Watts Vision BT-CT02 RF User manual

www.wattswater.eu
BT-CT02
Central Unit WIFI
WATTS Vision®System
EN
DE
FR
NL
IT
ES
DA
SV
NO
FI
Installation and user guide......................................................... 2-24
Installations- und Bedienungsanleitung ................................... 26-48
Guide d‘installation et d‘utilisation .......................................... 50-72
Installatie- en gebruikersgids................................................... 74-96
Guida all‘installazione e all‘uso .............................................. 98-120
Guía de instalación y uso ..................................................... 122-144
Installations- og brugervejledning........................................ 146-168
Installations och användaranvisningar ................................. 170-192
Installasjons- og brukerhåndbok .......................................... 194-216
Asennus- ja käyttöopas ........................................................ 218-240

ENGLISH
EN
22019 / 06 Watts | PPLIMW15428C
TABLE OF CONTENT
General information ..........................................................................3
1. Presentation ................................................................................. 4
2. Installation .....................................................................................5
2.1 Installation sequence
2.2 Install your central
2.2.1 Wall mounting
2.2.2 Table installation (with optional mini USB cable – sold seperately)
2.3. Main screen icons
2.3.1 General pictograms
3. Settings..........................................................................................7
3.1 Main menu
3.2 Adjust time / user settings
3.3 Configure your house
3.4 Pair your devices to the central
4. Hydraulic system pairing ............................................................ 11
5. Installation types (heating/cooling) ............................................13
6. Set up Wifi connection for remote control ................................ 15
7. Heating/cooling devices management & programming............16
7.1 Programming your devices
7.2 Lighting devices management
7.3 ON/OFF devices management
8. Maintenance ................................................................................21
9. Technical characteristics ............................................................21
10. EU Declaration of conformity ....................................................22
11. Compatible devices ...................................................................23

ENGLISH EN
3
PPLIMW15428C | 2019 / 06 Watts
GENERAL INFORMATION
Safety warnings and operating
instructions
• This product should be installed prefer-
ably by a qualified professional.Subject
to observation of the above terms, the
manufacturer shall assume the liabil-
ity for the equipment as provided by
legal stipulations. All instructions in this
Installation & Operation manual should
be observed when working with the
controller.
• Failures due to improper installation,
improper use or poor maintenance are
voiding manufacturer liability
• Any attempt to repair voids the respon-
sibility and the obligation to guarantee
and replacement from the manufacturer.
Disposal and recycling
information
The full text of the EU declaration of con-
formity is available at the following internet
address: www.wattswater.eu
• 2012/19/EU (WEEE directive): Products
marked with this symbol cannot be dis-
posed of as unsorted municipal waste
in the European Union. For proper recy-
cling, return this product to your local
supplier upon the purchase of equiva-
lent new equipment, or dispose of it at
designated collection points. For more
information see: www.recyclethis.info
• 2006/66/EC (battery directive): This
products contains a battery that cannot
be disposed of as unsorted municipal
waste in the European Union. See the
product documentation for specific bat-
tery information. The battery is marked
with this symbol, which may include
lettering to indicate cadmium (Cd), lead
(Pb), or mercury (Hg). For proper recy-
cling, return the battery to your supplier
or to a designated collection point. For
more information see: www.recycle-
this.info

