weBoost DRIVE 4G-X OTR User manual

Install
Guide
DRIVE
4G-X OTR

Get ready
for a great signal.
Follow these easy steps and the Drive 4G-X OTR will be boosting
your signal in no time. Drive 4G-X OTR technology - the solution
for a strong, reliable cell signal.
For more information please refer to this package’s User
Manual, or find it online at:
https://cellphonesignalbooster.us/weboost-drive-4g
-x-otr-470210-truck-signal-booster-kit/
PACKAGE CONTENTS
FCC ID: PWO460021 IC: 4726A-460021 Model# 460021 Product# U470010
Drive 4G-X
Signal
Booster
4G-OTR
Antenna &
Mount
Slim Low
Profile
Antenna
Mounting
Bracket
DC Power
Supply
https://cellphonesignalbooster.us/weboost-drive-4g-x-otr-470210-truck-signal-booster-kit

HOW DOES DRIVE 4G-X OTR WORK?
Drive 4G-X OTR receives a cell signal from the tower, amplifies it, and sends
it over the cable to the antenna. The antenna broadcasts the amplified signal
throughout the cab of the truck.
https://cellphonesignalbooster.us/weboost-drive-4g-x-otr-470210-truck-signal-booster-kit

Step 2
RUNNING ANTENNA CABLE
Run the Outside Antenna cable into the vehicle.
The cable is strong enough that it may be shut in
most vehicle doors without damaging the cable.
For a cleaner look, carefully pull down the door
seal, run the cable under the seal, and push the
seal back into place. This method reduces wear
on the cable as the door opens and closes.
Quick Install Guide
Please refer to our User Manual for more options on how to
properly install your booster.
Step 1
4G-OTR ANTENNA INSTALLATION
Select a location on one of the mirror rails to
mount the 4G-OTR Antenna that is:
• At least 12 inches from any other antennas.
• Free of obstructions.
• At least 6 inches from any windows
(including sunroofs).
Remove existing nut from mount as shown.
Mount antenna with fitted disc washer and nut
provided in package. Add included thread lock
on all threads.
Remove
Remove
Remove
Remove
4G-OTR
Antenna
https://cellphonesignalbooster.us/weboost-drive-4g-x-otr-470210-truck-signal-booster-kit

Step 4
Step 3
INSIDE ANTENNA INSTALLATION
Identify a place on the side of the seat to mount
the Slim Low Profile Antenna. The location
should be at least 18 inches but no more than
36 inches from where the cellular device will be
used. Peel off the backing of the Velcro® and
attach to seat.
CONNECT COAX CABLES TO DRIVE 4G-X
Select a location for the Drive 4G-X that is
free from excessive heat, direct sunlight and
moisture and that has proper ventilation. Good
locations include underneath a seat or under the
dashboard. Connect the cable from the 4G-OTR
Antenna to the port labeled “Outside Antenna”
on the Drive 4G-X and connect the cable from
the Slim Low Profile Antenna to the port labeled
“Inside Antenna” on the booster.
Step 5
CONNECT TO POWER SUPPLY
Connect the power supply cord to the end of the
Drive 4G-X labeled “Power.” NOTE: Do NOT con-
nect the power to the Signal Booster until you have
connected both the Inside and Outside Antennas.
Slim Low
Profile
Antenna
Slim Low
Profile
Antenna
4G-OTR
Antenna
https://cellphonesignalbooster.us/weboost-drive-4g-x-otr-470210-truck-signal-booster-kit

GREEN BLINKING RED SOLID RED
Booster is operating
seamlessly
Booster has reduced
power to eliminate
oscillation
Booster has shut down
due to oscillation.
FOR ADDITIONAL INFORMATION PLEASE REFER TO OUR USER MANUAL
WHAT COLOR IS YOUR LIGHT?
Step 6
CONNECT TO POWER SUPPLY
Plug the power adapter into vehicle’s 12V DC
power supply. Power up your Drive 4G-X by
flipping the switch on the back of the DC power
adapter on. If your Drive 4G-X is working correctly,
the lights will remain green.
NOTE: If light is not green on your weBoost
booster, please refer to the full user manual online
or contact customer support at 1-800-501-3153
Congratulations! Once your booster is running, please allow some time for your
phone to adjust to your new signal.
Read more about it here at
https:/cellphonesignalbooster.us/weboost-drive-4g-x-otr-470210-truck-signal-booster-kit/
switch
Vehicle’s Power
Supply
