Weber mt CF 3 R Operating instructions

CF 3 R 1
0710/englisch/Übersetzung der Original-Betriebsanleitung
CF 3 R
Robin-Subaru EX 17
Weber Maschinentechnik GmbH
Im Boden 5 - 8 , 10
D-57334 Bad Laasphe-Rückershausen / Germany
Tel.: + 49 (0) 27 54 / 398 0
Fax: + 49 (0) 27 54 / 398 101
E-Mail: [email protected]
Web: www.webermt.de
Operating and
Maintenance Manual

2 CF 3 R

CF 3 R 3
Table of contents
Introduction 4
Safety guidelines 5
Graphic presentation 8
Device description 9
Technical data 10
Activities prior to starting work 12
Starting 14
Compacting 15
Shutting down 15
Maintenance overview 16
Maintenance work 17
Operating uids and ll levels 19
Troubleshooting 19
Measures to be taken if stored for long periods 20
Contact addresses 23

4 CF 3 R
Introduction
This operating and maintenance manual is designed to facilitate familiarization with your soil
compactor, and enable you to maintain the compactor and use it in accordance with the proper
application possibilities.
When complying with the instructions in the operating and maintenance manual you help avoid
hazards, reduce repair and downtime costs, and increase the reliability and service life of your
compactor.
This operating and maintenance manual must always be available at the implementation site of
the soil compactor.
If needed you can obtain additional information from your authorized WEBER dealer, or you can
obtain information from one of the contact addresses on the last page.
The valid conformity declaration is enclosed with every machine delivery.
You can obtain information on the assembled Honda petrol engine and nd a spare-part list for it at
www.robin-europe.de

CF 3 R 5
Safety guidelines
General
All safety instructions must be read and complied with, non-compliance results in
- Danger to life and limb of the user
- Impairments to the machine or other property.
In addition to the operating manual the binding accident prevention guidelines in the country where
the compactor is used must be complied with.
Proper use
The soil compactor should only be used in technically faultless condition, as intended, in a safety-
conscious and hazard-conscious manner, in compliance with the instructions in the operating
manual. Malfunctions that impair safety must be eliminated without delay.
The CF 3 soil compactor is designed exclusively for compacting
- Sand
- Gravel
- Crushed rock
- Semi-cohesive mixed material
- Concrete paving stone
Any other use of the soil compactor is considered to be improper use for which the owner shall be
exclusively responsible. All liability is rejected if damage occurs due to non-compliance with this
provision. This risk is borne solely by the user.
Driving
Soil compactors should only be driven by suitable personnel at least 18 years of age, Drivers must
be instructed in how to guide the compactor by the owner or by owner’s assigned personnel.
The machine operator must comply with trafc regulations. If instructions that affect safety are given
by third persons, then the operator must be authorized to reject these instructions.
Unauthorized persons are forbidden from being in the area of the soil compactor during the
compacting process.
Protective equipment
This machine is capable of exceeding the permissible sound level of 80 dB(A). The owner might
also face additional dangers when using the machine. Precautionary action must, therefore, be
taken.
Protective equipment includes:
Ear protection
Hard hat
Safety shoes
Protective gloves
Easily foreseeable misuse
Any use for which the machine is not intended.