ENGLISH
EN
42019 / 06 Watts | PPLIMW15428C
1. PRESENTATION
Thank you for choosing WATTS Vision®,
a Wireless communication system for con-
trolling heating and cooling system. It allows
multi zones management (up to 50) of your
electrical and hydraulic heating system.
The central unit, main characteristics:
• Touch screen
• Interface via internet (WiFi)
• Wall mountable with power supply
85-265VAC (50-60) Hz
• Table mountable with supplied bracket
and mini USB power supply (0-5V)
(sold separately)
• Back up Battery for installation opera-
tion of 1 hour maximum
• RF Communication only with WATTS
Vision®devices (up to 40m internal,
extendable with repeater)
• Able to manage up to 50 zones or
rooms and 4 main supply circuits with
a dedicated pump or boiler on each
• Multiple heating / cooling devices control
• SD Card slot for updating software
• Intuitive menus for devices manage-
ment
Content of the packaging:
• central unit
• 230V Flush mounted power supply
• wall/table support
• CE conformity declaration
• Installation and user guide
2. INSTALLATION
2.1 Installation sequence
Please follow the set-up sequence below;
STEP 1 Install your central unit (see 2.2
Install your central)
STEP 2 Create your house / create and
name your rooms (see 3.3 Configure your
house – page 10). Please note when pairing
the BT-M6Z02 RF with the central unit, the
rooms are automaticaly created according
to the number of RF thermostats.
STEP 3 Pair your devices to the central
controller / allocate them to the appropri-
ate rooms (see 3.4 Pair your devices to
the central – page 11) Please charge the
central unit for at least 1 hour before
pairing the devices already mounted
STEP 4 Personalise your central unit user
settings (see 3. Settings – pages 7 to 11)
STEP 5 Set up Wifi for remote control of
your system via smart-phone / tablet (see
6. Set up Wifi control – page 15)
STEP 6 Program your devices so that they
work on a time schedule (see 7. Heating /

ENGLISH EN
5
PPLIMW15428C | 2019 / 06 Watts
Cooling Device Management – page 16)
2.2 Install your central
2.2.1 Wall mounting
2.2.2 Table installation (with
optional mini USB cable – sold
seperately)
Connect the central unit with the
mini USB cable (5V, 1A) and then
mount the leg support on it and
put the switch on ON position.
The central unit is ready for oper-
ation.
mains power supply
85-265vac - 50 /60hz
not to be used
Connect the power as described above
Screw the power unit on the wall and
connect to power supply.
Note! The tab must be on the top!
Put the switch on ON position
ON /OFF
Mount the Central on the
power unit and slide it on the
bottom to clip it. The Central
is ready for operation.
ON /OFF
Mini
USB
cable
Tab
UP

ENGLISH
EN
62019 / 06 Watts | PPLIMW15428C
1Display the time or the ambient T° of
the room or zone. Make your choice
by pressing on the central part of the
screen
2Date
3Holidays mode status.
4 Display the ambient temperature in
desired room.
5Screen lock. Long press toggles
between locking / unlocking.
6Main menu.
2 31
11
9
10 5
6
4
8 7
7The device is working on battery (! only for set-
tings and pairing).
8Error flag – press to access RF, limits, alarms,
battery anomalies.
9Rooms access (if Central is locked – cannot
change settings).
10 Boiler status displayed if connected to the
Central.
11 Outside sensor temperature (Require Outdoor
sensor device)
To return to the main screen.
To return to the previous
screen.
The buttons with a red point
requires a long press (min 5s)
short press
long press (min 5s)
2.3 Main screen icons description
2.3.1 General pictograms and actions

ENGLISH EN
7
PPLIMW15428C | 2019 / 06 Watts
6 7 8
3. SETTINGS
3.1 Main menu
1Energy consumption statistics menu.
2Language (the flag of the current lan-
guage is displayed). 8 languages are
proposed. If you want to select another
language, you need to insert the soft-
ware (available on www.wattswater.eu.)
on a microSD then select yours.
3 General commands menu. Use this
menu to put all the same devices type
in the same operating mode.
Press to go to
main menu
2 3 41
5
To select the heating/
cooling devices mode
for all the installation.
To select the ON/OFF
devices mode for all
the installation.
To select the lighting devices
mode for all the installation. To validate the selections.

