Installation Guide
Home Room
A WILSON ELECTRONICS BRAND
Cell Signal Booster

Package Contents 1
STEP 1: Preparation 2
STEP 2: Find The dBm Reading On Your Phone 3
STEP 3: Measure Signal Strength For Inside Antenna 4
STEP 4: Measure Signal Strength For Outside Antenna 5
STEP 5: Temporarily Mount The Outside Antenna 6
STEP 6: Connect The System 7
STEP 7: Compare Results 8
STEP 8: Permanently Mount The Outside Antenna 9
STEP 9: Route & Secure The Cable 11
Troubleshooting 12
Specifications 16
Warranty 17
______
Index

1
HOME ROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
______
Package
Contents
Home
Room
Inside
Antenna
Outside
Antenna
Cable
Connector
Window
Entry Cable
Roof/Pole
Mount
Bracket
Wall Mount
Bracket
30' Cables
Qty. 2

2CELL PHONE SIGNAL BOOSTER HOME ROOM
ENGLISH
______
Step 1: Preparation
NOTE: These instructions will walk you through a “soft” install process to find the
optimal locations for the inside and outside antennas, then through the process of the
permanent installation.
You Will Need (tools not included)
Make sure the following materials are prepared and ready for your installation.
o Ladder
o Phillips-head screwdriver
o 10mm open-end wrench or adjustable wrench
o Drill (if routing cable through wall)
o Mounting Option A:1-2” diameter pole (#901117) or an
existing pole
o Recommended: Power Strip with surge protection
1 to 2 hours
2 people (a person to help with antenna calibration)

3
HOME ROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
Dial *3001#12345#* then press Call.
1Hold down power button until you see 'Slide to
Power O'.
2Then release the power button.
3 Hold the Home button until your main screen appears.
If you want to check 3G/1x but your iPhone is picking up 4G/
LTE signal, go to Settings>Cellular>Cellular Data Options>En-
able LTE>Select O.
After you system is set up, you can go back to the dots signal
by once again dialing *3001#12345#* then pressing call.When
the menu comes back up, tap “phone” in the top left corner of
your phone.
Settings > About Phone > Status or Network > Signal Strength
or Network Type and Strength (exact options/wording
depends on phone model).
______
Step 2: Find The dBm
Reading On Your Phone
All Other Phones & Alternate Methods
• https://www.weboost.com/test-mode-instructions/
All Phones:
• Keep track of the network (3G or 4G) phone is connected to.
• Any signal readings you take are valid for that phone’s carrier. To get readings
from other carriers, you’ll need phones from each carrier.
iPhone®
Android™
NEED HELP? support.weboost.com 866.294.1660
iPhone is a registered trademark of Apple Inc. Android is a trademark of Google Inc.

4
CELL PHONE SIGNAL BOOSTER HOME ROOM
ENGLISH
______
Step 3: Measure Signal
Strength For Inside
Antenna Placement
Having an accurate measurement of signal strength in decibels (dBm) is crucial
when installing your system. Decibels accurately measure the signal strength you
are receiving. Test both 3G and 4G signal for best results by turning the LTE o in
the carrier settings of your device.
SIGNAL STRENGTH EXCELLENT GOOD FAIR POOR DEAD ZONE
3G/1x
(typically voice) -70dBm -71 to -85dBm -86 to -100dBm -101 to -109dBm -110dBm
4G/LTE
(typically data) -90dBm -91 to -105dBm -106 to -110dBm -111 to -119dBm -120dBm
Turn o your cell phone’s WiFi to ensure you
are checking the cellular connection. The dBm
reading will be refreshed every 30-60 seconds.
Want faster results? Once you have a reading,
turn on airplane mode. Wait 15 seconds.
Turn o airplane mode. The signal strength
reading is refreshed.
Walk around your home/oce taking signal
strength readings until you find the area that has
the weakest reception, or number farthest away
from zero. For example -100 is a weaker signal
than -80.
Weakest Signal Number:___________
Weakest Signal Location: ___________
Place your Inside Antenna in this poor signal area.
For best results, keep the inside antenna more
than 18 inches away from the booster.

5
HOME ROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
______
Step 4: Measure Signal
Strength For Outside
Antenna Placement
This is the most critical step of the installation
process because it will determine the overall
performance of the booster system. Using the
same method as Step 3, find the place with the
strongest signal (number closest to zero) on the
outside of your home.
The further apart the Inside Antenna is located
from the Outside Antenna, the better. To
determine the best location for your Outside
Antenna, note the dBm reading in a variety of
locations.