6 CF 3 R
Prior to maintenance and repair work
Only use original Weber spare parts to ensure reliable and safe operation for maintenance or repair
work.
For repair, maintenance, or inspection work the engine of the compactor must be safeguarded
against unintentional starting.
All pressurized lines, particularly hydraulic lines and lines of the injection system of the drive motor
must be depressurized before performing maintenance or repair tasks.
For maintenance and repair tasks the compactor must be parked on a level and stable substrate and
must be secured from rolling off or tipping over.
Heavy components and subassemblies must be secured on hoisting machines with adequate bearing
capacity when they are replaced. Ensure that no hazard exists related to the raised components or
subassemblies.
Do not position yourself or work under suspended loads.
Operation under difcult conditions
Never inhale the exhaust gas; it contains carbon monoxide, a colorless and odorless gas that is
extremely hazardous, which if inhaled even briey can cause unconsciousness and death.
Never operate the engines in enclosed areas or in areas that are poorly ventilated (tunnels, caves,
etc.) Exercise particular caution when operating the engine in the vicinity of people and livestock.
Hydraulic hose lines must be checked at regular intervals in accordance with standard engineering
practice, or they must be replaced at appropriate intervals, even if no signs of safety-relevant defects
are present.
Adjusting tasks, maintenance tasks, and inspection tasks must be executed on schedule as specied
in this operating and maintenance manual. These activities should only be executed by instructed
personnel.
Operation
Prior to starting work the owner of the compactor must be familiar with the work environment. The
work environment includes obstacles in the work and trafc area, the bearing capacity of the ground,
as well as the necessary safeguarding of the construction site in the area adjacent to public trafc;
and it includes compliance with trafc regulations.
The soil compactor should only be operated when the protective xtures are mounted. The protective
xtures must all be in functional condition.
At least once per shift the compactor must be checked for apparent defects. If there are apparent
defects then operation of the compactor must be stopped immediately and the responsible person
must be informed. Prior to restarting, compactor malfunctions that have occurred must be corrected.
If lubricating oils and fuel come into contact with skin, they can cause skin cancer. Upon contact
with the skin, clean affected skin with suitable cleaning agent without delay.

CF 3 R 7
Inspection
Compactors must be inspected in accordance with appropriate implementation conditions and
operating conditions, as needed; however an inspection to ensure operationally safe status must be
performed by an expert at least once a year. The results of the inspection must be recorded in writing
and must be stored until the next inspection.
Cleaning work
Prior to cleaning the compactor with a high-pressure cleaner, protect all accessible energized
switches, cable connections, etc. against water penetration by masking them off.
Cleaning tasks should only be executed in areas that suitable and approved for this purpose (oil
separator).
Disposal
All operating uids and auxiliary materials must be disposed of in an environmentally-compatible
manner, in accordance with country-specic regulations.
Important information for operating and maintenance personnel is marked by pictograms.
Warning against irritants or materials hazardous to health
Warning against a hazardous place
Warning against a suspended load
Wear ear protection
General regulation
Environmental protection
Hard hat
Safety shoes
Protective gloves

8 CF 3 R
Graphic presentation
Overall view CF 3 R
1 Water tank
2 Engine
3 Handle
4 Under carriage
5 Engine bracket
6 Base plate
7Wear ear protection (Stickers)
8 Gas lever
9 Poly pad
10Exciter
3
8
4
5
2
7
6
10

CF 3 R 9
Device description
The CF 3 compactor is used for road-building and landscaping compaction tasks.
Drive
The compactor is propelled by an air-cooled Robin-Subaru- gasoline engine.
Force is transferred to the exciter mechanically via a V-belt.
Operation
Start the Robin - Subaru-gasoline engine with the attached reversing starter.
After starting, vibration is switched on via the centrifugal clutch attached to the engine. Use the
gas lever to vary the engine speed between idle and full throttle.
The machine is steered with the handle.

10 CF 3 R
Technical data
CF 3 R
Weight
Operating weight CECE in kg (basic device) 99
Dimensions
Overall length in (in mm) 1160
Overall width/with attachment plates (in mm) 500
Height with folded manual guidance rod (in mm) 550
Base plate length (base in mm) 400
Pressure surface (in mm) 400x450
Propulsion
Engine manufacturer Robin-Subaru
Type EX 17
Performance at operating speed in accordance with ISO 3046-1 (kW) 4,2
Combustion process 4-stroke gasoline
rpm 3000
Operating speed (1/min) 26
Incline capacity (ground-dependent in %) 30
Area capacity/with attachment plates (in m²/h) 780
Vibration
system One-wave vibrator
Drive concept Mechanical
Frequency (in Hz) 95
Centrifugal force (in kN) 20
CF 3 R
Noise emissions in accordance with 2000/14/EC
Sound pressure level LPA ascertained in accordance with EN
500, in dB (A) 91
Sound power level LPA ascertained in accordance with EN ISO
3744 and EN 500, in dB (A) 105
Vibration values
Root-mean-square acceleration value for hand-arm vibration
ascertained in accordance with EN 500 in m/s² 4,0
In accordance with directive 2006/42/EC,
complying with the vibration values is
the owner‘s responsibility.

