Watts Lync WQ-RS User manual

Lync WQ-RS
Commercial Reverse Osmosis Systems
Engineered Solutions
Lync • 425 W Everman Pkway, St. 101 • Fort Worth, TX 76134
USA: T: [phone]
Technical Support • [phone] (ext. 3) • Mon-Fri, 8 am - 5 pm CST
© 2021 LYNC
L- OMM-005_A • 2/23/2022
Disclaimer
The information contained in this manual is subject to change without notice
from Lync, a division of Watts Water Technologies, Inc. Lync makes no
warranty of any kind with respect to this material, including, but not limited to,
implied warranties of merchantability and fitness for a particular application.
Lync is not liable for errors appearing in this manual, nor for incidental or
consequential damages occurring in connection with the furnishing,
performance, or use of these materials.
Installation, Operation and
Maintenance Manual

Lync WQ-RS
Table of Contents
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 2 of 34
TABLE OF CONTENTS
Commercial Reverse Osmosis Systems ..................................................................................................1
1. INTRODUCTION...................................................................................................................................3
1.1. Specifications ...........................................................................................................................4
1.2. RO Overview .............................................................................................................................4
1.3. Pretreatment..............................................................................................................................5
2. CONTROLS, INDICATORS, AND COMPONENTS.............................................................................7
2.1. System Components .................................................................................................................7
2.2. Controller Drawing ...................................................................................................................8
3. OPERATION.......................................................................................................................................10
3.1. Installation................................................................................................................................10
3.2. Plumbing Connections.............................................................................................................10
3.3. Electrical Connections.............................................................................................................10
3.4. Startup.....................................................................................................................................11
3.5. Reverse Osmosis Controller Operations and Maintenance....................................................13
4. Replacement Part List ......................................................................................................................31
5. Membrane Replacement...................................................................................................................32
6. Appendix............................................................................................................................................33

Lync WQ-RS
SECTION 1: INTRODUCTION
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 3 of 34
1. INTRODUCTION
WARNING!
Do not use with water that is microbiologically unsafe or of unknown quality without adequate
disinfection before or after the system.
•Pretreatment must be sufficient to eliminate chemicals that would attack the membrane
materials.
•Always turn off the unit, shut off the feed water, and disconnect the electrical power
when working on the unit.
•Never allow the pump to run dry.
•Never start the pump with the reject valve closed.
•Never allow the unit to freeze or operate with a feed water temperature above 100°F
•Save manual for future reference.
•Please refer to Section 6 of this manual for operating parameters according to your
specific feed water Silt Density Index (SDI). For all other settings according to your
specific feed water quality, please contact your Lync representative. A chemical analysis
of the feed water should be conducted prior to the initial sizing and selection of this
system.
NOTES:
Changes in operating variables are beyond the control of Lync. The end user is responsible
for the safe operation of this equipment.
The suitability of the product water for any specific application is the responsibility of the end
user.
Successful long-term performance of an RO system depends on proper operation and
maintenance of the system. This includes the initial system startup and operational startups
and shutdowns.
Prevention of fouling or scaling of the membranes is not only a matter of system design, but
also a matter of proper operation. Record keeping and data normalization are required in
order to know the actual system performance and to enable corrective measures when
necessary. Complete and accurate records are also required in case of a system
performance warranty claim.
Changes in the operating parameters of an RO system can be caused by changes in the
feed water or can be a sign of trouble. Maintaining an operation and maintenance log is
crucial in diagnosing and preventing system problems. For your reference, a typical log sheet
is included in this manual.

