Watts Premier WP-2 LCV User manual

INSTALLATION, OPERATION AND MAINTENANCE MANUAL
MODELS
WP-2 LCV, WP-2 BVC
Watts Premier, Inc. 1725 W. Williams Drive C-20 Phoenix, AZ 85027
Phone: [phone] www.wattspremier.com Fax: [phone]
Manual #: 199389 Manual Date: 12/05/08
WP-2 LCV Tested and certified by NSF International against NSF/ANSI
Standard 53 for the reduction of claims specified on the performance data sheet.
Please read carefully before proceeding with installation. Your failure to follow any attached instructions or
operating parameters may lead to the product’s failure and possible damage to property.
Refer to enclosed warranty for operating parameters to ensure proper use with your water supply.
WP-2 BVC Tested and certified by NSF International against NSF/ANSI
Standard 42 for the reduction of claims specified on the performance data sheet.
WP-2 BVC has been tested by Bio Vir as a Microbiological Water Purifier based upon the
recommendations set forth in the USEPA Guide Standard and Protocol for Microbiological Water
Purifiers (OPP Task Force Report, 1987)

Thank you for your purchase of a state of the art Watts Premier Water Treatment system.
WP-2 BVC Microbiological Water Treatment System:
Watts Premier WP-2 BVC water treatment system contains a patented State of the Art
Microbiological Filter. This filter has been independently tested and certified to remove disease
causing microorganisms from the drinking water, including bacteria, viruses and protozoan cysts.
While these water contaminants may not be in your water at all times, it provides a level of security
in the event there is a short term water concern such as a boil alert.
This filter has also been tested and certified to reduce chlorine tastes and odors from the drinking
water providing you great tasting water in addition to the comfort in knowing you have the protection
of the Microbiological Filter. See performance data sheet for individual contaminants and reduction
performance.
WP-2 LCV Water Treatment System:
Watts Premier WP-2 LCV water treatment system contains a heavy duty lead, cyst and VOC
filter block. This specialty formulated block is capable of reducing lead, cryptosporidium, Giardia,
Entamoeba as well as harmful Chemicals (See performance data sheet for complete list of
VOC’s). It is estimated that VOC’s are present in one-fifth of the nation’s water supplies. These
water contaminants can enter ground water from a variety of sources including localized use of
herbicides and pesticides, gasoline or oil spills, leaking underground fuel tanks, septic system
cleaners, and chemicals used in the dry-cleaning industry. See performance data sheet for individual
contaminants and reduction performance.
System Maintenance
Just because you can not taste it, does not mean that it is not there. Many contaminants in the
drinking water are undetectable to the taste. Additionally, over time if you do not replace the
filter elements, other bad tastes and odors will be apparent in your drinking water. This is why
it is important to change your filters at the recommended intervals as indicated in this system
manual.
When replacing any of the filter elements, pay special attention to any cleaning instructions. Should
you have any further questions please refer to our web site at www.wattspremier.com or call our
customer service department at 1-800-752-5582.
2

Table of Contents
Maintenance Record......................................................................................................
Operational Parameters ................................................................................................
Contents of WP-2 System .............................................................................................
Tools Recommended For Installation ............................................................................
Installation......................................................................................................................
Drill / Punch a Hole for Watts Top Mount Faucet...........................................................
Watts Top Mount Faucet Installation .............................................................................
Adapt-a-Valve Installation................................................................................................
System Start Up...............................................................................................................
Filter Change..................................................................................................................
Parts Listing ..................................................................................................................
Performance Data Sheets..............................................................................................
California Certificate.......................................................................................................
Other Products by Watts................................................................................................
Warranty Registration.....................................................................................................
Warranty ........................................................................................................................
3
4
4
4
4
5
6
7
7
8
9
10-12
13
14
15-16
18
3
Service Record
Date of Purchase:__________ Date of Install:___________ Installed by:_____________
NOTES:
Date Sediment
Filter
(6 months)
Date BVC/LCV
Filter
(6 Months)
BVC/LCV
Filter
(6 Months)
Sediment
Filter
(6 months)
Model Number:__________ Serial Number:___________

