Wells SS-206T User manual

WELLS
R A I S I N G T H E S T A N D A R D
SS-206T BUILT-IN TOP MOUNT
RECTANGULAR FOOD WARMER
SS-206T BUILT-IN TOP MOUNT RECTANGULAR FOOD WARMER
I T E M N O .
WE L L S M A N U F A C T U R I N G
Features
• 12” x 20” standard warming pan easily
adapts to a variety of fractional or round inset
pans up to 6” deep.
• Warming pan is deep-drawn, stainless steel
for maximum strength and durability.
• The tubular element, located under the
warming pan, allows for quick heating.
• The positive-off thermostat (T) controls the
element allowing for adjustable and more
consistent temperatures.
• Models are available with optional drain (D).
• Wellslok allows for quick and easy installation
in stainless steel countertops.
• Warmer is designed for either wet or
dry operation.
• The SS-206T Warmer is Underwriters
Laboratories, Inc. Recognized and meets
NSF International standards.
• A one-year warranty against defects covers
parts and labor.
Wells SS206T Built-In Rectangular Food
Warmer is designed for top mount installation.
This dependable and practical unit is thermostatically
controlled, has a heavy-duty stainless steel warming
pan and is available with an optional drain. The
warming pan accommodates a standard 12” x 20”
inset pan up to 6” deep.
SS-206T
Specifications
Overall Dimensions: Inches MM
Width 13 11/16 348
Depth 21 3/4 552
Temperature Settings: OFF/LO to HI
Weights: Lbs. KG
Installed 14 6
Shipping 16 7
Accessories / Options
Adapter Top, to convert SS-206T to hold
two 7-quart insets, 20176
Adapter Top, to convert SS-206T to hold
two 4-quart insets and two 2 1/2-quart
insets, 20434
Adapter Top, to convert SS-206T to hold
one 7-quart and one 11-quart inset, 21621
Adapter Top, to convert SS-206T to hold
three 4-quart insets, 21615
Adapter Top, to convert SS-206T to hold
four 2 1/2-quart insets, 21624
Adapter Top, to convert SS-206T to hold
one 4-quart and one 7-quart inset, 21617
Inset, 2 1/2-quart capacity with lid, 20773
Inset, 4-quart capacity with lid, 20774
Inset, 7-quart capacity with lid, 20587
Inset, 11-quart capacity with lid, 20908
Individual drain (D) available on all models
Drain Valve Extension Kit, extension from
drain to counter front with remote handle,
for use with “D” models only, 20385

WELLS
S S - 2 0 6 T E L E C T R I C A L S P E C I F I C AT I O N S :
MODELS VOLTS WATTS AMPS PHASE POWER SUPPLY CORD
R
STD.4
R
(125)
4 15/16
(348)
13 11/16
(305)
12
(508)
20
(552)
21 3/4
(221)
8 11/16
POWER SUPPLY LEADS
(SS-206TD ONLY)
1/2 IN DRAIN NPT
WELLS MANUFACTURING COMPANY
2 ERIK CIRCLE, PO BOX 280, VERDI, NV 89439 U.S.A. • USA PHONE: [phone] • FAX: [phone]
FOR ORDERS ONLY: [phone] • FAX: [phone] • www.wellsbloomfield.com
© 2001 WELLS MANUFACTURING • PRINTED IN THE U.S.A. • 04/01 • REV(K) • PART NO. 44244
MODEL
SS-206T
B U I LT - I N T O P M O U N T
R E C TA N G U L A R F O O D WA R M E R
DIMENSIONS: INCH
(MM)
WE L L S M A N U F A C T U R I N G
SUGGESTED CLEARANCE REQUIRED FROM
UNIT TO THE NEAREST SURFACE
BACK SIDE BOTTOM FRONT
2 2 6 3/4 4 1/8
(51) (51) (171) (105 )
SS-206T 120 1200 10.0 SINGLE NONE
SS-206T 208 900 4.3 SINGLE NONE
SS-206T 240 1200 5.0 SINGLE NONE
NOTE: Specifications are subject to change without notice. See installation instructions prior to installing the unit.
This document is not for installation purposes. The installation of recognized component units requires additional
evaluations to Underwriters Laboratories, Inc. standards.
THIS UNIT IS DESIGNED TO BE INSTALLED IN METAL COUNTERS ONLY.
All models with a 'D' suffix have the same electrical specifications as the standard units.
NOTE: Depending on the installation,
clearances can be reduced upon further
evaluations to UL standards.
E6070