Lync WQ-RS
SECTION 1: INTRODUCTION
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 4 of 34
1.1. Specifications
WQRS-005-R
WQ-RS-010-R
WQ-RS-015-R
Productivity (gallons per day / gallons per
minute)
3600 / 2.5
7200 / 5.0
10800 / 7.5
Quality (typical membrane percent
rejection)
98 %
% Recovery (adjustable)
25 - 75 %
42 - 75 %
50 - 75 %
Membrane Size
4”x 40”
Number Of Membranes Per Vessel
1
Pressure Vessel Array
1:1
1:1:1:1
1:1:1:1:1:1
Number Of Membranes
2
4
6
Prefilter (system ships with one 5 micron
cartridge)
20" BB
Feed Water Connection
1" NPT
Product Water Connection
3⁄4" NPT
Reject Water Connection
3⁄4" NPT
Feed Water Required (at 50% recovery)
5 gpm
10 gpm
15 gpm
Feed Water Pressure (minimum)
20 psi
Drain Required (maximum)
15 gpm
Electrical Requirement 230 VAC, 3-ph, 60
Hz (other voltages available)
230 VAC, 3-phase, 60 Hz, 15 amps
(other voltages available)
TEFC Motor (horse power)
5
Dimensions L x W x H (inches)
51” x 18” x 57”
Shipping Weight (estimated pounds)
400
600
800
NOTE:
For allother guidelineinformation,pleasecontactyour Lync representative.Published
maximum production rates are based onafeedwaterof 77°F,SDI of less than 3, 1000 ppm
TDS, and pH 8. Individual membrane productivity may vary (±15%). May be operated on other
feed waters with reducedcapacity. Percentrejectionis basedonmembranemanufacturer’s
specifications;overallsystempercentrejectionmaybeless.
1.2. RO Overview
Reverseosmosissystemsutilizesemipermeablemembraneelementstoseparatethefeedwater
intotwostreams.Thepressurizedfeedwater is separated into purified (product) water and
concentrate(reject) water. Theimpurities contained in the feed water are carried to drain bythe
reject water. It is critical to maintain adequate reject flow in order to prevent membrane scaling
and/or fouling.

Lync WQ-RS
SECTION 1: INTRODUCTION
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 5 of 34
Figure 1-1 RO Membrane
1.3. Pretreatment
The RO feed water must be pretreated in order to prevent membrane damage and/or fouling.
Table below shows the feed water chemistry requirements.
pH
6 to 9
Hardness (maximum)
Less than 1 grain per gallon as CaCO3 (Softened) or anti scale
chemical injection if not softened (contact your Lync representative)
Water Pressure
20 –90 psi
Temperature
35 - 100°F (2 - 38°C)
Free Chlorine
None allowed
Iron (maximum)
0.1 ppm
Manganese
0.05 ppm
Oil and H2S
None Allowed
Turbidity
Less than 1.0 NTU
Silt Density Index (SDI)
Less than 5.0 SDI
Proper pretreatment is essential for reliable operation of any RO system. Pretreatment
requirements vary depending on the nature of the feed water. Pretreatment equipment is sold
separately. The most common forms of pretreatment are described below.
Media Filter - Used to remove large suspended solids (sediment) from the feed water.
Backwashing the media removes the trapped particles. Backwash can be initiated by time or
differential pressure.
Water Softener - Used to remove calcium and magnesium from the feed water in order to
prevent hardness scaling. The potential for hardness scaling is predicted by the Langelier
Saturation Index (LSI). The LSI should be zero or negative throughout the unit unless
approved antiscalants are used. Softening is the preferred method of controlling hardness scale.
Carbon Filter - Used to remove chlorine and organics from the feed water. Free chlorine will
cause rapid irreversible damage to the membranes.
The residual free chlorine present in most municipal water supplies will damage the thin film
composite structure of the membranes used in this unit. Carbon filtration or sodium bisulfite
injection should be used to completely remove the free chlorine residual.
Chemical Injection - Typically used to feed antiscalants, coagulant, or bisulfite into the feed
water or to adjust the feed water pH.
Feed Water
Product Water
Reject Water

Lync WQ-RS
SECTION 1: INTRODUCTION
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 6 of 34
Prefilter Cartridge - Used to remove smaller suspended solids and trap any particles that may
be generated by the other pretreatment. The cartridge(s) should be replaced when the pressure
drop across the housing increases 5 - 10 psig over the clean cartridge pressure drop. The effect
of suspended solids is measured by the silt density index (SDI) test. An SDI of five (5) or less is
specified by most mem- brane manufacturers and three (3) or less is recommended.
Iron & Manganese - Iron should be removed to less than 0.1 ppm. Manganese should be
removed to less than 0.05 ppm. Special media filters and/or chemical treatment is commonly
used.
pH - The pH is often lowered to reduce the scaling potential.
Silica: Reported on the analysis as SiO2. Silica forms a coating on membrane surfaces when
the concentration exceeds its solubility. Additionally, the solubility is highly pH and temperature
dependent. Silica fouling can be prevented with chemical injection and/or reducing the recovery.