1 WP-2 Unit
2 Filters
1 Parts Bag
1 Faucet Assembly
If any of the items are missing, please contact Watts Premier prior to installing
Tools Recommended For Installation
A small knife
Variable speed drill
1/8” (3mm), 1/4” (6.4 mm) and 7/16” (11.0mm) drill bits
1/2” Diamond Tip Drill bit (for porcelain sinks)
1/2” hole punch (for stainless steel sinks)
1/2” and 5/8” open-end wrenches (or adjustable wrenches)
Phillips screwdriver
Contents of Under Counter System
Installation
This system has been designed to fit under most kitchen sinks. Please read the entire manual carefully
before proceeding with installation.
4
Step 1: Mounting System Under Sink
(A) Locate a space under the sink that
allows the unit to be mounted close
to the cold water supply and allows
for easy access during maintenance
and filter changes. System must
be installed to the cold water supply
only. Allow approximately 2” (5cm)
clearance between the bottom of the
filter housing and the floor of the sink
cabinet.
(B) Using the mounting holes on the
bracket, mark the location for the
mounting screws on the cabinet wall
under the sink.
(C) Screw the (2) screws into the wall at
the marked location.
(D) Hang the module on the screws using
the mounting holes in the bracket.
Installation needs to comply with state and local plumbing regulations.
Operational Parameters
Maximum Minimum
Operational Temperature 100°F (37.8°C) 40°F (4.4°C)
Operating Pressure 85 psi (5.98 kg/cm²) 20 psi (1.406 kg/cm²)
pH Parameters 10 5
Flow Rate 0.5 GPM @ 60 psig
Sink
Green
Tubing
Blue
Tubing
HOT COLD
Counter Top
Two Stage Under Counter (WP-2)

Make sure the surroundings of the sink are cooled before mounting the
faucet to the sink after drilling and remove all sharp edges.
Step 3
Step 4
Determine desired location for the faucet on your sink and place a
piece of masking tape over where the hole is to be drilled. Mark the
center of the hole on the tape.
Step 1
Using a variable speed drill set on the slowest speed, drill a
1
/ 8 “ pilot
hole through both porcelain and metal casing of sink at the marked
center of the desired location. Use lubricating oil or liquid soap to keep
the drill bit cool (If drill bit gets hot it may cause the porcelain to crack
or chip).
Using a 1/2” Drill Bit, proceed to drill the larger hole. Keep drill speed
on the slowest speed and use lubricating oil or liquid soap to keep the
hole saw cool during cutting.
Step 2
Drill a Hole for the Faucet in a Porcelain Sink
Punch a Hole for the Faucet in a Stainless Steel Sink
Drill a ¼” pilot hole. Use a
1
/ 2 ” Hole Punch and an adjustable wrench
to punch the hole in the sink.
Step 5
The faucet can now be installed.
If mounting faucet to a Stainless Steel Sink you will need a 1/2”
Hole Punch. The faucet opening should be centered between the
back splash and the edge of the sink, ideally on the same side as
the vertical drain pipe.
Note:
Note: Most sinks are pre drilled with 1 ½” or 1 ¼” diameter hole that you can use for your
faucet. (If you are already using it for a sprayer or soap dispenser, see step 1)
Porcelain sinks are extremely hard and can crack or chip easily.
Use extreme caution when drilling. Watts Premier accepts no responsibility for
damage resulting from the installation of faucet.
Diamond tip drill bit is recommended for drilling in porcelain.
5

