Watts W561 User manual

U-W561

User Manual

W561 WiFi Thermostat

WARNING

!

Please read carefully before proceeding with

installation. Your failure to follow any attached

instructions or operating parameters may lead to the

product’s failure.

Keep this Manual for future reference.

Works with the

Watts®Home Mobile App

Current time

Current temperature

Equipment operation

(Heat On)

Change operating mode

Touch or to adjust

temperature

Hold overrides the

programmed schedule until

the time shown

‘Save to schedule’ applies the

new temperature to the current

schedule event.

Go to settings

Swipe to view:

• Weather

• Outdoor temperature

• Floor temperature

• Heat To setting

Go to schedule

After 60 seconds of inactivity, the thermostat home screen displays only the time

and the temperature.

Save

Cancel

Mode

Off

Heat

Temperature Adjustment

Hold Until 5:00 PM

Save to Schedule

70

Heat To

MENU SELECTION

AWAY SCHEDULE

DISPLAY TIME

WIFI SETUP

WIFI: Connected

Home Screen

2

The App Store®is a registered trademark of Apple Inc.

The “Google Play” name and the Google Play Store icon are property of Google LLC.

Set heating temperature

Select skip if you don’t

want a temperature

change.

Set schedule start time

Operates normally

Operates using the Away

temperature selected in the

Setup menu

Use the Away setting to save

energy when the building is

unoccupied

•

The Away temperature can be

adjusted in the Setup / Temps

menu.

• Selecting the Away setting on

a thermostat or the mobile app

will affect all devices linked to

that location through the app.

Save Info

Home / Away

At Home

Away

Heating temperature

Go to the next group of

program days.

Current group of

program days.

Early Start

anticipates the

time required to

heat

a room and

starts early.

Set to On to follow the

schedule. Set to Off to use the

same temperature all of the

time.

Creates a new schedule.

New

Schedule

Early Start

On

Schedule

On

Wake 6:00 AM 70°

Leave 8:00 AM 65°

Return 6:00 PM 70°

Sleep 10:00 PM 65°

Schedule

Mon Tue Wed Thu Fri

On

Skip

Wake

Schedule Setup

Mon Tue Wed Thu Fri

6:00 AM

Heat to 70°

User Settings

3

Away

Schedule

Select °F or °C

Brightness when

touching the display

Choose the background

color

Select English, French or

Spanish

Brightness after 60 second timeout

of no use

Energy use. See below.

DISPLAY 1/2

Temperature Units: °F

Brightness - Active: 80%

Theme: Light

Energy Use: Monthly

Brightness - Inactive: 50%

Language: English

Daily Usage

Monthly

Usage

Today 0 hrs

Yesterday 0 hrs

Tue 0 hrs

Mon 0 hrs

Sun 0 hrs

Sat 0 hrs

Fri 0 hrs

View each day’s run time

for heating.

Toggle between Daily

and Monthly Usage.

Energy Use

10 second count down

to allow the screen to be

cleaned with a moist cloth.

Select if the time is shown

when inactive

Select if the outdoor

temperature is shown

when inactive

DISPLAY OPTIONS 2/2

Clean Screen: Off

Inactive Time Display: On

Inactive Outdoor Display: Off

Display

4

When connected to the Internet, the time can be set automatically.

The time and date can be manually set by highlighting a field and

then using the or buttons.

Incorrectly setting the time and date manually may prevent the thermostat from communicating

to the mobile app. Automatic time source is recommended when using an Internet connection.

TIME & DATE

1 30 PM

Aug 25 2016

OPTIONS

Time options are:

• 12 hour or 24 hour time format

• Automatic or manual time setting

• Time zone

• Daylight savings time

Time

5

The thermostat includes a step by step tutorial to setup the WiFi connection.

Step 1

Agree to Terms of Use

Step 2

Turn on WiFi

Step 3

Enter wireless network name.

It must support WPA2 security

encryption.

Step 4

Enter WiFi password.

Step 6

Select if the time is set

automatically from the Internet

or manually.

Step 5

Enter ZIP or postal code. This

determines your location for

weather information.

Tutorial

DISAGREE AGREE

Before first using WiFi features

of this product, you must accept

the Terms of Use available at

https://www.watts.com/terms-

of-use

by pressing AGREE below.

If you do not accept these terms,

this product can still be used

without WiFi features.

WIFI

On

Time Source

Manual

NETWORK SSID

CONNECT

Select a network

from the list:

Your House

A C EB D F

M O QN P R

Y A/1ZShft Del

G I KH J L

S U WT V X

Enter Password

CONNECT

135246

: ( $; ) &

' A/1\Shft Del

7 9 -8 0 /

@ . ?" , !

ZIP/Postal

OK

Before using the WiFi features of this product, you must accept the Terms of Use, as amended

from time to time and available at Watts.com/terms-of-use. If you do not accept these terms,

this product can still be used without WiFi features.

WiFi

6

7

Notes

___________________________________________________________________________________________________________________________________

Need help? Go to our website or contact us.

Watts.com | radiant@wattswater.com | 1-800-276-2419

USA: T: (800) 276-2419 • Watts.com

Canada: T: (888) 208-8927 • Watts.ca

Latin America: T: (52) 55-4122-0138 • Watts.com