ENGLISH
EN
82019 / 06 Watts | PPLIMW15428C
4Heating/cooling mode man-
agement menu. See section
“Heating and cooling control”
5 User settings menu.
In this menu, you can set:
• Time, Date (Manual, Automatic).
•Time zone (UTC) if the device is in
automatic time update mode.
•Time and date if the device is in manual
time update mode.
• Summer-Winter (Manual, Automatic).
• Temperature unit (°C, °F).
• Background Color.
• Buttons color.
• Backlight.
• Screen saver (Enabled, Disabled).
• Default screen (Home, Clock, Disabled)
• Screen cleaner.
• Factory default user (interface).
6 WIFI menu.
Reading button (refreshment).
The Internet Access password allows to link
your central unit to your Internet account
(See below) for a remote control of your sys-
tem through the Internet or Smart Phone.
n.b.: At first use or software update, wait for
some time until the green State icon is active.
7 Holidays menu.
• To set the departure / return dates and
time.
• Use <or >to select year / month / day,
hour & minute.
• Set and validate the operating mode
of the devices in holiday mode. (Same
menu then general commands menu).
8 Installation menu
AHouse creation.
See house creation section.
BRadio pairing.
See radio pairing section.
CDelete a device:
Select device type and then the
device.
DDelete all devices:
All devices installed in the system will
be deleted (rooms will be maintained).
A
D
J
B
E
K
C
F
L
G
H
I

ENGLISH EN
9
PPLIMW15428C | 2019 / 06 Watts
EIdentify a device
To identify a device of the installation,
go to Installation Menu, then “Identify
a Device”
Process:
to make the Central listening
on the device receiver and wait a
few seconds until radio communication
frame is transmitted.
Note: ID-number is displayed on the
screen, please repeat to be sure to have
the same ID.
on to change device param-
eters (name, power …).
FAntifreeze setpoint:
You can set the antifreeze setpoint as
reference for the whole installation.
GHeating setting:
You can fix setpoint limitations (min/
max) per zone and the offset assigned
to devices working in floor sensor reg-
ulation
HHeating/cooling settings:
You can set the installation:
• in heating mode,
• in cooling mode or
• in manual mode.
If you set the device in manual mode, the
icon appears on the main menu.
IWIFI settings:
To set the WIFI configurations (SSID/
Protected Access Key Type/ Password).
You can do it manually or scan the
active networks.
Configuration requesting a registration
on a web page is not supported.
WIFI Status:
0/2: Central unit not connected to the wifi
router and server
1/2: Central unit connected to the Wifi
router (not to the server)
2/2: Central unit connected to the wifi
router and to the server (Pairing of the
central to an account is required)
n.b.: The connection to Internet is
recommended with Certified WiFi routers
(http://www.wi-fi.org/certification).
n.b.: Automatic pairing time to WiFi router
with WEP key: 3-4 min, with WPA2 key: 1 min.
n.b.: For the network scan, Repeat at least
twice the operation if your desired WiFi net-
work is not displayed. If your desired WiFi
network is still not displayed, enter the WiFi
settings manually
JGeneral factory default:
To reset the system with the factory
values, but the software version will
remain the same.
KUpdate Firmware:
To update the software, with the SD-card.
The system is qualified to work with
SD-cards less than or equal to 16GB.
Please wait the end of the update
procedure (The Wifi icon should be
available for the Wifi central unit) before
removing the microSD from the cen-
tral unit. The SW and the procedure to
update the central unit is available on
www.wattswater.eu.
To put the menu in
reception mode
To access to the
device parameters

ENGLISH
EN
10 2019 / 06 Watts | PPLIMW15428C
LCloning:
The menu allows to transfert a configu-
ration from central 1 to central 2. If you
change the central, you do not have to
reconfigure your system.
Put update.bin file on SD card (Special
software for cloning available on www.
wattswater.eu).
Insert the SD card (load with the clon-
ing sofware) in central 1 and make
an update firmware. Insert the same
SD card in central 2 and launch the
cloning. After the cloning, you need to
reconfigure the Wifi and the langage.
3.2 Adjust time / user settings
Language
Set the time and the date manualy or in
automatically you have to set the time
zone (UTC) and the device is getting the
time from internet (WIFI connection is
needed).
Personalise your screen settings, e.g.
background colour etc.
See “User Settings Menu” in MAIN MENU
section (page 8) for further information.
3.3 Configure your house
Create all the rooms and re-name them e.g.:
• room 1 = Kitchen,
• room 2 = Lounge etc,
where the various devices such as thermo-
stats will be placed.
Scroll over rooms. To change current room (zone) name.
To create or
add a room
(zone).
To delete a
room (zone).
Current room name