Lync WQ-RS
SECTION 2: CONTROLS, INDICATORS AND COMPONENTS
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 7 of 34
2. CONTROLS, INDICATORS, AND COMPONENTS
2.1. System Components
Figure 2-1 General System Component Identification
A. Controller - Controls the operation of the system and displays the product water quality.
B. Reject Control Valve - Controls the amount of reject flow.
C. Reject Recycle Control Valve –Controls the amount of reject recycle flow.
D. Pump Discharge Valve - Used to throttle the pump.
E. Prefilter Pressure Gauges - Indicates the inlet and outlet pressure of the prefilter. The
difference between these two gauges is the prefilter differential pressure.
F. Pump Discharge Pressure Gauge - Indicates the pump dis- charge pressure.
G. Reject Pressure Gauge - Indicates the reject pressure.
H. Reject Flow Meter - Indicates the reject flow rate in gallons per minute (gpm).
I. Product Flow Meter - Indicates the product flow rate in gallons per minute (gpm).
J. Reject Recycle Flow Meter –Indicates the reject recycle flow rate in gallons per minute
(gpm).
K. Prefilter Housing - Contains the RO prefilter.
L. Automatic Inlet Valve - Opens when pump is on and closes when the pump is off.
M. Low Pressure Switch - Sends a signal to the controller if the pump suction pressure is low.
N. RO Feed Pump - Pressurizes the RO feed water.
O. RO Membrane Vessels - Contains the RO membranes.

Lync WQ-RS
SECTION 2: CONTROLS, INDICATORS AND COMPONENTS
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 8 of 34
2.2. Controller Drawing
Figure 2-2 Controller

Lync WQ-RS
SECTION 2: CONTROLS, INDICATORS AND COMPONENTS
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 9 of 34
Figure 2-3 Controller (Continued)
RO PUMP

Lync WQ-RS
SECTION 3: OPERATION
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 10 of 34
3. OPERATION
3.1. Installation
1. The water supply should be sufficient to provide a minimum of 20 psig pressure at the design
feed flow.
2. Proper pretreatment must be determined and installed prior to the RO system.
3. A fused high voltage disconnect switch located within 10 feet of the unit is recommended.
This disconnect is not provided with the RO system.
4. Responsibility for meeting local electrical and plumbing codes lies with the owner /operator.
5. Install indoors in an area protected from freezing. Space allowances for the removal of the
membranes from the pressure vessels should be provided. This system requires 42"
minimum clear space on each side.
3.2. Plumbing Connections
NOTE:
It is the responsibility of the end user to ensure that the installation is done according to local
codes and regulations.
1. Connect the pretreated feed water line to the inlet side of the prefilter housing (Figure 2-1,
item A). A feed water shutoff valve should be located within 10 feet of the system.
2. Temporarily connect the outlet of the product water flow meter to drain (Figure 2-1, item B).
The product water line should never be restricted. Membrane and/or system damage may
occur if the product line is blocked.
3. Connect the outlet of the reject water flow meter to a drain (Figure 2-1, item C). The reject
drain line should never be restricted. Membrane and/or system damage may occur if the
reject drain line is blocked. An air gap must be located between the end of the drain line and
the drain. The use of a standpipe or other open drain satisfies most state and local codes
and allows for visual inspection and sampling.
3.3. Electrical Connections
NOTE:
It is the responsibility of the end user to ensure that the installation is done according to local
codes and regulations.
1. A safety switch or fused disconnect should be installed within 10 feet of the system.
2. Verify that the disconnect switch is de-energized using a voltmeter.
3. Connect the outlet of the disconnect switch to the terminals on top of the motor starter (Figure
2-2). Attach the power supply ground to the chassis ground. It may be necessary to drill a
hole in the enclosure and install a water-tight strain relief or conduit connector. The hole size