6CELL PHONE SIGNAL BOOSTER HOME ROOM
ENGLISH
______
Step 5: Temporarily Mount
The Outside Antenna
Use one of the two options to mount the
outside antenna on the side of the house with
the strongest signal.
Note: Using an app like 'Open Signal' will help
you point the outside antenna in the direction of
the nearest cell phone tower.
AOption (Best)
BOption (Better)
Note: The Outside Antenna must be at least
50 feet horizontal or 20 feet vertical from the
Inside Antenna for best performance. Make sure
the Inside Antenna and outside Antennas are
facing away from each other.
A
B

7
HOME ROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
OUTSIDE
INSIDE
OUTSIDE
INSIDE
OUTSIDE
INSIDE
______
Step 6: Placing Inside Antenna
And Connect The System
Connect the supplied Inside Antenna to
end of booster labeled Inside.
Power up the Booster by connecting it
to a power source.
Note: To protect Booster from power
surges, connect to a power strip.
Connect the supplied Coax Cable to
end of booster labeled Outside.
If you choose to bring the cable in
through a window, you can use the flat
Window Entry Cable to connect the
two 15 feet cable sections. You can
use this option during set-up and/or
permanently if you don’t want to drill
holes through your wall.
Place inside antenna in weak signal
area at least 18 inches away from
booster.
Outside
Antenna
Inside
Antenna
Power
Supply
1
2
3
4
Window Entry Cable

8CELL PHONE SIGNAL BOOSTER HOME ROOM
ENGLISH
______
Step 7: Compare Results
Using the field test mode described in step 3, measure the new signal
strength and write it down here ___________.
Compare this number with the original reading you took in the same part of the house.
If the number is higher (closer to zero) than the original reading without booster, your
booster is working. If it is not, look at the lights on the booster and the section at the
end of this manual “Test System: Lights”.
Did you know a signal increase in just
3dB is 2 times the power and signal amplification!
Distance from Cell Tower
CELL
TOWER
Signal Strength
GOOD
Signal Strength
POOR
Signal Strength
DEAD ZONE
Signal Strength
EXCELLENT
Signal Strength
FAIR
3G/1x
4G/LTE
-70dBm
-90dBm
-75dBm
-100dBm
-90dBm
-108dBm
-105dBm
-115dBm
-110dBm
-120dBm
DECIBEL GAIN POWER INCREASE
3dB 2 times the power and signal amplification
6dB 4 times the power and signal amplification
10dB 10 times the power and signal amplification
12dB 16 times the power and signal amplification
20dB 100 times the power and signal amplification

9
HOME ROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
______
Step 8: Permanently Mount
The Outside Antenna
Option A: Outside Roof/Pole Mount (Best Option)
Mount, or use an existing pipe in an optimal signal location. Watch out for power lines.
Mounting on existing roof exhaust pipe would be
a good time-saver option.
Outside Antenna
(pole mount)
Home Room
Power Supply
Inside Antenna
50 feet horizontal or
20 feet vertical for best performance
A flat Window Entry
Cable is provided
that allows you to run
the cable through a
window if needed

10 CELL PHONE SIGNAL BOOSTER HOME ROOM
ENGLISH
Option B: Outside Wall Mount (Better Option)
______
(STEP 8 cont.)
Outside Antenna
(wall mount)
Home Room
Power Supply
Inside Antenna
50 feet horizontal or
20 feet vertical
Drill holes using
3/16 inch bit
Tap anchors in
Fasten bracket to back
of Outside Antenna Secure bracket to wall
mounting
Outside Antenna
on wall bracket
sideview
Note: A flat Window Entry Cable is provided that allows you to run the cable
through a window.

11
HOME ROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
______
Step 9: Route & Secure
The Cable
Secure cable on outside home/oce. If following Option A, some homes have eaves
you can tuck the cable between the sot and the exterior wall. If needed, cable clips
can be purchased at most hardware stores.
cable running to
Outside Antenna
most eaves you can tuck the cable
between the sot and the exterior wall
cable running through
gable vent
To protect your system , you will want to purchase/install a lightening surge
protector (#859992). To purchase, call 866-294-1660 or visit weboost.com
After installing your system, check the lights after 24 hours to ensure no
changes.
If the Outside Antenna is mounted outdoors, weatherproof connections 1”
(25mm) beyond where the connections begin and end with electrical tape.
Optional: To improve the aesthetic of your antennas use non-metallic paint.
If you haven’t already, be sure to register your product!
Note: A flat Window Entry Cable is provided that allows you
to run the cable through a window if needed.

