WayteQ P-35 User manual

1
Foreword
First of all, thank you very much for using the MP4
digital walkman of this company!
This player is a specialized top quality portable
player product with a series of remarkable functions. In
order to give full play to all functions of the new player,
please read this manual carefully before using the unit.
There will be no separate notice in the case of any
change in content of this text.
This company will continue to provide new
functions for the development of the product, and there
will be no separate change in the case of any change in
the product’s performance and functions. While this unit
is used as a mobile hard disk, this company will not be
held liable for the security of files saved in the disk.
If the actual setup and the application methods are
not identical to those as set forth in this manual, please
access to the latest product information of this company's
web sit.

2
Contents
Foreword............................................................................................................1
Contents.............................................................................................................2
Points for attention.............................................................................................3
Kind reminder....................................................................................................4
Key Functions....................................................................................................6
Shapes and Keys................................................................................................7
Display screen....................................................................................................8
Basic operation ................................................................................................11
Main interface..................................................................................................14
Video ...............................................................................................................15
TV-out..............................................................................................................19
Music...............................................................................................................20
E-Book.............................................................................................................23
Photo................................................................................................................26
FM Radio.........................................................................................................28
Record..............................................................................................................30
Games..............................................................................................................31
Explorer...........................................................................................................32
Settings............................................................................................................33
Light ................................................................................................................35
Theme..............................................................................................................35
Common troubleshooting.................................................................................36
Specification ....................................................................................................38

3
Points for attention
1．Do not use the player in exceptionally cold or hot, dusty, damp or dry
environments.
2．Do not allow the player to fall down while using it.
3．Please charge your battery
A. Battery power icon shows an empty icon;
B. The system automatically shuts down and the power is soon off
when you switch on the unit once again;
C. There is no response if you operate on any key
4．Please do not disconnect power abruptly when the player is being
formatted or in the process of uploading or downloading. Otherwise it
may lead to the error in the program.
5．When this unit is used as a moving disk, the user shall store or export files
in the proper file management operation method. Any improper operation
method may lead to the loss of files, for which this Company will be held
no liable.
6．Please do not dismantle this unit by yourself. If there is any inquiry,
please contact the dealer.
7．There will be no separate notice in the case of any change in the functions
and performance of this product.

4
Kind reminder
● The playback time of the player refers to the maximum playback time that
can be realizable under the playback condition at the minimum power
consumption (black screen state). The actual playback time may differ as the
factors such as operation conditions and environments (like size of a file and
time of bright screen) are different. Meanwhile, there is slight difference in the
player itself.
● The following two conditions will lead to difference in actual capacity and
nominal capacity:
1. Error caused in the calculation of capacity: Software producers
calculate it on the basis of 1MB=1000KB, while software is calculated
on the basis of 1MB=1024KB. For the MP3 at the hardware nominal
of 128MB, the capacity converted into software identification will be
128MB X 1000KB / 1024KB=125MB, so there is the calculation error
of 3MB. The greater the capacity of product is, the greater error the
calculation errors.
2. The software will take up some disk space.
● As there are many brands of Micro SD cards in markets, the quality is
different, and the specification standards are changeable. Therefore, we are
unable to ensure that our products will be compatible with all types or brands of
Micro SD cards, but will be compatible with those Micro SD cards with
mainstream specifications in the markets, and will constantly expand the
compatibility of new models of Micro SD card products by upgrading the
firmware.
● As parameters such as formats, coding modes, definition and code flow rates
of video files provided by the internet differ, the player is unable to be
compatible with all video files (especially those video files with high definition
or high code rates). If the downloaded video files are out of the range supported
by the player, which renders it impossible to play normally in the player, it is
recommended that the video conversion software from a third party be used,
and file formats be converted via computers into the ones within the range

5
supported by the player before the same are duplicated into the player for
playing.
● As the coding modes of music files (e.g. APE, FLAC, MP3, etc), code flow
rates and sampling rates are different in size settings, it is likely that part of
music files will be unable to play normally in the player. Please use the audio
conversion tools of a third party, and convert them into the music file formats
via computers within the range supported by the player before they are
duplicated into the player for playing.
● When there is any failure in the course of using the unit affecting normal
operation, please first log on the official website of this company to download
the latest version of firmware, and upgrade them by referring to the firmware
updating manner as set out in the operation instructions. This will be the
solution to most of problems. If it is still unable to settle the matter even after
updating, please contact the dealer in the time of purchase or have them sent to
the service center for repairs.