ENGLISH EN
11
PPLIMW15428C | 2019 / 06 Watts
3.4 Pair your devices to the
central
• Install your devices (see relevant
device manuals)
• Create the room if it doesn’t exist (See
section 3)
• Go to Radio pairing
• Choose the device type (heating, On/Off
Device etc)
• Choose the room
• Note: The master (thermostat or
BT-M6Z02 RF) must be the first paired
device
• Put the device in pairing
mode (refer to device leaflet)
• Follow the instructions given by the
Central (check on the device that
the pairing is successful, refer to the
device leaflet)
• n.b.: Automatic pairing time in case of
RF communication loss: 10s.
• n.b.: Pairing of the repeater: Select any
device type, any room and does not
consider the pairing failure message
on the central unit at the end of the
procedure. The led should be green fix
on the repater.
• Check the successful installation
You will have warning in home menu
for RF errors communications. The warn-
ing flag should appear for a maximum of
10mn. It would then disappear if there are
no communication problems. If not, check
devices showing RF errors, try moving
them to another place and repeat the
procedure.
4. HYDRAULIC SYSTEM
ASSIGNEMENT
Within an installation, it may be necessary
to control devices such as pumps, valve
drives or heat / cool producers, as soon
as heating or cooling demand exists on at
least one zone.
With WATTS Vision®, up to 4 such devices
can be switched via the “hydraulic circuit”
function.
Each of these 4 possible circuits can be
controlled via a single radio receiver.
STEP 1:Define which device is assigned
to a hydraulic circuit
With the plan of your installation, define
which devices are on “circuit 1”. Then, using
the Central controller, pair and configure all
these devices on circuit 1.
, enter a zone (room) that belong
to circuit 1,
, and select one device of circuit 1
(radio connecting box, radio receiver or radia-
tor thermostatic head)
Now you have entered the
configuration menu of the device. Select
the menu “Heating settings” and make
sure that “Hydraulic heating” is selected

ENGLISH
EN
12 2019 / 06 Watts | PPLIMW15428C
You can now select the
hydraulic circuit linked to this receiver (e.g.
circuit 1).
Repeat the procedure for each device of
the room (zone) you want to link to the
hydraulic circuit. Further devices can be
selected using the buttons [<<<] or [>>>] at
the top of the device name.
Repeat the procedure for each room (zone)
that you want to link to hydraulic circuit
1. If you have assigned all rooms / devic-
es, repeat the procedure for any further
hydraulic circuits.
STEP 2:pairing radio receiver hydraulic
circuit with the central unit
For each circuit, you can link a circuit receiver
to drive the pump devices, valve drive or
heat / cool generator of the circuit. This can
be done for example by BT-WR02 RF.
Select “Circuit”, then select the number
of the circuit, e.g. circuit 1. Put the radio
receiver in pairing mode (BT WR02 RF).
Repeat the procedure for additional
hydraulic circuits.
Heat and Cool installations
If your installation includes both heating and
cooling functions, you can switch either
from Heat to Cool manually or automati-
cally:
• If you have a BT HCM02 RF in your
installation set as “Master” (refer to
Manual instruction of the device) then
all is automatic you don’t have to do
anything
• For all other cases, you have to do the
switch manually:
and go in “H&C”.
There you will have the choice netween
“Heating Only” “Cooling Only” or “Manual
Reversible”. With this last option, you cre-
ate a shortcut in the main menu where you
can easily change Heat/Cool mode.
Notes:
• In Cooling Mode, Reduced mode and
Antifreeze mode are inactive:
icon is displayed
instead of or .
• In the thermostat, user can configure
the parameter “Cold” that allows the
zone to do Cooling or not. If it is set
to “No”, then if the mode of the zone
is Cooling then the zone won’t make
Cooling.