6
Remove faucet base & spout from their respective plastic
bags. Feed the faucet tubing through the round rubber gasket
which you will find in the faucets parts bag. Peel the white
backing from the upper side of the gasket and press firmly
on to the base of the faucet. From above the sink, feed the
faucet tubing & toggle bolt down through the .5” mounting
hole in the sink.
Peel the white backing from the bottom side of the rubber
gasket, align the faucet base so that the handle is on the
right side and press the faucet base down firmly over the
mounting hole. Turn the handle down (towards you) to the
“ON” position to reveal the tightening screw (located where
the spout will be inserted). Using a Phillips head screwdriver,
turn the screw clockwise until the toggle bolt secures the
faucet base snug onto the sink top, do not over torque toggle
bolt (5lb.in. max)
Once the faucet base is securely fastened to the sink top,
insert the faucet spout into the faucet base until it is fully
seated. Turn the handle up (away from you) to the “OFF”
position.
Connect the 3/8” blue tube from faucet to the 1/4” blue
tube from the system using the 3/8” x 1/4” union provided.
Remove the faucet battery from the plastic bag. Locate the faucet battery compartment drawer on the base of the faucet. Use
a small screwdriver to pry on the notch at the compartment drawer face and slide the drawer out. Insert the battery into the
battery compartment drawer.
NOTE: The + side of the battery faces up. The compartment drawer will not slide in if the battery is installed upside
down.
Once the battery is in place, slide the battery compartment drawer back into the base until it is flush.
When the battery is first installed, both the red and green lights will flash to indicate that both lights are functional. Thereafter, it will
flash green only when the faucet handle is turned to the “ON” position. When your system is ready to be serviced (approximately
six months) you will see the light flash red when the handle is turned to the “ON” position.
NOTE: If your water usage is high the red light may activate sooner than six months indicating the need for filter
replacement.
This faucet provides an electronic monitor that will tell you when it is time to replace the filters in your water treatment
device. The light indicator will be green for the life of the filter, turning red once the life of the filter has been reached.
This can occur after six months of use, or sooner for heavy water usage. The battery life is expected to last one
year, however, under heavy use the battery may need to be replaced sooner. For replacement, look for battery
number CR2354 (Watts p/n:116082) which should be available at your local battery store or contact Watts Premier
at 800-752-5582. You may also order online at www.wattspremier.com.
WATTS Premier Monitored & Non-Monitored
(Top Mount) Faucet Installation
Step 6
Step 7
Step 8
Step 9
Step 10
Faucet Battery Installation
Minimum Maximum
Mounting Hole Size .5” 1.25”
Torque on Toggle Bolt 5lb.in. (max)
Line from Faucet
Line from Unit

7
Adapt-a-Valve Installation
(A) Turn off the main supply water to the house.
Note: Housing plumbing may be the opposite of that shown in Figure B.
(B) Turn off the cold water supply to the faucet by turning the angle stop valve clockwise
until it is completely off. Drain any water in the line by opening the faucet cold side.
(C) Attach adapt-a-valve as illustrated in the center photo below, choosing the configuration
that fits your plumbing.
(D) Attach the loose end of the green tube to the Adapt-a-Valve, remove a brass nut,
plastic sleeve and brass insert from the parts bag. Place nut on the tube first, then
the plastic sleeve (small taper end of plastic sleeve must point to the end of tube) and
then insert the brass Insert into the end of the tube (see Figure C). Insert the green
tube into the ¼” opening on the adapt-a-valve until it stops. Slide nut and sleeve down
and thread onto the male pipe threads. Use a ½” wrench to securely tighten.
Configuration for 3/8”
compression fittings
Configuration for 1/2” fittings
(E) Turn on water supply and open the Adapt-a-valve. Check for leaks.
Correct installation of
the Adapta Valve
Figure B
System Start Up
(A) Turn faucet handle to the open position to start the flow of water through the unit. Run 7
gallons of water through the unit in order to flush out the normal black carbon fines (it will
“sputter” until the air is purged out) from the unit. Initially, the water may appear cloudy which
is due to tiny air bubbles and it will clear up shortly. Close the faucet when finished.
(B) Check for leaks. If you have any leaks, shut off the water supply to your system, tighten
any fittings / housings and restart unit.
HOT COLD
Figure C
Figure C
Caution: Water supply line to the system must be from the cold water supply line.
Hot water will severely damage your system.