6
Key Functions
3.0 inch TFT screen (400*240dpi)
Supports multiple formats video play such as RM/RMVB, AVI, MKV,
MOV, VOB, DAT, and FLV etc.
Supports maximum 720P resolution video file putout
Supports multiple audio formats such as MP3, WMA, AAC, APE and
FLAC, etc;
Supports music lyric and video subtitle synchronous display
Integrated TV output function
Supports picture browsing, rotation and lantern slide playing in the formats
of JPG, BMP, PNG and GIF, etc.
Supporting E-book reading, independent bookmarks and automatic rotate
functions
Built-in microphone and long time recording
Supporting FM radio
Supports Micro SD Card to extend capacity
Supports energy saving settings, various of font color for your choice,
adjustable brightness, automatic shutdown and background setting
USB2.0 high rate transmission

7
Shapes and Keys
1.play/pause 2.volume- 3. volume+ 4. menu
5. the previous/fast rewind 6.the next/fast forward
7.return 8.ear/TV out 9.USB
10.MSD 11.reset 12.MIC

8
Display screen
Video playing
Music playing

9
E-Book
FM Radio

10
Record

11
Basic operation
Power on
In the power off state, press " "key, the unit will display the starting logo,
and then access to the main menu interface.
Power off
Under power on state, long press " " for 5 seconds key to turn off MP4
player.
Power reset
If the screen frozen or breaking down in the process of MP4 player
operation, you can turn off and restart the player by pressing "reset" key.
Connecting the computer and data file transmission
Start computer and connect unit with it by USB cable. Then you can make
data transmission and MP4 player charging. Also MP4 player can be used as
removable disk. Then you can copy your favorite files into correspondent folder
of this unit.
Volume Control
In the states of playing music, FM radio and video, etc, you can perform
volume control using "+/-"icon. "+" icon is for increased volume and "-" icon is
for reduced volume. Hold the key "+" or icon"-" to continuously increase or
reduce volume
Battery
High capacity Polymer battery is built-in this unit.
The duration available of the battery power depends on volume, types of
playing files and operation of batteries. The player can be set up by the user as
“user define power off time”or “display setup”to save power.
Charging
This unit can be recharged by USB port, you can also use the designated
normal charger which was provided to you with the unit (output current 500MA,

12
output voltage 5V~5.2V) to charge it. Connect the unit with the charger to
charge it.
If you connect the player with computer, when the battery icon displays as
full, it indicates that the charging is full. Otherwise, when the battery icon
displays as charging, it display is charging.
Using the Micro SD card
After this unit is connected with the computer, you will find two movable
disks. The first one is the built-in memory disk of this unit and the other is the
disk for the Micro SD card. If no card is inserted, the second disk can not be
opened. This unit supports the extension of the Micro SD card from 128MB to
8GB.
Inserting and Pulling out the Micro SD card
Inserting:
Put the Micro SD card face up (side with words) (with the direction of the
display screen as the face), and slightly insert the card into the socket of the
card, i.e. connecting the unit. Under this state, you can play the content in the
Micro SD card.
Pulling:
Slightly push the Micro SD, and it will bounce by a section, and then you
can take it out.
Caution:
Please perform inserting and pulling operation under power off state!
Otherwise, there will be data loss or damaged to the files of the unit! If no card
is inserted, the computer will be unable to perform read and write operation for
the disk notes of the later removable disk (Micro SD card).
Power adapter is a key component of the portable player, which play a
crucial role in keeping the portable player’s normal work and protecting your
security when using the player, a long-term customer surveys and after-sales

13
service Practice shows that the malfunction of the portable player In many cases
were caused by using inappropriate accessories, in particular the power adapter.
Use the substandard power adapter will shorten the life of the portable
player by considerably, the voltage instability will seriously affected the normal
work of the portable player and bring permanent damage on the player’s
performance and reliability, Use the substandard power adapter will also
reduced the vocal quality of the players, shutdown the player when you using it,
In addition, Use the substandard power adapter will cause combustion and
explosion which will disserve the safety of the consumers.

14
Main interface
In the main menu, there are 11 functional icons, including：Video, Music,
E-Book, Photo, FM, Record, Games, Explorer, Settings, Bright and Theme.
Click on corresponding functional icon to be able to access the function menu.
Press the icon to be able to fold or expand all function icon.
Functions of keys in the master interface list:
'' / " key: press it to select left/right function options.
"M" key: short press it to confirm the function of the selected icon and
access the selected function option.
" " key: short press it to return to the upper interface and long press it to
come back to the main interface.
Main interface

15
Video
In the main menu, select the option of "Video" and press the “M”key to be
able to access video folder. This menu list includes 2 options such as Local disk,
TF Card.
Description of functions:
Local disk
Users can choose the file and its subdirectories from local drive.
TF Card
If no card is inserted, the TF card can not be display. Otherwise,
users can choose the file and its subdirectories from Micro TF Card
File list interface
Function of keys
'' / " key: press it to select PREV/NEXT function option or
file;
" M " key: short press it to access the selected function option or
file.
“+/-”key: press it to volume up or volume down.
" " key: short press it to return to the upper interface and long
press it to come back to the main interface.