12 CELL PHONE SIGNAL BOOSTER HOME ROOM
ENGLISH
______
Troubleshooting
Fix Any Red Light Problems (red indicates oscillation)
• If you are happy with coverage, red lights don’t have to be resolved.
• Solid Red = Band has shut o
• Blinking Green/Red = Band has reduced gain
Each light corresponds to a frequency band.
No Lights
Booster does not have power. Un-plug and securely re-plug in power supply.
Note: Lights may be dim.
IMPORTANT: To get an accurate reading of the lights, unplug and re-plug
the power supply from the Booster.
Band 4
Band 5
Band 2
!
Skinny
top view
Fat
1Verify Outside Antenna faces away from the
Inside Antenna. Un-plug and re-plug in power
supply.
2Verify the Inside Antenna is at least 18” from the
Booster and pointed away from the Booster. Un-
plug and re-plug in power supply.
3Tighten all cable connections (be sure to hand-
tighten only, do NOT use tools). Un-plug and re-
plug in power supply. You may want to undo and
redo the connection completely.
4BEST: Increase the distance (horizontally or
vertically) between the Outside and Inside
antenna. Add included cable if needed. Un-plug
and re-plug in power supply.
OUTSIDE ANTENNA: The skinny side
should always face outside, towards the
cell tower.
Power Indicator Light

13
HOME ROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
NEED HELP? support.weboost.com 866.294.1660
Fix Any Orange Light Problems (orange indicates a cell
tower is close by)
If you are happy with coverage, orange lights don’t have to be resolved
• Solid Orange = Band has shut o
• Blinking Green/Orange = Band has reduced gain.
1If the light is solid orange, the Outside Antenna must be adjusted (see below). Wait
10 seconds between adjustments for the lights to reset.
• For Roof/Pole Mount Option = Rotate the Outside Antenna away from the
strongest cellular signal in small increments (45°) until the light turns green. Un-
plug and re-plug power supply.
• For All Other Mount Options = Change mount location. For example, if the
Outside Antenna is a window mount, move the Outside Antenna to a wall
outside the building to see if the lights turn green. Un-plug and re-plug power
supply.
2If the light is blinking green/orange, re-locate the Outside Antenna. Un-plug and
re-plug power supply.
All Green Lights? = Band is set up optimally. Verify you
have good coverage.
If you have green lights, but poor coverage:
• Rotate the Outside Antenna in small increments (roof/pole mount only). Un-plug
and re-plug power supply.
• Move the Outside Antenna to a dierent location. Un-plug and re-plug power
supply.
• Change the method of mounting the Outside Antenna. Un-plug and re-plug power
supply.
______
(TROUBLESHOOTING cont.)

14 CELL PHONE SIGNAL BOOSTER HOME ROOM
ENGLISH
______
Antenna Kit Options
Outside antenna maximum permissible
antenna gain (dBi) 50Ω
Inside antenna maximum permissible
antenna gain (dBi) 50Ω
3.71 4.92
4.90
3.49
Ω
50
50
50
75
75
50
50
70
75
75
50
Antenna Type
4G Dome
4G Dome
4G Dome
4G Dome
4G Dome
Wall Mount Panel Antenna
Wall Mount Panel Antenna
Wall Mount Panel Antenna
Wall Mount Panel Antenna
Wall Mount Panel Antenna
RV Desktop Antenna
Coax Type
RG-174
Wilson-400
RG-58
RG-6
RG-11
Wilson-400
RG-58
RG-6
RG-11
Wilson-400
RG-58
Kit #
304412-17410
304412-40010
304412-5810
304419-0610
304419-1110
311135-40060
311135-5820
311155-0630
311155-1150
311155-40060
311160
Ln(ft)
10
10
10
10
10
60
20
30
50
60
13
FIXED INSIDE ANTENNA KIT OPTIONS
3.73
BAND 5 BAND 4 BAND 25/2
6.60