ENGLISH EN
13
PPLIMW15428C | 2019 / 06 Watts
5. INSTALLATION TYPES (HEATING/COOLING)
TYPE 1 In this configuration:
• Pair first the thermostat (master) with the Central before pairing the other devices
(configured as heating devices).
• The actuators regulate on thermostat temperature.
TYPE 2 In this configuration:
• Pair first the thermostat (master - configured as a heating device) with the Central
before pairing the other devices.
• The other devices regulate on thermostat temperature.
Warning! In this installation type, the thermostat (MASTER) must be in regulation Air
mode (not floor or Air + Floor)
ROOM 1
ROOM 1
Master-Thermostat
Master
and/or
and/or
and/or
and/or and/or
Actuators

ENGLISH
EN
14 2019 / 06 Watts | PPLIMW15428C
TYPE 3 In this configuration (no thermostat):
• BT-TH configured as heating device. BT-PR, BT-FR, BT-WR can be configured as
an On / Off or lighting devices.
TYPE 4 In this configuration:
• Each thermostat is first paired with the appropriate UFH1 and then the UFH1(s) are
paired with the Central
• During the pairing, the Central automatically creates rooms according to the number
of thermostats (rooms) of UFHs.
ROOM 1
and/or
Max. 4 UFH1
and/or and/or
ROOM 1 ROOM 2 ..... ROOM 12
BT-PRBT-TH BT-FR BT-WR

ENGLISH EN
15
PPLIMW15428C | 2019 / 06 Watts
STEP 3 Create an Account
• Enter your details and select language.
• Select “Validate” (email will be sent to
you with link).
• Go to your email and click on the link.
• Go back to your App account and fol-
low the on screen instructions.
• Request a pairing code to link your
central unit. The pairing code (valid
24h) is sent to your email inbox.
In the WiFi status menu of the central
unit, enter the pairing code (internet access
password).
Your central unit should appear after a few
minutes in the application or the web page.
Click the refresh button if necessary. WiFi
status should read 2/2.
Please note! It may take up to a few hours
to display all rooms and devices in the
application. You can then operate your
central unit from anywhere.
Watts is not responsible for the correct
operation of the connected devices, and
potential damage caused by malfunction
or improper use of the connected devices
and appliances.
6. SET UP WIFI
CONNECTION FOR MOBIL
APP REMOTE CONTROL
STEP 1 Connect the central unit to
your WiFi network:
• Choose WiFi settings
• Choose Research Networks (searches
for your wifi)
• Choose your WiFi from the list and
enter your regular WiFi password
• Observe unit counting down from 120
to zero
• Make sure that the central is now
connected to the WiFi network with
an IP address (WiFi status should read
1/2)
If after several attempts, connection is
unsuccessful, connect the central unit to
WiFi manually (see WiFi settings page 9).
STEP 2 Download the app to your
device:
• For PC: click on dedicated link avail-
able on www.wattswater.eu homepage
• For Smartphone: download WATTS
Vision®application from App store or
Google Play.

ENGLISH
EN
16 2019 / 06 Watts | PPLIMW15428C
1Device type choice (heating/cooling,
lighting, On/Off). These buttons are
only displayed if one device type is
installed in the room (colored if active).
2Current mode, press on this icon
to enter in the menu where you can
change the current operating mode.
3Ambient temperature or setting tem-
perature (setpoint) or humidity after
one press on 8.
4Heating/cooling indicator (animated if
demand).
5Information about the heating/cooling
devices installed in the room
6Only displayed if the screen is locked.
7Set the current setpoint (deactivated if
the screen is locked).
8To display either the ambient or setting
temperature or Humidity in 3.
9Quick access to the desired room.
10 Pilot wire status.
11 Current room name.
12 Floor temperature if floor regulation.
13 Room changing.
34 5 62
17
8
9
13
11 1012
in the main screen and after
selecting the room
7. HEATING/COOLING DEVICES MANAGEMENT &
PROGRAMMING