Lync WQ-RS
SECTION 3: OPERATION
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 11 of 34
and location must be determined by the installer. Check the pump motor nameplate for the
amperage draw at various voltages to determine the wire size required.
4. Do not apply power to the RO unit at this time.
3.4. Startup
1. Verify that the pretreatment equipment is installed and working properly. Verify that no free
chlorine is present in the feed water.
2. Verify that the pump discharge valve (Figure 2-1, item D) is open.
3. Install a 20" five micron filter cartridge in the prefilter housing. (Figure 2-1, item K)
4. Open the reject control valve completely (Figure 2-1, item B) by turning it counterclockwise.
Close the reject recycle control valve completely (Figure 2-1 item C) by turning it clockwise.
5. Open the feed water shutoff valve installed in step III-B-1 above.
6. Manually open the inlet solenoid valve (figure 2-1, item L) by turning the white lever located
near the valve outlet.
7. Water will flow through the system and to drain through the reject flow meter (Figure 2-1, item
H).
8. Manually close the inlet solenoid valve after the air has been purgedfrom the system, or after
10 minutes, whichever occurs first.
9. Close the pump discharge valve half way. (Figure 2-1, item D)
10. Engage the safety switch or disconnect (installed in Section 3.3, step 1, above) to apply
electrical power to the RO system.
11. Press the On/Off button on the controller. When the pump starts, press and hold the On/Off
button to turn off the pump and look at the motor fan as the pump stops to determine if the
pump rotation is correct. See the controller section for more details. The fan should rotate in
the direction of the rotation arrow located on the pump. Continue with the startup if the pump
is rotating in the proper direction. If the pump is rotating backwards, change the rotation by
disconnecting the power and reversing any two of the wires on the power inlet. Verify proper
pump rotation before continuing.
12. Turn the system on.
13. Adjust the reject control valve(s) (Figure 2-1 items B & C) and the pump discharge valve
(Figure 2-1 item D) until the desired flows are achieved. Closing the reject valve increases
the product flow and decreases the reject flow. Opening the pump discharge valve increases
both the reject flow and the product flow. See the flow rate guidelines and Temperature
Correction table in the Appendix to determine the flow rates for different operating
temperatures.
14. Allow the product water to flow to drain for 30 minutes.
15. Turn off the system and connect the product line to the point of use. (Figure 2-1 item I) The
product water line should never be restricted. Membrane and/or system damage may occur
if the product line is blocked.
16. Restart the system and record theinitial operating data usingthe log sheet in the next section.

Lync WQ-RS
SECTION 3: OPERATION
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 12 of 34
NOTES:
See the controller section of this manual for more installation and operation information.
It is very important to vent the mechanical seal during startup. Failure to vent the seal may
result in premature seal failure.
Figure 3-1 Needle Valve Location
Drain Plug
Vented Priming Plug
Back off needle valve to vent air.
Retighten to 25 in.-lbs. when vent port
runs a steady stream of water.

Lync WQ-RS
SECTION 3: OPERATION
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 13 of 34
3.5. Reverse Osmosis Controller Operations and Maintenance
The controller for this system is the ROC-4 controller. This is a microprocessor-based controller
with a product water conductivity meter. A separate manual for this controller begins on the next
page.
TABLE 1. SPECIFICATIONS
Inputs
Tank level switches
(2) Normally-Closed. Can be used with a single level switch.
Inlet pressure switch
Normally-Open.
Pretreat lockout switch
Normally-Open.
High pressure switch
Normally-Open.
(opt) Controller Power
24 VAC, 60/50Hz
Permeate Conductivity
0-3000 PPM, 0-6000 µs (standard sensor, CP-1, K=.75)
Feed Conductivity (opt)
0-3000 PPM, 0-6000 µs (standard sensor, CP-1, K=.75)
Output Ratings
Feed Solenoid
24 VAC –1 amp
Flush Solenoid
24 VAC –1 amp
Divert (opt)
24 VAC –1 amp
Motor Contactor Coil
24 VAC –1 amp
Circuit Protection
Main Power Fuse
F1
5 x 20 mm
2 Amp
Relay/XFMR Fuse
F2
5 x 20 mm
0.125 Amp
Other
Dimensions
11.5" tall, 9.3" wide, 6.7" deep. Nema 4X non-metallic (10 x 8 x 6)
13.5" tall, 11.4" wide, 6.7" deep. Nema 4X non-metallic (12 x 10 x 6)
15.5" tall, 13.3" wide, 7.7" deep. Nema 4X non-metallic (14 x 12 x 7)
Weight
4.2 lb. (10 x 8 x 6) (Enclosure, CPU-4 and TB-3 only.)
6.0 lb. (12 x 10 x 6) (Enclosure, CPU-4 and TB-3 only.)
10.6 lb. (14 x 12 x 7) (Enclosure, CPU-4 and TB-3 only.)
Environment
0-50°C, 10-90%RH (non-condensing)