15
HOME ROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
Ω
75
50
75
50
75
75
50
50
75
50
50
50
50
50
50
50
50
75
75
75
75
Antenna Type
Yagi Directional
Yagi Directional
Yagi Directional
Yagi Directional
4G Omni
4G Omni
4G Omni
4G Omni
4G Omni
4G Omni
4G Omni
Omni-Directional
Omni-Directional
Wide Band Directional
Wide Band Directional
Pole Mount Panel
Pole Mount Panel
Pole Mount Panel
Pole Mount Panel
Wide Band Directional
Wide Band Directional
Coax Type
RG-6
RG-58
RG-11
Wilson-400
RG-11
RG-6
Wilson-400
RG-58
RG-11
RG-58
RG-174
Wilson-400
RG-58
Wilson-400
RG-58
RG-58
Wilson-400
RG-6
RG-11
RG-6
RG-11
Kit #
301111-0675
301111-5850
301111-11140
301111-400170
304421-1120
304421-0610
304422-40020
304422-5810
304422-1120
304421-5810
304421-17410
311203-40020
311203-5820
314411-40075
314411-5825
314453-5825
314453-40075
314473-0640
314473-1175
314475-0630
314475-1175
Ln(ft)
75
50
140
170
20
10
20
10
20
10
10
20
20
75
25
25
75
40
75
30
75
FIXED OUTSIDE ANTENNA KIT OPTIONS
______
(ANTENNA KIT OPTIONS cont.)

16 CELL PHONE SIGNAL BOOSTER HOME ROOM
ENGLISH
______
Specifications
Home Room™
Product Number U530001
Connectors SMA-Female on the Inside Antenna / F-Female on the Outside Antenna
Antenna Impedance 75 Ohms / 50 Ohms
Frequency 824-894 MHz, 1850-1995 MHz, 1710-1755/2110-2155 MHz
Passband Gain (nominal) 800 MHz
Band 5
59.5
1700/2100 MHz Band 4
63.7
1900 MHz
Band 2
63.7
Power output for single cell phone
(Uplink) dBm
800 MHz
Band 5
1700 MHz
Band 4
1900 MHz
Band 2
20 20 20
Power output for single cell phone
(Downlink) dBm
800 MHz
Band 5
2100 MHz
Band 4
1900 MHz
Band 2
23 19 21
Power output for multiple received
channels (Uplink) dBm
No. Tones
Maximum Power
800 MHz
Band 5
1700 MHz
Band 4
1900 MHz
Band 2
2 23.4 21.2 19.1
3 19.9 17.7 15.5
4 17.4 15.2 13.0
5 15.4 13.3 11.1
6 13.9 11.7 9.5
Power output for multiple received
channels (Downlink) dBm Maximum Power
No. Tones 800 MHz
Band 5
2100 MHz
Band 4
1900 MHz
Band 2
2 11.8 11.9 12.6
3 8.2 8.4 9.1
4 5.7 5.9 6.6
5 3.8 4.0 4.7
6 2.2 2.4 3.1
Noise Figure 5 dB nominal
Isolation > 110 dB
Power Requirements AC / DC 5V, 2.5A, w/2.5x5.5mm Jack

17
HOME ROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
2 YEAR WARRANTY
weBoost Signal Boosters are warranted for two (2) years against defects in
workmanship and/or materials. Warranty cases may be resolved by returning
the product directly to the reseller with a dated proof of purchase.
Signal Boosters may also be returned directly to the manufacturer at the
consumer’s expense, with a dated proof of purchase and a Returned Material
Authorization (RMA) number supplied by weBoost. weBoost shall, at its option,
either repair or replace the product.
This warranty does not apply to any Signal Boosters determined by weBoost
to have been subjected to misuse, abuse, neglect, or mishandling that alters
or damages physical or electronic properties.
Replacement products may include refurbished weBoost products that have
been recertified to conform with product specifications.
RMA numbers may be obtained by contacting Customer Support as below.
DISCLAIMER: The information provided by weBoost is believed to be complete
and accurate. However, no responsibility is assumed by weBoost for any
business or personal losses arising from its use, or for any infringements of
patents or other rights of third parties that may result from its use.

3301 East Deseret Drive, St. George, UT
T. 866.294.1660
www.weboost.com | support.weboost.com
Copyright © 2017 weBoost. All rights reserved.
weBoost products covered by U.S. patent(s) and pending application(s)
For patents go to: weboost.com/us/patents
NOT AFFILIATED WITH WILSON ANTENNA
