WE-EF QRI354 LED User manual

WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Wall Luminaire Recessed
QRI354 LED
Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.

1
Wall Luminaire Recessed
QRI354
,3,.&ODVV,WDů&
262
25
90
230
Installation Accessories
Pre-installation blockout is recommended for mounting in concrete.
Installation blockout – Luminaire frame proud of surface. C
for QRI354 197-0129 BQR25 –I 125
Installation blockoutt/XPLQDLUHIUDPHƃXVKZLWKVXUIDFH  &
for QRI354 197-0132 BQR25 –II 150
C C
BQR-I BQR-II

2
Light Source
LED
Maintenance
Apart from cleaning the product’s exterior surfaces, no special maintenance work is required.
Do not use high-pressure cleaners.
In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out
E\DVXLWDEO\TXDOLƂHGDQGWUDLQHGSURIHVVLRQDO
Warning: Do not open luminaire while mains supply is switched on.

3
Installation
The product must be installed and maintained by a
VXLWDEO\TXDOLƂHGSURIHVVLRQDOLQFRPSOLDQFHZLWKODWHVW
building/construction and/or electrical regulations and
relevant legislation.
Warning: Switch off mains electrical supply prior to
installing and connecting the luminaire.
Notice:,IWKHOXPLQDLUHLVPRGLƂHGE\DQ\ERG\RWKHU
than the original manufacturer, then the warranty will
no longer be valid and shall become the full respon-
sibility of the modifying person/organisation. Claims
based on defects attributable to improper installation
and/or application, and the consequences thereof, are
excluded.
Installation Procedure
1) Switch off the mains electrical supply.
2) Remove cover Aby releasing screws Band pull off
plug Kfrom socket L.
3) Check that rating shown on luminaire label
conforms with mains electrical supply. Check that
the recess provided can accommodate luminaire
housing.
a) If option involving installation blockout BQR has
EHHQFKRVHQWKHOXPLQDLUHLVƂWWHGE\XVLQJWKH
screws through the thread Mof the aluminium
frame of the blockout. If necessary use the instruc-
tions accompanying blockout BQR. Ensure the two
nylon plugs Nremain in position for protection
against insects, dust and water.
b) If option involving cavity in wall has been
FKRVHQGHWHUPLQHSRVLWLRQIRUƂ[LQJVFUHZVC. Drill
relevant holes Dand insert wall plugs E.
Warning: Ensure not to damage any electric cable,
water pipe or other devices while drilling holes.
4) Feed the mains supply cable F(and the second
cable Gfor through wiring, if required) through the
grommets Hat the bottom of the housing, while
VHWWLQJDQGƂ[LQJOXPLQDLUHSRVLWLRQEORFNRXWDRU
cavity (b)).
5) Connect mains supply leads to respective terminals
in terminal block I:
a) ON/OFF (L = Phase, N = Neutral, = Earthing)
b) 1-10 V/DALI (L = Phase, N = Neutral,
= Earthing, DA/DA = DALI control line,
D–/D+ = 1-10 V control line).
6) Reconnect plug Kwith socket L, reposition cover A
and tighten screws Bevenly.

4

5
Maximum ø 10 mm, 2 x 1.5 mm² for through wiring
Fig. I
Individual connection Through wiring

www.we-ef.com
WE-EF LEUCHTEN
Germany
Tel [phone]
Fax [phone]
[e-mail]
WE-EF LUMIERE
France
Tel [phone]
Fax [phone]
[e-mail]
WE-EF HELVETICA
Switzerland
Tel [phone]
Fax [phone]
[e-mail]
WE-EF LIGHTING
United Kingdom
Tel [phone]
Fax [phone]
[e-mail]
WE-EF LIGHTING
Thailand
Tel [phone]
Fax [phone]
LQIRDVLDSDFLƂF#ZHHIFRP
WE-EF LIGHTING
Australia
Tel [phone]
Fax [phone]
[e-mail]
WE-EF LIGHTING
United States of America
Tel [phone]
Fax [phone]
[e-mail]
TO9117W0817 © WE-EF 2017
7HFKQLFDOVSHFLƂFDWLRQVDUH
subject to change.