16
Video playing interface
Function of keys
'' '': play or pause current movie
'' / " key: shot press to play the last /next movie, long press
for fast rewind / forward;
“+/-”key: press it to volume up or down
" " key: short press it to return to the upper interface and long
press it to come back to the main interface.
" M " key: short press it to popup movie setting interface.
Setup video interface
In video playing interface, click “M”functional icon to be able to export
the video setup menu. There are 6 options such as Playback mode, Zoom, File
information, Video enhancement, Subtitle display and Subtitle list.
Description of functions
1. break point
You can continue playing video place where you stopped the last time. The
default setting is "YES", if you select "YES", this video will be played from the
picture you exit last time; if you select "NO", this video will be played from the

17
beginning.
2. Playback mode
By this function, you can perform play mode to video. This player
provides 5 display scales such as: Single play, Repeat one, Repeat all, Sequence
and Random, which can be set flexibly according to solution.
3. Zoom
By this function, you can perform aspect ratio to video image. This player
provides 3 display scales such as: Ratio(4:3) Ratio (16:9) and Original size,
which can be set flexibly according to the solution of video source files for an
optimal visual effect.
4. File information
File information can display the currently playing video file information,
including the file name, file size, file format, encode format, sample rate, frame
rate and resolution.
5. video enhancement
There are 5 modes to choose from, such as "Very sharp", "Sharp",
"Natural", "soft" and "Very soft".
6. Subtitle display
This feature can be set to closed or open caption display synchronization.
7. Subtitle list
If the video file embedded multiple subtitles, through this option to select
the different subtitle synchronized display
Tips:
1、This MP4 player support maximum 1280 *720 resolution video files.
2、Subtitle display
This player supports "*.SRT" subtitle files (The user can download it
from the website) for the synchronous playing of subtitle and video.
When there is any subtitle file with the same name in the folder for

18
playing video, the player will be able to achieve synchronous subtitle
display
3、It’s supports video playing in multiple formats such as, AVI, MKV, VOB,
MOV, FLV and MP4, H.264 encoding high-definition video etc. As parameters
such as formats, coding modes, definition and code flow rates of video files
provided by the internet differ, the player is unable to be compatible with all
video files (especially those video files with high definition or high code rates).
If the downloaded video files are out of the range supported by the player,
which renders it impossible to play normally in the player, it is recommended
that the video conversion software from a third party be used, and file formats
be converted via computers into the ones within the range supported by the
player before the same are duplicated into the player for playing.

19
TV-out
The play supports TV-output. The way of operation as follows:
1、In the settings interface, select "TV Output" option. There are two options
for selected such as Output select and TV Format for selected: PAL and
NTSC. Select appropriate resolution according to the solution of TV or
LCD for better visual effect.
2、Connect one end of the component volume connection line to the TV output
port of the player, and the other end to the AV IN video input port of the TV
set by selecting any plug in the order of green, blue or red (generally, the
color of this interface on a TV set is yellow).
3、Connect one end of the component volume connection line (2-pin) to the
unit to the earphone port of the player, and the other end to the left or right
input channel of the TV set in the order of white and red, corresponding to
the colors of theAV IN audio input port of the TV set.
4、Set the signal input source of TV as AV IN input state.
5、The player supports PAL or NTSC TV Format .Select appropriate resolution
according to the solution of TV or LCD for better visual effect.
6、In the video play interface, select the TV or LCD icon to be able to be able
to switch over the video to be played on the TV screen.
Note:
1、If the video playback frame is switched over to TV output, the screen of
the player will be switched off, but you can also operate the player
using the keys.
2、If you want to exit the TV output function, you can shot press " " key
to return to the player screen for play.

20
Music
In the main menu, select the option of "Music" and short press the “M”
key to be to be able to access music folder. This menu list includes 5 options
such as Media library, Update, Previous Played, Local disk, Local Disk and TF
Card.
Description of functions:
Media library
You can use the "Update Media Library" feature in the local disk to
classify all the music files, Users can through the media library options, to
play all or category pay the media library music. Such as "All ","Artist",
"Album"，"Genre", "Star", "Year", etc.
Update
This option will update all music in the player to the "All Music" List.
Previous Played
Select the option, the player return to the pervious played music interface.
Local disk
Users can choose the file and its subdirectories from local drive.
TF Card
If no card is inserted, the TF card can not be display. Otherwise,
User can choose the file and its subdirectories from Micro TF Card.
File list interface
Function of keys
'' / " key: press it to select PREV/NEXT function option or
file;
