Weco LED FLEX BNX Series User manual

LED FLEX - 05.BNx
VERSION UM.BND.230.17K.EN
USER MANUAL

1.
Lower the LED Flex down the shaft whilst holding it firmly underneath the
connection point with the power cable.
3.
Secure the LED Flex to the plugs with the cable ties provided.
4.
Continue with the installation of the LED Flex.
NOTE: 2 or 3 fixings may be required for the first metre / top of the shaft,
depending on the nature of the wall. Thereafter, a fixing every 1 to 2 m
should suffice.
5.
Power-on the LED Flex.
2.
Drill 8mm holes along the desired path of the LED Flex and insert
the push-plugs, as shown.
INSTALLATION INSTRUCTIONS
Do not suspend the LED Flex by the power cable,
as this may cause the electrical connection to loosen.

PRODUCT FEATURES
Input voltage
Max current
Cut length
Max. working length
LED model
Diode/m
CCT
Working temperature
Power cable type
230VAC±10%, 50/60HZ
4A
1m
50m
SMD5050
60x
6500K±8%
-20°C to 50°C
H03VVH2-F
2 core / 0.75mm²
The LED Flex can be cut every metre. The cut points are clearly
marked on the LED Flex.
Do not bend or squeeze the LED Flex sharply.
The LED Flex is designed for high luminance. The lifetime (MTTF)
of the LEDs is much higher compared to fluorescent tubes.
Nevertheless, we recommend a cool down phase after 12 hours
of continuous operation to maximise the lifetime.
Do not hold the LED Flex by the power cable, as this may loosen
the connection between the power cable and the LED Flex.
The maximum length of the Flex is 50m.
Please make sure that the PVC coating is not damaged,
as this may cause the LED Flex to short circuit.
Do not perform any local electrical installation whilst the
LED Flex is powered-on.
Do not submerge the LED Flex in water.
1.
2.
3.
4.
5.
6.
7.
8.
WARNING INSTRUCTIONS

DO NOT POWER-ON THE
LED FLEX WHEN COILED
DO NOT DROP THE LED FLEX
DOWN THE SHAFT WHEN
HOLDING ONLY THE CABLE
DO NOT SHARPLY
BEND THE LED FLEX
TROUBLESHOOTING
1.
The LED Flex does not light when powered on.
- The power cable is damaged or broken. Check for integrity.
- The connection between the power cable and the LED Flex has loosened.
Push the power cable and the LED Flex together firmly.
2.
A section in the middle of the LED Flex does not light up.
- The circuit at the rear of the LED Flex has broken. Please replace the
relevant section of LED Flex.
3.
The PVC coating of the LED Flex feels hard and the LED Flex is difficult
to bend and flex.
- The environmental temperature is too low.
4.
There is a strange odour and the PVC coating of the LED Flex feels soft.
- The environmental temperature is too high, causing heat accumulation.
Power off and allow the LED Flex to cool down.
SAFETY INSTRUCTIONS
www.wecoeurope.com - [email protected]