CF 3 R 11
1Description 2 TYPE
.................................................... ...................................................
3 Serial-Number 4 Year of construction
.................................................... ....................................................
5 Mass 6 Rated power KW
2
1
3 4
56

12 CF 3 R
Transport
Fit the crane hook into the hinged lifting ring (2) and lift the
machine onto the desired means of transport.
Only use lifting machines with a minimum bearing
capacity of 150 kg.
Hand guide rod (1) forward fold.
1
2
Transport with hand truck
Use the two screws (2) to fasten the undercarriage (1) at the
engine bracket.
1
Slide the hand truck under the base plate.
Never transport a hand guide rod to be cocked.
1
2
Arrest the hand guidance rod (1) with the spring bolt (2). 1
2
Activities prior to starting work
When transporting the soil compactor on a vehicle,
secure it with suitable restraints.
Do not step under suspended loads.
Use the handle (1) to tilt the machine to the front and swivel
the undercarriage (2) beneath the base plate (3).
2
3

CF 3 R 13
The correct oil level is between the min. and max. marks.
Checking the engine oil level
Unscrew and remove the oil dip stick from the crankcase.
Insert the oil dip stick in the oil ller neck, however do
not screw it in.
max.
min.
1
Mounting the Poly pad
Fasten the Poly pad with holder, screws, spring-lock
washers and nuts on the base plate front and rear.
Ensure that the Poly pad rests under the base plate.
1
Attach the Poly pad (1) to the rear of the base plate (2).
2
1
Open the gas cap (1), check the ll level, if necessary top
off with clean fuel in accordance with the specication to the
lower edge of ller neck.
Check the fuel level
For work at the fuel system, have a suitable re-extin-
guishing agent at the ready.
Fire, naked light, and smoking is forbidden!
1

14 CF 3 R
Slowly tighten the handle (1) of the reversing starter (2) until
resistance is noticeable.
Allow the handle (1) to slide back into the initial position, and
then forcefully and completely pull it through with both hands.
2
1
Mounting the watertank
Tank set (1) in the frame (2).
1
2
Star screw (1) down press and tank mounted in the frame (2).
1
2
By releasing the star screw is fastened in the frame.
In case of danger of frost, completely drain the water tank.
Starting
Bring the gas lever (1) into full-throttle position.
Slide the choke lever (2) to the left (close).
Slide the lever of the fuel cock (3) to the right.
After the engine has warmed up, slide the choke lever (2)
to the right (open).
2
3
1
Turn the short-circuit button to the „ON position.
1

CF 3 R 15
Shutdown
Bring the gas lever (1) into idle position.
Compacting
Control drive speed and direction of travel with the handle
(1).
Bring the gas lever (1) into full-throttle position.
Push the fuel cock (1) to the right (close).
Turn the short-circuit button (1) to the „0“ - OFF position.
Only run machine within reach of the manual guidance
rod.
During breaks—even if they are short—the machine
must be shut down.
Parked devices that represent an obstacle must be
safeguarded against conspicuously.
1
1
1
1
1

