
XCS 880 Rear Power Indicators and Alarm Reset
Alarm reset

Hardware Specifications
6
Replace a Power Supply
Your XCS device is equipped with dual power supplies. If one of the power supplies fails, the XCS device will
continue normal operation with the remaining power supply.
It is not necessary to turn off the XCS device to replace a failed power supply.
Caution
The power supply can be extremely hot when removed. The top of each power supply is a
heat sink and can reach temperatures of 50 - 60 degrees Celsius (122-140 Fahrenheit).
Avoid any contact until the metal has cooled. Do not put the power supply directly on a heat
sensitive surface.
To replace a power supply:
1. Remove the power cable from the power supply you want to replace.
2. Slide the power supply release tab to the right, and then use the power supply handle to pull the power
supply out.
3. Remove the failed power supply.
4. Slide the replacement power supply into the open slot.
5. Press firmly on the face of the power supply until it clicks into place and is flush with the back of the
XCS device.
6. Plug in the power cord. If the replacement is successful, the power indicator light for the new power
supply is green.
Release Tab

Hardware Guide 7
Hardware Specifications
Network Interfaces
This is a close-up of the network interfaces on the rear of the device.
Onboard Network Interfaces
The XCS device has four network interfaces. The network interfaces have standard RJ45 connectors.
Network Interface Indicators
Each network interface has a pair of indicators. The left indicator is the activity indicator for the
interface. The right indicator shows the connection speed for the interface.
Indicator Indicator Color Interface Status
Activity (Left) Not lit No connection
Amber Connection established
Blinks Network activity, data sent and
received
Connection Speed
(Right)
Not lit Operates at 10 Mbps or no link
Green Operates at 100 Mbps
Amber Operates at 1000 Mbps