Watts Premier recommends changing the filter element every 6 months. However filter life
may vary depending on local water conditions and water use.
Use Watts Premier’s replacement cartridge only. Other filters may look the same, but only
filters by Watts are manufactured to fit your WP-2 filter unit in order to ensure proper reduction
of water contaminants.
Sediment Pre-Filter
WP-2 BVC & WP-2 LCV Part# 104017
Carbon Block Filter
WP-2 BVC Part# 101003
WP-2 LCV Part# 101014
(A) Turn off incoming water supply to the WP-2 unit by
turning the needle valve on the adapt-a-valve clockwise.
Note: There will be water in the filter housing. Lift the
faucet handle to relieve the water pressure.
(B) Remove filter housing from lid by turning it to the left,
as shown in Figure D.
(C) Remove used filter cartridge and discard.
NOTE: Do not discard filter-housing o-ring.
(D) Clean inside of filter housing with warm soapy water
and rinse well to remove soap.
(E) Lubricate o-ring with water-soluble lubricant (i.e. K-Y Jelly ®).
NOTE: Do not use Petroleum based lubricants such as Vaseline ®.
(F) Seat o-ring in groove in filter housing and insert new filter cartridges into appropriate filter
housing.
(G) Screw filter housing onto lid as shown in Figure D.
(H) Turn on water supply to filter unit by turning needle valve on Adapt-a-Valve counter
clockwise
(I) Check system for leaks.
Filter Change
8
To Loosen To Tighten
Figure D

9

10
Performance Data Sheet
Watts Premier Inc.
1725 W. Williams Drive C-20
Phoenix, AZ 85027 USA
WP-2 LCV
GENERAL USE CONDITIONS:
1: System to be used with municipal or well water sources treated and tested on regular basis to insure bacteriological safe
quality. DO NOT use with water that is micro biologically unsafe or of unknown quality without adequate disinfection
before or after the system. Systems certified for cyst reduction may be used on disinfected waters that may contain filterable
cysts.
2: Operating Temperature: Maximum 100o F (40.5o C) Minimum 40o F (4.4o C)
3: Operating Water Pressure: Maximum 85-psi (5.98 kg/cm2) Minimum 20-psi
4: Maximum flow Rate: 0.50 gpm (1.89 lpm)
5: Rated Capacity: 600 Gallons (2,200 liters)
RECOMMENDED REPLACEMENT PARTS AND CHANGE INTERVAL:
Note: Depending on incoming feed water conditions replacement time frame may vary.
Description Part Number Change time Frame Cost
Stage 1: Sediment: 5M-10 104017 6 Months or 600 gallons of water $ 3.50*
Stage 2: Carbon block 101014 6 Months or 600 gallons of water $28.95*
*All prices subject to change without notice
This system has been tested according to NSF/ANSI Standard 53 for the reduction of the substances listed below. The concentration of the indicated
substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system, as
specified in NSF/ANSI 53. Testing performed under standard laboratory conditions, actual performance may vary.
Substance Percent
Reduction
Influent Challenge
Concentration
(mg/L unless noted)
Maximum Permissible
Product Water
Concentration
ALACHLOR* >98% 0.05 0.001
ATRAZINE* >97% 0.1 0.003
BENZENE* >99% 0.081 0.001
BROMODICHLOROMETHANE (TTHM)* >99.8% 0.300 +/- 0.30 0.015
BROMOFORM (TTHM)* >99.8% 0.300 +/- 0.30 0.015
CARBOFURAN (Furadan)* >99% 0.19 0.001
CARBON TETRACHLORIDE* 98% 0.078 0.0018
CHLOROBENZENE (Monochlorobenzene)* >99% 0.077 0.001
CHLOROFORM (TTHM)* >99.8% 0.300 +/- 0.30 0.015
CRYPTOSPORIDIUM (see Cyst) 99.99% minimum 50,000/mL 99.95%
CYST 99.99% minimum 50,000/mL 99.95%
2, 4-D* 98% 0.110 0.0017
DBCP (see Dibromochloropropane)* >99% 0.052 0.00002
1,2-DCA (see 1,2-DICHLOROETHANE)* 95% 0.088 0.0048
1,1-DCE (see 1,1-DICHLOROETHYLENE)* >99% 0.083 0.001
DIBROMOCHLOROMETHANE
(TTHM;Chlorodibromomethane)* >99.8% 0.300 +/- 0.30 0.015
DIBROMOCHLOROPROPANE (DBCP)* >99% 0.052 0.00002
o-DICHLOROBENZENE (1,2 Dichlorobenzene)* >99% 0.08 0.001
p-DICHLOROBENZENE (para-Dichlorobenzene)* >98% 0.04 0.001
1,2-DICHLOROETHANE (1,2-DCA)* 95% 0.088 0.0048
1,1-DICHLOROETHYLENE (1,1-DCE)* >99% 0.083 0.001
CIS-1,2-DICHLOROETHYLENE* >99% 0.17 0.0005
TRANS-1,2- DICHLOROETHYLENE* >99% 0.086 0.001
1,2-DICHLOROPROPANE (Propylene Dichloride)* >99% 0.08 0.001
CIS-1,3- DICHLOROPROPYLENE* >99% 0.079 0.001
DINOSEB* 99% 0.17 0.0002
EDB (see ETHYLENE DIBROMIDE)* >99% 0.044 0.00002
ENDRIN* 99% 0.053 0.00059