16 CF 3 R
Maintenance overview
In addition to the aforementioned maintenance work, the engine manufacturer’s regulations must
be complied with.
Work must be carried out using regulation tools and the operating and maintenance manual must
be complied with for all work.
All maintenance work: select a collection vessel that is large enough to prevent oil from spilling onto
the ground. Dispose of waste oil in an environmentally friendly manner (regulation on waste oils).
Dispose of oils, oil-soaked cloths, and parts replaced and smeared with oil in an environmentally
friendly manner.
If lubricating oils and fuel come into contact with skin, they can cause skin cancer. Upon contact
with the skin, clean affected skin with suitable cleaning agent without delay.
If accessible during maintenance, check the condition and stability of all screws.
Maintenance interval Maintenance
point Maintenance activity
After the rst 25
operating hours
Engine - Change engine oil
-Re-tighten all accessible
threaded connections
Every 8 operating
hours/daily Air lter -
Clean air lter insert,
check for damage,
replace if necessary
Every 150 operating
hours/every 6 months
Engine - Change engine oil
-Change the fuel lter
-Change oil lter
Every 150 operating
hours/every year
Transmission - Change oil
Exciter - Change oil

CF 3 R 17
Changing the engine oil
Remove oil dip stick (1).
When working in the area of the engine compartment
there is danger of burn injury!
Screw the oil drain pipe (2) and drain off the oil.
After emptying completely, unscrew the oil drain pipe (2)
from the drain valve and ll with oil in accordance with the
specication.
Clean/change air lter cartridge
Unscrew the air lter cover (1).
Remove the air lter (1) insert from the air lter enclosure
Clean the air lter insert in accordance with theguidelines
provided by the engine manufacturer, or replace if there is
extreme fouling.
Only drain engine oil when at operating temperature
Danger of scalding due to hot oil
If lubricating oils and fuel come into contact with skin,
they can cause skin cancer. Upon contact with the
skin, clean affected skin with suitable cleaning agent
without delay.
Dispose of oils, oil-soaked cloths, and parts replaced and
smeared with oil in an environmentally friendly manner.
1
2
1
Maintenance work
1

18 CF 3 R
Changing the oil in the exciter
Remove the oil drain plug (1) and drain oil.
To ll - tilt the machine slightly and ll with fresh oil through
the drain opening in accordance with the ll level table.
Checking the V-belt
Remove the V-belt guard (1).
Check the V-belt (1) for cracks, damaged anks, and wear.
If there is excessive wear - replace the V-belt as specied in
the repair manual.
All maintenance work: select a collection vessel that
is large enough to prevent oil from spilling onto the
ground. Dispose of waste oil in an environmentally
friendly manner (regulation on waste oils).
Dispose of oils, oil-soaked cloths, and parts replaced
and smeared with oil in an environmentally friendly
manner.
1
1
1

CF 3 R 19
Operating uids and ll levels
Troubleshooting
Subassembly Fuel Quantity
Summer Winter CF 3 R
Quality
Engine
Engine oil SAE 10 W 40 0,6 l
(-10 ~ + 50 °C)
API - CD CE-CF-CG
or SHPD
or CCMC - D4 - D5 - PD2
Fuel tank Regular unleaded gasoline 3,6 l
Vibrator Motoroil 10 W 40 / 15 W 40 0,2 l
Fault Possible cause Remedy
Soil compactor
does not start Operating error Execute start process as prescribed
Lack of fuel Check the fuel level
Fuel lter fouled Change the fuel lter
Air lter fouled Clean/change air lter
cartridge
No vibration / no
forward motion
or insufcient
forward motion
Vibrator V-belt
defective Change vibrator V-belt

20 CF 3 R
Measures to be taken if stored for long periods (longer than one month)
If the machine is to be stored for longer than six months, then contact the Weber service organi-
zation to discuss additional measures.
Entire soil compactor
- Clean thoroughly
- Check watertight
- If there are leaks, correct defect
Fuel tank
-
Empty fuel and ll with clean fuel
up to the lower edge of ller neck
Engine
-Check oil level, if necessary ll to
upper oil-level mark
-Check air lter, clean, replace if
necessary
-Check fuel lter, change if
necessary
All bare parts/accelerator/accelerator
control cable/fastening bolts - Oil/grease
