weBoost Office 200 User manual

Installation Guide
Cell Signal Booster
Oce 200
Oce 200
A WILSON ELECTRONICS BRAND
NEED HELP? support.weboost.com 866.294.1660

Package Contents 1
Preparation 3
STEP 1: Inside Antenna & Booster Placement 5
STEP 2: Mount Outside Antenna 6
STEP 3: Route & Connect Outside Antenna To Booster 7
STEP 4: Route & Connect Inside Antenna To Booster 8
STEP 5: Power Up The Booster 9
Measuring Booster Performance 10
Menu System 12
Troubleshooting 16
Safety Guidelines 17
Specifications 19
Warranty 20
______
Index

1
OFFICE 200 CELL PHONE SIGNAL BOOSTER
______
Package
Contents
Office 200
Booster
Office 200
Booster
Power
Supply
(850026)
Power
Supply
(850026)
Lightning Surge
Protector
(859902)
Lightning Surge
Protector
(859992)
Cable Mounting
Clips
Cable Mounting
Clips
Inside
Antenna
(314407)
Inside
Antenna &
Connector
(314407)
Outside
Antenna
(314422)
Outside
Antenna
(314423)
75’ & 60’
Wilson 400 Cables
(952360 & 952375)
75’ & 60’
RG-11 Cables
(951160 & 951175)
2’ Wilson 400
Cable
(952302)
2’ RG-11
Cable
(951127)
Oce 200 50 Ohm Kit
Oce 200 75 Ohm Kit

2CELL PHONE SIGNAL BOOSTER OFFICE 200
______
Key Features
Extended Dynamic Range (XDR) for continuous
connectivity: XDR lets the Oce 200 system work with
any incoming signal and never shuts down due to a
strong outside signal.
Simple Wall-Mount Installation: An indoor and outdoor
port are located on top of the amplifier for easy antenna
connections, while an exposed mounting flange at each
corner of the amplifier provides for simple and clean wall-
mount installation.
Onboard Software for Better Control: The amplifier is
automatically controlled with automatic onboard software,
ensuring great connectivity throughout large spaces and
multi-story buildings. The amplifier will adjust its gain
level up or down as required by the conditions of the
immediate signal environment.
Color LCD Touch Screen: The Oce 200 utilizes a color
LCD touch screen for assessing amplifier performance,
making adjustments to the outside antenna, and turning
bands on and o.

3
OFFICE 200 CELL PHONE SIGNAL BOOSTER
______
Preparation
You Will Need (tools not included)
Make sure the following materials are prepared and ready for your installation.
o Ladder
o Drill
o 1” - 2” diameter existing pole for mounting
Outside Antenna (#901117 Pole Mount can be
purchased separately if needed)
o Recommended: Power Strip with surge protection
1 to 2 hours

4CELL PHONE SIGNAL BOOSTER OFFICE 200
______
Installation Diagram
Outside
Antenna
Booster
75’ Coax Cable
Troubleshooting section recommends increasing distance
further if needed.
60’ Coax Cable
to power
Lightning Surge
Protector
Inside
Antenna
60 FEET HORIZONTAL OR 25 FEET VERTICAL DISTANCE
G
r
o
u
n
d

5
OFFICE 200 CELL PHONE SIGNAL BOOSTER
AT LEAST 24” APART
Oce 200
Plastic Nut
Tab Ring
ceiling mount
drywall
NOTE: Do not connect booster to power until the system is fully installed.
______
Step 1: Inside Antenna &
Booster Placement
Place the inside antenna in the ceiling over where you need the greatest signal
boost and place booster in your desired location at least 24” away from
inside antenna.