Substance Percent
Reduction
Influent Challenge
Concentration
(mg/L unless noted)
Maximum Permissible
Product Water
Concentration
ENTAMOEBA 99.99% minimum 50,000/mL 99.95%
ETHYLBENZENE* >99% 0.088 0.001
ETHYLENE DIBROMIDE (EDB)* >99% 0.044 0.00002
FURADAN (see CARBOFURAN)* >99% 0.19 0.001
HALOACETONITRILES (HAN)*
BROMOCHLOROACETONITRILE 98% 0.022 0.0005
DIBROMOACETONITRILE 98% 0.024 0.0006
DICHLOROACETONITRILE 98% 0.0096 0.0002
TRICHLOROACETONITRILE 98% 0.015 0.0003
HALOKETONES (HK):*
1,1-DICHLORO-2-PROPANONE 99% 0.0072 0.0001
1,1,1-TRICHLORO-2-PROPANONE 96% 0.0082 0.0003
GIARDIA LAMBLIA (see Cyst) 99.99% minimum 50,000/mL 99.95%
HEPTACHLOR* >99% 0.25 0.00001
HEPTACHLOR EPOXIDE* 98% 0.0107 0.0002
HEXACHLOROBUTADIENE
(Perchlorobutadiene)* >98% 0.044 0.001
HEXACHLOROCYCLOPENTADIENE* >99% 0.060 0.000002
LEAD pH 6.5 99% 0.15 +/- 10% 0.010
LEAD pH 8.5 99% 0.15 +/- 10% 0.010
LINDANE* >99% 0.055 0.00001
METHOXYCHLOR* >99% 0.050 0.0001
METHYLBENZENE (see TOLUENE)* >99% 0.078 0.001
MONOCHLOROBENZENE
(see CHLOROBENZENE)* >99% 0.077 0.001
PCE (see TETRACHLOROETHYLENE)* >99% 0.081 0.001
PENTACHLOROPHENOL* >99% 0.096 0.001
PERCHLOROBUTADIENE
(see HEXACHLOROBUTADIENE)* >98% 0.044 0.001
PROPYLENE DICHLORIDE
(see 1,2 -DICHLOROPROPANE)* >99% 0.080 0.001
SIMAZINE* >97% 0.120 0.004
SILVEX (see 2,4,5-TP)* 99% 0.270 0.0016
STYRENE (Vinylbenzene)* >99% 0.15 0.0005
1,1,1-TCA
(see 1,1,1 - TRICHLOROETHANE)* 95% 0.084 0.0046
TCE (see TRICHLOROETHYLENE)* >99% 0.180 0.0010
1,1,2,2- TETRACHLOROETHANE* >99% 0.081 0.001
TETRACHLOROETHYLENE* >99% 0.081 0.001
TOLUENE (Methylbenzene)* >99% 0.078 0.001
TOXOPLASMA minimum 50,000/mL 99.95%
2,4,5-TP (Silvex)* 99% 0.270 0.0016
TRIBROMOACETIC ACID* 0.042 0.001
1,2,4 TRICHLOROBENZENE (Unsymtrichlorobenzene)* >99% 0.160 0.0005
1,1,1-TRICHLOROETHANE (1,1,1-TCA)* 95% 0.084 0.0046
1,1,2-TRICHLOROETHANE* >99% 0.150 0.0005
TRICHLOROETHYLENE (TCE)* >99% 0.180 0.0010
TRIHALOMETHANES (TTHM) (Chloroform; Bromoform;
Bromodichloromethane; Dibromochloromethane) >99.8% 0.300 +/- 0.30 0.015
Unsym-Trichlorobenzene (see 1,2,4-
TRICHLOROBENZENE)* >99% 0.160 0.0005
Vinylbenzene (see STYRENE)* >99% 0.150 0.0005
XYLENES (TOTAL)* >99% 0.070 0.001
11