ENGLISH EN
17
PPLIMW15428C | 2019 / 06 Watts
Anti freeze Mode: Use this mode
to put your room in anti-freeze mode (the
temperature is set in the Installation menu)
OFF Mode: To switch OFF the
device (room in off mode). Be careful! In
this mode, your installation can freeze!
to access this modes menu:
Comfort Mode: Set the room
in comfort mode. If it remains active, the
comfort temperature will be followed all
the time.
Reduced Mode: Set the room
in reduced mode. If it remains active, the
reduced temperature will be followed all
the time.
Timer or Boost Mode: Temporary
derogation. Set the timer duration (days,
hours, minutes) by pressing on button,
then validate and set the desired tempera-
ture on main screen.
MODES
Comfort mode
Automatic mode Reduced mode Timer or Boost Mode
Anti-Freeze mode
OFF mode

ENGLISH
EN
18 2019 / 06 Watts | PPLIMW15428C
7.1 Programming your devices
Auto Mode: In this mode, the
room temperature will follow the program
you have chosen. You can choose between
existing programs or you can create a new
one that you can modify as you want.
to select between :
Use the Comfort button to select
the hourly ranges during which the com-
fort temperature will be followed (brown
range)
• and the reduced button to select
the hourly ranges during which the
reduced temperature will be followed
(blue range).
• Use the arrows and to put
the cursor on the desired hours.
Validate the program; the validated days
are then highlighted in green (on this exam-
ple: Monday and Tuesday).
The days that are not programmed are
displayed in red.
• to view the current program
• Default programms:
P1: morning, evening & weekend.
P2: morning, midday, evening & weekend.
P3: day & weekend.
P4: evening & weekend.
P5: morning, evening (bathroom).
To select an
existing program.
To create a
new program. To view and modify an existing program
Select the days for which you
want the same program (in the
example, Wednesday, Thursday
and Friday).

ENGLISH EN
19
PPLIMW15428C | 2019 / 06 Watts
7.2 Lighting devices
management
in the main screen and
1Device type choice (heating / cooling,
lighting, On / Off). These buttons are
only displayed if one device type is
installed in the room (colored if active).
2Information about the lighting devices
installed in the room.
3Indicates both the current lighting
device number / the number of lighting
devices in the room.
4Only displayed if the number of devices
is upper than 1; used to select the
devices in the room.
5Only displayed if the screen is locked.
7Quick access to the desired room.
3 4 52
1
10
6
7
9
8
6General management for all lighting in
the room.
8Current room.
9Room changing.
10 Indicates the lighting status. A press on
it switches the lighting status.
Please note that the lighting functionality
does not support programs. If you want
to program the lighting devices, please set
the devices as ON / OFF.

ENGLISH
EN
20 2019 / 06 Watts | PPLIMW15428C
7.3 ON/OFF devices
management
in the main screen and on
1Long press to switch between auto
mode and normal mode (colored if
active).
2Information about the device.
3Indicates both the number of the current
device / number of devices in the room.
4Displayed only if the device is in Auto
mode, press to access and edit the
device program.
5Only displayed if the number of devices
is upper than 1; used to select the devic-
es in the room.
6Only displayed if the screen is locked.
7General management for all the
ON / OFF devices in the room.
8Quick access to the desired room.
9Current room.
10 Room changing.
11 Indicates the ON / OFF status. A press
on it switches the status of the device.
12 Device type choice (heating/cooling,
lighting, On / Off). These buttons are
only displayed if one device type is
installed in the room (colored if active).
3 5 641 2
12
11
7
8
10
9