6CELL PHONE SIGNAL BOOSTER OFFICE 200
______
Step 2: Mount Outside Antenna
NOTE: Mounting on existing roof exhaust pipe would be a good time-saver option. Watch
out for power lines.
Pole mounting and wall mounting options are included.
Attach the mount to the outside antenna and use the bracket clamp to attach
the antenna to a pole or exhaust pipe.
Outside
Antenna
U-Bolt
L-Bracket
existing
pole
Pole
Bracket

7
OFFICE 200 CELL PHONE SIGNAL BOOSTER
______
Step 3: Route & Connect
Outside Antenna To Booster
Route cable to the Oce 200 booster and connect to the port labeled
‘OUTSIDE ANTENNA’.
Outside
Antenna
75’ Coax Cable 2’ Coax Cable
Outside
Antenna
Lightning Surge
Protector
Booster
Booster
Cable Mounting Clips
provided
Lightning Surge
Protector
Connect 2 ft. coax cable to outside antenna, attach the lightning surge
protector, then connect the black 75 ft. coax cable and route into building.
G
r
o
u
n
d

8CELL PHONE SIGNAL BOOSTER OFFICE 200
______
Step 4: Route & Connect
Inside Antenna To Booster
Inside
Antenna
60’ Coax Cable
Booster
Connect the black 60 ft. coax cable to inside antenna and route to the Oce
200 booster and connect to the port labeled ‘INSIDE ANTENNA’.
Outside
Antenna
Booster
Cable Mounting Clips
provided
Inside
Antenna

9
OFFICE 200 CELL PHONE SIGNAL BOOSTER
Oce 200
______
Step 5: Power Up The Booster
Plug the power supply into wall outlet then connect to end of booster
labeled “ ” and enjoy your boosted signal.
Booster
to power
NOTE: We strongly recommend using a power strip with surge protection.
Inside
Antenna
Outside
Antenna
Troubleshooting section recommends increasing distance
further if needed.
60 FEET HORIZONTAL OR 25 FEET VERTICAL DISTANCE
Oce 200
to power

10 CELL PHONE SIGNAL BOOSTER OFFICE 200
______
Measuring Booster
Performance
Settings > About Phone > Status or Network > Signal Strength or
Network Type and Strength (exact options/wording depends on
phone model).
Android™
iPhone is a registered trademark of Apple Inc. Android is a trademark of Google Inc.
iOS 11 and later no longer displays the decibel (dBm) reading
in ‘Field Test Mode’. Tip: Using the signal bars and performing
data speed tests on your cell phone can assist you in finding
the strongest signal direction as well as placing calls in dierent
locations. For changes/updates on this issue, periodically go to
weboost.com/signalstrength.
iPhone®
How To Get Signal Strength As A Number
All Other Phones & Alternate Methods
Go to www.weboost.com/signalstrength

11
OFFICE 200 CELL PHONE SIGNAL BOOSTER
EXCELLENT GOOD FAIR POOR DEAD ZONE
3G/1x
4G/5G
-70dBm
-90dBm
-71 to -85dBm
-91 to -105dBm
-86 to -100dBm
-106 to -110dBm
-101 to -109dBm
-111 to -119dBm
-110dBm
-120dBm
SIGNAL
STRENGTH
EXCELLENT GOOD FAIR POOR DEAD ZONE
3G/1x
4G/LTE
-70dBm
-90dBm
-71 to -85dBm
-91 to -105dBm
-86 to -100dBm
-106 to -110dBm
-101 to -109dBm
-111 to -119dBm
-110dBm
-120dBm
SIGNAL
STRENGTH
Having an accurate measurement of signal strength in decibel-milliwatts (dBm) is crucial
when installing your system. dBm accurately measure the signal strength you are receiving.
DID YOU KNOW a signal increase of just 3dB is 2
times the power and signal amplification!
Compare Results
______
(MEASURING BOOSTER PERFORMANCE cont.)
Signal Strength with Booster
Note here:
Signal Strength without Booster
Note here:

12 CELL PHONE SIGNAL BOOSTER OFFICE 200
______
Menu System
The Oce 200 takes about 5 seconds to boot up. Once boot up is complete, the home
screen will appear, showing the amplification and status of each port and band.
GREEN: A solid green light indicates that a band is operating correctly with maximum
allowable gain.
YELLOW: A solid yellow light indicates band gain reduction because of an oscillation
condition. Reposition antennas (increase separation between indoor and outdoor
antennas, and then reboot (turn the unit o & on) the Oce 200 to reactivate the band
and maximize performance. When adequate separation is achieved, the yellow lights
will return to green upon reboot. Note: when the light is yellow, the band is operational;
however, performance is reduced.
RED: A red light indicates a band has been shut down because of a severe oscillation
condition or repeated oscillation. Reposition antennas (increase separation between
indoor and outdoor antennas, and then reboot (turn the unit o & on) the Oce 200
to reactivate the band and maximize performance. When adequate separation is
achieved, the red light(s) will return to green upon reboot.
GRAY: Gray indicates band has been disabled.
Band Menu Color Desrciption
Start Up Screen
Home Screen