Performance Data Sheet
Watts Premier Inc.
1725 W. Williams Drive C-20
Phoenix, AZ 85027 USA
WP-2 BVC
GENERAL USE CONDITIONS:
1: System has been independently tested for the removal of microbiologically contaminated water. The system is not intended
for the treatment of water that has an obvious contamination source, such as raw sewage. This system is not intended to
convert wastewater to microbiologically safe drinking water.
2: Operating Temperature: Maximum 100o F (37.8o C) Minimum 40o F (4.4o C)
3: Operating Water Pressure: Maximum 85-psi (5.98 kg/cm2) Minimum 20-psi
4: Maximum flow Rate: 0.50 gpm (1.89 lpm)
5: Rated Capacity: 2000 Gallons (7,500 liters)
RECOMMENDED REPLACEMENT PARTS AND CHANGE INTERVAL:
Note: Depending on incoming feed water conditions replacement time frame may vary.
Description Part Number Change Time Frame Cost
Stage 1: sediment: 5M-10 104017 6 Months $ 3.50*
Stage 2: Microbiological Carbonblock 101003 6 Months $33.95*
*All prices subject to change without notice
This system has been tested according to NSF/ANSI Standard 42 for the reduction of the substances listed below. The concentration of the indicated
substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system, as
specified in NSF/ANSI 42. Testing performed under standard laboratory conditions, actual performance may vary.
Contaminant Influent Challenge Concentration Percent Reduction Achieved
Chlorine Taste & Odor 2.0 mg/L + 10% 98%
Bacteria* 99.9999%
Virus* 99.99%
Cyst* 99.95%
* Independently tested and verified by BioVir Laboratories
These substances are not necessarily in your drinking water.
Refer to the owners manual for further maintenance requirements and warranty information. System must be maintained according to
manufacturers use instructions, including replacement of filter elements.
Questions? Contact Watts Premier 800-752-5582 www.wattspremier.com
623-931-1977
System has been tested by Bio Vir as a Microbiological
Water Purifiers based on the recommendations set forth in
the USEPA Guide Standard and Protocol for Microbiological
Water Purifiers (OPP Task Force Report, 1987).
12