Lync WQ-RS
SECTION 3: OPERATION
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 14 of 34
fgdafdfgbd
Alternate Wiring, Single Tank Level Switch
Divert Valve/Alarm contacts can
be powered or dry-contact -
selectable with switch S1.
Close on Fault
iControls TB-24V3 Schematic, Rev:NC Dec 2015
POWER INPUT
INLET VALVE
FLUSH VALVE
PUMP (Contactor)
DIVERT/ALARM
Figure 3-2

Lync WQ-RS
SECTION 3: OPERATION
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 15 of 34
Figure 3-3 Controller Overview
CPU Board
Terminal Board
Conductivity
Probe
Connections
Programing
Transformer
Keypad
System On/Off
Up Arrow
Down Arrow
Manual Run, Manual Flush
Display
(4 line, 20 character)
Provides feedback on
the system status

Lync WQ-RS
SECTION 3: OPERATION
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 16 of 34
Pictorial Schematic of a Typical ROC-4 System
Figure 3-4 Wiring Diagram

Lync WQ-RS
SECTION 3: OPERATION
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 17 of 34
Typical Configuration
Detailed View
Figure 3-5 Controller Detail: CPU-4
Shield White Black
Shield White Black
Main interface port.
Connects via ribbon
cable to Terminal Board.
Bootload Switch Used
for field updates of
CPU-4 firmware
Programming Port
Standard USB printer cable
used for programming. See
Appendix B for more about
the programming interface
(Optional Feed
Conductivity Probe)
(Permeate
Conductivity Probe

Lync WQ-RS
SECTION 3: OPERATION
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 18 of 34
Figure 3-6 Controller Detail: Terminal Board, TB-3
For schematic, see Figure 2-2.
TB24V3

Lync WQ-RS
SECTION 3: OPERATION
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 19 of 34
Install the Conductivity Probe in the “Run” of a Tee or equivalent location. Orient the probe so
that air cannot become trapped in the area near the probe.
Figure 3-7 Conductivity Probe Installation
Figure 3-8 Input Wiring
Conductivity Probe
Line 2 input for 460 volts
Line 2 input for 230 volts
Line 2 input for 208 volts
Line 1 input for all voltages
Flow
Flow

Lync WQ-RS
SECTION 3: OPERATION
L- OMM-005_A •2/23/2022 Technical Support • [phone] • Mon-Fri, 8 am - 5 pm EST 20 of 34
Control Box Installation
1. Drill the enclosure as needed and install liquid-tight fittings for thewiring.
2. Mount the enclosure in the desired location on the RO system.
3. Bring the wires from the peripheral devices into the enclosure and connect them to the
appropriate terminals. (See Figures 2- and 3-4 through 3-6.)
4. Install the conductivity cell in the permeate line (see Figure 3-7 and 3-8 for conductivity cell
installation instructions).
5. Connectthe conductivitycell totheterminals on theCPU Board(see Figure3-4).RepeatSteps
6 & 7 for the Feed Conductivity cell if your system will utilize both feed and permeate
conductivity measurement.
6. Provide power to the RO system.
7. Press the System On/Off switch to turn the system ON.
8. Select theProgram Mode(see Figure 3-7and3-8, and Table 2). Thedefaultis Program 1, which
is a general purpose setting. Use Program 2 if your system is not equipped with a flush valve.
9. Make any other changes you want to the settings. Press System On/Off to save your
changes.
10. The controller is now ready for service.
NOTE:
The above information is provided in case the controller is purchased as a standalone
product.
Figure 3-9 Controller Programming. Accessing the hidden menus
1. With the System
ON, press and hold
the UP and DOWN
arrows.
2. With the UP and Down
arrows depressed, press the
System On/ Off switch. The
menu will switch to the RO
Presets menu shown here.