13
OFFICE 200 CELL PHONE SIGNAL BOOSTER
Tap icon to view the Settings Screen.
Bands can be disabled/enabled by tapping the desired band. Note: disabling a cell band is
not recommended. Bands should only be disabled by expert installers.
Settings Screen

14 CELL PHONE SIGNAL BOOSTER OFFICE 200
To go back to the home screen tap on the home icon.
To view specific band information (such as the strength of the received uplink &
downlink signal, status details and the amplifier gain) tap desired band on the home
screen.

15
OFFICE 200 CELL PHONE SIGNAL BOOSTER
By tapping on the desired Band, a more detailed screen will appear for better
troubleshooting.
Note: If the reduced gain due to oscillation is greater or equal to 60dB, this condition
will be displayed as Green instead of Yellow and no action is necessary.

16 CELL PHONE SIGNAL BOOSTER OFFICE 200
______
Troubleshooting
If the bands are any color other than green, use the touchscreen LCD and
tap any given band that’s not green to see troubleshooting options.
IF YOU ARE HAPPY WITH THE COVERAGE, THESE LIGHT ISSUES DON’T HAVE TO
BE RESOLVED. YOUR CARRIER’S BAND HAS NOT BEEN AFFECTED.
NEED HELP? support.weboost.com 866.294.1660

17
OFFICE 200 CELL PHONE SIGNAL BOOSTER
______
Safety Guidelines
FOR MORE INFORMATION ON REGISTERING YOUR SIGNAL BOOSTER WITH YOUR
WIRELESS PROVIDER, PLEASE SEE BELOW:
T-Mobile/MetroPCS: https://www.t-mobile.com/support/coverage/register-a-signal-booster
Verizon Wireless: https://www.verizon.com/solutions-and-services/accessories/register-signal-booster/
AT&T/Cricket: https://securec45.securewebsession.com/attsignalbooster.com/
UScellular: https://www.uscellular.com/support/fcc-booster-registration
This is a CONSUMER device.
BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your
provider’s consent. Most wireless providers consent to the use of signal boosters. Some providers
may not consent to the use of this device on their network. If you are unsure, contact your provider.
You MUST operate this device with approved antennas and cables as specified by the
manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from any person.
You MUST cease operating this device immediately if requested by the FCC or licensed wireless
service provider.
WARNING. E911 location information may not be provided or may be inaccurate for calls served by
using this device.
This device may be operatedONLYin a fixed location for in-building use.
Use only the power supply provided in this package. Use of a non-weBoost power supply may
damage your equipment.
The signal booster unit is designed for use in an indoor, temperature-controlled environment
(less than 100 degrees Fahrenheit). It is not intended for use in attics or similar locations subject
to temperatures in excess of that range.
RF Safety Warning: Any antenna used with this device must be located at least 8 inches from all
persons.
AWS Warning: The outside antenna must be installed no higher than 10 meters (31’9”)
above ground.

18 CELL PHONE SIGNAL BOOSTER OFFICE 200
Ω
Ω
50
50
75
75
50
75
50
Antenna Type
Antenna Type
Omni Plus
Dome
Omni Plus
Dome
Omni
Omni
Low Profile Dome
Coax Type
Coax Type
LMR-400
LMR-400
RG-11
RG-11
LMR-400
RG-11
LMR-400
Kit #
Kit #
304422
304412
314423
304419
304424
304421
314407
Ln(ft)
Ln(ft)
75
60
75
60
75
75
60
FIXED OUTSIDE ANTENNA KIT OPTIONS
FIXED INSIDE ANTENNA KIT OPTIONS
The following accessories are certified by the FCC to be used with the Oce 200 Booster.
______
Antenna Kit Options
Outside antenna maximum permissible
antenna gain (dBi) 50
Inside antenna maximum permissible
antenna gain (dBi) 50
4.4 4.74.5 4.2
-0.4 -0.1 1.6
BAND 25/2
BAND 4
2.4
BAND 5
4.5
-0.7
BAND 13
BAND 12/17