13

Watts Premier has other fine water filtration products and accessories to enhance your water and to
compliment your water filtration system. Listed on this page are only a few of the items we offer. Visit
our web site at www.wattspremier.com or call our Customer Service Representatives at
1-800-752-5582 (inside USA) 1-623-931-1977 (outside USA) for more products.
Other Products from Watts Premier
Watts Premier Ice Maker Filter Kit - High efficiency replaceable filter that
can last up to 5 years or 20,000 gallons. Perfect for residential and com-
mercial ice makers as well as refrigerators, drinking fountains, coffee & tea
brewers, motor homes and campers. Reduces chlorine taste and odor.
Part No. 500327 *$36.95/ea
*All prices subject to change without notice.
One Piece Manifold 5-Stage Reverse Osmosis WP-5
This state of the art manifold reverse osmosis system provides a seamless
water path eliminating 17 connections from standard style units. Includes
carbon block technology and high production 24gpd Thin Film Membrane
- NSF Certified for the reduction of a wide range of contaminants including:
Arsenic, Chromium, Perchlorate, Lead, Radium, and many others.
Part No. 500023 *$239.00/ea
14
Watts Premier Hot Water Recirculation System
Bring convenience and savings to your home, giving you hot water instantly
at every faucet, when you need it. This unique product is easy to install and
not only provides you with the convenience of hot water when you need it, but
saves an average of over 15,000 gallons per year.
Part No. 500800 *$229.99/ea
Whole House Filter
Great for sediment problems such as in well water supply or areas where dirt
and rust particles are a problem. Includes three 50 micron sediment filters
and wrench
(3/4” ports)
Part No. 500223 *$42.95/ea
Replacement filter
Part No. 304007 *$ 4.50/ea
PoolDocTM accurately measures pool and spa chemistry and provides
instructions on how to bring the pool/spa back into balance.
Part No. 164040 *$189.99/ea
Pool Doc Pool & Spa Water Tester

4 Ways to Register
1. On-line at www.wattspremier.com
2. Call in your information 1-800-752-5582
3. Fax in your information 623-931-0191
First Name:_________________________ Last Name:____________________________
Address: ________________________________________ City: ____________________
State: _______________________________________ Zip Code: ___________________
Country: USA CANADA MEXICO OTHER ____________
Phone # ______-__________ -__________ Email Address: ______________________
Date of Purchase: ___________________ Date of Install: _______________________
Installed By: SELF Plumbing Professional Where Purchased: ____________
Model Number: _______________________ Serial Number: ____ - __________
Watts Premier, Inc. 1725 W. Williams Drive C-20 Phoenix, AZ 85027
Phone: [phone] www.wattspremier.com Fax: [phone]
Register your product on-line and receive a 5% discount on your next on-line order, Plus receive reduced shipping.
4. Mail in the information.
Please complete the form below. Mail to: Watts Premier
1725 W. Williams Dr. C-20
Phoenix, AZ 85027
Fax this form directly to us.
Call and we will enter your registration information for you.
XXXXX XXXXXX
-
Watts Premier Inc. is concerned for the safety of your personal information. Watts Premier collects personal information when you register
with Watts Premier. This information is stored in our data base and we do not rent, sell, or share personal information with other people
or nonaffiliated companies. We reserve the right to send you certain types of communications such as direct mail, email, or by telephone
relating to our products or products that you have purchased. We limit access to your personal information to those employees who will
directly provide you with services or products in order to do their jobs. We want to offer you four ways to communicate with us. 1.Online,
2.Fax, 3.Telephone, and 4. Mail the form below. By registering your product you will receive the full benefit of our warranty. Watts Premier
will also send you a semiannual filter change reminder beginning six months from date of installation. To insure the highest quality of your
water, filters should be replaced every 6 months. If you have any questions or comments please give us a call at 1-800-752-5582 M-F
8:00am -5:00pm MST.
Registering will
insure you
receive Watts
FREE
Filter
Reminder
Notice
Thank you for selecting Watts Premier for your water filtration needs.
WARRANTY REGISTRATION
15

WARRANTY REGISTRATION
Please Fill out and keep for your Records
Insert into envelope and return to Watts Premier
First Name:_________________________ Last Name:____________________________
Address: ________________________________________ City: ____________________
State: _______________________________________ Zip Code: ___________________
Country: USA CANADA MEXICO OTHER ____________
Phone # ______-__________ -__________ Email Address: ______________________
Date of Purchase: ___________________ Date of Install: _______________________
Installed By: SELF Plumbing Professional Where Purchased: ____________
Model Number: _______________________ Serial Number: ____ - __________
Iowa Department of Public Health - Sales in Iowa require this to be completed, signed and returned.
These signatures will be retained on file for two years.
XXXXX XXXXXX
-
Watts Premier
1725 W. Williams Dr. C-20
Phoenix, AZ 85027
16

17

1725 W. Williams Dr. C-20 • Phoenix, Arizona 85027
Limited Warranty
What your Warranty Covers:
If any part of your WATTS PREMIER WP-2 is defective in workmanship (excluding replaceable filters ), return unit after
obtaining a return authorization (see below), within 3 years of original retail purchase, WATTS PREMIER will repair or, at
WATTS PREMIER’S option, replace the system at no charge.
How to obtain Warranty Service:
For warranty service, call 1-800-752-5582 for a return authorization number. Then, ship your unit to our factory, freight and
insurance prepaid, with proof of date of original purchase. Please include a note stating the problem. Premier will repair it,
or replace it, and ship it back to you prepaid.
What this warranty does not cover:
This warranty does not cover defects resulting from improper installation, (contrary to WATTS PREMIER’S printed
instructions), from abuse, misuse, misapplication, improper maintenance, neglect, alteration, accidents, casualties, fire,
flood, freezing, environmental factors, water pressure spikes or other such acts of God.
This warranty will be void if defects occur due to failure to observe the following conditions:
1. The WP-2 System must be hooked up to a potable municipal or well cold water supply.
2. The pH of the water must not be lower than 5 or higher than 10.
3. The incoming water pressure must be between 20 and 85 pounds per square inch.
4. Incoming water to the Counter Top cannot exceed 100 degrees F (38 degrees C.)
This warranty does not cover any equipment that is relocated from the site of its original installation.
This warranty doe not cover any charges incurred due to professional installation.
This warranty does not cover any equipment that is installed or used outside the United States of America and Canada.
LIMITATIONS AND EXCLUSIONS:
WATTS PREMIER WILL NOT BE RESPONSIBLE FOR ANY IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. WATTS PREMIER WILL NOT BE RESPONSIBLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES, INCLUDING TRAVEL EXPENSE, TELEPHONE CHARGES, LOSS OF REVENUE, LOSS OF TIME,
INCONVENIENCE, LOSS OF USE OF THE EQUIPMENT, AND DAMAGE CAUSED BY THIS EQUIPMENT AND ITS FAILURE TO
FUNCTION PROPERLY. THIS WARRANTY SETS FORTH ALL OF PREMIER’S RESPONSIBILITIES REGARDING THIS EQUIPMENT.
OTHER CONDITIONS:
If WATTS PREMIER chooses to replace the equipment, WATTS PREMIER may replace it with reconditioned equipment. Parts used in
repairing or replacing the equipment will be warranted for 90 days from the date the equipment is returned to you or for the remainder of
the original warranty period, whichever is longer. This warranty is not assignable or transferable.
YOUR RIGHTS UNDER STATE LAW:
Some states do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitations or exclusions may not apply. This warranty gives you specific legal rights,
and you may have other legal rights which vary from state to state.
18
